READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-
covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester
for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland,
Page 1
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019. FORM NO. 769-02308 12/15/05 PRINTED IN U.S.A MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019...
Page 2
Model Number Serial Number This information will be necessary to use the manufacturer’s web site, to obtain assistance from the Customer Support Department, or when contacting an authorized service dealer. MTD LLC P. O. BOX 361131 CLEVELAND,OH 44136 330-220-4683 www.mtdproducts.com...
Page 3
Use this page as a guide to determine slopes where you may not operate safely. Do not operate your lawn mower on such slopes. Slope Gauge WARNING Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet).
Page 4
WARNING: Engine Exhaust, some of its constituents, and certain vehicle compo- nents contain or emit chemicals known to State of California to cause cancer and birth defects or other reproductive harm. DANGER: This machine was built to be operated according to the rules for safe operation in this manual.
Page 5
The cutting blade continues to rotate for a few seconds after 7. Extinguish all cigarettes, cigars, pipes and other sources the engine is shut off. Never place any part of the body in of ignition. the blade area until you are sure the blade has stopped 8.
Page 6
1. Follow the steps below to remove the unit from the carton: a. Open carton and remove loose parts included with � unit. Do not crimp cables while removing loose parts or the entire unit from the carton. b. Cut corners and lay carton down flat. Remove Setup and packing material.
Page 7
6. Follow the steps below, if needed, to assemble the 7. Follow steps below to install the grass catcher, grass catcher, Figure 3-5. Figure 3-6. a. Place bag over frame so that its black plastic side a. Lift rear discharge door. is at the bottom.
Page 8
Know Your Lawn Mower Blade Control Operating Drive Control Your Lawn Mower Recoil Starter Height Adjustment Levers (for each wheel) WARNING The blade control is a safety device. Never attempt to bypass its operations. Figure 4-1: The main components on the mower. Use extreme care when handling gasoline.
Page 9
WARNING: The operation of any lawn mower can result in foreign objects being thrown into the eyes, which can damage your eyes severely. Always wear safety glasses while operating the mower, or while performing any adjustments or � repairs on it. Operating Starting the Mower Your Lawn...
Page 10
Lubrication 1. Lubricate pivot points on the blade and drive control handles at least once a season with light oil, Figure 5-1. 2. Lubricate the wheels at least once a season with light oil (or motor oil). If wheels are removed for any reason, lubricate surface of the pivot arm and inner Maintaining surface of the wheel with light oil.
Page 11
Blade Care WARNING: When removing cutting blade, protect your hands with a pair of heavy gloves or use a heavy rag to hold blade. 1. Disconnect spark plug wire from spark plug. Turn mower on its side making sure that the air filter and Maintaining the carburetor are up.
Page 12
Problem Remedy Cause Engine fails to start 1. Blade control disengaged. 1. Engage blade control. 2. Spark plug wire disconnected. 2. Connect wire to spark plug. 3. Fuel tank empty or stale fuel. 3. Fill tank with clean, fresh gasoline. 4.
Page 13
Off-Season Storage 4. Coat mower’s cutting blade with chassis grease to prevent rusting. The following steps should be taken to prepare your lawn mower for storage. 5. Store mower in a dry, clean area. Do not store next 1. Clean and lubricate mower thoroughly as described in to corrosive materials, such as fertilizer.
Page 15
731-2626 Bail Cover 37 782-7551A Wheel Cover 747-1161A Blade Control 38 717-1762 Spur Gear 14T RH 746-1113 Control Cable 37.75-inch 717-1761 Spur Gear 14T LH Parts List 726-0240 Cable Tie 39 710-04531 Screw 1/4-20 x .39 664-04007A Grass Bag Assembly 40 734-04093 Front Wheel 8 x 2.125 Gear Zag Blk 747-04080...
Page 16
MANUFACTURER’S LIMITED WARRANTY FOR The limited warranty set forth below is given by MTD LLC with respect e. MTD does not extend any warranty for products sold or exported to new merchandise purchased and used in the United States, its outside of the United States, its possessions and territories, except possessions and territories.
