OWNER'S MANUAL

DRYER

Before beginning installation, read these instructions

carefully. This will simplify installation and ensure that the

product is installed correctly and safely. Leave these

instructions near the product after installation for future

reference.

ENGLISH

DF20*V2W / DF20*V2** / DF50*V2S6W*

MFL67652546

Rev.00_112724

www.lg.com

Need help?

Do you have a question about the DF50MV2S6WE and is the answer not in the manual?

Questions and answers

Summary of Contents for LG DF50MV2S6WE

Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH DF20*V2W / DF20*V2** / DF50*V2S6W* www.lg.com MFL67652546 Rev.00_112724 Copyright © 2024 LG Electronics. All Rights Reserved...
Page 2 Connecting Electric Dryers................30 Connecting the Water Inlet Hose..............35 Final Installation Check ...................37 OPERATION Before Use ......................40 Loading the Dryer ....................41 Control Panel ....................43 Dry Cycles......................45 Cycle Modifiers ....................48 Options and Extra Functions ................49 SMART FUNCTIONS LG ThinQ Application ..................51 Smart Diagnosis ....................51...
Page 3 MAINTENANCE Regular Cleaning....................53 TROUBLESHOOTING Before Calling for Service................55...
Page 4 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety for a Dryer WARNING Fire Hazard Failure to follow safety warnings exactly could result in serious injury, death or property damage. Do not install a booster fan in the exhaust duct. Install all clothes dryer in accordance with the installation instructions of the manufacturer of the dryer.
Page 5 IMPORTANT SAFETY INSTRUCTIONS WARNING - Risk of Fire Install the clothes dryer according to the manufacturer’s instructions and local codes. • Clothes dryer installation must be performed by a qualified installer. • Do not install a clothes dryer with flexible plastic venting materials.
Page 6 IMPORTANT SAFETY INSTRUCTIONS WARNING STATEMENTS WARNING • To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons when using this product, follow basic precautions, including the following: Installation • Adhere to all industry recommended safety procedures including the use of long-sleeved gloves and safety glasses.
Page 7 IMPORTANT SAFETY INSTRUCTIONS covered with rugs, bedspreads, or plastic sheets can become airtight chambers. • Place the appliance at least 45 cm above the floor for a garage installation. • Do not use sheet metal screws or other fasteners which extend into the duct that could catch lint and reduce the efficiency of the exhaust system.
Page 8 • If you detect a strange sound, a chemical or burning smell, or smoke coming from the appliance, unplug it immediately, and contact an LG Electronics customer information center. • Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight out from the outlet.
Page 9 • Do not modify or extend the power cord. • If the appliance has been submerged, contact an LG Electronics customer information center for instructions before resuming use. • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Page 10 IMPORTANT SAFETY INSTRUCTIONS • Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of the fabric softener or product. • Do not reach into the appliance if the drum is moving. • Do not dry articles that have been previously cleaned in, washed in, soaked in, soiled with or spotted with gasoline, dry cleaning solvents, vegetable oil, cooking oil or other flammable or explosive substances, as they give off vapors that could ignite or explode.
Page 11 IMPORTANT SAFETY INSTRUCTIONS • Items such as foam rubber (latex foam), shower caps, waterprooftextiles, rubber backed articles and clothes or pillows fitted with foamrubber pads should not be dried in the appliance. • Fabric softeners, or similar products, should be used as specified bythe fabric softener instructions.
Page 12 IMPORTANT SAFETY INSTRUCTIONS • The interior of the appliance and exhaust duct should be cleaned periodically by qualified service personnel. • Certain internal parts are intentionally not grounded and may present a risk of electronic shock only during servicing. Service personnel - do not contact the following parts while the appliance is energized: CONTROL BOARD Grounding Instructions...
Page 13 • You can take your appliance to any of the authorised centres for collection. If you want to know an updated list of countries that have this service, visit the page https:// www.lg.com/global/take-back-recycling-global-network- south-america.
