2001 Volvo S60
Introduction
Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe
driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure
your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment
descriptions, operating instructions and maintenance require- ments/ recommendations in this manual.
We also urge you and your passengers to wear seat belts at all times in this (or any other) automobile.
And, of course, please do not operate a vehicle if you may be affected by alcohol, medication or any
impairment that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the
certification labels attached to the driver's door opening and on the left wheel housing in the engine
compartment.
For further information please contact your retailer, or:
In the USA:
Volvo Cars of North America
Customer Relations
P.O. Box 914
Rockleigh, New Jersey 07647-0914
800-458-1552
In Canada:
Volvo Canada Ltd.
175 Gordon Baker Road
file:///K|/ownersdocs/2001/2001_S60/01s60_00.htm (1 of 7)12/30/2006 3:46:52 PM
2 0 0 1
VOLVO
S60

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S60 2001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo S60 2001

Summary of Contents for Volvo S60 2001

  • Page 1 VOLVO Introduction Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance require- ments/ recommendations in this manual.

  • Page 2: General Information

    Optional equipment described in this manual may not be available in all markets. Volvo reserves the right to make model changes at any time, or to change specifications or design file:///K|/ownersdocs/2001/2001_S60/01s60_00.htm (2 of 7)12/30/2006 3:46:52 PM...

  • Page 3: Volvo And The Environment

    Volvo and the environment Volvo is committed to the well being of its customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.

  • Page 4: Instruments, Switches And Controls

    2001 Volvo S60 On the surface of the radiator in the engine compartment, there is a special coating called Prem- Air. Prem- Air works as a catalytic converter, converting most of the ground level ozone passing through the radiator into oxygen, thereby reducing harmful ground-level ozone.
  • Page 5 2001 Volvo S60 37, 38 11. Center console switches 12. Climate control 13. Audio system 14. 12 V socket 15. Hazard warning flashers 16. Glove compartment 17. Panel vents 18. Text window 19. Temperature gauge 20. Odometer/ Trip odometer/Cruise control indicator 21.
  • Page 6 2001 Volvo S60 Contents Contents Safety Instruments and controls Climate control Audiio Interior Locks and alarm Starting and driving Wheels and tires Car care Maintenance and service Specifications Index file:///K|/ownersdocs/2001/2001_S60/01s60_00.htm (6 of 7)12/30/2006 3:46:52 PM...
  • Page 7 2001 Volvo S60 Contents Top of Page file:///K|/ownersdocs/2001/2001_S60/01s60_00.htm (7 of 7)12/30/2006 3:46:52 PM...
  • Page 8 Seat belts Not wearing a seat belt is like believing "It'll never happen to me!" Volvo, the inventor of the three- point seat belt, urges you and all occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
  • Page 9 2001 Volvo S60 To buckle a seat belt: Pull the belt out far enough to insert the latch plate into the receptacle until a distinct click is heard. The seat belt retractor is normally "unlocked" and you can move freely, provided that the shoulder belt is not pulled out too far.
  • Page 10 Never repair the belt on your own; have this work done by an authorized Volvo retailer only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.

  • Page 11: Airbags (Supplemental Restraint System)

    12 Airbags (Supplemental Restraint System) Driver's side airbag As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS) to complement the three-point seat belt system. The inflatable airbag is installed folded up in the center of the steering wheel. The wheel is embossed with SRS.
  • Page 12 When installing any optional equipment, make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible.
  • Page 13 NOTE: Volvo's dual- threshold, dual- stage airbags use special sensors that are integrated with the front seat buckles. The point at which the airbag deploys is determined by whether or not the seat belt is being used, as well as the severity of the collision.
  • Page 14 14 Airbags (Supplemental Restraint System) WARNING! Children must never be allowed in the front passenger's seat. Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the back seat of any vehicle with a front passenger-side airbag.
  • Page 15 If the SRS warning light stays on after the engine has started or if it comes on while you are driving, drive the car to the nearest authorized Volvo retailer for inspection as soon as possible. pg. 15 Airbags (Supplemental Restraint System)
  • Page 16 Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car.
  • Page 17 (see below). This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs.
  • Page 18 2001 Volvo S60 Front airbag (SRS) system As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supple- mental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars.

  • Page 19: Side Airbags (Sips Airbags)

    2001 Volvo S60 WARNING! injury. Deployment occurs very quickly and with considerable force. During normal deployment and depending on variables such as seating position, one may experience abrasions, bruises, swellings, or other injuries as a result of airbag( s) deployment.
  • Page 20 Never try to open or repair any components of the SIPS airbag system. This should be done only by an authorized Volvo service technician. In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright position with the seat belt properly fastened.
  • Page 21 2001 Volvo S60 Contents Top of Page file:///K|/ownersdocs/2001/2001_S60/01s60_01a.htm (14 of 14)12/30/2006 3:46:53 PM...

