PARTS AND OPERATION MANUAL

PLASTER / MORTAR MIXER

A D I V I S I O N O F M U LT I Q U I P I N C.

MS20H (Steel-Gasoline)

MS20E (Steel-Electric)

Effective S/N SEC55001

Revision #3 (08/10/06)

STOW CONSTRUCTION EQUIPMENT

A DIVISION OF MULTIQUIP INC.

POST OFFICE BOX 6254

CARSON, CALIFORNIA 90749

310-537-3700 • 888-252-STOW [888-252-7869]

FAX: 310-537-1986 • FAX: 800-556-1986

E-MAIL: stow@multiquip.com • WWW: stowmfg.com

PARTS DEPARTMENT:

800-427-1244

FAX: 800-672-7877

SERVICE DEPARTMENT/TECHNICAL ASSISTANCE:

800-478-1244

FAX: 310-631-5032

Need help?

Do you have a question about the Stow MS20H and is the answer not in the manual?

Questions and answers

Summary of Contents for MULTIQUIP Stow MS20H

Page 1 Effective S/N SEC55001 Revision #3 (08/10/06) STOW CONSTRUCTION EQUIPMENT PARTS DEPARTMENT: A DIVISION OF MULTIQUIP INC. 800-427-1244 POST OFFICE BOX 6254 FAX: 800-672-7877 A D I V I S I O N O F M U LT I Q U I P I N C.
Page 2 PAGE 2 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 3 FAX: 800-672-7877 or 310-637-3284 SERVICE DEPARTMENT/TECHNICAL ASSISTANCE 800-478-1244 or 310-537-3700 FAX: 310- 537-4259 WARRANTY DEPARTMENT 888-661-4279, or 310-661-4279 FAX: 310- 537-1173 MAIN 800-421-1244 or 310-537-3700 FAX: 310-537-3927 MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 3...
Page 4 Honda Engine Assembly ........38-39 Electric Motor Assembly........40-41 Steel Tub Assembly ...........42-43 Paddle Shaft Assembly ........44-45 Axle Assembly ...........46-47 Frame Assembly ..........48-49 Engine Cover Assembly ........50-51 PAGE 4 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 5 Toll-free nationwide — 800-427-1244 POST OFFICE BOX 6254 CARSON, CA 90749 888-252-STOW [888-252-7869] 310-537-3700 Toll-free FAX — 800-6-PARTS-7 (800/672-7877) FAX: 310-537-1986 FAX: 800-556-1986 E-MAIL: stow@multiquip.com INTERNET: www.stowmfg.com MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 5...
Page 6 Potential hazards associated with operation of the mixer will be referenced with Hazard Symbols which appear throughout this manual, and will be referenced in conjunction with Safety Message Alert Symbols. PAGE 6 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 7 ALWAYS wear approved eye and hearing the surrounding environment. protection. NOTE This MIXER , other property, or the surrounding environment could be damaged if you do not follow instructions. MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 7...
Page 8 ■ NEVER operate the mixer in an explosive atmosphere or near combustible materials. An explosion or fire could result causing severe bodily harm or even death. PAGE 8 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 9 ■ Refer to the HONDA Engine Owner's Manual for engine technical questions or information recommended by Multiquip for this equipment. Damage to the equipment and/or injury to user may result. MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 9...
Page 10 , doctor and fire department . This information will be invaluable in the case of an emergency. ■ ALWAYS know the location of the nearest and first aid kit . PAGE 10 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 11 Figure 1 below illustrates these decals as they appear on the machine. Should any of these decals become unreadable, replacements can be obtained from your dealer. Figure 1. Mixer Operation and Safety Decals MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 11...
