The following document provides general information relative to the hardware installation of the Matrix
Area Controller hardware. Please read through this document carefully before proceeding with the
hardware installation process.
1.1 I
NTRODUCTION
Unpack your Matrix Area Controller and inspect the contents for damaged or missing items. Included in
this package, you should find the following items:
Matrix Area Controller with lock and key

Matrix Hardware Installation Guide

Matrix Quick Start Guide

1.1.1 T R
OOLS EQUIRED
The following tools and supply may be required for installation:
Small flat-bladed screwdriver - for field-bus and power connectors

Drill - for mounting the product onto a wall

Wire-strippers - for terminating EIA-485 connections

1.1.2 S P
AFETY RECAUTIONS
A
ATRIX REA
I
NSTALLATION
NOTE
All equipment must be installed in accordance with
NEC and local codes. For more information on
local codes, please check state/local regulations in
your area.
CAUTION
To prevent damage to any of the electrical
components of this product and to ensure that it
continually operates, do not attempt to attept to
alter any componentry.
WARNING
Prior to serving the Matrix Area Controller,
always disconnect power first.
