ORDER-CODES:
,
KXP-PS1 KXP-PS1-CLONE
The master card set is used for the initial setup of DoorLock radio components based on a unique
system key (system card) and includes cards and tools for service purposes.
The master card set is used for:
Provision of the radio teach-in card (service key) to prepare radio components and
subsequently teach them into KentixONE. The service key card contains a unique system key,
this is noted on the system card and must be well secured.
Provision of additional cards for service purposes such as battery replacement and
assembly/disassembly. These are not needed in the same way for all products.
Tools for assembly and battery replacement
With the Servicekey card, the wireless components such as knobs, door handles or wall readers are
integrated into the wireless network and the communication is encrypted. Only one master card set is
required per system or installation. We recommend using an extra set of master cards for each
project. The supplied system card is only used for physical management of the printed system key
and should be stored in a safe place. It is not required for operation, but is necessary to generate new
system key cards in case of loss.
The master card set is only required for Kentix wireless components, not for wired readers. It is
only required once per installation/customer.
Assignment of the content depending on the product
System
card*
Type
(YELLOW)
DoorLock-DC
BASIC
X
(ART: KXC-
KN1/2)
DoorLock-DC
PRO
X
(ART: KXC-
KN4)
© Kentix GmbH. This file was automatically generated on 2024-12-30 01:58:53. Please visit
latest documentation.
Service Battery
key replacement
card
(YELLOW) (GREEN)
X X
X –
Master card set for DoorLock radio – MANUAL | 1
Dismantling
RFID
card
Schlüssel-anhänger
(BLUE)
X X
– X
Batterie- Montage-
Wechsel-werkzeug werkzeug
Bracket –
Inbus
Magnet
2mm