  • Page 22: Inflatable Curtain (Ic)

    VOLVO pg. 20 Inflatable Curtain (IC) Volvo Inflatable Curtain (VIC) This system consists of inflatable curtains located along the sides of the roof liners, stretching from the center of both front side windows to the rear edge of the rear side door windows. It is designed to help protect the heads of the occupants of the front seats and the occupant of the outboard rear seating positions in certain side impact collisions.
  • Page 23 The year and month specified on the decal in the door pillar( s) is the date when you should contact your Volvo retailer to inspect and, if necessary, replace the airbags and seat belt tensioners. If you have any questions concerning either system, contact an authorized Volvo retailer.
  • Page 24 2001 Volvo S60 pg. 22 WHIPS Whiplash Protection System (WHIPS) -front seats only The WHIPS system consists of specially designed hinges and brackets on the front seat backrests and head restraints designed to help absorb some of the energy generated in a collision from the rear (" rear- ended").
  • Page 25 If your car has been involved in a collision, the front seat backrests must be inspected by an authorized Volvo retailer even if the seats appear to be undamaged. Certain components in the WHIPS system may need to be replaced. Do not attempt to service any component in the WHIPS system yourself.
  • Page 26 24 Child safety Child safety Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a car. Restraint systems for children are designed to be secured in the vehicle by lap belts or the lap portion of a lap-shoulder belt.

  • Page 27: Child Safety

    Volvo retailer. When a child has outgrown the child safety seat, you should use the rear seat with the standard seat belt fastened. The best way to help protect the child here is to place the child on a...
  • Page 28 The booster cushion should also be replaced if it is badly worn or damaged in any way. This work should be performed by an authorized Volvo retailer only. The booster cushion should be cleaned while in place in the vehicle if possible. If this is not possible, please consult your Volvo retailer.
  • Page 29 NOTE: Please also refer to the instructions on the integrated booster cushion. Child restraint anchorages Volvo cars are equipped with child restraint top tether anchorages in the rear seat. Installing the top tether The straps for the child seat should be placed between the head restraint and the backrest. This may make it necessary to temporarily fold down the backrest when attaching the straps to the anchorages.
  • Page 30 Because of the size of the airbag and its speed of inflation, a child should never be placed in the front seat, even if he or she is properly belted or strapped into a child safety seat. Volvo has been an innovator in safety for over fifty years, and we'll continue to do our part.
  • Page 31 Volvo Concern for Safety Safety is the cornerstone for Volvo. Our concern dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy-absorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation.
  • Page 32 However, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Cars of North America. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 202-366-0123 in Washington, D. C. area) or write to: NHTSA, U.

  • Page 33: Instruments And Controls

    2001 Volvo S60 2 0 0 1 VOLVO Instruments and controls pg. 29 Instruments and controls Instrument panel Indicator and warning symbols Steering wheel adjustment Switches in the center console Lighting panel Turn signals Windshield wipers/ washer Hazard warning flashers, rear window/ sideview mirror defroster, heated front...
  • Page 34 2001 Volvo S60 1. Turn signal indicators - right - left 2. Text window The text window displays information and warning messages. 3. Temperature gauge The pointer should be approximately midway on the gauge when driving. Do not drive the car if the warning light is on.

  • Page 35: Indicator And Warning Symbols

    2001 Volvo S60 11. Ambient temperature gauge This display indicates the air temperature outside your car. A "snowflake" symbol in the text window is displayed when the temperature is in the range of 23 - 36° F (- 5 - +2° C). Please note that this symbol does not indicate a fault with your car.
  • Page 36 DO NOT DRIVE. Have the car towed to an authorized Volvo retailer and have the brake system inspected. If the brake fluid level is above the MIN mark, drive carefully to an authorized Volvo retailer and have the brake system inspected.
  • Page 37 If the light comes on (or stays on after the vehicle has started), the SRS diagnostic system has detected a fault. Drive to an authorized Volvo retailer for an inspection of the system. See the SRS section for more information.
  • Page 38 Stop the car in a safe place and switch off the engine. Restart the engine. If the indicator light goes off, no further action is necessary. If the indicator light remains on, drive to an authorized Volvo retailer to have the system inspected. pg. 35 Indicator and warning symbols...
  • Page 39 2001 Volvo S60 Messages in the text window When a warning light in the instrument panel comes on, a message is also displayed in the text window. After you have read the message, you can erase it by pressing button A (see illus- tration).
  • Page 40 2001 Volvo S60 Both the height and the reach of the steering wheel can be adjusted to a comfortable position for the driver. Pull down the lever on the left of the steering column. Adjust the steering wheel to a suitable position and press the lever back into place to lock the steering wheel in the new position.
  • Page 41 2001 Volvo S60 WARNING! For safety reasons, no one should be allowed to sit in the outboard rear seat positions if the head restraints are folded down. If these positions are occupied, the head restraints should be in the upright (fixed) position.

  • Page 42: Lighting Panel

    This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. The ignition key must be in position 1 (or higher) for the auxiliary socket to function. NOTE: The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer.
  • Page 43 2001 Volvo S60 Headlights, parking lights, license plate lights and instrument panel illumination are on if the ignition key is in position II. If the headlight switch is in this position, all lights will go out when the ignition is switched off.
  • Page 44 2001 Volvo S60 2 0 0 1 VOLVO pg. 40 Turn Signals 1. Lane change position In maneuvers such as lane changing, the driver can flash the turn signals by moving the turn signal lever to the first stop and holding it there. The lever will return to the neutral position when released.

  • Page 45: Windshield Wipers/ Washer

    2001 Volvo S60 your discretion and can be changed by an authorized Volvo retailer). Approach lighting When approaching the car at night, press the yellow button in the central locking remote control (see illustration on page 117). This lights up the interior courtesy lights, parking lights, license plate lights and the lights in the sideview mirrors.

  • Page 46: Hazard Warning Flashers, Rear Window/ Sideview Mirror Defroster, Heated Front Seats

    2001 Volvo S60 pg. 42 Hazard warning flashers, rear window/ sideview mirror defroster, heated front seats Hazard warning flashers The four- way flasher should be used to indicate that the vehicle has become a traffic hazard. To activate the flashers, press the triangular button in the center dash. Press the button again to turn off the flashers.

