2001 Volvo V70
This manual deals with the operation and care of your Volvo.
Welcome to the worldwide family of Volvo owners. We trust that you will enjoy many years of safe
driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure
your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment
descriptions, operating instructions and maintenance requirements/ recommendations in this manual. We
also urge you and your passengers to wear seat belts at all times in this or any other automobile. And, of
course, please do not operate a vehicle if you may be affected by alcohol, medication or any impairment
that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the
certification labels attached to the driver's door opening and on the left wheel housing in the engine
compartment.
For further information please contact your retailer, or:
In the USA:
Volvo Cars of North America
Customer Relations
P.O. Box 914
file:///K|/ownersdocs/2001/2001_V70/01v70_00.htm (1 of 5)12/30/2006 3:50:48 PM
2 0 0 1
VOLVO
V70
In Canada:
Volvo Canada Ltd.
175 Gordon Baker Road
Willowdale, Ontario M2H 2N7

Advertisement

loading
Need help?

Need help?

Do you have a question about the V70 2001 and is the answer not in the manual?

Questions and answers

DOVE
April 12, 2025

WASTE BIN, BASKET ASSEMBLY? flummoxed ?

0
1 comments:
Mr. Anderson
April 12, 2025

The waste bin or basket assembly in a 2001 Volvo V70 is located in the rear seat area and can also be used as a holder for larger bottles or containers. However, for safety reasons, glass bottles should not be used anywhere in the car.

This answer is automatically generated

0

Related Manuals for Volvo V70 2001

Summary of Contents for Volvo V70 2001

  • Page 1 This manual deals with the operation and care of your Volvo. Welcome to the worldwide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/ recommendations in this manual.
  • Page 2 2001 Volvo V70 Rockleigh, New Jersey 07647-0914 800-663-8255 800-458-1552 We also invite you to visit our Home Page on the Internet at: http://www.volvocars.com Contents Contents Chapter 1 - Safety Chapter 2 - Instruments, switches and controls Chapter 3 - Climate control system...
  • Page 3 ("Check Engine" light) may indicate a fault. Volvo and the environment Volvo is committed to the well being of our customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.
  • Page 4 In addition to continuous environmental refinement of conventional gasoline-powered internal combustion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles. When you drive a Volvo, you become our partner in the work to lessen the car's impact on the environment.
  • Page 5 Prem-Air works as a catalytic converter, converting most of the ozone passing through the radiator into oxygen, thereby reducing harmful ground-level ozone. For additional information regarding the environmental activities in which Volvo Cars of North America, Inc. and Volvo Car Corporation are involved, visit our Internet Home Page at: http://www.volvocars.com Top of Page file:///K|/ownersdocs/2001/2001_V70/01v70_00.htm (5 of 5)12/30/2006 3:50:48 PM...
  • Page 6 1 Safety Not wearing a seat belt is like believing "It'll never happen to me!" Volvo, the inventor of the three-point seat belt, urges you and all adult occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
  • Page 7 2001 VOLVO V70 Stability Traction Control (STC) 20 Dynamic Stability Traction Control (DSTC) pg. 2 Seat belts Seat belts Always fasten the seat belts before you drive or ride. A chime will sound several times if the driver's seat belt is not fastened.
  • Page 8 2001 VOLVO V70 Child seats: Please refer to page 14 for information on securing child seats with the seat belts. During pregnancy Pregnant women should always wear seat belts. Remember that the belt should always be positioned in such a way as to avoid any possible pressure on the abdomen. The lap portion of the belt should be located low, as shown in the above illustration.
  • Page 9 Never repair the belt on your own; have this work done by an authorized Volvo retailer only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
  • Page 10 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4). The system is designed to supplement the protection provided by the three-point seat belt system.
  • Page 11 When installing any optional equipment, make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible.
  • Page 12 If the SRS warning light stays on after the engine has started or if it comes on while you are driving, drive the car to the nearest authorized Volvo retailer for inspection as soon as possible. There is no maintenance to perform on the SRS yourself. The month and year shown on the decal on the door pillar indicate when you should contact your Volvo retailer for specific servicing or replacement of airbags and seat belt tensioners.
  • Page 13 2001 VOLVO V70 P.O. Box 914 Willowdale, Ontario M2H 2N7 Rockleigh, New Jersey 07647-0914 800-663-8255 800-458-1552 pg. 6 Front airbags - SRS file:///K|/ownersdocs/2001/2001_V70/01v70_01a.htm (8 of 16)12/30/2006 3:50:50 PM...
  • Page 14 Collisions can occur where only one of the airbags deploys. NOTE: Volvo's dual-stage air bags:If the impact is less severe, but severe enough to present a clear injury risk, the dual-stage airbags are triggered at just 70% of its total capacity. If the impact is more severe, the dual-stage airbags are triggered with full capacity.
  • Page 15 2001 VOLVO V70 WARNING! Children must never be allowed in the front passenger seat. Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the back seat of any vehicle with a passenger-side front airbag. See page 14 for guidelines.
  • Page 16 Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car.
  • Page 17 Never try to open or repair any components of the SIPS airbag system. This should be done only by an authorized Volvo service technician. In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright position with the seat belt properly fastened.
  • Page 18 This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs.
  • Page 19 2001 VOLVO V70 Volvo Inflatable Curtain (VIC) This system consists of inflatable curtains located along the sides of the roof liners, stretching from the center of both front side windows to the rear edge of the rear side door windows. It is designed to help protect the heads of the occupant of the front seat and the occupant of the outboard rear seat position in certain side impact collisions.
  • Page 20 Never try to open or repair any components of the IC system. This should be done only by an authorized Volvo service technician. The inflatable curtains are designed to deploy only during certain side-impact collisions, depending on the crash severity, angle, speed and impact.
  • Page 21 If your car has been involved in a collision, the front seat backrests must be inspected by an authorized Volvo retailer even if the seats appear to be undamaged. Certain components in the WHIPS system may need to be replaced. Do not attempt to service any component in the WHIPS system yourself.
  • Page 22 2001 VOLVO V70 pg. 11 Child safety If all the seats are occupied, a rear-facing auxiliary seat in the cargo area can be used. This seat is designed for two children, each weighing between 50 - 88 lbs. (23 - 40 kg) with a total seat capacity of 176 lbs.
  • Page 23 12 Child safety Integrated booster cushions, outboard positions (optional) Volvo's own integrated booster cushions have been specially designed to help safeguard a child seated in the rear seat. When using an integrated booster cushion, the child must be secured with the vehicle's three-point seat belt.
  • Page 24 2001 VOLVO V70 Outboard integrated booster cushions - Raising 1. Pull the handle at the front of the cushion forward. 2. With both hands push the cushion rearward. 3. Push the cushion until it locks in place. Outboard integrated booster cushions - Lowering 1.
  • Page 25 The booster cushion should also be replaced if it is badly worn or damaged in any way. This work should be performed by an authorized Volvo retailer only. The booster cushion should be cleaned while in place in the vehicle if possible. If not, please consult your Volvo retailer.
  • Page 26 Important! Why Volvo believes no child should sit in the front seat of a car. It's quite simple really. A front air bag is a very powerful device designed, by law, to help protect an adult. Because of the size of the air bag and its speed of inflation, a child should never be placed in the front seat, even if he or she is properly belted or strapped into a child safety seat.
  • Page 27 15 Child safety Child Restraint Anchorages Volvo cars are fitted with child restraint top tether anchorages in the rear seat. WARNING! Child Restraint Anchorages are designed to withstand only those loads imposed by correctly fitted Child Restraints. Under no circumstances are they to be used for adult seat belts or harnesses. The anchorages are not able to withstand excessive forces on them in the event of collision if full harness seat belts or adult seat belts are installed to them.
  • Page 28 2001 VOLVO V70 Isofix fasteners and Seat guide The Isofix fasteners are installed in the outboard rear seat positions. Consult your Volvo retailer for more information on child safety accessories. pg. 16 Child safety Child safety Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a car.
  • Page 29 A specially designed and tested booster cushion (not available in Canada ) for children between 50 - 80 lbs (22.7 - 36 kg) and 46 -54" (117 - 137 cm) can be obtained from your Volvo retailer. If necessary, an auxiliary seat for children is available for use in the luggage compartment of station wagon models.
  • Page 30 Check seat belt mechanism function as follows: Attach the seat belt and pull rapidly on the strap. Volvo Concern for Safety Safety is the cornerstone of Volvo. Our concern dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy-absorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation.