Page 14 PRODUCT OVERVIEW PRODUCT OVERVIEW Product Features The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Front View Control Panel Lint filters Leveling feet Reversible door Rear View...
Page 15 PRODUCT OVERVIEW Gas Connection (for Gas Models) Exhaust Duct Oulet Terminal Block Access Panel (for Electric Models) Water Inlet Hose Connection (for Steam Models) Product Specifications Model DF20*V2W / DF20*V2** / DF50*V2S6W* Gas : 120 V~ 60 Hz, 400 W Electrical Requirements Electric : 120/240 V~ 60 Hz, 5550 W Min.
Page 16 PRODUCT OVERVIEW Side vent kit (Kit No. 383EEL9001B) NOTE • For your safety and extended product life, use only authorized components. The manufacturer is not responsible for product malfunction or accidents caused by the use of unauthorized components or parts.
Page 17 INSTALLATION INSTALLATION Before Installing Installation Overview Please read the following installation instructions first after purchasing this dryer or transporting it to another location. Choose the proper location. Level the appliance. Vent the appliance. Connect the inlet hose (for steam models) Connect the Gas / Electric dryer.
Page 18 INSTALLATION Choosing the Proper NOTE Location • A sturdy floor is needed to support the total appliance weight when loaded. The combined WARNING weight of additional appliances should also be considered. • Read all installation instructions completely • Clothes may not tumble properly, and automatic before installing and operating the appliance.
Page 19 INSTALLATION Dimensions and Clearances The following clearances are recommended for the appliance. • Additional clearances should be considered for ease of installation and servicing. • Additional clearances should be considered on all sides of the dryer to reduce noise transfer. Installation Spacing for Recessed Area or Closet Installation Description Dimension/Clearance...
Page 20 INSTALLATION Description Dimension/Clearance Side Clearance 25 mm Width 686 mm Height of Cabinet Opening 990 mm Closet Ventilation Requirements Closets with doors must have both an upper and lower vent to prevent heat and moisture buildup in the closet. One upper vent opening with a minimum opening of 310 cm must be installed no lower than 182.9 cm above the floor.
Page 21 INSTALLATION Description Dimension/Clearance Distance to Ventilation Opening 76 mm Front Clearance 25 mm Back Clearance 140 mm Top Clearance to the Ceiling 152 mm 1968 mm Height to the Top of Stacked Appliances Side Clearance 25 mm 686 mm Width *1 Differs depending on the washer dimensions.
Page 22 INSTALLATION Description Dimension/Clearance Front Clearance 25mm Side Clearance 25 mm Width 686 mm Clearance to Top of Cabinet 229 mm...
Page 23 INSTALLATION Leveling the Appliance Adjusting the Leveling Feet Use an adjustable wrench to turn the leveling feet. WARNING Unscrew the legs to raise the appliance or screw in the legs to lower it. Raise or lower with the leveling • Use long-sleeved gloves and safety glasses. feet until the appliance is level from side to side •...
Page 24 INSTALLATION Door Reversal Instructions WARNING The instructions here are for changing the door • Be sure to support the weight of the door before swing from a right to a left side hinge. If the door inserting the hinge screws. has been reversed, and it is necessary to change it back, use care when following these instructions.
Page 25 Be sure that the male end of the • An adapter kit, part number 383EEL9001B, may elbow faces AWAY from the appliance. Insert be purchased from your LG retailer. This kit the elbow/duct assembly through the side contains duct components necessary to change opening and press it onto the adapter duct.
Page 26 INSTALLATION • If appliances are already installed, disconnect Press the adapter duct onto the blower them from all power, water and drain housing and secure it to the base of the connections. appliance as shown. This stacking kit includes: • Two (2) side rails Insert the 10.2 cm elbow through the rear •...
Page 27 INSTALLATION the appliance. Slowly slide the appliance • Use only 4-inch (10.2 cm) rigid, semi-rigid or toward the back of the washer until the side flexible metal ductwork inside the dryer cabinet bracket stoppers catch the dryer feet. and for venting outside. •...
Page 28 INSTALLATION Ductwork Number of 90° Maximum length of 10 cm diameter rigid Wall Cap Type Elbows metal duct Recommended 19.8 m 16.8 m 14.3 m 11.0 m 8.5 m Use for only short run 16.8 m installations 14.3 m 12.5 m 9.1 m 6.7 m NOTE...
Page 29 INSTALLATION Connecting Gas Dryers • Isolate the dryer from the gas supply system by closing its individual manual shutoff valve during any pressure testing of the gas supply at WARNING pressures greater than 3.5 kPa. • Supply line requirements: Your laundry room •...