  • Page 47: Trip Computer (Option)

    2001 Volvo S60 The front seat heating can be switched on and off as required. Press the switch once for maximum seat heating. Both LEDs in the switch will be lit. Press the switch a second time for comfort heating. One LED in the switch will be lit.
  • Page 48 2001 Volvo S60 When the driving distance on current fuel reserve is less than 12 miles (20 km), "----" will be displayed in the text window. Average fuel consumption This value indicates fuel consumption since the last time the trip computer was reset (by pressing RESET, button C).

  • Page 49: Parking Brake, Electric Socket/ Cigarette Lighter

    2001 Volvo S60 Cruise control is automatically disengaged when the brake pedal is depressed. The currently set speed is stored in memory. Quickly pressing resume will return the car to the previously set speed. Acceleration Momentary acceleration, such as when passing another car, does not affect cruise control operation.
  • Page 50 I (or higher) for the auxiliary socket to function. The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer. NOTE: The cover should be kept on when the auxiliary socket is not in use.

  • Page 51: Electrically Operated Windows

    2001 Volvo S60 Ashtrays Volvo cars in North America do not have an ashtray in the front seat as standard equipment. If you want to have an ashtray in the front seat, please contact your Volvo retailer. pg. 46 Electrically operated windows Electrically operated windows The electrically operated windows are controlled by buttons in the arm rests.
  • Page 52 2001 Volvo S60 WARNING! Always remove the ignition key when the vehicle is unattended. Make sure that childrens' hands are clear before raising the windows. Never leave children unattended in the car. Cutout switch for rear windows The electrically operated rear door windows can be disabled by a switch located on the driver's door (see illustration).

  • Page 53: Rearview Mirror/ Sideview Mirrors

    2001 Volvo S60 Electrically operated window in the front passenger's seat The control for the electrically operated window in the front passenger's seat operates that window only. Electrically operated windows in the rear doors. The rear door windows can be operated with the control on each door and the switch on the driver's door.
  • Page 54 2001 Volvo S60 Rearview mirror A Normal position B Night position, reduces glare from following headlights Autodim function (option) The autodim function reacts to headlights from following traffic and automatically reduces glare. NOTE: This function is automatically switched off when the gear selector is placed in the Reverse position.

  • Page 55: Electrically Operated Sun Roof

    2001 Volvo S60 the adjustment control. WARNING! The mirrors should always be adjusted prior to driving. Objects seen in the passenger's side wide- angle sideview mirror are closer than they appear to be. Remote control (central locking system) - option...
  • Page 56 2001 Volvo S60 AUTO open: Pull the switch as far back as possible and release it to automatically slide open the sun roof to the "comfort" position. Pull the switch again to open the sun roof completely. To close the sun roof: Push the switch forward to the first detent (" stop") and hold it until the sun roof has closed completely.
  • Page 57 2001 Volvo S60 WARNING! The sun roof must never be obstructed in any way when in operation. Contents Top of Page file:///K|/ownersdocs/2001/2001_S60/01s60_02b.htm (14 of 14)12/30/2006 3:46:57 PM...

  • Page 58: Climate Control

    2001 Volvo S60 2 0 0 1 VOLVO Climate control pg. 51 Climate control Climate control systems - general information Air distribution Electronic climate control, ECC (option) Manual climate control with air conditioning, (A/ pg. 52 Climate control systems - general information...

  • Page 59: Air Distribution

    Acceleration The air conditioning is momentarily disengaged during full-throttle acceleration. Climate control maintenance All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a.
  • Page 60 2001 Volvo S60 Air vents in the dash A Open B Closed C Horizontal air flow D Vertical air flow Direct the outer air vents toward the side windows to defrost. In cold weather, close the air vents in the center of the dash to direct as much air as possible toward the windows.

  • Page 61: Electronic Climate Control, Ecc (Option)

    2001 Volvo S60 pg. 54 Electronic climate control, ECC (option) pg. 55 Electronic climate control, ECC (option) AUTO This function automatically regulates the Electronic Climate Control system so that the selected temperatures are maintained. The blower, heating, air distribution (air flow) and air conditioning are controlled.
  • Page 62 2001 Volvo S60 Never use ice scrapers made of metal as they can easily scratch the mirror surface. Temperature These controls are used to individually set the temperature for both sides of the passenger compartment. Please note that the compartment will not be heated or cooled faster by setting the temperature higher or lower than necessary.
  • Page 63 2001 Volvo S60 Air distribution Press AUTO to automatically regulate air flow or press any combination of the controls shown in the illustration to manually adjust air flow. An LED in the switch will light up if an air flow control has been pressed.
  • Page 64 2001 Volvo S60 Recirculation Press this switch to engage the recirculation function (air in the passenger compartment recirculates - no fresh air enters the compartment). The LED in the switch will light up to indicate that the function is engaged.
  • Page 65 2001 Volvo S60 Operation Press to operate the air quality sensor (normal setting). Select one of the following three functions by pressing .1, 2 or 3 times. 1. The AUT LED lights. The air quality sensor is now activated. 2. No LED lights. Recirculation is not activated unless needed to cool the passenger compartment in a warm climate.
  • Page 66 2001 Volvo S60 pg. 59 Manual climate control with air conditioning, (A/ C) A/ C - ON/ OFF The air conditioning function is engaged by pressing ON and disengaged by pressing OFF. When you select Defroster , the air conditioning is automatically engaged if the fan is not set to position 0.
  • Page 67 2001 Volvo S60 Temperature Turn the control to set the temperature for the driver's and passenger's sides of the car. For cooler air, the air conditioning function must be engaged. Rear window and sideview mirror defrosters This function defrosts/ de-ices the rear window and sideview mirrors. The LED in the switch will light up to indicate that the heating function is engaged.
  • Page 68 2001 Volvo S60 Recirculation Recirculation can be used to shut out stale air, exhaust, etc. from the passenger compartment. The air in the passenger compartment is then recirculated, i. e. no air from outside the car is taken into the car when this function is activated.
  • Page 69 2001 Volvo S60 Contents Top of Page file:///K|/ownersdocs/2001/2001_S60/01s60_03.htm (12 of 12)12/30/2006 3:46:58 PM...
  • Page 70 2001 Volvo S60 2 0 0 1 VOLVO Audio pg. 61 Audio Audio system HU- 413 - overview Audio system HU- 613 - overview Audio system HU- 803 - overview Audio systems HU- 413/ HU- 613/ HU- 803 Audio systems HU- 803 - radio...
  • Page 71 2001 Volvo S60 1. Display 2. Radio - Manual station selection Cassette - Fast winding forward/ backward CD - Fast forward/ backward. 3. Radio - Station seek up/ down Cassette - selecting next/ previous track CD - Selecting next/ previous track 4.