  • Page 31 WARNING! If the fluid level is below the MIN mark in the reservoir: DO NOT DRIVE. Tow the car to a Volvo retailer and have the brake system inspected. NOTE: When the car is at a standstill and the engine is idling, e.g. at a traffic light and the brake pedal is depressed, the pedal may go down slightly.
  • Page 32 If the warning lamp lights up there is a malfunction of the ABS system (the standard braking system will however function) and the vehicle should be driven cautiously to a Volvo retailer for inspection. The Anti-lock Braking System (ABS) helps to improve vehicle control (stopping and steering) during severe braking conditions by limiting brake lockup.
  • Page 33 If the fluid level is below the MIN mark in the reservoir, DO NOT DRIVE. Have the car towed to an authorized Volvo retailer and have the brake system inspected. If the brake fluid level is above the MIN mark, drive carefully to an authorized Volvo retailer and have the brake system inspected.
  • Page 34 If the indicator light goes off, no further action is required. If the light remains on, have the STC system inspected by an authorized Volvo retailer. * Standard on cars equipped with the B 5234 T3 engine and optional on models with the B 5244 T3 or non-turbo engines.
  • Page 35 DSTC has been temporarily switched off due to high brake temperature. The system will automatically switch on again when the brakes have cooled. If the system has been switched off due to a fault. An authorized Volvo retailer should check the system. Contents Top of Page file:///K|/ownersdocs/2001/2001_V70/01v70_01b.htm (14 of 14)12/30/2006 3:50:51 PM...
  • Page 36 2001 VOLVO V70 2 0 0 1 VOLVO Chapter 2 - Instruments, switches and controls pg. 21 Instruments, switches and controls Interior 22 Exterior 23 Instruments 24 Instrument panel 25 Indicator and warning lights 26 Text information window 28 Switches in the center console 29...
  • Page 37 2001 VOLVO V70 Rearview/sideview mirrors 39 Sun roof 40 pg. 22 Instruments, switches and controls pg. 23 Instruments, switches and controls file:///K|/ownersdocs/2001/2001_V70/01v70_02a.htm (2 of 13)12/30/2006 3:50:52 PM...
  • Page 38 2001 VOLVO V70 pg. 24 Instruments, switches and controls file:///K|/ownersdocs/2001/2001_V70/01v70_02a.htm (3 of 13)12/30/2006 3:50:52 PM...
  • Page 39 2001 VOLVO V70 pg. 25 Instruments, switches and controls 1 Turn signals 2 Text window 3 Temperature gauge The pointer should be approximately midway on the gauge when driving. file:///K|/ownersdocs/2001/2001_V70/01v70_02a.htm (4 of 13)12/30/2006 3:50:52 PM...
  • Page 40 2001 VOLVO V70 Do not drive the car if the warning light is on. The text window will provide you with additional information. If the engine temperature remains high, check coolant level - see page 125. 4 Trip odometer/reset button The trip odometer is used for measuring shorter distances.
  • Page 41 2001 VOLVO V70 Turn the button to adjust the clock. 13 Fuel gauge The fuel tank holds approximately 21.1 US gal. (80 liters)*. When the warning light comes on there are approximately 1.8 US gal. (8 liters) of fuel remaining.
  • Page 42 If the light comes on (or stays on after the vehicle has started), the SRS diagnostic system has detected a fault. Drive to an authorized Volvo retailer for an inspection of the system. See the SRS section for more information.
  • Page 43 If the light comes on (or stays on after the vehicle has started), the engine diagnostic system has detected a possible fault in the emission control system. Although driveability may not be affected, see an authorized Volvo retailer as soon as possible for inspection. Canadian models are equipped with this warning light: NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the is refueled, the Malfunction Indicator Lamp may indicate a fault.
  • Page 44 2001 VOLVO V70 Stability Traction Control (STC) system (option) Dynamic Stability and Traction Control (DSTC) system (option) An LED in the STC or DSTC switch in the center console will light up to indicate that the system is activated. See page 20 for further information.
  • Page 45 STOP SAFELY ASAP: Stop and switch off the engine - to help prevent serious risk of damage. SERVICE URGENT: Take your car to an authorized Volvo retailer for inspection as soon as possible. SERVICE REQUIRED: Take your car to an authorized Volvo retailer for inspection at your convenience (but preferably before the next scheduled maintenance service).
  • Page 46 2001 VOLVO V70 FIX NEXT SERVICE: Have the system affected inspected at the next scheduled maintenance service. SEE MANUAL: Refer to your owner's manual. For additional information, please contact your Volvo retailer. pg. 29 Instruments, switches and controls 1. Not in use 2.
  • Page 47 This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. The ignition key must be in position 1 (or higher) for the auxiliary socket to function. NOTE: The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer.
  • Page 48 2001 VOLVO V70 Average fuel consumption Current fuel consumption Average speed NOTE: Warning messages from the car's monitoring systems will override the trip computer function. If a warning message is displayed in the text window while you are using the trip computer, you must acknowledge the message by pressing button A.
  • Page 49 2001 VOLVO V70 pg. 31 Cruise control Cruise control The cruise control panel is located on the left side of the steering wheel hub. Engaging cruise control/setting speed Press the CRUISE button Press + or - to set the current speed Increase or decrease speed as desired NOTE: Cruise control will not function at speeds below 22 mph (35 km/h).
  • Page 50 II. Front and rear parking lights and license plate lights will also be on. Volvo recommends the use of daytime running lights. If, however, you would prefer to have these lights turned off (USA only), please consult your Volvo retailer. Please note that the use of daytime running lights is mandatory in Canada.
  • Page 51 2001 VOLVO V70 ignition key is in position II. If the headlight switch is in position all lights will go out when the ignition is switched off. The headlight switch must be in this position before the high beams will function.
  • Page 52 2001 VOLVO V70 Rear fog light in the instrument panel This light indicates that the rear fog light is on. pg. 33 Steering wheel adjustment, Ignition switch/steering wheel lock Steering wheel adjustment Both the height and the reach of the steering wheel can be adjusted to a comfortable position for the driver.
  • Page 53 2001 VOLVO V70 A chime will sound if the key is left in the ignition and the driver's door is opened. * The gear selector must be in the (P)ark position. Steering wheel lock The steering wheel lock might be under tension when the car is parked. Turn the steering wheel slightly to free the ignition key.
  • Page 54 2001 VOLVO V70 1 Lane change position. In maneuvers such as lane changing, the driver can flash the turn signals by moving the turn signal lever to the first stop and holding it there. The lever will return to the neutral position when released.
  • Page 55 2001 VOLVO V70 The rain sensor replaces the intermittent wiper function. The windshield wiper interval increases or decreases according to the amount of rain. The sensitivity of the sensor can be adjusted by twisting control A upward or downward. Normal wiper speed High wiper speed 3 Windshield wiper/washer, headlight wiper/washer (certain models).
  • Page 56 If the tailgate wiper is already in normal wiping function, the normal wiping function will continue. * Ask your Volvo-retailer, if you would like to turn off this function. pg. 36 Warning flashers, Heated mirrors/rear window, Heated front seats Hazard warning flashers The four-way flasher should be used to indicate that the vehicle has become a traffic hazard.
  • Page 57 2001 VOLVO V70 Heated sideview mirrors/rear window Press the switch to start heating the rear window and sideview mirrors to remove ice or condensation. An LED in the switch will light up. A timer automatically switches off the heating to the sideview mirrors after approximately 6 minutes and to the rear window after approximately 12 minutes.
  • Page 58 2001 VOLVO V70 Parking brake (hand brake) The lever is situated between the front seats. The brake is applied to the rear wheels. The indicator light in the instrument panel will light up to indicate when the parking brake is applied. Apply the parking brake by pulling up firmly on the lever.
  • Page 59 NOTE: The cover should be kept on when the auxiliary socket is not in use. Ashtrays Volvo cars in North America do not have an ashtray in the front seat as standard equipment. If you want to have an ashtray in the front seat, please contact your Volvo retailer.
  • Page 60 2001 VOLVO V70 Electrically operated windows The electrically operated windows are controlled by buttons in the arm rests. The ignition switch must be ON * (ignition key in position I, II or the engine running) for the electrically operated windows to function.
  • Page 61 2001 VOLVO V70 Cutout switch for rear windows The electrically operated rear door windows can be disabled by a switch located on the driver's door (see illustration). If the LED in the switch is OFF: The rear door windows can be raised or lowered with the buttons on the rear door armrests or with the buttons on the driver's door armrest.
