SIGMATEK SEC 171 Instruction Manual

S-dias ethercat splitter
Hide thumbs

Advertisement

Quick Links

Download this manual
SEC 171
S-DIAS EtherCAT Splitter
Instruction Manual
Date of creation: 22.08.2024
Version date: 22.08.2024
Article number: 20-023-171-E

Advertisement

loading
Need help?

Need help?

Do you have a question about the SEC 171 and is the answer not in the manual?

Questions and answers

Related Manuals for SIGMATEK SEC 171

Summary of Contents for SIGMATEK SEC 171

  • Page 1 SEC 171 S-DIAS EtherCAT Splitter Instruction Manual Date of creation: 22.08.2024 Version date: 22.08.2024 Article number: 20-023-171-E...
  • Page 2 (print, photocopy, microfilm or in any other process) without express permission. We reserve the right to make changes in the content without notice. SIGMATEK GmbH & Co KG is not responsible for technical or printing errors in this handbook and assumes no responsibility for damages that occur through its use.
  • Page 3 ETHERCAT SPLITTER SEC 171 EtherCAT Splitter SEC 171 1 EtherCAT IN 7 EtherCAT OUT With its 7 EtherCAT OUT ports, the EtherCAT splitter enables the creation of an EtherCAT bus system in line, tree and star structure. The EtherCAT IN port is the input port for the splitter.
  • Page 4 SEC 171 ETHERCAT SPLITTER Table of Contents Introduction ................5 Target Group/Purpose of this Operating Manual ...... 5 Important Reference Documentation ......... 5 Contents of Delivery ..............5 Basic Safety Guidelines ............6 Symbols Used ................6 Disclaimer ..................8 General Safety Directives ............
  • Page 5 ETHERCAT SPLITTER SEC 171 Interfaces ..................17 7.1.1 X1: EtherCAT IN (RJ45)..............17 7.1.2 X2-X8: EtherCAT OUT (RJ45) ............17 Status LEDs ................. 18 Applicable Connectors ............... 19 Label Field ................... 20 Wiring Guidelines ..............21 Shielding Recommendation ............21 Shielding ..................
  • Page 6 SEC 171 ETHERCAT SPLITTER Page 4 22.08.2024...
  • Page 7 Our support team is happily available to answer your questions. Please see our website for our hotline number and business hours. Important Reference Documentation This and additional documents can be downloaded from our website or obtained through support. Contents of Delivery 1x SEC 171 22.08.2024 Page 5...
  • Page 8 SEC 171 ETHERCAT SPLITTER Basic Safety Guidelines Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes: DANGER Danger indicates that death or serious injury will occur, if the specified measures are not taken.
  • Page 9 ETHERCAT SPLITTER SEC 171 CAUTION Danger for ESD-sensitive components. Les signes de danger pour les composants sensibles aux décharges électrostatiques. INFORMATION Information  Provides important information on the product, handling or relevant sections of the documentation, which require attention. 22.08.2024...
  • Page 10 It does not guarantee properties under the warranty. Please thoroughly read the corresponding documents and this operating manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations.
  • Page 11 ETHERCAT SPLITTER SEC 171 General Safety Directives The Safety Directives in the other sections of this operating manual must be observed. These instructions are visually emphasized by symbols. INFORMATION According to EU Directives, the operating manual is a component of a product.
  • Page 12 SEC 171 ETHERCAT SPLITTER CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened! Manipulez l’appareil avec précaution et ne le laissez pas tomber.
  • Page 13 The product was constructed in compliance with the following European Union directives and tested for conformity. 3.1.1 EU Conformity Declaration EU Conformity Declaration The product SEC 171 conforms to the following European directives: • 2014/35/EU Low-voltage Directive • 2014/30/EU Electromagnetic Compatibility (EMC guideline) •...
  • Page 14 SEC 171 ETHERCAT SPLITTER Type Plate HW: Hardware version SW: Software version Page 12 22.08.2024...
  • Page 15 ETHERCAT SPLITTER SEC 171 Technical Data Performance Data Interfaces 1x EtherCAT In (RJ45) 7x EtherCAT Out (RJ45) Cable length maximum 100 m between stations Propagation delay approx. 1 µs per port Data transfer rate 100 Mbits/s Electrical Requirements Supply voltage +24 V DC ±20 % (SELV/PELV)
  • Page 16 SEC 171 ETHERCAT SPLITTER Miscellaneous Article number 20-023-171 Standard designed according to UL Approvals Environmental Conditions Storage temperature -20 ... +85 °C Environmental temperature 0 ... +55 °C Humidity 0-95 %, non-condensing Installation altitude above sea 0-2000 m without derating level >...
  • Page 17 ETHERCAT SPLITTER SEC 171 Mechanical Dimensions 22.08.2024 Page 15...