Page 12 . n i . n i ) . g ) . g PAGE 12 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 13 1/2" - 13 (Grade 8) In accordance with our established NOTE policy of constant improvement, we reserve the right to amend these specifications at any time without notice. MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 13...
Page 14 10. Fuel Tank – Holds unleaded gasoline. For additional information refer to engine owner's manual. PAGE 14 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 15 MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 15...
Page 16 MS20H/MS20E MIXER — ELECTRIC MOTOR Figure 3. Single Phase Electric Motor with 18 inch Pigtail Cable PAGE 16 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 17 The safety grill should only be un-locked when cleaning of the blades and drum is required. MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 17...
Page 18 Torque wheel lug nuts as described in the " Lug Nut Torque Requirements ", Table 6. ■ Check tightness of suspension hardware (nuts and bolts) . PAGE 18 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 19 This will keep the drum from rotating. Figure 5. Mixer Safety Chain and Coupler Figure 6. Drum Latch Pin (Tow or Locked Position) MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 19...
Page 20 Figure 7. Axle Support Components ALWAYS wear safety glasses when removing or installing force fitted NOTE parts. Failure to comply may result in serious injury. PAGE 20 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 21 NOTE NEVER! use an pneumatic air gun to tighten wheel lug nuts. Figure 8. Wheel Lug Nuts Tightening Sequence MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 21...
Page 22 MS20H/MS20E MIXER — PADDLE BLADE ADJUSTMENT Adjust paddles as shown in Figure 9. Figure 9. Paddle Blade Adjustment, Steel Drum PAGE 22 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 23 C ° 2. Remove the filler dipstick from the engine oil filler hole (Figure 10) and wipe it clean. r e t C ° MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 23...
Page 24 Check the zerk grease fittings at each end of the mixing drum. These grease fittings lubricate the dumping mechanism. If the dumping handle is stiff or hard to move lubricate these fittings. PAGE 24 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 25 If your mixer has an electric motor disregard this section. Move the fuel shut-off lever (Figure 12) to the ON position. Figure 14. Throttle Lever Figure 12. Fuel Shut-OFF Lever MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 25...
Page 26 Pull the starter grip (Figure 20) lightly until you feel resistance, then pull briskly. Return the starter grip gently. Figure 18. Belt Slip Lever (Start/Stop Position) Figure 20. Starter Grip PAGE 26 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 27 When the dump handle is released, the drum will return to an upright position. Clean drum of all debris and foreign matter MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 27...
Page 28 Oil these fittings two or three times each week as they lubricate materials to form on the blades or anywhere inside the drum. the dumping mechanism of the mixing drum. PAGE 28 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 29 . r e u f l o i t t e r . r o r o t o l f . t a MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 29...
Page 30 . l a r o t s u j s u j t e r . r o e " c i r PAGE 30 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 31 . e t i t c r o t c t i c t i i t c r o t r i a MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 31...
