- Page 1 BT 2000 CTO USER MANUAL ------------------------------ 2019 Ver04.01-----------------------------------...
- Page 2 INSTRUCTION Thank you for purchasing BT-2000 CTO, every unit has been thoroughly tested and shipped in perfect condition. Carefully check the shipping carton for damage that may have occurred during shipping. If the carton appears to be damaged, carefully inspect your unit for any damage and be sure all accessories necessary to operate the unit has arrived well.
- Page 3 3.Specification Model: BT-2000 CTO Lamp: 1920pcs X 0.2W white LED ( 960pcs 3200K LEDs+960pcs 5600K LEDs) CTO: 3000K-6000K Power Supply: AC90V-250V, 50Hz/60Hz Power consumption: 220W DMX Channel: 2CHs Display: LCD touch screen Flicker-free; 0-100% linear dimmer system Connector: PowerCON in/out; 3pin/ 5pin DMX XLR Dimmer system: 4 dimmer curves Control Mode: Master/Slave mode;...
- Page 4 5. DMX 512 control connections Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to the male 3-pin XLR input of the light. You can chain multiple lights together through series linking. The cable needed should be two core, screened cable with XLR input and output connectors.
- Page 5 6. Display Control Main Control The control board on the fixture bottom is your interface to access and control all the functions on the unit. It is LCD touchable display gives you a code view of the options and functions. The following will explain each function and its options.
- Page 6 1. Intensity: Press Master to enter sub-menu white point, this function allows you to adjust intensity on fixture form 000 to 100. 2. White Point: This function allows you to adjust color temperature from 3000K to 6000K 1. Software: The display issues software number on the fixture is S1-M0C1 2.
- Page 7 Channel Value Function 001-255 Dimmer 0-100% 001-011 3000K 012-019 3100K 020-235 3200K-5800K 236-243 5900K 244-255 6000K 9. Photometric Data 8. APPENDIX - 6 -...
- Page 8 1. Issues and Solution Issue Reason Solution AC100V-250V, 50Hz/60Hz. Check the power connection, and make sure device Device not work No power connect the mains in well condition. Check if switch is on. Check if the fuse is good. Led lamp burnt Replacing led bulb Driver stop working Replacing led driver board...