  • Page 62 2001 VOLVO V70 A Normal position B Night position, reduces glare from following headlights Autodim function (option) The autodim function reacts to headlights from following traffic and automatically reduces glare. NOTE: This function is automatically switched off when the gear selector is placed in the Reverse position.
  • Page 63 2001 VOLVO V70 WARNING! The mirrors should always be adjusted prior to driving. Objects seen in the wide-angle sideview mirror are closer than they appear to be. pg. 40 Sun roof (option) Electrically operated sun roof To operate the sun roof, the ignition key must first be turned to the intermediate or drive position (position I or II).
  • Page 64 2001 VOLVO V70 To close the sun roof: Push the switch forward to the first detent ("stop") and hold it until the sun roof has closed completely. AUTO close:Push the switch forward as far as possible and release it to automatically close the sun roof.
  • Page 65 2001 VOLVO V70 WARNING! The sun roof must never be obstructed in any way when in operation. * A position where the sun roof is not quite fully open which helps alleviate rumbling wind noise. Contents Top of Page file:///K|/ownersdocs/2001/2001_V70/01v70_02b.htm (17 of 17)12/30/2006 3:50:54 PM...
  • Page 66 2001 VOLVO V70 2 0 0 1 VOLVO Chapter 3 - Climate control system pg. 41 Climate control system Ventilation 42 Climate control system - general information 43 Electronic Climate Control (ECC) 44 pg. 42 Ventilation Air vents (dash) A Open...
  • Page 67 2001 VOLVO V70 D Vertical air flow Direct the outer air vents toward the side windows to demist. In cold weather, close the air vents in the center of the dash to direct as much air as possible toward the windows.
  • Page 68 2001 VOLVO V70 B Closed C Horizontal air flow D Vertical air flow Direct the air vents toward the rear side windows to demist. Direct the air vents toward the rear seat for the best heating/cooling effect. pg. 43 Climate control system - general information...
  • Page 69 Acceleration The air conditioning is momentarily disengaged during full-throttle acceleration. ECC maintenance All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a.
  • Page 70 2001 VOLVO V70 pg. 45 Electronic Climate Control (ECC) AUTO This function automatically regulates the Electronic Climate Control system so that the selected temperatures are maintained. The blower, heating, air distribution (air flow) and air conditioning are controlled. If you prefer to manually set any of these functions, the remaining functions will still be controlled automatically.
  • Page 71 2001 VOLVO V70 lower than necessary. Set the control to the temperature you prefer. Defroster This function demists/de-ices the windshield and front side windows. The LED in the switch will light up to indicate that the defrost function is engaged. Blower speed increases automatically and the air in the passenger compartment is dehumidified.
  • Page 72 2001 VOLVO V70 Recirculation should not be used for more than 15 minutes. If your windows begin to fog or mist, make sure that the recirculation function is switched off. Selecting Defroster automatically switches recirculation off. Timer function: (Cars with Interior Air Quality system have no timer function) Pressing and holding the switch for at least 3 seconds activates a timer function.
  • Page 73 2001 VOLVO V70 Press the switch to turn the air conditioning on or off. The "ON" or "OFF" LED will light up to indicate if the system is switched on or off. Other functions will still be regulated automatically (if the AUTO switch is on).
  • Page 74 2001 VOLVO V70 Or select one of three functions by pressing 1. Press : the LED AUT comes on. The Air quality sensor is now activated. 2. Press 3. Press : the LED MAN comes on. Recirculation is now activated.
  • Page 75 2001 VOLVO V70 2 0 0 1 VOLVO Chapter 4 - Interior pg. 49 Interior Front seats 50 Interior lighting 52 Storage compartments 53 Storage compartment, front/Vanity mirrors Rear seat and cargo area 57 Spare tire 66 pg. 50 Front seats Electrically operated front seats file:///K|/ownersdocs/2001/2001_V70/01v70_04a.htm (1 of 12)12/30/2006 3:50:56 PM...
  • Page 76 2001 VOLVO V70 From the time the driver's door is unlocked, the driver's seat can be adjusted with the ignition off during a 10 minute period, if the door remains opened. If the door is closed, the seat can be adjusted for 40 seconds.
  • Page 77 2001 VOLVO V70 Three seat positions can be programmed. To program a seat position: 1 Adjust the seat to the desired position. 2 Hold down the MEM button. 3 While holding down the MEM button, press button 1 to program the current position of the seat.
  • Page 78 2001 VOLVO V70 opened. The key does not have to be in the ignition switch during this period. Remote control (central locking system) If you lock the car and later unlock it with the same remote control and open the driver's door, the driver's seat will automatically move to the position it was in when you left the car.
  • Page 79 When switched on with the engine running, the light will stay on indefinitely. The light may be switched off at any time by pressing the center button a second time. The courtesy light timer periods can be changed. Consult your Volvo retailer. Overriding the Interior Courtesy Lights Normally if a car door is left open with the engine turned off, the interior courtesy light will stay on for 10 minutes.
  • Page 80 2001 VOLVO V70 To switch off the interior and tailgate courtesy lights indefinitely, press and hold the center button in the panel above the rearview mirror for 3 seconds. The courtesy lights will go off and remain off until the center button is pressed again.
  • Page 81 2001 VOLVO V70 Ashtray (option) To empty the ashtrays: Front seat, open the ashtray, pull out the insert. Rear seat, as above. Cup holders Some models are equipped with cup holders for the front and rear seat occupants. You can also use the center console's storage compartment for cassette tapes, CD's etc.
  • Page 82 2001 VOLVO V70 Inside the armrest there is a storage compartment which you may use for different personal accessories. The armrest's lid is twofold. To open only the upper lid: press the locking mechanism underneath the upper lid and fold the lid backwards to desired position. To open the upper and lower lid: lift the lid from underneath upwards and fold to desired position.
  • Page 83 2001 VOLVO V70 The glove compartment has storage spaces designed specifically to hold credit cards, pens, and pencils. Vanity mirrors Both sun visors are equipped with lighted vanity mirrors. The light comes on when the cover is opened. pg. 55 Storage compartments, front Pen holder on the center console file:///K|/ownersdocs/2001/2001_V70/01v70_04a.htm (9 of 12)12/30/2006 3:50:57 PM...
  • Page 84 The side panel on the passenger side of your car has an opening for various accessories. You must pry off its cover before you can use it. You can fit a hook for a handbag, waste bin, tray for personal effects etc. Consult your Volvo retailer. Coat hanger Use the coat hanger for clothes of normal weight.
  • Page 85 2001 VOLVO V70 Waste bin / bottle holder in rear seat To change the waste bag: Open the holder. Using both hands, press out the lower part of the holder. Fit the bag around the lower part. Press the lower part back onto the upper part.
  • Page 86 2001 VOLVO V70 Pull the tab and fold the table section forward. Fold the armrest in the backrest forward. Fold out the table so that it rests on the armrest. Press to release the cup holder. You do not have to fold the backrest forward, if you only want to use the cup holder.
  • Page 87 2001 VOLVO V70 pg. 57 Rear seat and cargo area Extension of cargo area The rear seat is in two sections and each section can be folded forward separately. Tip the front seat backrests into a more upright position if they are excessively reclined. Pull the seat cushion tab and fold the cushion forward against the front seat backrests.
  • Page 88 2001 VOLVO V70 Models with 2 or 3-section rear seat Press the backrest catch to the rear and tip the backrest forward. See the illustration in the right-hand column. A - Catch in closed position. B - Catch in open position.
  • Page 89 2001 VOLVO V70 Folding down the center section of the backrest V70 XC with 3-section rear seat To fold down the center section of the backrest (without folding down either of the outboard sections): Lower the head restraint. Press the center section backrest catch to the rear and tip the backrest forward.
  • Page 90 This partition can help prevent objects in the cargo area from being thrown forward when the center section of the backrest is not in the upright position. Please refer to the installation instructions that are included with the partition or consult your Volvo retailer. pg. 59 Rear seat and cargo area Removing the center backrest file:///K|/ownersdocs/2001/2001_V70/01v70_04b.htm (4 of 18)12/30/2006 3:50:58 PM...
  • Page 91 Replace the backrest by pressing the bottom section onto the retaining bar until the backrest clicks into place. Please consult your Volvo retailer for information about accessory equipment that can be placed in the center section of the backrest. WARNING! For safety reasons, the center section of the backrest or seat cushion should not be left in the car after they have been removed.
  • Page 92 2001 VOLVO V70 Center armrest V70 XC with 3-section rear seat The center backrest can be reversed and used as an armrest. Remove the center backrest as described in the left-hand column. Turn the backrest so that the front side faces up (see illustration above).
