Summary of Contents for IDTECH UniMag II
- Page 1 User Manual UniMag II/ Shuttle Magnetic Stripe Reader For Mobile Devices 80110509-001-E 03/13/2013...
- Page 2 Added more information on the data output format 10/31/2011 Updated Apple demo screenshots. Initial release. 11/16/2011 Updated for UniMag II Android SDK v2.4 12/05/2011 Updated for UniMag II Android SDK v2.6 and iOS 04/23/2012 SDK v5.11 Updated for Android Demo v2.12 and iOS Demo 11/19/2012 v5.13...
- Page 3 IDTECH UniMag II/ Shuttle User Manual 1. Introduction The UniMag II/ Shuttle is a compact MagStripe reader designed for mobile devices. UniMag II reads up to 2 tracks of MagStripe data with encryption capability. It works on Apple iPod Touch, iPhone 3G/3GS/4/4S/5, iPad1/2/3/4/Mini, and selected Android platform devices. A complete list of supported device can be found on the ID TECH website.
- Page 4 IDTECH UniMag II/ Shuttle User Manual 2. <Connecting with uniMag> message will pop up, as shown below. Make sure the reader status changes to <CONNECTED> after that. 3. Click on the <Click to Swipe> button, <Please swipe card > message box will pop up.
- Page 5 Click on the demo “*.apk” file to install demo application. e. UniMag II demo application will be found under Applications after installed. Copyright © 2010-2013, International Technologies & systems Corporation. All rights reserved.
- Page 6 IDTECH UniMag II/ Shuttle User Manual 2. Adjust audio volume to maximum and plug the reader into the audio jack. Launch the demo application. If the phone is supported by the SDK, the phone would power up the reader when it‟s plugged in.
- Page 7 IDTECH UniMag II/ Shuttle User Manual b. If the phone is not supported by the SDK, the following screen would show up. And you could run the auto configuration function to see if it can help support the new phone.
- Page 8 IDTECH UniMag II/ Shuttle User Manual iv. Please swipe a card a few times to make sure the result is working stably v. The next time you launch the demo, please click [Android Menu button] => [Settings] => Check [Use AutoConfig profile] 3.
- Page 9 IDTECH UniMag II/ Shuttle User Manual 5. To send commands to UniMag, click on the button „Command‟ and select the command to send. 6. To enable the event log, click [Android menu button] => [Settings] => [Save Log Option]. The log file will be saved in the SD Card root directory.
- Page 10 IDTECH UniMag II/ Shuttle User Manual 7. To delete the log, click on the menu button and select „Delete Logs‟. 8. To exit the application, click on the menu button and select “Exit”. The volume level will be restored after the demo is exited.
- Page 11 The default character is CR (Carriage Return). For example: %B4352378366824999^TFSTEST /THIRTYONE ^05102011000088200882000000?;4352378366824999=051020110000882?<CR> 3.2. UniMag II Encrypted Data Output Format UniMag II uses ID TECH enhanced data encryption format. In this format, all tracks of the data are encrypted. Output Format: <STX><LenL><LenH><Card Data><CheckLRC><CheckSum><ETX> Field...
- Page 12 IDTECH UniMag II/ Shuttle User Manual T1 data (masked if card type 80) T2 data (masked if card type 80) Encrypted section T1 data encrypted (if card type 80, or force encrypt track 1 setting) else omitted. T2 data encrypted (if card type 80, or force encrypt track 2 setting) else omitted.
- Page 13 IDTECH UniMag II/ Shuttle User Manual Bit 5: 0 — Reserved for future use Bit 6: 0 — Reserved for future use Bit 7: if 1—KSN present 4) Card Type: Value Encode Type Description ISO/ABA format Other 5) Field Description: Track 1, Track 2 Unencrypted Length This one-byte value is the length of the original Track data.
- Page 14 IDTECH UniMag II/ Shuttle User Manual Example: 02D500801F3723008383252A353135302A2A2A2A2A2A2A2A373836315E50415950415353 2F4D4153544552434152445E2A2A2A2A2A2A2A2A2A2A2A2A2A2A2A3F2A3B35313530 2A2A2A2A2A2A2A2A373836313D2A2A2A2A2A2A2A2A2A2A2A2A2A2A2A3F2AA096A 6F5D1DCBE45B5F77EB2559FEE0411013232E3F42044C0397E3E9E6D9B3A11FB8ADE07 12AFD097C23AA86DFDC9DBA0E73A6FD698FD2F80800C0E1E9ED1BEED5EEA9840DA 53F41254FDB79E89B76B127C25FE44AE7524BAEB5BDAACF777FA313233343536373839 30FFFF9876543210E0004ABBF903 ISO/ABA Data Output Format STX: 02 Data Length Low Byte: D5 Data Length High Byte: 00 Total Data Length: 0x00D5 (in HEX) 213 (in DECIMAL) Card Encode Type: 80 Track Status: 1F Bit 0: 1—...
- Page 15 IDTECH UniMag II/ Shuttle User Manual Bit 6: 0 — not used Bit 7: 1 —KSN present Track 1 Clear / Masked Data: %*5150********7861^PAYPASS/MASTERCARD^***************?* Track 2 Clear / Masked Data: ;5150********7861=***************?* Account Number: 5150********7861 Card Holder Name: PAYPASS/MASTERCARD Expiration Date:**** Track 1 Encrypted Data: Track 1 encrypted length = track 1 unencrypted length 37h rounded up by 8 bytes ->...