Page 32 MS20H/MS20E MIXER — WIRING DIAGRAM (ELECTRIC MOTOR) Figure 22. Electric Motor Wiring Diagram PAGE 32 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 33 NOTE PAGE MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 33...
Page 34 Note: If more than one of the same reference number is listed, the last one listed indicates newest (or latest) part available. NOTE The contents of this parts catalog are subject to change without notice. PAGE 34 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 35 3 .... 9807956846 ..SPARK PLUG HONDA 8.0 HP 3 .... 17210ZE2505 . ELEMENT, AIR HONDA 8.0 HP 1 .... 28462ZE2W11 ROPE, RECOIL STARTER MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 35...
Page 36 MS20H/MS20E MIXER — NAMEPLATE AND DECALS NAMEPLATE AND DECALS. PAGE 36 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 37 DECAL: CAUTION, DRUM LOCK 21513-001 DECAL: WARNING TOW POLE DCLMS20 KIT, DECAL ........1 .... INCLUDES ITEMS W/ SEE DECAL ILLUSTRATIONS ON PAGE 11. MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 37...
Page 38 MS20H/MS20E MIXER — HONDA ENGINE ASSY. HONDA ENGINE ASSY. PAGE 38 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 39 492077 DRIVEN PULLEY 07030-016 FLAT WASHER 503640 V-BELT ..........2 .... HONDA, B &S 20771-354 ENGINE MOUNT 06500-010 CAP SCREW 5/16- 18 x 1-1/4 MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 39...
Page 40 MS20H/MS20E MIXER — ELECTRIC MOTOR ASSY. (ELECTRIC) ELECTRIC MOTOR ASSY. PAGE 40 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 41 DRIVEN PULLEY 10057-032 SQUARE KEY 1/4 x 1-1/2 491112 V-BELT 24975-001 BELT RETAINER BAR 12969-008 SOCKET SET SCREW 5/16-18 06500-008 CAP SCREW 5/16-18 x 1 MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 41...
Page 42 MS20H/MS20E MIXER — STEEL TUB ASSY. STEEL TUB ASSY. PAGE 42 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 43 CLEVIS PIN 07030-008 FLAT WASHER 1/2 13698-010 HITCH PIN 07594-012 ROLL PIN 3/16 x 3/4 07028-055 COTTER PIN 5/32 x 1 07745-001 GREASE FITTING MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 43...
Page 44 WHEN ORDERING SCRAPPER AND WIPER(LONG) SEE ITEMS 39 AND 40 CENTER TOW END WHEN ORDERING SCRAPPER AND WIPER (LONG) SEE ITEMS 39 AND 40 ENGINE END PAGE 44 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 45 LOCK WASHER 1/2 GRADE 8 07037-108 HEX NUT 1/2-20 GRADE 5 29285-503 PADDLE KIT ..........1 ..INCLUDES ITEMS W/ 25647-503 WIPER KIT ..........1 ..INCLUDES ITEMS W/ # MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 45...
Page 46 MS20H/MS20E MIXER — AXLE ASSY. AXLE ASSY. PAGE 46 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 47 U-BOLT AXLE MNT. EM941306 HUB ASSY..............2 .... INCLUDES ITEM W/ 502246 SLOTTED HEX NUT 1-20 3005 WHEEL & TIRE ASSY. -12” 3469 DUST COVER MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 47...
Page 48 MS20H/MS20E MIXER — FRAME ASSY. FRAME ASSY. PAGE 48 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 49 CONNECTOR LINK ........1 ... AFTER JANUARY 2006 111A# 516580 CLEVIS SAFETY HOOK ......1 ... AFTER JANUARY 2006 13363KIT CHAIN AND LINK KIT ......... 1 ... INCLUDES ITEMS W/# MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 49...
Page 50 MS20H/MS20E MIXER — ENGINE COVER ASSY. CABINET ASSY. PAGE 50 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 51 CAP SCREW 3/8 - 16 x 1 29173-001 STOP SWITCH 29174-001 RED KNOB 491010 LATCH ASSY. 23342-523 WIRE ASSY. GROUND LEAD ....1 ..HONDA, B & S MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 51...
