Summary of Contents for Settop M1
- Page 1 COMPONENTS QUICK START GUIDE Video tutorials on setting up Settop M1...
- Page 2 COMPONENTS OPTIONAL To set up the Settop Octohub accessory, see the Settop M1 + Settop Octohub section Settop M1 TPN: 110471-41 COM1 to COM2 to Power source connect the connect the PN: 310603 TPN: 110471-61 power cable cable to the...
- Page 3 HARDWARE CONFIGURATION To set up the Settop M1 you must carry out the following steps INSERT THE SIM CARD REMOVE THE PIN CODE First of all, you have to insert the SIM card in the BEFORE INSERTING THE SIM CARD...
- Page 4 ONLINE CONFIGURATION CONNECT TO THE SETTOP M1 WIFI First of all you have to connect to the Settop M1 wifi network SettopM1SN (where SN is the serial number) with the password “settopm1” Once you are connected, you can access the device via WIFI: IP 192.168.2.2 The first time you log on, the user is “admin”.
- Page 5 BASIC LED INDICATORS POWER PHONE Turned off NOT CONNECTED Turned off PHONE NOT CONNECTED Fixed TURNED ON Fixed DOES NOT HAVE SIM CARD SLEEP MODE GPRS / 3G/4G COVERAGE 1 flash every 10s Constant flashing Rapid flashing LOW VOLTAGE Constant rapid flashing ERROR...
- Page 6 SETTOP M1 + SETTOP OCTOHUB Connect the 4G telephone antennas OPTIONAL Connect the Settop Octohub to the COM2 of the Settop M1 Connect the grey Connect the Y-shaped cable to the COM4 power cable to the port of the Settop...
- Page 7 CABLES FOR KIT SETTOP SOLAR CABLES FOR BASIC INSTALLATION DO NOT EXTEND THE Power CABLE supply Pigtail Y-shaped cable power cable and PN: 310628-10 temperature sensor PN: 310655 TPN: 110471-61 CABLES FOR SOLAR PANEL (EXTENDED) Settop Solar System or High capacity battery USE ONLY SETTOP CABLES.
- Page 8 Screwdriver and allen key TPN: 110471-41 Settop Octohub PN: 310603 PN: 310655 PN: 310605 TPN: 110471-61 Settop M1 to Trimble S Cable Power cable + Thermometer Power source ACCESSORIES (NOT INCLUDED) Bases and cabinets PN: M1 CABINET EXTENDED PN: M1 CABINET STANDARD...
- Page 9 QUICK START GUIDE Remember that you can get more information about the use and configuration of the device at: Downloads: User Guide and Configuration https://drive.google.com/drive/ folders/17B05RjUQ8BhdE6zVANMPyxVFiXQZ6ULW?usp=drive_link Setup Videos https://www.youtube.com/ watch?v=4PC3pWioAFo&list=PLLtqXAmxiIObGFyXXYhoPm6v142AMW8OB More info at www.settopsurvey.com info@settopsurvey.com Specifications may change without notice. All brands, products and images SETTOPSURVEY, S.L.
