- Page 2 CONTENTS Precautions For Use ........................1 1.Introduction ..........................1 2.Electrical Symbols ........................3 3.Model ............................3 4.Technical Specification ........................4 5.Instrument Structure ........................6 6.Operation Method ........................7 7.Battery Replacement ........................9 8.FAQ ............................10 9.Assembly Details ........................12 10.Accessories ..........................13...
- Page 3 Precautions For Use Thank you for purchasing PHS-864/PHS-864A Non-contact Phase Sequence Indicator.In order to better use of the product, please be certain: ---Read the instruction manual in detail. ---Comply with safety regulations and cautions listed in manual. In any case, should pay special attention to safety when using the tester.
- Page 4 1. Introduction PHS-864/PHS-864A Non-contact Phase Sequence Indicator is a major break through in the traditional phase sequence detection method, in the traditional phase sequence deteicon, the 3-phase wiring terminal must be peeled off and connected the three exposed clips or test probe of the phase sequence meter to the three exposed live wires.
- Page 5 Warning! The operators must keep to the safety rules strictly, otherwise, personal injury or equipment damage will occur. Double Insulation Alternate Current（AC） Direct Current（DC） 3. Model Model Diameter Of The Clamped Wire Conductor PHS-864 ø1.6mm~ø16mm PHS-864A ø10mm~ø40mm...
- Page 6 4. Technical Specification Phase detection(positive phase,reverse phase, default phase), live Function line detection, simple power electricity detection, break point location, lines circuit maintenance Power Supply DC 3V AA alkaline batteries (LR6)×2PCS Electricity Testing AC 70~1000V, 45~65Hz(sine wave continuous input) Range Available Clamp Diameter: ø1.6mm-ø16mm or ø10mm-ø40mm (optional) Wire Size...
- Page 7 4pcs magnets are installed on the bottom plate of the meter, which Magnet can be hung on the distribution box, load weight 800g Automatic Shutdown 5 minutes after power up, the meter automatic shutdown Meter Dimension 70mm×75mm×30mm Clamp Lead Length 0.6m Meter Weight 200g...
- Page 8 5. Instrument Structure 1. Operate indication panel 2.Test Clamps 3. Clamp Lead Wire 4. Meter body 5. L2 phase indicator lamp 6. L1 phase indicator lamp 7. L3 phase indicator lamp 8.Phase sequence indicator lamp (4 lamps) 9. Low battery voltage indication 10.
- Page 9 6. Operation Method 6.1.Phase sequence detection Danger! High voltage! Please pay attention to safety! 6.1.1.Connection: Clamp on three phase wires respectively with the three clamps (Shown in Figure-1). 6.1.2.The detected wire should be clamped at the mark “ ” (Shown in Figure-2) Figure-1 Figure-2 6.1.3.Press the red “ON”...
- Page 10 6.1.5.Press white color “OFF” key to shut down, the instrument will automatically shut down after about 5 minutes without any operation to reduce battery consumption. 6.2.Live wire check, simple electricity detection Danger! High voltage! Please pay attention to safety! 6.2.1.Use any clamps to clamp on the tested wire. If the conductor with electricity (within the setting range of live line voltage AC70~1000V), the lamp of L1/U, L2/V or L3/W light up, it can be detected whether the wire is live or not.
- Page 11 6.3.Default phase judgment, open circuit searching, breakpoints location Danger! High voltage! Please pay attention to safety! 6.3.1.Use any clamps to clamp on the three-phase line separately. If it is default phase, the lamp L1, L2 or L3 will not light up. 6.3.2.Use any clamps to clamp on the tested wire which along the maintenance line.
- Page 12 8. FAQ Fault Phenomenon Possible Causes Solution Without batteries Install batteries Wrong battery type Replace with right type Low battery power Replace the new batteries Cannot power on Faulty battery polarity Install batteries in correct polarity (LED power indicator Poor contact of battery is not light up, without Replace the battery contacts contacts...
- Page 13 LED dim display Low battery power Replace the new batteries The three phase wires Not belong to instrument faults are not electrified Failed to clamp the wire Clamp again refer the manual Start up normal, but can not detect Lead wire break Change the lead wire Defect of circuit Repair or replace the PCB...
- Page 14 Assembly Details...
- Page 15 10. Accessories Indicator 1 PCS Carry Box 1 PCS Tool Bag 1 PCS Manual 1 PCS Warranty Card / Qualification Certificate 1 copy...
- Page 16 The company reserves the right to modify the contents of the user manual. If there are any changes, no further notice will be given. Tecpel Co., Ltd. 3F., No.12, Lane. 130, MinQuan Road., XinDian Dist., New Taipei City 23141, TAIWAN...