Page 52 HONDA GX240K1HA2 ENGINE — AIR CLEANER ASSY. AIR CLEANER ASSY. PAGE 52 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 53 ELBOW COMP., AIR CLEANER ....1 ..... INCLUDES ITEM W/ # 90203ZA0800 WINGNUT 6MM 90325044000 WINGNUT, TOOL BOX SETTING 90009ZE2003 BOLT- WASHER 6 X 22 9405006000 NUT, FLANGE 6MM MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 53...
Page 54 HONDA GX240K1HA2 ENGINE — CAMSHAFT ASSY. CAMSHAFT ASSY. PAGE 54 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 55 RETAINER, IN. VALVE SPRING 14773ZE2000 RETAINER, EX. VALVE SPRING 14781ZE2000 ROTATOR, VALVE 14791ZE2010 PLATE, PUSH ROD GUIDE 90012ZE0010 BOLT, PIVOT 8MM 90206ZE1000 NUT, PIVOT ADJ. MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 55...
Page 56 HONDA GX240K1HA2 ENGINE — CARBURETOR ASSY. CARBURETOR ASSY. PAGE 56 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 57 99101ZH70850 JET, MAIN #85, OPTIONAL 99101ZH70880 JET, MAIN #88 99204ZE20400 JET SET, PILOT #40 16015ZE8005 CHAMBER SET, FLOAT ....1 ..INCLUDES ITEMS W/ MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 57...
Page 58 HONDA GX240K1HA2 ENGINE — CONTROL ASSY. CONTROL ASSY. PAGE 58 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 59 BOLT, FLANGE (6 X 12) (CT200) 90015ZE5010 BOLT, GOVERNOR ARM 90114SA0000 NUT, SELF- LOCK (6MM) 93500050280A SCREW, PAN (5 X 28) 9405006000 NUT, FLANGE MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 59...
Page 60 HONDA GX240K1HA2 ENGINE — CRANKCASE COVER ASSY. CRANKCASE COVER ASSY. PAGE 60 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 61 BOLT, FLANGE (8 X 35) 961006202000 BEARING, RADIAL BALL (6202) 961006204000 BEARING, RADIAL BALL (6204) 961006206000 BEARING, RADIAL BALL (6206) 961006302000 BEARING, RADIAL BALL (6302) MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 61...
Page 62 HONDA GX240K1HA2ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PAGE 62 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 63 HONDA GX240K1HA2ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PART NO. PART NAME QTY. REMARKS 13320ZE2611 CRANKSHAFT (L- TYPE) 13351ZE2010 WEIGHT BALANCER INCLUDES ITEM W/ 961006206000 BEARING, RADIAL BALL (6206) MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 63...
Page 64 HONDA GX240K1HA2 ENGINE — CYLINDER BARREL ASSY. CYLINDER BARREL ASSY. PAGE 64 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 65 WASHER, DRAIN PLUG 12MM 9425110000 PIN, LOCK 10MM 957010601200 BOLT, FLANGE 6X12 961006202000 BEARING, RADIAL BALL 6202 90013883000 BOLT, FLANGE 6X12 CT200 34150ZH7003 ALERT UNIT, OIL MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 65...
Page 66 HONDA GX240K1HA2 ENGINE — CYLINDER HEAD ASSY. CYLINDER HEAD ASSY. PAGE 66 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 67 PIN A, DOWEL 12X20 950051100130M BULK HOSE, VACUUM 11X1000, 11X100 957011008000 BOLT, FLANGE 10X80 9807956846 SPARK PLUG, BPR6ES, NGK 9807956855 SPARK PLUG, W20EPR-U, DENSO MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 67...
Page 68 HONDA GX240K1HA2 ENGINE — FAN COVER ASSY. FAN COVER ASSY. PAGE 68 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 69 19610ZE2010ZC COVER COMP., FAN *NH1* BLACK 19631ZE2D00 SHROUD 32197ZH8003 SUB-HARNESS 36100ZE1015 SWITCH ASSY., ENGINE STOP 90013883000 BOLT, FLANGE 6X12, CT200 90684ZA0601 CLIP, WIRE HARNESS MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 69...