  • Page 93 2001 VOLVO V70 Removing the seat cushion Models with 2 or 3-section rear seat Pull up the seat by the handle. Unlock the two red locking tabs. Lift out the seat. When replacing, do everything in reverse order. Make sure the red locking tabs are in a locked position.
  • Page 94 2001 VOLVO V70 Rear seat backrest You can adjust the angle of the rear seat backrests. To adjust a backrest to a more upright position: Press the catch until the red mark is visible. Pull the backrest forward to a new locked position.
  • Page 95 2001 VOLVO V70 Open the tailgate. Hang or secure your grocery bags by means of tensioning straps or holders. To remove the plastic tray (option), turn the two knobs at the sides. Auxiliary 12 Volt socket in cargo area This feature is standard equipment on the V70 XC and optional on other models. Fold down the cover when you want to use the electric socket.
  • Page 96 WARNING! The eyelets are not to be used as passenger restraints or as anchorages for child restraints. Unless the car is equipped with an optional Volvo auxiliary seat for children, passengers should not ride in the rear cargo area. Remember that a 44 lbs object produces a force of 2,200 lbs in a head-on collision at 30 mph! Auxiliary seat If an auxiliary seat is installed in the vehicle, store the seat before loading cargo.
  • Page 97 2001 VOLVO V70 Load the cargo against the backrest. Load heavy cargo as low as possible. Load wide cargo on either side of the rear seat split. If no one is sitting in the rear seat, reinforce the backrest by fastening the rear seat belts.
  • Page 98 2001 VOLVO V70 To remove the steel grid, perform the above steps in the reverse order. Green mark - locked position. Red mark - unlocked position. Cargo net (option on V70) Models with 2-section rear seat Your car can be equipped with a cargo net made of strong nylon fabric that can be unrolled from the rear seat backrest.
  • Page 99 Nylon cargo net (option on V70 XC) The Volvo V70 XC can be equipped with a cargo net made of strong nylon fabric that can be installed with the rear seat backrests in the upright position or folded down. The upper and lower rods of the cargo net are hinged.
  • Page 100 2001 VOLVO V70 WARNING! The nylon cargo net must not be used when the optional rear-facing auxiliary child seat in the cargo area is in use. When not in use, the cargo net should not be stored unattached in the car to prevent it from being thrown forward in the event of a sudden stop, etc.
  • Page 101 2001 VOLVO V70 Withdraw the cargo area cover, pull it over the luggage compartment and hook it in the holes in the rear cargo area pillars. Removing the cargo area cover: Press the end pieces of the cargo area cover inward, pull up and remove.
  • Page 102 2001 VOLVO V70 WARNING! If your car is equipped with an auxiliary seat (option or accessory), the tailgate must be fitted with a lock cylinder. Unlocking from the outside can then be carried out in the usual way (key in driver's door and/or remote control) and also by using the key in the tailgate.
  • Page 103 2001 VOLVO V70 WARNING! Make sure that the spare tire, jack and tool kit are properly secured with the securing bracket and strap to help keep these components in place in the event of a sudden stop. Spare tire, tool kit, jack - cars with subwoofer (option) The spare tire, jack and tool kit are located under the floor of the cargo space in a compartment in front of the spare tire.
  • Page 104 2001 VOLVO V70 Extra handgrip The Volvo V70 XC is equipped with an extra handgrip on the front passenger's side. This handgrip can be used for added support when travelling on unpaved roads, etc. pg. 68 Contents Top of Page...
  • Page 105 2001 VOLVO V70 2 0 0 1 VOLVO Chapter 5 - Keys, Locks, Alarm pg. 69 Keys, Locks, Alarm Keys, Exterior courtesy lights, Locking and unlocking the car 70 Remote keyless entry system 71 Unlocking the tailgate, Central locking buttons, "Trunk lock"...
  • Page 106 The car will start only with a properly coded key. If you misplace a key, take the other keys to an authorized Volvo retailer for reprogramming as an antitheft measure. *This key operates only driver's door and ignition switch/steering wheel lock.
  • Page 107 The headlights, parking lights, license plate lights and the lights in the sideview mirrors will now come on and remain on for 30, 60 or 90 seconds (the time interval is at your discretion and can be changed by an authorized Volvo retailer). Approach lighting When approaching the car at night, press the yellow button in the central locking remote control (see illustration on page 70).
  • Page 108 The car can also be locked/unlocked with the key. As an extra security precaution in certain situations (valet parking, etc.), Volvo recommends that the transmitter not be included when the keys are given to anyone. The service key can be used instead. If one of the transmitters is misplaced, contact your nearest authorized Volvo retailer for assistance.
  • Page 109 Avoid touching the contact surfaces of the battery with your fingers. Reinstall the cover and tighten the screw to help protect the transmitter. NOTE: The old battery should be disposed of properly at a recycling center or at your Volvo retailer. WARNING! Volvo does not recommend using the transmitter to lock the doors from inside the car.
  • Page 110 2001 VOLVO V70 Unlocking the tailgate The tailgate lock is incorporated in the central locking system and is locked or unlocked when the driver's door is locked/unlocked. The tailgate can be unlocked by: Pressing UNLOCK on the remote control twice.
  • Page 111 2001 VOLVO V70 exceeds a speed of 3 mph (5 km/h). Please be aware of the following: If the doors are unlocked using the central locking button after the doors have automatically locked and no door has been opened, the doors will not automatically re-lock the next time the car exceeds 3 mph (5 km/h).
  • Page 112 2001 VOLVO V70 unlocking the driver's door with the key. Visual alarm signal The visual alarm signal is given by flashing all turn signals and turning on the interior lighting for approximately 5 minutes. Audible alarm signal An audible alarm signal is given by a battery powered siren. One alarm cycle lasts for 25 seconds.
  • Page 113 LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact a Volvo retailer. Automatic re-lock/re-arm system If the car is unlocked with the remote, the car will re-lock and the alarm will re-arm after 2 minutes unless a door or the tailgate has been opened.
  • Page 114 2001 VOLVO V70 Child safety locks - rear doors The controls are located on the rear door jambs. Use a screwdriver to adjust these controls. A The door cannot be opened from the inside. Normal operation from the outside. B The door lock functions normally.
  • Page 115 2001 VOLVO V70 If you do not want anyone else to be able to open the glove compartment, you should lock it with the master key. Contents Top of Page file:///K|/ownersdocs/2001/2001_V70/01v70_05.htm (11 of 11)12/30/2006 3:50:59 PM...
  • Page 116 2001 VOLVO V70 2 0 0 1 VOLVO Chapter 6 - Starting and driving pg. 77 Starting and driving Fuel requirements 78 Refueling 79 Starting the engine 80 Manual transmission 81 Automatic transmission (AW5) 82 Automatic transmission (Geartronic) Driving economy 86...
  • Page 117 New Vehicle Limited Warranty. Unleaded fuel Each Volvo has a three-way catalytic converter and must use only unleaded gasoline. U.S. and Canadian regulations require that pumps delivering unleaded gasoline be labelled "UNLEADED". Only these pumps have nozzles which fit your car's filler inlet.
  • Page 118 (MMT). If such fuels are used, your Emission Control System performance may be affected, and the Check Engine light (malfunction indicator lamp) located on your instrument panel may light. If this occurs, please return your vehicle to an authorized Volvo retailer for service.
  • Page 119 2001 VOLVO V70 Refueling The fuel tank is designed to hold approximately 21.1 US gal. (80 liters)* with sufficient volume left over to accommodate possible expansion of the fuel in hot weather. Be aware that the "usable" tank capacity will be somewhat less than the specified maximum. When the fuel level is low, such factors as ambient temperature, the fuel's "Reid vapor pressure"...
  • Page 120 * If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. pg. 80 Starting the engine Starting the engine 1.
  • Page 121 2001 VOLVO V70 Your car is equipped with a KEYLOCK system. When the engine is switched off, the gear selector must be in the (P)ark position before the key can be removed from the ignition switch. When starting in cold weather, the transmission may shift up at slightly higher engine speeds than normal until the automatic transmission fluid reaches normal operating temperature.
  • Page 122 2001 VOLVO V70 Shift positions Depress the clutch pedal completely when changing gears*. Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th gear) should be used as often as possible to help improve fuel economy. This gear should be engaged at speeds above approx.
  • Page 123 2001 VOLVO V70 The clutch must be fully depressed before you can start your car. If the clutch is not depressed, it will not be possible to start the engine. WARNING! An extra mat on the driver's floor can cause the accelerator pedal and the clutch to catch. Check that the movement of the accelerator pedal and clutch is not impeded.