  • Page 18 SEC 171 ETHERCAT SPLITTER Connector Layout INFORMATION The connections of the +24 V supply (X9: pin 1 and pin 2) or the GND supply (X9: pin 3 and pin 4) are internally bridged. To supply the module, only one connection to a +24 V pin (pin 1 or pin 2) and a GND pin (pin 3 or pin 4) is required.
  • Page 19 ETHERCAT SPLITTER SEC 171 Interfaces 7.1.1 X1: EtherCAT IN (RJ45) Function Tx+/Rx+ Tx-/Rx- Rx+/Tx+ n.c. Rx-/Tx- n.c. n.c. = do not use 7.1.2 X2-X8: EtherCAT OUT (RJ45) Function Tx+/Rx+ Tx-/Rx- Rx+/Tx+ n.c. Rx-/Tx- n.c. 22.08.2024 Page 17...
  • Page 20 SEC 171 ETHERCAT SPLITTER Status LEDs DC OK green module is supplied with a voltage > 18 V status Operational EC Run green BLINKS status Initalization or Bootstrap FAST SINGLE status Safe Operational FLASH FAST status Pre-operational BLINKING: status Init...
  • Page 21 ETHERCAT SPLITTER SEC 171 Applicable Connectors X1-X8: RJ45 (not included in delivery) X9: Connectors with spring terminals (included in delivery) The spring terminals are suited for the connection of ultrasonically compacted (ultrasonically welded) stranded wire. Connections: Stripping length/sleeve length: 10 mm...
  • Page 22 SEC 171 ETHERCAT SPLITTER Label Field Manufacturer Weidmüller Type MF 10/5 CABUR MC NE WS Article number Weidmüller 1854510000 Compatible printer Weidmüller Type Printjet Advanced 230V Article number Weidmüller 1324380000 Page 20 22.08.2024...
  • Page 23 ETHERCAT SPLITTER SEC 171 Wiring Guidelines Shielding Recommendation Laying the EtherCAT cables in accordance with the EtherCAT Technologies Group (ETG) specification. Shielding CAT5e (STP - Shielded Twisted Pair) cables are recommended for Ethernet. The cable shielding is connected to ground via the RJ45 connector. Noise signals can then be prevented from reaching the electronics and affecting the function.
  • Page 24 SEC 171 ETHERCAT SPLITTER Strain Relief INFORMATION The EtherCAT cable must be mounted close to the module (e.g. using a clamp)! No mechanical stress can be applied to the connection! Page 22 22.08.2024...
  • Page 25 To provide eight EtherCAT connections, the SEC 171 has three internal communication modules (ESC), which are connected in series within the device. As a result, the SEC 171 appears in the EtherCAT configurator as three individual slaves that are installed together in one housing.
  • Page 26 SEC 171 ETHERCAT SPLITTER When using the LASAL CLASS 2 tool together with a CPU unit from SIGMATEK, the devices are addressed automatically. Ports X2-8 are provided in sequence ("EtherCatOut_1-7" server). The connections of the individual ESC ports are automatically taken into account (client "SlaveIndex", "SlaveIndexB"...
  • Page 27 ETHERCAT SPLITTER SEC 171 10 Assembly/Installation 10.1 Check Contents of Delivery Ensure that the contents of the delivery are complete and intact. See chapter 1.3 Contents of Delivery. INFORMATION On receipt and before initial use, check the device for damage. If the device is damaged, contact our customer service and do not install the device in your system.
  • Page 28 SEC 171 ETHERCAT SPLITTER 10.2 Mounting The modules are designed for installation into the control cabinet. To mount the modules, a DIN-rail is required. The DIN rail must establish a conductive connection with the back wall of the control cabinet. Depending on the load and temperature, the individual modules are hooked into the top-hat rail in a row and fixed with the snap-in hook.
  • Page 29 ETHERCAT SPLITTER SEC 171 Recommended minimum distances between the S-DIAS modules and the surrounding components or control cabinet wall: 22.08.2024 Page 27...
  • Page 30 SEC 171 ETHERCAT SPLITTER 11 Transport/Storage INFORMATION This device contains sensitive electronics. During transport and storage, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport.
  • Page 31 ETHERCAT SPLITTER SEC 171 12 Storage INFORMATION When not in use, store the operating panel according to the storage conditions. See chapter 11 Transport/Storage. During storage, ensure that all protective covers (if available) are placed correctly, so that no contamination, foreign bodies or fluids enter the device.
  • Page 32 SEC 171 ETHERCAT SPLITTER 13 Maintenance INFORMATION During maintenance as well as servicing, observe the safety instructions from chapter 2. 13.1 Service This product was constructed for low-maintenance operation. 13.2 Repair INFORMATION In the event of a defect/repair, send the device with a detailed error description to the address listed at the beginning of this document.
  • Page 33 ETHERCAT SPLITTER SEC 171 14 Disposal INFORMATION Should you need to dispose of the device, the national regulations for disposal must be followed. The device appliance must not be disposed of as household waste. 22.08.2024 Page 31...
  • Page 34 SEC 171 ETHERCAT SPLITTER Documentation Changes Change date Affected Chapter Note page(s) Page 32 22.08.2024...