Page 70 HONDA GX240K1HA2 ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PAGE 70 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 71 PART NAME QTY. REMARKS 19511ZE2000 FAN, COOLING 28450ZE2W11 PULLEY COMP., STARTER, SCREEN GRID 31100ZE2010 FLYWHEEL COMP. 90201ZE3V00 NUT, SPECIAL 16MM 90741ZE2000 KEY, SPECIAL WOODRUFF 25X18 MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 71...
Page 72 HONDA GX240K1HA2 ENGINE — MUFFLER ASSY. MUFFLER ASSY. PAGE 72 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 73 BOLT, FLANGE (6 X 12) (CT200) 90050ZE1000 SCREW, TAPPING (5 X 8) 90055ZE1000 SCREW, TAPPING (4 X 6) 90050ZE1000 SCREW, TAPPING (5 X 8) (OPTIONAL) 9405008000 NUT, FLANGE (8MM) MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 73...
Page 74 HONDA GX240K1HA2 ENGINE — FUEL TANK ASSY. FUEL TANK ASSY. PAGE 74 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 75 FILTER, FUEL 91353671003 O-RING 14MM, ARAI 9405008000 NUT, FLANGE 8MM 950014500360M BULK HOSE, FUEL 4.5X3000, 4.5X222 9500202080 CLIP, TUBE, B8 957010802500 BOLT, FLANGE 8X25 MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 75...
Page 76 HONDA GX240K1HA2ENGINE — IGNITION ASSY. IGNITION COIL ASSY. PAGE 76 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 77 PART NAME QTY. REMARKS 30500ZE2023 COIL ASSY., IGNITION 30700ZE1013 CAP ASSY., NOISE SUPPRESSOR 31512ZE2000 GROMMET, WIRE 36101ZE1010 WIRE, STOP SWITCH 370MM 90015883000 BOLT, FLANGE 6X28 MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 77...
Page 78 HONDA GX240K1HA2 ENGINE — PISTON ASSY. PISTON ASSY. PAGE 78 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 79 ROD ASSY., CONNECTING STANDARD ....1 ..INCLUDES ITEMS W/ 13200ZE2305 ROD ASSY., CONNECTING, US 0.25, OPT. 90001ZE8000 BOLT, CONNECTING ROD 90551ZE1000 CLIP, PISTON PIN 18MM MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 79...
Page 80 HONDA GX240K1HA2 ENGINE — RECOIL STARTER ASSY. RECOIL STARTER ASSY. PAGE 80 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 81 28442ZE2W01 SPRING, STARTER RETURN 28443ZE2W01 SPRING RATCHET 28444ZE2W01 RETAINER, SPRING 28461ZE2W02 GRIP, STARTER 28462ZE2W11 ROPE, RECOIL STARTER 90004ZE2W01 SCREW, CENTER 90008ZE2003 BOLT, FLANGE 6X10 MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 81...
Page 82 HONDA GX240K1HA2 ENGINE — GEAR REDUCTION ASSY. GEAR REDUCTION ASSY. PAGE 82 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 83 PIN A, DOWEL ( 8 X 14) 957010802500 BOLT, FLANGE (8 X 25) 957010804000 BOLT, FLANGE (8 X 40) 961006206000 BEARING, RADIAL BALL (6206) 961006302000 BEARING, RADIAL BALL (6302) MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 83...
Page 84 HONDA GX240K1HA2 ENGINE — LABEL ASSY. LABEL ASSY. PAGE 84 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 85 QTY. REMARKS 87521ZE2W01 EMBLEM, INTERNAL 87522ZE1810 MARK, CAUTION, EXTERNAL 87522ZH9000 LABEL, CAUTION 87528ZE2810 MARK, CHOKE, EXTERNAL 87586ZH7W00 LABEL, FUEL CAUTION 87532ZH8810 MARK, OIL ALERT MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 85...
Page 86 310-661-4242 • 877-BUY-STOW FAX: 310-604-9237 E-MAIL: stow@stowmfg.com Atlanta • Boise • Newark • Quebec, Canada www.stowmfg.com Manchester, UK • Rio de Janeiro, BR • Puebla, MX PAGE 86 — MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06)
Page 87 NOTE PAGE MQ STOW MS20H/MS20E MIXER — PARTS & OPERATION MANUAL — REV. #3 (08/10/06) — PAGE 87...
Page 88 800-421-1244 or 310-537-3700 FAX: 310-537-3927 STOW CONSTRUCTION EQUIPMENT PARTS DEPARTMENT: A DIVISION OF MULTIQUIP INC. 800-427-1244 POST OFFICE BOX 6254 FAX: 800-672-7877 A D I V I S I O N O F M U LT I Q U I P I N C.
