Vestil COLV-5 Series Instruction Manual

Rev. 9/15/2016
COLV-5 S
Receiving instructions:
Remove the packaging from the product in a manner that preserves the packaging. Then, inspect the
product closely to determine whether it sustained damage during transport. If damage is discovered,
immediately record a complete description of the damage on the bill of lading. If the product is
undamaged, discard the packaging.
NOTES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location
where the product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to
apply either: a) Instructions in this manual; or b) Information provided on labels affixed to the product.
Vestil is not responsible for any consequential damages sustained as a result of failing to apply the
instructions in this manual while assembling, installing, using or maintaining this product.
Table of Contents
Signal words..................................................................................................................... 2
Safe use recommendations.................................................................................................. 2
Specifications.................................................................................................................... 3
FIG. 1: COLV-5-58-8 exploded parts diagram and bill of materials............................................... 3
FIG. 2: COLV-5-58-20 exploded parts diagram & bill of materials................................................ 4
FIG. 3: COLV-5-58-32 exploded parts diagram & bill of materials................................................ 4
FIG. 4: COLV-5-58-44 exploded parts diagram & bill of materials................................................ 4
FIG. 5: COLV-5-58-56 exploded parts diagram & bill of materials................................................ 5
Installation instructions....................................................................................................5 - 6
Inspections & Maintenance.................................................................................................. 6
Labeling diagram.............................................................................................................. 7
Limited warranty................................................................................................................8
Copyright 2016 Vestil Manufacturing Co.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
V
ERIES ERTICAL
I
NSTRUCTION
V M
ESTIL ANUFACTURING
Fax: (260) 665-1339
www.vestilmfg.com
C
ROSSOVER
M
ANUAL
COLV-5, MANUAL
C
ORP
e-mail: sales@vestil.com
L
ADDERS
Page 1 of 8
.