  • Page 72: Audio System Hu- 613 - Overview

    2001 Volvo S60 pg. 63 Audio system HU- 613 - overview 1. .On/ off - press Volume - turn 2. Selector knob for: Stored radio frequencies CD changer - selecting disc 3. Selector knob: Radio Cassette CD changer (option) 4. Fader - press and turn Balance - press, pull and turn 5.

  • Page 73: Audio System Hu- 803 - Overview

    2001 Volvo S60 16. Cassette opening 17. Cassette eject 18. Display pg. 64 Audio system HU- 803 - overview 1. On/ off - press Volume - turn 2. Bass - press and turn Treble - press, pull and turn 3. Fader - press and turn Balance - press, pull and turn 4.
  • Page 74 2001 Volvo S60 13. CD slot 14. CD random play 15. Program type 16. News 17. Traffic information 18. Automatic presetting of radio stations 19. Display pg. 65 Audio systems HU- 413/ HU- 613/ HU- 803 Switch on/off Press the knob to switch on or turn off the radio.

  • Page 75: Audio System(S)

    2001 Volvo S60 "ASC ON" or "ASC OFF" will be shown in the display for several seconds. Bass Adjust the bass by pressing the button to extend the control and turning it to the left (less bass) or to the right (more bass).
  • Page 76 2001 Volvo S60 A - Setting station Press the left side of the button to select lower frequencies and the right side for higher frequencies. Set frequencies are displayed. B - Station seek up/ down Press the left side (lower frequency) or right side (higher frequency) of the button to start the seek function.
  • Page 77 2001 Volvo S60 Scan function Press the SCAN button (HU- 613) or the SOURCE knob (HU- 803) to start the station scan function. When a station is found, scanning stops for several seconds, after which scanning will continue. Press the SCAN button or SOURCE knob when a station has been found if you would like to listen to that station and to discontinue the scan function.
  • Page 78 FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information. Please refer to the following pages regarding specific descriptions and operation of these functions.
  • Page 79 2001 Volvo S60 Traffic information can only be heard when TP and are displayed at the same time. If only TP is displayed, it means that no traffic information is being broadcast from the current transmitter. If you do not wish to listen to an ongoing traffic bulletin, press the TP button. The TP function, however, is still connected and the radio waits for the next traffic bulletin.

  • Page 80: Program Types (Hu- 803 Only)

    2001 Volvo S60 3. When you have reached the program type you require press the 4. "1- 20/ DISC" knob to begin the search. 5. If there is more than one station with the selected program type, you can select using or the scan button.
  • Page 81 2001 Volvo S60 Text Program type displayed News News Information Inform Sports Sports Talk Talk Rock Rock Classic rock Cls_ Rock Adult hits Adlt_ Hit Soft rock Soft_ Rck Top 40 Top_ 40 Country Country Oldies Oldies Soft Soft Nostalgia...
  • Page 82 2001 Volvo S60 2 0 0 1 VOLVO pg. 72 AUM (Advanced User Mode) AUM (Advanced User Mode) With the radio switched off, press and hold the volume wheel down for at least 5 seconds to start the AUM function.
  • Page 83 2001 Volvo S60 AF SWITCHING ON/ OFF (automatic frequency update) - The AF function ensures that the strongest available trans- mitter for a program is selected. REGIONAL ON/ OFF (regional radio program) - This function makes it possible to continue to listen to a regional transmitter, even if the signal is weak.
  • Page 84 2001 Volvo S60 Dolby B Noise reduction The function is preset. To switch the function off, hold down the " " button until the Dolby symbol in the display goes out. Press the same button again to reactivate the function or use the Advanced User Mode function.
  • Page 85 2001 Volvo S60 pg. 75 Audio system HU- 613/ HU- 803 - CD player CD player - on HU- 613: Insert a CD. HU- 803: Insert a CD. If you would like to insert another disc (a maximum of 4 CD's can be inserted in the player), turn the "1- 20/ DISC"...
  • Page 86 2001 Volvo S60 Fast winding Press " " or " " to seek within a track. Next/ previous track Press " " to skip to the next track or " " to skip to the previous track. The track number is shown in the display.
  • Page 87 2001 Volvo S60 CD player The accessory CD changer, mounted in the cargo area, can accommodate 10 discs. To load the magazine: Slide the cover on the CD changer open. Press the eject button. Pull the magazine out of the changer and insert the discs.