Page 30 INSTALLATION • If necessary, the correct nozzle (for the NG Securely tighten all connections between the nozzle kit, order part number 383EEL3002K) dryer and your laundry room’s gas supply. should be installed by a qualified technician and the change should be noted on the dryer. •...
Page 31 INSTALLATION SHOULD BE OF THE MAXIMUM RATE VOLTAGE • Use a 30-amp, 240-volt, 4-wire, UL-listed LISTED ON THE NAMEPLATE. DO NOT CONNECT power cord with #10 AWG-minimum copper THE APPLIANCE TO 110-, 115-, OR 120-VOLT conductor and closed loop or forked CIRCUIT.
Page 32 INSTALLATION ground wire . Cut off approximately 3.8 cm Attach the neutral (white) wire to the center from the other three wires and strip 2.5 cm screw of the terminal block. insulation from each wire. Bend the ends of the three shorter wires into a hook shape.
Page 33 INSTALLATION MOVED to the neutral terminal when a 4-wire • A UL-listed strain relief is required. cord is to be used, or where grounding through the neutral conductor is prohibited. • Use a 30-amp, 240-volt, 3-wire, UL-listed power cord with #10 AWG-minimum copper conductor and closed loop or forked terminals with upturned ends.
Page 34 INSTALLATION Bend the ends of the three wires into a hook Connect the external ground (if required by shape. local codes) to the green ground screw. Tighten all screws securely. Reinstall the terminal block access cover. Remove the terminal block access cover on the upper back of the appliance.
Page 35 • Do not reuse old hoses. Use only new hoses when installing the appliance. Old hoses could leak or burst causing flooding and property damage. Contact an LG Customer Information Center for assistance in buying hoses. Check the type of installation and connect the...
Page 36 INSTALLATION hoses tightly by hand and then tighten another NOTE 2/3 turn with pliers. • Type 1 : WITHOUT WASHER (The dryer does • Before connecting the water line to the dryer, not share the faucet with the washing flush out the hose with several gallons of water machine.) into a drain or bucket.
Page 37 INSTALLATION Checking Levelness NOTE Once the appliance is in its final location, recheck • If any leaks are found, shut off the water faucet, the appliance to be sure it is level. Make sure it is remove the hose and check the condition of the level front to back and side to side, and that all four rubber seal.
Page 38 INSTALLATION problems with the exhaust duct in your home. Press and hold the Anti Arrugas (Wrinkle However, since the test performed during Care) and Temp. buttons and then press the normal operation provides more accurate Power button. information on the condition of the exhaust duct •...
Page 39 INSTALLATION Restricted or Blocked Airflow Avoid long runs or runs with multiple elbows or bends. Excess or crushed Too many elbows or transition duct exhaust too long Check for blockages and lint buildup. Make sure the ductwork is not crushed or restricted.
Page 40 OPERATION OPERATION Before Use WARNING • To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. Operation Overview Normal cycle with the default settings. Select the Normal cycle to change the default settings.
Page 41 OPERATION Check the Lint Filter Before Grouping Similar Items Every Load For the best drying results, and to reduce the possibility of damage to clothing, sort clothes into Always make sure the lint filter is clean before loads that can be dried with the same drying cycle. starting a new load;...
Page 42 OPERATION Fabric Care Labels Many articles of clothing include a fabric care label. Using the chart below, adjust the cycle and option selections to care for your clothing according to the manufacturer's recommendations. Tumble Dry Label Directions Normal Permanent Press / Wrinkle Resistant Gentle / Delicate Do not tumble dry...
Page 43 3 seconds. The corresponding symbol lights up in the display. Remote Start • With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use the Remote Start function, refer to SMART FUNCTIONS.
Page 44 OPERATION Description Time and Status Display • The display shows the settings, estimated remaining time, options, and status messages. When the appliance is turned on, the default settings in the display will illuminate. Time and Status Display Description Limpieza de Filtro (Filter Cleaning) lights up when the lint filter should be cleaned or inserted.
Page 45 OPERATION Dry Cycles Turn the knob or press the button to select the desired cycle. When you select a dry cycle the light for the corresponding dry cycle will turn on. Sensor Drying Programme Guide The appliance automatically sets the dryness level and temperature at the recommended setting for each programme.
