  • Page 1 Quick Start Guide Rev. 2024-3 MB48LI82.GW MB48LI50.GW & MtB Smart GateWay...
  • Page 2: Table Of Contents

    Contents Inverter compability list II Start-up procedure III Inverter instructions III.I Victron Energy ........III.II Solis .
  • Page 3: I Inverter Compability List

    Quick Start Guide I Inverter compability list All VE.Bus inverters compatible with a GX Victron Energy device running VenusOS 3.40 or higher RHI-(3-6)K-48ES-5G Solis S5-EH1P(3-6)K-L Deye All single and three phase LV Hybrid inverters INVT BD3∼6KTL-RL1 HI-3∼6K-SL INHENERGY HI-5∼12K-TL SOFAR HYD 3000–6000-ES II Start-up procedure 1.
  • Page 4 Smart GateWay, and connect your smartphone or computer to the Wi-Fi network whose name can be found on the MtB Smart GateWay side sticker (MeterBoost-GW-xxxxxxxxxxxx). Alternatively, you can scan the QR Code to automatically connect to the MtB Smart GateWay’s Wi-Fi network. Go to the MtB Smart GateWay web page at http://192.168.33.1...
  • Page 5 3. Turn ON the rest of the batteries: When all batteries have LED2 slowly blinking magenta, press the red switch on the batteries that are not yet ON until one sound signal is emitted to turn them ON. Alternatively, the MtB Smart GateWay interface can be used to turn ON all batteries simultaneously.
  • Page 6: Inverter Instructions

    1. To connect the MtB Smart GateWay to a Victron system, a Victron VE.Can to CAN-bus BMS cable should be used. Both type A and type B can be used. Please do not use handmade cables, both MeterBoost and Victron don’t support installations with handmade cables.
  • Page 7 8. Using VEConfigure, set the parameters presented in the figures below.
  • Page 8 9. In case of the ESS system, configure also the following parameters.
  • Page 9 10. If there are Solar Chargers on the system, set the following parameters using VictronConnect. The charge current should be set to the lowest value between Ah/2×number of batteries or the maximum Solar Charger current.
  • Page 10: Solis

    "Solis" is selected under "Inverter Settings" on the MtB Smart GateWay settings page. If any of the steps in this guide are not visible the inverter should be updated, please contact MeterBoost or your Solis dealer. 1. The first step is to check the firmware version. First, click the "ENTER"...
  • Page 11 The version displayed should match the ones shown in the image above on the right, or be newer. After that, click the button "ESC" until the inverter Menu appears again. 2. Connect the MtB Smart GateWay’s CAN port to the inverter’s BMS port using the CAN cable provided with the inverter.
  • Page 12 6. Once in the Storage Energy Set menu, press the "DOWN" button until the Battery Select option is selected, as shown in the figure below. Then click the "ENTER" button. 7. Once in the Battery Select menu, a No Battery option will appear for the Battery Module parameter, and then the button "UP"...
  • Page 13 8. A Overdischg SOC parameter will appear, click the "ENTER" button and set it to 10%, as in the figure below. Then click the "ENTER" button. A new menu like the one in the figure below on the left will be presented. Then click the "ENTER"...
  • Page 14 10. For the Mode parameter the Self use option must be selected, as shown in the figure below. Then click the "ENTER" button. 11. The ON option must be selected and click the "ENTER" button, as shown in the figure below, on the left. Then, on the Self use menu, select the Charging from grid menu and click the "ENTER"...
  • Page 15 Press the button "ESC" to finish. Then a Save/Cancel menu will appear, select the Save & Send option, and click the "ENTER" button, as in the figure below in the right. 14. The inverter setup is complete and ready to work with MeterBoost batteries.
  • Page 16: Deye

    The Batt Capacity, Max A Charge and the Max A Discharge parameters in the image below should be multiplied by the number of batteries in the installation, considering that MB48LI82.GW batteries are being used. When MB48LI50.GW batteries are being used please consider 50 Ah, 25 A and 25...
  • Page 17 5. The final step is to click on Battery Icon from the main screen and then click on Li-BMS in the bottom right corner. Make sure that after LiBms field appears MeterBoost. If not, please check your connection and inverter...
  • Page 18 The inverter setup is complete and ready to work with MeterBoost batteries.
  • Page 19: Invt

    III.IV INVT Note: Version - ARM: V1.00.38; DSP: V1.01.38 or newer must be used. Please make sure that the option "Invt" is selected under "Inverter Settings" on the MtB Smart GateWay settings page. 1. The first step is to check the firmware version. First, click until the inverter User Menu is shown.
  • Page 20 4. Before starting the setup configurations a password will be requested. The default password, "00000", as shown in the picture below, should be introduced using the arrow buttons. 5. The configuration’s first step is to press the ∨ button until the Bat Setting option is selected, as shown in the figure below.
  • Page 21 ∨ button until the Bat Comm option is selected, as shown in the figure below on the left. Then click button. The CAN option should be selected, as shown in the figure below on the right. The inverter setup is complete and ready to work with MeterBoost batteries.
  • Page 22: Inhenergy

    "Inverter Settings" on the MtB Smart GateWay settings page. If any of the steps in this guide are not visible the inverter should be updated, please contact MeterBoost. 1. The first step is to click the button ↑ until the inverter software version is shown in the bottom part.
  • Page 23 4. Press the button ↓ until the System Config option appears and click 5. Press the button ↓ until the BAT0: Lead Acid option appears and click 6. Press the button ↓ until the BAT9: MeterBoost option appears and click . If this option doesn’t appear the inverter must be updated, please...
  • Page 24 7. The message Set OK ! should appear in the display and the inverter will reboot. The inverter setup is complete and ready to work with MeterBoost batteries.
  • Page 25: Sofar

    III.VI SOFAR Note: Version - Software: G3.60; DSP1: V3.60; DSP2: V3.60 or newer must be used. Please make sure that the option "Sofar" is selected under "Inverter Settings" on the MtB Smart GateWay settings page. 1. Once the inverter is ON, the first step is to choose the operating language. Press the ↓...
  • Page 26 example for Portugal. Press the ↑ and ↓ arrows until you reach the correct code and then press the button. 4. Then, for the battery type, select General Lithium and press the button. 5. The next step is to confirm the inverter’s version. Start in the main menu presented, like in the figure below on the left, and then press the button.
  • Page 27 6. Then you should select the Inverter Info option and press the button, figure below. 7. Information about the inverter will be displayed as presented in the left figure. Press the ↓ button and the information of the right figure will appear. Press the button.
  • Page 28 9. The Software Version, DSP1 and DSP2 should be equal or newer to the ones presented in the figure below. 10. Connect the MtB Smart GateWay’s CAN port to the inverter’s BMS port using the CAN cable provided with the inverter. 11.
  • Page 29 13. Then, select the Battery Parameter option, the figure below. Press the button. 14. Select the Discharge Depth option, the figure below. Press the button. 15. Change the parameters for the values presented in the figure below. 16. The inverter setup is complete and ready to work with MeterBoost batteries.