  • Page 124 2001 VOLVO V70 WARNING! Never leave the car unattended when the engine is running. If, by mistake, the gear selector is moved from P, the car may start moving. R (Reverse) Never engage R while the car is moving forward.
  • Page 125 2001 VOLVO V70 Gears 4, 3, or L can be used if you are driving in a mountainous area, towing a trailer or to increase engine braking effect. The transmission has a built-in limiter designed to help prevent excessive engine speeds (high rpm) when gears 4, 3 or L are selected.
  • Page 126 2001 VOLVO V70 W Winter/Wet driving mode -enhanced vehicle traction Mode W will only function if the gear selector is in the (D)rive position. Press the button at the base of the gear selector to engage/disengage this driving mode (see illustration).
  • Page 127 2001 VOLVO V70 P (Park) Use this position when starting the engine or parking the car. Never use P while the car is in motion. The parking brake should be set whenever the car is parked. The gear selector is mechanically locked in the P position (SHIFTLOCK). To release the gear selector from this position, the engine must be running (or the ignition key must be in position II) and the brake pedal must be depressed.
  • Page 128 2001 VOLVO V70 The car should not be moving when shifting from R to the D position. Kickdown Automatic shift to a lower gear (kickdown) is achieved by depressing the accelerator pedal fully and briskly. An upshift will occur when approaching the top speed for a particular gear or by releasing the accelerator pedal slightly.
  • Page 129 2001 VOLVO V70 You can move the gear selector freely between the (MAN)ual and (D)rive positions while driving. Gears 2, 3, and 4 have a "lock-up" function which reduces engine speed and helps save fuel. The currently selected gear will be displayed in the instrument panel (see page 25).
  • Page 130 2001 VOLVO V70 pg. 86 Driving economy Economical driving conserves natural resources Better driving economy may be obtained by thinking ahead, avoiding rapid starts and stops and adjusting the speed of your vehicle to immediate traffic conditions. Observe the following rules: Bring the engine to normal operating temperature as soon as possible by driving with a light foot on the accelerator pedal for the first few minutes of operation.
  • Page 131 2001 VOLVO V70 At the specified curb weight your car has a tendency to understeer, which means that the steering wheel has to be turned more than might seem appropriate for the curvature of a bend. This ensures good stability and reduces the risk of rear wheel skid. Remember that these properties can alter with the vehicle load.
  • Page 132 2001 VOLVO V70 CAUTION: Drive slowly and carefully if going through standing water (i.e. flooded roadways, etc.). Damage to the engine could result if excess water is drawn in through the air intake system. Never drive the vehicle in water deeper than 1 foot (300 mm). See the flood warning on...
  • Page 133 2001 VOLVO V70 Load carriers (accessory) Load carriers are available as Volvo accessories. Observe the following points when in use: To avoid damaging your car and to achieve maximum safety when driving, we recommend using the load carriers that Volvo has developed especially for your car.
  • Page 134 2001 VOLVO V70 5 Turn the tightening wheel to secure the load carrier in the attachment bracket. 6 Repeat this procedure for the other load carrier attachments. 7 Check that the hooks on all four load carrier attachments are securely tightened in the respective attachment brackets on the roof of the car.
  • Page 135 2001 VOLVO V70 Fitting the load carriers (accessory) Make sure that the load carrier is pressed firmly out against the roof rail. Screw the load carrier in place. Use the supplied torque wrench and tighten to the mark on the wrench (corresponding to 6 Nm). See illustration.
  • Page 136 2001 VOLVO V70 pg. 90 Emergency towing Emergency towing The towing eyelet is located in the tool kit, under the floor of the cargo area, with the spare tire. This eyelet must be screwed into the positions provided on the right sides of either the front or rear bumper (see illustration).
  • Page 137 2001 VOLVO V70 Precautions when the car is in tow The steering wheel must be unlocked. Turn the ignition key to position I or II. The gear selector must be in position N. Maximum speed: 50 mph (80 km/h) Maximum distance with front wheels on ground: 50 miles (80 km).
  • Page 138 Towing cars with front wheel drive Volvo recommends the use of flat bed equipment. If wheel lift equipment must be used, please use extreme caution to help avoid damage to the car. In this case, the car should be towed with the rear wheels on the ground if at all possible.
  • Page 139 92 Towing a trailer When preparing for trailer towing, observe the following: Volvo recommends the use of Volvo trailer hitches which are specially designed for the car. Maximum trailer weight recommended by Volvo is: Trailers without brakes: 1100 lbs (500 kg) Trailers with brakes: 3300 lbs (1,500 kg), Observe the legal requirements of the state/province in which the vehicles are registered.
  • Page 140 2001 VOLVO V70 Volvo recommends the use of synthetic engine oil when towing a trailer over long distances or in mountainous areas. WARNING! Bumper-attached trailer hitches must not be used on Volvo's, nor should safety chains be attached to the bumper.
  • Page 141 2001 VOLVO V70 pg. 94 Detachable trailer hitch - removing file:///K|/ownersdocs/2001/2001_V70/01v70_06b.htm (6 of 11)12/30/2006 3:51:03 PM...
  • Page 142 2001 VOLVO V70 pg. 95 Jump starting Jump starting Follow these instructions to jump start your car's dead battery or to jump start another car's dead battery using your car. Although your car's battery is located under the floor of the cargo area, jumper cables should be connected in the engine compartment, to the points shown in the illustrations.
  • Page 143 2001 VOLVO V70 auxiliary battery to be used is in another car, check that the cars are not touching to prevent premature completion of a negative circuit. Be sure to follow jump starting instructions provided for the other vehicle. To jump start your car: Switch off the ignition.
  • Page 144 It is therefore advisable to check the state of charge more frequently and spray an anti-rust oil on the battery posts. Volvo recommends the use of snow tires on all four wheels for winter driving - see section "Wheels and tires".
  • Page 145 Check all lights, including high beams. Reflective warning triangles are legal requirement in some countries. Have a word with your Volvo retailer if you intend to drive in countries where it may be difficult to obtain the correct fuel. Consider your destination. If you will be driving through an area where snow or ice are likely to occur, consider snow tires.
  • Page 146 2001 VOLVO V70 Three-way catalytic converter cautions Keep your engine properly tuned. Certain engine malfunctions, particularly involving the electrical, fuel or distributor ignition systems, may cause unusually high three-way catalytic converter temperatures. Do not continue to operate your vehicle if you detect engine misfire, noticeable loss of power or other unusual operating conditions, such as engine overheating or backfiring.
  • Page 147 2001 VOLVO V70 2 0 0 1 VOLVO Chapter 7 - Wheels and tires pg. 99 Wheels and tires General information, Wear indicator, Tire economy, Flat spots Wheels and tires - All Wheel Drive vehicles 101 Snow chains, Snow tires/studded tires 102...
  • Page 148 Unbalanced wheels impair tire economy and driving comfort. Volvo does not recommend rotating the tires. However, if tires are rotated, they must be kept on the same side of the car so that they revolve in the same direction as before rotation.
  • Page 149 Tire Replacement When tire replacement is necessary, Volvo strongly recommends replacing all four tires at the same time with identical tires as explained above. Failure to do so can result in a circumference difference that may damage the transmission and all-wheel-drive system.
  • Page 150 2001 VOLVO V70 2 0 0 1 VOLVO Chapter 8 - Maintenance/Servicing pg. 107 Maintenance/Servicing Fuses 108 Replacing bulbs 112 Paint touch up 118 Washing the car 119 Cleaning the upholstery 120 Maintenance service, Warranty 121 Maintenance schedule 122 Fuel/emissions systems 124...
  • Page 151 If so, put in a new fuse of the same color and amperage (written on the fuse). Spare fuses are stored in the fuse box in the passenger compartment. If fuses burn out repeatedly, have the electrical system inspected by an authorized Volvo retailer. pg. 109 Fuses in the engine compartment...
  • Page 152 2001 VOLVO V70 (written on the fuse). Fuse amperage is also indicated on the inside of the fuse box cover. Ordinary fuses Location Amperage 1 Accessories 2 Auxiliary lamps (option) 4 Oxygen sensors 5 Crankcase ventilation heater, Solenoid valves 6 Mass airflow sensor, Engine control module,...
  • Page 153 2001 VOLVO V70 20 - 21 - 22 Starter motor 23 Engine control module 24 - pg. 110 Fuses in the passenger compartment Fuse box in the passenger compartment This fuse box is located at the far left side of the instrument panel. Extra fuses and the fuse removal tool are also stored here.