  • Page 88: Dolby Surround Pro Logic Hu- 803 (Option)

    2001 Volvo S60 Changing tracks Press " " to skip to the next track or " " to skip to the previous track. The disc and track numbers are shown in the display. If you have a keypad in the steering wheel, you can use the arrows.
  • Page 89 2001 Volvo S60 Dolby Surround Pro Logic To select Dolby Surround Pro Logic during CD playback, press " PL". "Dolby Pro Logic" is displayed. Press "OFF" to return to 2 channel stereo. 3 channel stereoM To select 3 channel stereo press "3- CH". "3 ch" is displayed. Press "OFF" to return to 2 channel stereo.

  • Page 90: Audio Systems - General Information

    The optional supplementary amplifier (HU- 803) may be mounted under the front passenger's seat. If the floor of the car has become soaked for any reason, do not turn on the radio. This would cause damage to the amplifier. Contact a Volvo retailer. pg. 81 Audio systems - general information...

  • Page 91: Homelink® Universal Transceiver (Option)

    Keep tapes away from oil, grease and other contaminants. For optimal tape deck performance Volvo does not recommend the use of C- 120 tapes. Take up slack using a pen or a pencil before inserting a cassette in the cassette slot.
  • Page 92 2001 Volvo S60 HomeLink® Universal Transceiver HomeLink® is an advanced system that can be programmed to learn the codes of three different remote controlled- devices (e. g., garage door openers, remote lighting, entry door lock). HomeLink® 's sun visor-mounted transceiver, powered by your car's electrical system, may then be used in place of your hand- held remote controls.
  • Page 93 2001 Volvo S60 If, after several attempts, you are unable to successfully train the HomeLink® Universal Transceiver to learn your hand-held transmitter's signal, contact HomeLink® toll-free 1-800-355-3515 (Internet: www. HomeLink.com). WARNING! If you use HomeLink® to open a garage door or gate, be sure no one is near the gate or door while it is in motion.
  • Page 94 2001 Volvo S60 the transceiver." The help of a second person may make training easier. 1. Locate the training button on the garage door opener motor head unit. The location and color of the training button may vary. If you encounter difficulty, refer to the garage door opener owner's manual or call toll- free 1-800-355-3515 (Internet: www.HomeLink.com).
  • Page 95 2001 Volvo S60 The HomeLink® buttons can be reprogrammed using the procedures described on the previous page. Reprogramming a single HomeLink® button 1. Press and hold the desired HomeLink® button. Do not release the button until step 3 has been completed.
  • Page 96 2001 Volvo S60 2 0 0 1 VOLVO Interior pg. 99 Interior Front seats Interior lighting Floor mats (option) Storage compartments Rear seat and trunk Spare wheel and tools pg. 100 Front seats Manual height adjustment - front seat The front edges of the driver and passenger seat cushions can be adjusted to seven different settings and the rear edges to nine different settings.
  • Page 97 2001 Volvo S60 pg. 101 Front seats Folding the backrests in the front seat The front passenger seat backrest can be folded to a horizontal position to make room for a long load. Fold the backrest as follows: Move the seat as far back as possible.
  • Page 98 Seat adjustment If your Volvo is equipped with power seats, the following may be adjusted with the two switches at the side of the seat:...

  • Page 99: Front Seats

    2001 Volvo S60 C - Rear edge of seat (raise/ lower) D - Backrest tilt NOTE! The power seats have an overload protector that activates if a seat is blocked by any object. If this occurs, switch off the ignition (key in position 0) and wait about 20 seconds before operating the seat again.

  • Page 100: Interior Lighting

    2001 Volvo S60 be programmed. To program a seat position: 1. Adjust the seat to the desired position. 2. Hold down the MEM button. 3. While holding down the MEM button, press button 1 to program the current position of the seat.
  • Page 101 You can disconnect the automatic function by pressing the courtesy light button for more than 3 seconds. Briefly pressing the courtesy light button again automatically reconnects the function. The courtesy light timer periods can be changed. Contact your Volvo retailer. Reading lights - front/ rear The reading lights can be switched on or off by pressing the respective buttons.
  • Page 102 2001 Volvo S60 Floor mats (option) Volvo offers floor mats specially manufactured for your car. They must be properly placed and secured in the mat clips. WARNING! An extra mat on the driver's floor can cause the accelerator pedal to catch. Check that the movement of the accelerator pedal is not impeded.
  • Page 103 2001 Volvo S60 2 0 0 1 VOLVO pg. 106 Storage compartments WARNING! Packages on the rear window shelf can obscure vision and may become dangerous projectiles in the event of a sudden stop or an accident. Anchor any heavy objects to help prevent them from moving during sudden stops.
  • Page 104 2001 Volvo S60 pg. 107 Storage compartments Storage compartments in the center console Cup holder Cup holders are provided for the front seat occupants (optional in the rear seat). You can also use the storage compartment in the center console for CD's, etc.
  • Page 105 2001 Volvo S60 pg. 108 Storage compartments Cup holder in the dashboard (option) Press the holder to open. Adjust the holder by pressing the arms inwards. Press the holder in after use. WARNING! Never use glass bottles. Remember also that hot drinks may cause burns.

