If you have any questions or problems during the setup of
your Nubert system, please do not hesitate to contact our
service team. Please have your customer number ready.
Phone: +49 7171 87120 · Email: info@nubert.de
Nubert
nuControl X
Operating Manual
Application Examples
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Nubert nuControl X
Summary of Contents for Nubert nuControl X
- Page 1 Operating Manual Application Examples If you have any questions or problems during the setup of your Nubert system, please do not hesitate to contact our service team. Please have your customer number ready. Phone: +49 7171 87120 · Email: info@nubert.de...
- Page 2 Additionally, it is essential that you also observe the additional safety instructions! Please install the nuControl X at a place that provides a flat and stable The Nubert team wishes you many hours of musical surface. Ensure that there is sufficient free space around the device for enjoyment! air circulation.
- Page 3 Airable (radio mode) ......... 15 Using the Nubert nuControl X App ......16 Remote Control .
- Page 4 X · 10 / 2024 Rear of the Device, Connections Make sure all cable connections are made before switching the nuControlX on. Observe the other steps listed in these instructions. 10 11...
- Page 5 X · 10 / 2024 Inputs 1. Phono input including screw terminal for ground connection and selection of the pickup system via toggle switch (MM/MC). Caution! Do not connect any devices with line level here! Otherwise the device may be damaged! 2.
- Page 6 X · 10 / 2024 Front of the Device, Controls...
- Page 7 X · 10 / 2024 1. On/Off with power LED Note: Starting the device can take around 45 seconds. In order to turn it off, hold the button for 4 seconds. 2. USB-C for storage media up to 2 TB 3.
- Page 8 X · 10 / 2024 Display The display provides information on the current operating status and, as Consists of two areas: · display areas (blue) a touchscreen, allows simple, direct and intuitive operation. · operating areas (yellow) Default view / Main screen –...
- Page 9 The Return button, situated on the right-hand side of the display, allows going back one menu level. Pressing it multiple times opens up the start screen. All controls are also accessible via the provided remote control or the Nubert app (see the corresponding sections in this manual).
- Page 10 X · 10 / 2024 Menu Setting Date and Time Date and time are displayed in the upper left area (1). This information is After switching on the nuControlX, the system takes approximately 45 automatically synchronized via the internet. Alternatively, this information can manually be set in the Settings >...
- Page 11 Choose between the rear outputs and the subwoofer. The following are available: equalizer, high/low pass, delay, left/right balance, parametric In order to connect a loudspeaker to the nuControl X wirelessly via X- equalizer as well as bass and treble. Connect, firstly activate the loudspeakers pairing mode (for details, refer to the manual of the loudspeaker).
- Page 12 The standby consumption is less than 8 watts. Status: WIFI connected to “Solidex_2.4G” Bluetooth Note: In order to save energy, the nuControl X automatically switches IP Asign: Static to the selected Auto Power mode when no incoming audio signal is Display detected for 5 minutes.
- Page 13 Contact the router manufacturer if necessary. The nuControl X is fully DLNA and UPnP compatible and can therefore be found automatically in the network. Note: The nuControl X can also be connected to the router via a LAN cable.
- Page 14 X · 10 / 2024 Setting up streaming services, The nuControl X preamplifier supports the following streaming services: source selection The corresponding menu can be opened by tapping on the icons of the available streaming services in the lower part of the display or by Apple AirPlay pressing the Internet button on the remote control.
- Page 15 X · 10 / 2024 Renaming inputs Further sources, such as YouTube or Amazon Music, become available when a smart TV or a computer is connected. Signal inputs can be renamed individually. Start by tapping on the Airable (digital radio) desired source (e.g.
- Page 16 Bluetooth should be activated on both devices. Nutzen Sie nicht den Weg über das Einstellungs-Menü des Smartphones! Wurde bislang noch kein Gerät mit der nuControl X App verbunden, so werden nach dem Afterwards, from within the app, connect the smartphone/tablet to Start von X-Remote direkt die verfügbaren Geräte angezeigt.
- Page 17 Antippen der Kachel Speaker settings (Geräteeinstellungen) gelangen sie ins Menü für weitergehende Einstellungen des nuControl X. Hier kann beispielsweise das Verhalten der on the nuControl X you want to connect. The app will signal a success- Status-LED konfiguriert und weitere Einstellungen vorgenommen werden.
- Page 18 Further notes: Installing the battery · The on/off button (2) turns the nuControl X on or puts it in standby Open the compartment on the back of the remote control using a Phil- mode. If the device has been put into standby mode using the lips screwdriver.
- Page 19 X · 10 / 2024 Explanation of keys Nr. button action 1 Mute mute the sound 2 Standby turn standby mode on/off 3 tone access to further sound settings E E Q Q 4 tone level opens up the menu for setting treble and bass...
- Page 20 X · 10 / 2024 Troubleshooting Symptom Cause Solution see page The device does not turn on. The power cord ist not correctly plugged in. Connect the power cord firmly to the power input socket of the device and to the power outlet.
- Page 21 X · 10 / 2024 Symptom Cause Solution see page No sound playback Source devices are connected incorrectly. Check the cable connection to the 4, 5 source devices. Incorrect input selected. Select the correct input. 18, 19 Volume is set too low.
- Page 22 X · 10 / 2024 Symptom Cause Solution see page Shrill sound Treble is set too high. Check the settings in the sound menu. Incorrect settings for the equalizer. Check the equalizer settings for extreme amplification or peaks. Low-frequency response The bass is set too loud.
- Page 23 Verify that the router is connected to the internet. Contact your internet service provider if necessary. – The connection to the No internet connection is available. Verify that the nuControl X has an active connection streaming service cannot to the internet. 4, 5, 13 be established.
- Page 24 X · 10 / 2024 Symptom Cause Solution see page No sound playback via Source volume is too low. Set the volume on the source device (e.g. on the – Bluetooth. smartphone) to the highest level. The source device might be muted.
- Page 25 1 × unbalanced, unregulated (RCA) Outputs, Digital: 1 × S/PDIF optical, unregulated, 192 kHz, 24 bit (TOSLINK) 1 × S/PDIF electrical, unregulated, 192 kHz, 24 bit (RCA) 1 × Nubert X-Connect – Hi-Res wireless standard 1 × USB, power supply (USB-A, 5V, 1.8A)
- Page 26 X · 10 / 2024 Headphone Outputs: 1 × unbalanced (6.3 mm jack plug) 1 × balanced (4.4 mm jack plug) Trigger: 2 × 12 Volt, 100 mA (Mini-XLR) Tone Control: Bass control / mid-high control, executed as “Klangwaage” (tone scale)
- Page 27 X · 10 / 2024 Frequency Response: 10 – 80 000 Hz (+0 / –0.5 dB) Power Consumption: Operation: 42 watts / Standby Mode: < 0.5 watts / Network Standby Mode: < 8 watts Dimensions: 43 × 11 × 39 cm (Width × Height × Depth) Weight: 11.2 kg...
- Page 28 X · 10 / 2024 Operating Manual Technical changes, errors and misprints excepted. More information on this product is available here: https://www.nubert.de/downloads You will find our General Terms and Conditions (AGB) on our website: www.nubert.de/agb.htm Nubert electronic GmbH Nubertstraße 1 73529 Schwäbisch Gmünd...