  • Page 154 2001 VOLVO V70 12 Headlight wipers 13 Electric socket 12 V 14 Power passenger's seat 15 Audio system 16 Audio system 17 Radio amplifier 18 Front fog lights 19 VNS display (option) 20 Transport switch 21 Transmission module 22 Direction indicators...
  • Page 155 2001 VOLVO V70 The fuses in the cargo area are located on the trim on the left-hand side. When replacing a blown fuse, be sure to replace it with a new one of the same color and amperage (written on the fuse).
  • Page 156 2001 VOLVO V70 pg. 112 Replacing bulbs Replacing high/low beam headlight bulbs The headlight bulbs must be replaced from the engine compartment. CAUTION: Do not touch the glass on halogen bulbs with your fingers. Grease, oil or any other impurities can be carbonized onto the bulb and cause damage to the reflector.
  • Page 157 NOTE: If the vertical aim of your headlights needs to be adjusted for any reason (e.g., towing a trailer for extended periods), this should be done by an authorized Volvo retailer. pg. 113 Replacing bulbs file:///K|/ownersdocs/2001/2001_V70/01v70_08a.htm (8 of 23)12/30/2006 3:51:06 PM...
  • Page 158 2001 VOLVO V70 To remove and install a high beam bulb (HB3): Switch off all lights and turn the ignition switch to position 0. Open the hood. Remove the cover by twisting it counter-clockwise. Twist the bulb holder counterclockwise, pull it out and fit a new bulb. Note its position.
  • Page 159 2001 VOLVO V70 Changing the bulb in the turn signals at the front corners Switch off all lights and turn ignition key to position 0. Pull out the bulb and its socket by twisting counterclockwise. Replace bulb. Press the bulb and its socket back into place.
  • Page 160 2001 VOLVO V70 Replacement of rear turn signal and brake light bulbs Switch off all lights and turn the ignition switch to position 0. Using a screwdriver, carefully pry off the speaker grille. Pull out the red tab in the speaker.
  • Page 161 2001 VOLVO V70 Front fog lights (option) CAUTION: Avoid touching the glass on the bulb with your fingers. Switch off all lights and turn the ignition key to position 0. Turn the bulb holder slightly counter-clockwise to release it. Replace the bulb. The shape of the base of the bulb corresponds to the shape of the bulb holder.
  • Page 162 2001 VOLVO V70 Remove the defective bulb by pulling it straight out. Insert a new bulb. Reinsert the bulb holder in the lens and press the entire unit back into place on the fender. pg. 116 Replacing bulbs License plate lights Switch off the ignition.
  • Page 163 2001 VOLVO V70 The door step courtesy lights are located under the dash on the driver's and passenger's sides. To replace a bulb: Carefully insert a screwdriver and pry out the lens. Replace the defective bulb. Reinstall the lens. Vanity mirror lights Carefully insert a screwdriver and pry out the lens.
  • Page 164 These bulbs may be difficult for you to replace yourself. We recommend that you let an authorized Volvo retailer replace these bulbs if necessary. NOTE: Other bulbs may be difficult for you to replace yourself. Let an authorized Volvo retailer replace these bulbs if necessary.
  • Page 165 2001 VOLVO V70 Minor stone chips and scratches Material: Primer - can Paint - touch-up bottle Brush Masking tape NOTE: When touching up the car, it should be clean and dry. The surface temperature should be above 60° F (15° C).
  • Page 166 2001 VOLVO V70 several thin paint coats and let dry after each application. 3. If there is a longer scratch, you may want to protect surrounding paint by masking it off. pg. 119 Washing the car Washing the car The car should be washed at regular intervals since dirt, dust, insects and tar spots adhere to the paint and may cause damage.
  • Page 167 2001 VOLVO V70 WARNING! When the car is driven immediately after being washed, apply the brakes several times in order to remove any moisture from the brake linings. Engine cleaning agents should not be used when the engine is warm. This constitutes a fire risk.
  • Page 168 The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician. To keep your Volvo in top condition, specify time-tested and proven Genuine Volvo Parts and Accessories.
  • Page 169 2001 VOLVO V70 Maintenance services Your Volvo has passed several major inspections before being delivered to you, according to Volvo specifications. The maintenance services outlined in this book should be performed as indicated. The extended maintenance service intervals make it even more advisable to follow this program. Inspection and service should also be performed any time a malfunction is observed or suspected.
  • Page 170 2001 VOLVO V70 Maintenance thousand 7.5 15 22.5 30 37.5 45 52.5 60 67.5 82.5 90 miles Operation (thousand (12) (24) (36) (48) (60) (72) (84) (96) (108) (120) (132) (144) EMISSION SYSTEM MAINTENANCE Engine oil and filter Engine drive belt (accessory belt)
  • Page 171 2001 VOLVO V70 Maintenance thousand 7.5 15 22.5 30 37.5 45 52.5 60 67.5 82.5 miles Operation (thousand (12) (24) (36) (48) (60) (72) (84) (96) (108) (120) (132) (144) EMISSION SYSTEM MAINTENANCE Engine Fuel line filter PCV nipple (orifice)/hoses, clean...
  • Page 172 2001 VOLVO V70 Washing (check all drain holes), polishing, cleaning Contents Top of Page file:///K|/ownersdocs/2001/2001_V70/01v70_08a.htm (23 of 23)12/30/2006 3:51:06 PM...
  • Page 173 2001 VOLVO V70 pg. 124 Fuel/emissions systems Fuel system The fuel system continually compensates for variation in engine load, speed and temperature. A mass air flow sensor continuously measures the inducted air and makes rapid adjustments for changes in air temperature and density, to balance fuel economy, emissions, and engine power requirements.
  • Page 174 2001 VOLVO V70 NOTE: Overfilling the fuel tank can cause damage to the evaporative control system. If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Malfunction Indicator Lamp may indicate a fault.
  • Page 175 2001 VOLVO V70 Changing coolant Normally, the coolant does not need to be changed. If the system must be drained, consult your Volvo retailer. NOTE: Do not top off with water only. This reduces the rust-protective and antifreeze qualities of the coolant and has a lower boiling point.
  • Page 176 60,000 miles (96,000 km) and thereafter, at 30,000 mile (48,000 km) intervals. Cabin air filter Replace the cabin air filter with a new one at 15,000 mile (24,000 km) intervals. Volvo recommends replacing the filter more often if the car is driven under dirty and dusty conditions. The filter cannot be cleaned and therefore should always be replaced with a new one.
  • Page 177 2001 VOLVO V70 liters). During cold weather, the reservoir should be filled with windshield washer solvent containing antifreeze. Hoisting the car If a garage jack is used to lift the car, the two jack attachments points should be used. They are specially reinforced to bear the weight of the car.
  • Page 178 2001 VOLVO V70 Opening the hood Pull the lever located under the left side of the dash to release the hood lock. Lift the hood slightly. Press up the release control located under the front edge of the hood (at the center) and lift.
  • Page 179 Conserving. Your Volvo V70 has been certified to standards using ILSAC oil specification GF-2 5W/30. Volvo recommends use of oil with a quality rating equal to or higher than ILSAC GF-2. Equivalent and better oils include ACEA A1, API SJ, SJ/CF, and SJ/Energy conserving. Lower quality oils may not offer the same fuel economy, engine performance, or engine protection.
  • Page 180 Oil and oil filter changes should be made at 7,500 mile (12,000 km) intervals. Extra oil additives must not be used unless advised by an authorized Volvo retailer. Synthetic oil is not used when the oil is changed at the normal maintenance service intervals.
  • Page 181 2001 VOLVO V70 Park the car on a level surface and wait for at least 5 minutes after the engine has been switched off. Be sure the oil level is maintained between the upper and lower marks on the dipstick. Low oil level can damage the engine.
  • Page 182 Replace: Every second year or 30,000 miles (48,000 km). The fluid should be replaced once a year or every 15,000 miles (24,000 km) when driving under extremely hard conditions (mountain driving, etc.) Always entrust brake fluid changing to an authorized Volvo retailer. pg. 132 Battery maintenance...
  • Page 183 2001 VOLVO V70 Battery maintenance The battery in your car is located under the floor of the cargo area. Driving habits and conditions, climate, the number of starts, etc. all affect the service life and function of the battery. In order for your battery to perform satisfactorily, keep the following in mind: Check the fluid level in each cell in the battery every 6 months or every 7,500 * miles (12,000 km).
  • Page 184 2001 VOLVO V70 pg. 133 Battery maintenance Replacing the battery file:///K|/ownersdocs/2001/2001_V70/01v70_08b.htm (12 of 15)12/30/2006 3:51:08 PM...