  • Page 106: Storage Compartments

    2001 Volvo S60 Glove compartment The glove compartment can be used to store things such as the owner's manual, maps, pens, etc. pg. 109 Storage compartments Accessory bracket The side panel on the passenger side of your car is equipped with a bracket for various acces- sories.
  • Page 107 2001 Volvo S60 Coat hanger Use the coat hanger for clothes of normal weight. pg. 110 Storage compartments Waste bin/ bottle holder in the rear seat (option) Do as follows to change the waste bag: 1. Open the holder. 2. Use both hands to press out the bottom of the holder.
  • Page 108 2001 Volvo S60 The waste bin can also be used as a holder for large bottles, etc. NOTE! For reasons of safety, glass bottles should never be used anywhere in the car! pg. 111 Rear seat and trunk Folding the rear seat backrest Both rear seat backrests can be folded down, together or individually to enable you to transport long objects.
  • Page 109 2001 Volvo S60 WARNING! Keep vehicle doors and the luggage compartment locked and keep keys out of a child's reach. Unsupervised children could lock themselves in an open trunk and risk injury. Children should be taught not to play in vehicles.
  • Page 110 2001 Volvo S60 side of the trunk. pg. 112 Rear seat and trunk Carrying long loads The center backrest cushion folds forward, allowing you to transport long, light cargo such as skis in the trunk of your car. To lower the backrest:...

  • Page 111: Spare Wheel And Tools

    2001 Volvo S60 Center head restraints The center head restraint can be adjusted according to the passenger's height. The restraint should be carefully adjusted to support the occupant's head. The head restraint can be raised by pulling straight up or lowered by pressing the catch at the base of the left head restraint support and pushing down.
  • Page 112 2001 Volvo S60 Remove the jack and tool kit. Unscrew the spare wheel and lift it out. WARNING! Make sure that the spare tire, jack and tool bag are properly secured with the securing bracket to help keep these components in place in the event of a sudden stop.

  • Page 113: Locks And Alarm

    2001 Volvo S60 2 0 0 1 VOLVO Locks and alarm pg. 115 Locks and alarm Keys and remote controls Locking and unlocking Child safety lock Alarm pg. 116 Keys and remote controls file:///K|/ownersdocs/2001/2001_S60/01s60_07.htm (1 of 11)12/30/2006 3:47:04 PM...
  • Page 114 The car will start only with a properly coded key. If you misplace a key, take the other keys to an authorized Volvo retailer for reprogramming as an antitheft measure.
  • Page 115 The car can also be locked/ unlocked with the key. As an extra security precaution in certain situations (valet parking, etc.), Volvo recommends that the transmitter not be included when the keys are given to anyone. The service key can be used instead. If one of the transmitters is misplaced, contact the nearest authorized Volvo retailer for assistance.
  • Page 116 2001 Volvo S60 Using the remote control Press the LOCK button once to lock all doors and trunk. Press the UNLOCK button once to unlock the driver's door and fuel filler door. Press this button again (within 10 seconds) to unlock all doors and the trunk.
  • Page 117 2001 Volvo S60 WARNING! Never use the transmitter to lock the doors from inside the car Doing so would ACTIVATE: the break in alarm, which would sound if one of the doors were opened the optional interior motion and inclination alarm sensors.

  • Page 118: Locking And Unlocking

    2001 Volvo S60 minus side upward. Avoid touching the contact surfaces of the battery with your fingers. Reinstall the cover and tighten the screw to help protect the transmitter. pg. 119 Locking and unlocking Locking and unlocking the car from the inside The switch on the driver's door armrest can be used to lock or unlock all doors and the trunk, and to set the alarm.
  • Page 119 2001 Volvo S60 Opening/ locking the trunk lid with the remote control Do as follows to unlock the trunk lid only: Press the "Open trunk" button on the remote control twice. If all doors are locked when you close the trunk lid, it locks automatically.
  • Page 120 2001 Volvo S60 The controls are located on the rear door jambs. Use a screwdriver to adjust these controls. A The door cannot be opened from the inside. Normal operation from the outside. B The door lock functions normally. WARNING!
  • Page 121 2001 Volvo S60 Arming the alarm Press the LOCK button on the remote control, lock the car using the key in the driver's door or press the central lock button on one of the front doors with the door open. One long flash of the turn signals will confirm that the alarm is armed.
  • Page 122 LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact your Volvo retailer. Automatic re-lock/ re-arm system If the car is unlocked with the remote, the car will re- lock and the alarm will re- arm after 2 minutes unless a door or the trunk has been opened.
  • Page 123 2001 Volvo S60 * The position of this button may vary, depending on the specifications of your car. Contents Top of Page file:///K|/ownersdocs/2001/2001_S60/01s60_07.htm (11 of 11)12/30/2006 3:47:04 PM...

  • Page 124: Starting And Driving

    2001 Volvo S60 2 0 0 1 VOLVO Starting and driving pg. 125 Starting and driving Refueling Starting the car General information Manual transmission Automatic transmission (option) Geartronic (option ) Brake system Stability system Towing Jump starting Towing a trailer...
  • Page 125 (MMT). If such fuels are used, your Emission Control System performance may be affected, and the Check Engine Light (malfunction indicator lamp) located on your instrument panel may light. If this occurs, please return your vehicle to an authorized Volvo retailer for service.
  • Page 126 To meet seasonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygenated" fuels; however, the octane ratings listed on this page must still be met.
  • Page 127 * If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. pg. 128 Starting the car Starting the engine 1.
  • Page 128 2001 Volvo S60 the key to the starting position. Release the pedal slowly when the engine starts. 4. To release the gear selector from the (P) ark position, the engine must be running (or theignition key must be in position II) and the brake pedal must be depressed.
  • Page 129 2001 Volvo S60 Ignition switch and steering wheel lock 0 Locked position: Remove the key to lock the steering wheel *. WARNING! Never turn the key to position O while driving or when the car is being towed. I Intermediate position - "radio position": Certain accessories, radio, etc. on, daytime running lights off.

