MF 59-69 SPLIT Electronic Modular Super-Flakers Fabbricatori di Ghiaccio Granulare Machines á Glace en Supergrains Fabricadores Modulares de Hielo Supertriturado Service Manual Manuale di Servizio Manuel de Service Manual de Servicio 090144 05 - REV. 03-2013...
Page 2
TABLE OF CONTENTS – INDICE – TABLE DES MATIERES ENGLISH Table of Contents ....................................Page 1 Specifications ......................................2 Technical Specifications ....................................2 Unpacking and Inspection ................................... 3 Location and Levelling ....................................3 Typical Installation on Refrigerant Plant ..............................4 ...
Page 4
UNPACKING AND INSPECTION LOCATION AND LEVELLING WARNING. This Modular Superflaker is designed Call your authorised SCOTSMAN Distributor for indoor installation only. Extended periods of or Dealer for proper installation. operation at temperature exceeding the following limitations will constitute misuse under the terms...
Page 5
Water containing excessive minerals will tend to SCOTSMAN icemakers require a solid earth wire. produce scale build-up on the interior parts of the All SCOTSMAN ice machines are supplied from the water system while too soft water (with too low factory completely pre-wired and require only...
Page 6
REFRIGERANT SYSTEM The refrigerant system of the new MF 59-69 Flakers Split versions consists off: Refrigerant inlet tube; 8 mm Refrigerant outlet tube; 9,5 mm MF 59 …… its electrical solenoid coil………. Carel Electronic Expansion Valve E2V… …….and NTC Sensor located on the suction line just before the KVP valve.
Page 7
Suction pressure regulating valve (Parker Hi pressure safety valve set up at 47 bar. A8A) to be adjusted at -20°C (18 bar) The refrigerant system is supplied completely sealed with two rubber caps on the inlet and outlet copper tubes. REFRIGERANT SYSTEM SCHEME ELECTRONIC EXPANSION...
Page 8
ELE C TRON IC E X PA NS ION V A LV E REFR IGE RA N T INLE T - L IQU ID K V P RE FR IGE RAN T OU TLE T - GA S E LE C TRON IC E X P A NS ION V A LVE MF 69...
Page 9
PC BOARD POWER BIN FULL NO WATER TOO LOW AMBIENT TEMP STAND BY WRONG ROTATION TOO HI EVAP TEMP P.C. BOARD (Data processor) output terminals for the leads of the ice maker electrical wires. The P.C. BOARD, fitted in its plastic box located in The P.C.
Page 10
TEST metal pins are in contact with water transmitting a low power current back to the PC Boards. Always open – It’s used ONLY in the factory to start up all electrical parts together. If left in place, the NOTE. In case of shortage of water in the reservoir machine runs for 3 minutes later it stops with all or, when the water used is too soft (de-mineralized- LEDs blinking.
Page 11
operation with the simultaneous extinguishing the 4. Select REFRIGERANT and push the Enter LED. Button then the “Arrows up-down” till the Refrigerant R744. At time of replacement of the Ice Level Control or any 5. Push again to confirm time needed, it’s possible to calibrate/recalibrate it by means of the push buttom of the PC Board as per 6.
Page 12
12. Select with “Arrows up-down” CONFIGURATION and move to the page 5 of 11 10. Once on END CONFIGURATION display, move with “Arrows up-down” to YES and push 13. Select RELAY CONFIGURATION and push 11. Push Prg Button and with “Arrows up-down” write the PWD 0066 then push 14.
Page 13
17. Select Superheat setpoint and push 25. With “Arrows up-down” go to page 5 of 9, select LowSH protect. threshold and push 18. With “Arrows up-down” move to 6K and push 26. With “Arrows up-down” select 3K and 19. Select Valve opening at start-up and push 27.
Page 14
30. With “Arrows up-down” move to -38°C and push 31. With “Arrows up-down” move protection integral time and push 32. With “Arrows up-down” move to 5s and push 33. Push “Esc” to leave the REGULATION...