  • Page 185 (see illustration). Be sure the ventilation hose is free of debris. Only use replacement batteries equipped with a ventilation hose. Consult your Volvo retailer. pg. 134 Replacing wiper blades...
  • Page 186 2001 VOLVO V70 Windshield wiper blades Lift the wiper arm off the windshield and hold the blade at a 45° angle to the arm. Press the end of the plastic clip located on the arm. Slide the wiper blade along the arm to release it from the hook. The entire hooked part of the wiper arm must pass through the opening in the wiper blade.
  • Page 187 2001 VOLVO V70 Replacement of tailgate wiper blade Pull the wiper arm out away from the glass. Pull off the wiper blade outwards toward the tailgate. Press the new wiper blade into place. Check that it is properly secured. Headlight wiper blades (certain models) Pull the wiper blade in the direction indicated by the arrow in the illustration to remove it.
  • Page 188 136 Label information B<>1 Vehicle Emission Control Information Your Volvo is designed to meet all applicable emission standards, as evi-denced by the certification label on the underside of the hood. For further informa-tion regarding these regulations, please consult your Volvo retailer.
  • Page 189 6 Federal Motor Vehicle Safety Stan-dards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further informa-tion regarding these regulations, please consult your Volvo retailer.
  • Page 190 2001 VOLVO V70 pg. 137 Dimensions and weights Dimensions Length 185.4 in. (471 cm), V70 XC -186.2 (473 cm) Width 70.9 in. (180 cm), V70 XC - 73.2 in. (186 cm) Height 57.5 in. (146 cm), V70 AWD - 58.7 in. (149 cm), V70 XC - 61.4 in. 156 cm) Wheelbase 108.7 in.
  • Page 191 ** The max permissible axle loads or the gross vehicle weight must not be exceeded. pg. 138 Engine/transmission specifications Engine specifications Designation: Volvo B 5234 T3 Output 247 hp at 5200 rpm (184 kW/87 rps) Max. torque 243 ft. lbs. at 2400-5200 rpm (330 Nm/42-87 rps) Number of cylinders 5 Bore 3.19"...
  • Page 192 3rd gear 1.19:1 4th gear 0.87:1 5th gear 0.70:1 Reverse 3.30:1 Designation: Volvo B 5244 T3 Output 197 hp at 6000 rpm (147 kW/100 rps) Max. torque 210 ft. lbs. at 1800-5000 rpm (285 Nm/30-83 rps) Number of cylinders 5 Bore 3.27"...
  • Page 193 Engine Oil Meeting or exceeding ILSAC specification GF-2, including ACEA A1, API SJ, SJ/CF, and SJ/Energy Conserving. Oil additives must not be used unless advised by an authorized Volvo retailer. Volume: Capacity (including oil filter): 6.1 US qts. (5.8 liters) Capacity (including oil filter and oil cooler): 7.1 US qts.
  • Page 194 2001 VOLVO V70 ATF fluid Volume: Brake fluid DOT 4+ Volume: 0.64 US qts (0.6 liters) Climate control system - refrigerant (R 134a) Oil: PAG Volume: 2.2 lbs (1,000 g) R134a Fuel Minimum octane requirement - AKI 87 (RON 91) Volume (fuel tank): 21.1 US gals (80 liters)*...
  • Page 195 2001 VOLVO V70 The spark plugs should be changed every 30,000 miles (48,000 km). However, city driving or fast highway driving may necessitate changing after 15,000 miles (24,000 km) of driving. When installing new plugs, be sure to fit the right type and use correct torque. When changing the plugs, check that the suppressor connectors are in good condition.
  • Page 196 2001 VOLVO V70 on the tire side: 1.8±1.8 2.0±2.0 ±1.9 V70 AWD** Toe-in, front (mm) on the wheel rims: 0.8±0.8 ±0.7 ±0.8 on the tire side: 0.9±0.9 1.0±1.0 ±0.9 Toe-in, rear (mm) on the wheel rims: 0.8±1.5 0.8±1.6 ±1.4 on the tire side: 2.0±2.0...
  • Page 197 Voltage: 12 Volt, capacity: 600 A/115 min reserve capacity. The battery contains corrosive and poisonous acids. It is of the utmost importance that old batteries are disposed of correctly. Your Volvo retailer can assist you in this matter. Generator Rated output: max. current: 120 A Starter motor: Output: 1.7 kW...
  • Page 198 2001 VOLVO V70 pg. 142 Volvo On Call Your new Volvo comes with a four year ON CALL road assistance. Additional information, features, and benefits are described in a separate information package in your glove compartment. If you have misplaced your package, dial: In the U.S.A.
  • Page 199 2001 VOLVO V70 2 0 0 1 VOLVO Chapter 10 - Audio systems pg. 143 Audio systems HU-413 overview 144 HU-613 overview 145 HU-803 overview 146 Functions 147 Specifications 159 General information pg. 144 Audio system HU-413 - overview file:///K|/ownersdocs/2001/2001_V70/01v70_10a.htm (1 of 11)12/30/2006 3:51:10 PM...
  • Page 200 2001 VOLVO V70 1. Display 2. Radio - Manual station selection Cassette - Fast winding forward/backward CD - Fast forward/backward. 3. Radio - Station seek up/down Cassette - selecting next/previous track CD - Selecting next/previous track 4. Fader - press and turn Balance - press, pull and turn 5.
  • Page 201 2001 VOLVO V70 1. On/off - press Volume - turn 2. Selector knob for: Stored radio frequencies CD changer - selecting disc 3. Selector knob: Radio Cassette CD changer TV (option on certain models) 4. Fader - press and turn Balance - press, pull and turn 5.
  • Page 202 2001 VOLVO V70 16. Cassette opening 17. Cassette eject 18. Display pg. 146 Audio system HU-803 - overview 1. On/off - press Volume - turn 2. Bass - press and turn Treble - press, pull and turn 3. Fader - press and turn Balance - press, pull and turn 4.
  • Page 203 2001 VOLVO V70 10. Dolby Pro Logic - switching on 11. 2 channel stereo 12 3 channel stereo 13. CD slot 14. CD random play 15. Program type 16. News 17. Traffic information 18. Automatic presetting of radio stations 19. Display pg.
  • Page 204 2001 VOLVO V70 Bass Adjust the bass by pressing the button to ex-tend the control and turning it to the left (less bass) or to the right (more bass). A "detent" indicates "equalized" bass. Press the button back in when you have made the adjustment.
  • Page 205 2001 VOLVO V70 Fader - Balance front/rear Adjust front/rear speaker balance by pressing the button to extend the control and turning it to the left (more sound from the rear speakers) or to the right (more sound from the front speakers). A "detent"...
  • Page 206 2001 VOLVO V70 Station seek up/down If you have a key pad in the steering wheel press the right or left arrow to switch between preset stations. Scan function Press the SCAN button (HU-613) or the SOURCE button (HU-803) to start the station scan function.
  • Page 207 The RDS or Radio Data System operates in the FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information. Please refer to the following pages regarding specific descriptions and operation of these functions.
  • Page 208 2001 VOLVO V70 will find the radio in your car is equipped to take advantage of this system. pg. 150 Audio systems HU-803 - radio Traffic information (TP) -HU- 803 only This feature may not be apply in your area and only functions with FM broadcasts. (See previous page) Push the "TP"...
  • Page 209 2001 VOLVO V70 News on/off - HU-803 only This feature may not apply in your area and only functions with FM broadcasts. (See previous page) Press the "NEWS" button to activate the news function. The text NEWS is displayed. Press the "NEWS"...
  • Page 210 2001 VOLVO V70 pg. 151 Audio systems HU-803 - radio Program types (HU-803 only) Program type Text displayed News News Information Inform Sports Sports Talk Talk Rock Rock Classic rock Cls_Rock Adult hits Adlt_Hit Soft rock Soft_Rck Top 40 Top_40...
  • Page 211 2001 VOLVO V70 pg. 152 AUM (Advanced User Mode) - certain models AUM (Advanced User Mode) With the radio switched off, press and hold the volume wheel down for at least 5 seconds to start the AUM function. Turn the 1-20/DISC knob to choose an AUM function (see function list on the right).
  • Page 212 2001 VOLVO V70 available transmitter for a program is selected. REGIONAL ON/OFF (regional radio program) - This function makes it possible to continue to listen to a regional transmitter, even if the signal is weak. EON (Enhanced Other Networks) LOCAL/DISTANT - This function determines whether the radio program you are listening to is to be switched off before e.g.