Page 46 OPERATION Programme Planchado Permanente (Perm. Press) Dry level Default: Normal Available: All Temperature Default: Media (Medium) Available: Media (Medium) Programme Delicados (Delicates) Description Use this programme for drying dress shirts/blouses, nylons, lingerie, or sheer and lacy clothes which can easily be damaged. Dry level Default: Normal Available: All...
Page 47 OPERATION Option Alerta Secado Programme Ahorro de Energía Anti Arrugas (Wrinkle Húmedo (Damp Dry Care) (Energy Saver) Signal) Carga Pesada (Heavy Duty) Ropa de cama (Bedding) Toallas (Towels) Planchado Permanente (Perm. Press) Delicados (Delicates) Secado Rápido (Speed Dry) Secado Con Aire (Air Dry) *1 This option helps to reduce the energy use by drying clothes at lower temperature than normal mode.
Page 48 OPERATION Cycle Modifiers About Modifier Buttons Each cycle has default settings that are selected automatically. Customize these settings using the cycle modifier buttons. Repeatedly press the button for the desired modifier until the indicator light for the desired setting is lit. Not every option is available with every cycle.
Page 49 OPERATION Options and Extra Wrinkle Care Functions Selecting this option will tumble the load periodically for up to 3 hours after the selected Your dryer includes several additional cycle options cycle, or until the door is opened. This is helpful in to customize cycles to meet your individual needs.
Page 50 OPERATION Locking/Unlocking the Control Panel Turn on the power. Press and hold the Anti Arrugas (Wrinkle Care) button for 3 seconds to activate/ deactivate this function. • When the function is deactivated, a chime will sound and the remaining time for the current cycle will reappear on the display.
Page 51 Follow the instructions below to use the audible notifications on a smartphone. The notifications diagnosis method. are triggered even if the LG ThinQ application is • Launch the LG ThinQ application and select the off. Smart Diagnosis feature in the menu. Follow...
Page 52 SMART FUNCTIONS • Keep the smartphone in place until the data transfer has finished. Time remaining for data transfer is displayed. After the data transfer is complete, the diagnosis will be displayed in the application. NOTE • For best results, do not move the smartphone while the tones are being transmitted.
Page 53 MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They will damage the finish. Regular Cleaning Maintaining Ductwork Vent ductwork should be checked for lint buildup Cleaning the Exterior once per month and cleaned at least once per year.
Page 54 MAINTENANCE For everyday cleaning, roll any lint off the filter with your fingers, or Vacuum the lint filter. If the lint filter has become very dirty or clogged with fabric softener, wash the lint filter in warm, soapy water and allow it to dry thoroughly before reinstalling.
Page 55 TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service The dryer is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the dryer does not function properly or does not function at all, check the following before you call for service.
Page 56 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance will not turn House fuse is blown, circuit breaker has tripped, or power outage has occurred. • Reset circuit breaker or replace fuse. Do not increase fuse capacity. If the problem is a circuit overload, have it corrected by a qualified electrician. Flow Sense indicator Exhaust system is too long or has too many turns/restrictions.
Page 57 TROUBLESHOOTING Symptoms Possible Cause & Solution Clothes take too long Load contains large and heavy fabrics. to dry. • Heavy fabrics take longer to dry because they tend to retain more moisture. To help reduce and maintain more consistent drying times for large and heavy fabrics, separate these items into smaller loads of a consistent size.
Page 58 TROUBLESHOOTING Performance Symptoms Possible Cause & Solution Greasy or dirty spots Fabric softener is used incorrectly. are left on clothes. • When washing clothes that are to be dried in the appliance, use the correct amount of fabric softener as recommended by the manufacturer of the fabric softener.
Page 59 TROUBLESHOOTING Symptoms Possible Cause & Solution Excess static in clothes Clothes have dried for too long (overdried). after drying. • Overdrying a load of clothes can cause a buildup of static electricity. Adjust settings and use a shorter drying time, or use Sensor Dry programmes. Drying synthetics, permanent press, or synthetic blends.