  • Page 130: General Information

    2001 Volvo S60 The steering wheel lock might be under tension when the car is parked. Turn the steering wheel slightly to free the ignition key. In order to help reduce car theft, make sure the steering wheel lock is engaged before leaving the car.

  • Page 131: Manual Transmission

    2001 Volvo S60 WARNING! Driving with the trunk open: Driving with the trunk open could lead to poisonous exhaust gases entering the passenger compartment. If the trunk must be kept open for any reason, proceed as follows - Close the windows - Set the ventilation system control to air flow to floor, windshield and side windows and blower control to its highest setting.
  • Page 132 2001 Volvo S60 Shift positions Depress the clutch pedal completely when changing gears*. Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th gear) should be used as often as possible to help improve fuel economy.

  • Page 133: Automatic Transmission (Option)

    2001 Volvo S60 "Space ball" gear selector (option) The shift positions for the "space ball" are the same as for the standard manual gear selector. pg. 133 Automatic transmission (option) Automatic transmission AW55- 50 (option) P Park Use this position when starting the engine or parking the car.
  • Page 134 2001 Volvo S60 WARNING! Never leave the car unattended when the engine is running. If, by mistake, the gear selector is moved from P, the car may start moving. R (Reverse)B Never engage R while the car is moving forward.
  • Page 135 2001 Volvo S60 W - Winter/ Wet driving mode - enhanced vehicle traction Mode W will only function if the gear selector is in the (D) rive position. Press the button at the base of the gear selector to engage/ disengage this driving mode (see illustration).

  • Page 136: Geartronic (Option )

    2001 Volvo S60 highway speeds. Automatic transmission - adaptive system The automatic transmission is controlled by an adaptive control system that constantly monitors the way in which the transmission functions. It senses and adapts each gear shift for optimal performance.
  • Page 137 2001 Volvo S60 N (Neutral) Neutral - no gear engaged. Use the parking brake. D (Drive) D is the normal driving position and should be used as often as possible to help improve fuel economy. The car should not be moving when shifting from R to the D position.
  • Page 138 2001 Volvo S60 Manual shifting - Geartronic You can move the gear selector freely between the (MAN) ual and (D) rive positions while driving. Gears 3, and 4 have a "lock- up" function which reduces engine speed and helps save fuel.
  • Page 139 If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to a Volvo retailer and have the brake system inspected.
  • Page 140 If both lights are still on after the engine has been restarted, switch off the engine again and check the brake fluid level (see page 170 for the location of the brake fluid reservoir). If the brake fluid level is above the MIN mark, drive carefully to an authorized Volvo retailer and have the brake system inspected.
  • Page 141 If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to a Volvo retailer and have the brake system inspected.

  • Page 142: Stability System

    2001 Volvo S60 2 0 0 1 VOLVO pg. 139 Stability system Stability and Traction Control (STC) - Anti-spin system (option) The STC system is designed to help reduce wheel spin by limiting power to the drive wheels if they begin to lose traction.
  • Page 143 DSTC has been temporarily switched off due to high brake temperature. The system will automatically switch on again when the brakes have cooled. If the system has been switched off due to a fault. An authorized Volvo retailer should check the file:///K|/ownersdocs/2001/2001_S60/01s60_08b.htm (2 of 13)12/30/2006 3:47:07 PM...
  • Page 144 2001 Volvo S60 system. pg. 141 Towing Emergency towing The towing eyelet is located in the tool bag, under the floor of the trunk, with the spare tire. This eyelet must be screwed into the positions provided on the right sides of either the front or rear bumper (see illustrations).
  • Page 145 2001 Volvo S60 Precautions when the car is in tow The steering wheel must be unlocked. Turn the ignition key to position I or II. The gear selector must be in position N. Maximum speed: 50 mph (80 km/ h). Do not exceed the maximum allowable towing speed.

  • Page 146: Jump Starting

    2001 Volvo S60 Towing cars with front wheel drive Volvo recommends the use of flat bed equipment. If wheel lift equipment must be used, please use extreme caution to help avoid damage to the car. In this case, the car should be towed with the rear wheels on the ground if at all possible.
  • Page 147 2001 Volvo S60 Jump starting Follow these instructions to jump start your car's dead battery or to jump start another car's dead battery using your car. Although your car's battery is located under the floor of the trunk, jumper cables should be connected in the engine compartment, to the points shown in the illustrations.
  • Page 148 144 Towing a trailer Towing a trailer Volvo recommends the use of Volvo trailer hitches that are specially designed for the car. Maximum trailer weight recommended by Volvo is: Trailers without brakes: 1100 lbs (500 kg) Trailers with brakes: 2" (50 mm) ball - 3300 lbs (1500 kg), 1 7/ 8" (47 mm) ball - 3300 lbs (1500 kg).