  • Page 213 2001 VOLVO V70 (certain models) This function can also be used in the CD mode. Steps 1-4 are the same as described to the left. 5. If there is more than one station with the selected program type, you can select using or the scan button.
  • Page 214 2001 VOLVO V70 CD player - on HU-613: Insert a CD. HU-803: Insert a CD. If you would like to insert another disc (a maximum of 4 CD's can be inserted in the player), turn the "1-20/DISC" button so that "CD 2 Load Disc" is displayed. Insert the CD. Repeat this procedure for discs 3 and 4.
  • Page 215 2001 VOLVO V70 NOTE: For traffic safety reasons, the ejected CD must be removed within 12 seconds or it will be automatically reinserted into the CD player. Fast winding Press " " or " " to seek within a track.
  • Page 216 2001 VOLVO V70 CD changer The optional CD changer, mounted in the cargo area, can accommodate 10 discs. To load the magazine: Slide the cover on the CD changer open. Press the eject button. Pull the magazine out of the changer and insert the discs.
  • Page 217 2001 VOLVO V70 Press " " to skip to the next track or " " to skip to the previous track. Disc and track number are displayed. If you have the key pad in the steering wheel you can also use these arrows in the same way.
  • Page 218 2001 VOLVO V70 Tape eject If you press this button the tape stops and the cassette is ejected. To select a new mode (radio, CD) turn the "SOURCE" button. A cassette can be ejected even if the ignition is switched off.
  • Page 219 2001 VOLVO V70 dashboard, offers you very clear and realistic sound. The Dolby unit divides the normal stereo channels from left - right to left - center - right. In addition, ambient surround sound is produced by the rear speakers. This ambient surround sound mirrors the resonance of a recording studio.
  • Page 220 2001 VOLVO V70 Center speaker volume Set the center speaker volume by pressing the button to extend the control and turning it to the left (quieter) or to the right (louder). A "detent" indicates "normal" volume. Press the button back after setting.
  • Page 221 Keep tapes away from oil, grease and other contaminants. For optimal tape deck performance Volvo does not recommend the use of C-120 tapes. Take up slack using a pen or a pencil before inserting a cassette in the cassette slot.
  • Page 222 2001 VOLVO V70 Cassette cleaning We recommend the use of the Volvo Cleaning Cassette available as a genuine Volvo accessory. Regular use improves sound quality, cleans vital parts and prevents tape tangle. Compact disc care Before using a new disc for the first time, remove any burrs in the center/outer edge by running the stem of a pen or similar object around the hole/edge of the disc.
  • Page 223 2001 VOLVO V70 Contents Top of Page file:///K|/ownersdocs/2001/2001_V70/01v70_10b.htm (14 of 14)12/30/2006 3:51:12 PM...
  • Page 224 2001 VOLVO V70 2 0 0 1 VOLVO HomeLink® Universal Transceiver (option) pg. 161 HomeLink® Universal Transceiver (option) HomeLink® Universal Transceiver HomeLink® is an advanced system that can be programmed to learn the codes of three different remote controlled-devices (e.g., garage door openers, remote lighting, entry door lock). HomeLink®'s sun visor- mounted transceiver, powered by your car's electrical system, may then be used in place of your hand- held remote controls.
  • Page 225 2001 VOLVO V70 the illustration) on the HomeLink® Universal Transceiver for about 20 seconds, until HomeLink®'s indicator light begins to flash. Then release the buttons. 3. Hold your hand-held transmitter (garage door opener, for example) 2 to 5 in. (5 to 12 cm) away from the HomeLink®...
  • Page 226 2001 VOLVO V70 Determine, in one of the following ways, if your garage door uses a rolling code system and is manufactured after 1996: Refer to the garage door opener owner's manual for verification. If your hand-held transmitter appears to program the HomeLink® Universal Transceiver but the programmed button does not activate the garage door, your garage door opener may have a rolling code.
  • Page 227 2001 VOLVO V70 Individual buttons cannot be erased. To erase all three programmed buttons: 1. Turn the ignition key to the "accessory" position (II). 2. Hold down the two outside buttons on the HomeLink® Universal Transceiver for about 20 seconds, until HomeLink®'s indicator light begins to flash.
  • Page 228 2001 VOLVO V70 Contents Top of Page file:///K|/ownersdocs/2001/2001_V70/01v70_11.htm (5 of 5)12/30/2006 3:51:12 PM...
  • Page 229 2001 VOLVO V70 2 0 0 1 VOLVO INDEX pg. 178 - 181 Index ABS - warning light Accessory lights Adjusting the steering wheel Advanced User Mode (AUM) - radio 44 - 47 Air conditioning Air pump system Air vents...
  • Page 230 2001 VOLVO V70 Audio systems cassette deck CD player HU-413 - overview HU-613 - overview HU-803 - overview specifications AUM (Advanced User Mode) - radio Automatic car washing Automatic locking Automatic Locking Retractor (ALR) Automatic transmission 84, 85 Geartronic 83, 84...
  • Page 231 2001 VOLVO V70 Cargo compartment lighting Cargo eyelets Cargo net Catalytic converters - three-way Center armrest - 3-section rear seat Center backrest (3-section rear seat) Center console - switches Center head restraint - 3-section rear seat Center head restraint - rear seat...
  • Page 232 2001 VOLVO V70 Detachable trailer hitch - installing Detachable trailer hitch - removing Dimensions Direction indicators Distributor ignition system Door step courtesy lights - replacing Doors and locks Drive belt Driving economy Driving mode indicator 83, 85, 96 Driving mode W...
  • Page 233 2001 VOLVO V70 Extension of cargo compartment Exterior courtesy lights Exterior features - overview Extra seat Fog light - rear Fog lights - front Folding passenger's seat backrest Folding sideview mirrors Foldtable Four wheel drive - towing 4 - 7...
  • Page 234 2001 VOLVO V70 84, 85 Geartronic (automatic transmission) Generator Generator warning light Glove compartment - locking Hand brake Handgrip - V 70 XC Handling Hazard warning flashers Head restraint (center) - 3-section rear seat Head restraint - center rear Headlight bulbs - replacing...
  • Page 235 2001 VOLVO V70 Interior Air Quality system Interior features - overview Interior lighting Isofix fasteners Jack Jump starting Key - removing from ignition switch 71, 72 Keyless entry system Keyless entry system - replacing batteries Keylock Keys 83, 84 Kickdown...
  • Page 236 2001 VOLVO V70 Mirrors, sideview - memory function Net - cargo Nylon cargo net Occupant safety Octane rating Odometer , 96, 129, 130 Oil - engine Oil pressure warning light Opening the hood Paint touch-up Panic function (alarm) Parking brake...
  • Page 237 2001 VOLVO V70 Refrigerant Refueling Remote control - keyless entry system Remote keyless entry system Remote keyless entry system - replacing batteries Removing the seat cushion 112 - 117 Replacing bulbs Replacing fuses Replacing wiper blades Reporting safety defects Road assistance...
  • Page 238 2001 VOLVO V70 Snow tires Spare tire Spark plugs Specifications SRS diagnostic system Stability Traction Control (STC) Stain removal Start inhibitor (immobilizer) Starting the engine Steel grid Steering wheel adjustment Steering wheel lock Stop and Store bag Storage compartments Storage in the glove compartment...
  • Page 239 2001 VOLVO V70 Tire pressure 100 -104 Tires 105, 106 Tires - changing Tool bag Towing a trailer Towing eyelet 90, 91 Towing the car Trailer towing Trailer weight - maximum 82 - 85 Transmission - automatic Transmission - specifications...
  • Page 240 2001 VOLVO V70 119, 120 Washing the car Waste bin Waxing Weight distribution Weights 105, 106 Wheels - changing 100 -106 Wheels and tires Whiplash Protection System (WHIPS) Windows - electrically operated Windshield washer solvent Windshield wiper blades - replacing...
  • Page 241 Your car is equipped with an accessory connector located under the dashboard on the driver's side. Please consult your Volvo retailer if you have any questions before connecting accessory or optional equipment to the vehicle's electrical system.
  • Page 242 2001 VOLVO V70 The following should be checked regularly: * 1 Washer fluid reservoir should be filled with water and solvent (wintertime: windshield washer anti- freeze). See page 127. 2 Power steering - When cold, the level must not be above the COLD mark and when hot it must not be above the HOT mark.
  • Page 243 2001 VOLVO V70 Octane rating, see page 78. Tire pressure, see label located on the rear edge of the right front door. Bulb Power Socket US no. 60 W HB 3 55 W 21 W 21 W BA 15s 1156 55 W 5 W W 2.1x9.5d 1157NA...