  • Page 149: Towing A Trailer

    If you use the manual (Geartronic) shift positions while towing a trailer, make sure the gear you select does not put too much strain on the engine (using too high a gear). The drawbar assembly/ trailer hitch may be rated for trailers heavier than the car is designed to tow. Please adhere to Volvo's recommended trailer weights.
  • Page 150 2001 Volvo S60 pg. 146 Detachable trailer hitch - installing pg. 147 Detachable trailer hitch - removing file:///K|/ownersdocs/2001/2001_S60/01s60_08b.htm (9 of 13)12/30/2006 3:47:07 PM...

  • Page 151: Attaching Load Carriers

    2001 Volvo S60 pg. 148 Attaching load carriers Attaching load carriers The attachment brackets for the load carriers are located under the roof molding. 1. Make sure that the load carriers are placed in the right direction. See the mark on the decal under the cover.
  • Page 152 Check periodically that the load carriers and load are properly secured. Load carriers (accessory) Load carriers are available as Volvo accessories. Observe the following points when in use: To avoid damaging your car and to achieve maximum safety when driving, we recommend using the load carriers that Volvo has developed especially for your car.
  • Page 153 It is therefore advisable to check the state of charge more frequently and spray an anti- rust oil on the battery posts. Volvo recommends the use of snow tires on all four wheels for winter driving - see section "Wheels and tires."...

  • Page 154: Before A Long Distance Trip

    Check all lights, including high beams. Reflective warning triangles are legal requirement in some countries. Have a word with your Volvo retailer if you intend to drive in countries where it may be difficult to obtain the correct fuel. Consider your destination. If you will be driving through an area where snow or ice are likely to occur, consider snow tires.

  • Page 155: Wheels And Tires

    2001 Volvo S60 2 0 0 1 VOLVO Wheels and tires pg. 151 Wheels and tires General information Tire pressure Tread wear indicators Changing wheels Uniform Tire Quality Grading pg. 152 General information General information about wheels and tires Your vehicle is equipped with tires according to the tire information label on the inside of the fuel filler door.
  • Page 156 2001 Volvo S60 preferably from the same manufacturer, on all four wheels. Otherwise there is a risk of altering the car's roadholding and handling characteristics. NOTE: When storing wheel/ tire assemblies (e. g. winter tires and wheels), either stand the assemblies upright, or suspend them off the ground.
  • Page 157 Snow chains can be used on your Volvo with the following restrictions: Snow chains should be installed on front wheels only. Use only Volvo approved snow chains. Special snow chains must be mounted on 195/ 65 R15. For tires of other dimen- sions, consult your Volvo retailer.
  • Page 158 With warm tires, correct only when the pressure is too low. The tire temperature rises after driving just a few miles. Vehicle loading The tires on your Volvo will perform to specifi- cations at all normal loads when inflated as recommended on the tire information label located on the inside of the fuel filler door. This label lists both tire and vehicle design limits.

  • Page 159: Tread Wear Indicators

    Recommended tire pressure (see decal on Fuel filler door) should be maintained irrespective of which position on the car the Temporary Spare tire is used on. In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING! Current legislation prohibits the use of the "Temporary Spare"...

  • Page 160: Changing Wheels

    2001 Volvo S60 Tires have tread wear indicators The tires have wear indicator strips running across or parallel to the tread. When approx. 1/ 16" (1.6 mm) is left on the tread, these strips become visible and indicate that the tire should be replaced.
  • Page 161 2001 Volvo S60 Engage the parking brake. Put the gear selector in (P) ark (automatic transmission) or reverse (manual trans- mission). Remove the wheel cap (where applicable) using the lug wrench in the tool kit. With the car still on the ground, use the lug wrench to loosen the wheel bolts 1/ 2 - 1 turn. Turn the bolts counterclockwise to loosen.
  • Page 162 2001 Volvo S60 Position the jack correctly on the bar in the attachment (see illustration above) and crank while simultaneously guiding the base of the jack to the ground. The base of the jack must be flat on a level, firm, non- slippery surface.

  • Page 163: Uniform Tire Quality Grading

    2001 Volvo S60 Apply the parking brake and put the gear selector in the (P) ark position (or reverse on manual transmissions). Block the wheels standing on the ground, use rigid wooden blocks or large stones. The jack should be kept well- greased.
  • Page 164 2001 Volvo S60 Motor Safety Standard No. 109. Grades B and A represent higher levels of performance on the laboratory test wheel than the minimum required by law. WARNING! The temperature grade for this tire is established for a tire that is properly inflated and not overloaded.

  • Page 165: Car Care

    2001 Volvo S60 2 0 0 1 VOLVO Car care pg. 159 Car care Washing and cleaning the Paint touch up pg. 160 Washing and cleaning the car Washing and cleaning the car The car should be washed at regular intervals since dirt, dust, insects and tar spots adhere to the paint and may cause damage.
  • Page 166 2001 Volvo S60 After cleaning the engine, the spark plug wells should be inspected for water and blown dry if necessary. Suitable detergents: Special car washing detergents should be used. A suitable mixture is about 2.5 fl. oz. (8.5 cl) of detergent to 2.6 US gal. (10 liters) of warm water. After washing with a detergent the car should be well rinsed with clean water.
  • Page 167 Leather upholstery/ suede- like upholstery (alcanteraª) can be cleaned with a soft cloth and mild soap solution. For more difficult spots, Volvo offers a leather care kit. Under no circumstances should gasoline, naphtha or similar cleaning agents be used on the plastic or the leather since these can cause damage.

  • Page 168: Paint Touch Up

    Paint repairs require special equipment and skill. Contact your Volvo retailer for any extensive damage. Minor scratches can be repaired by using Volvo touch- up paint. NOTE: When ordering touch- up paint from your Volvo retailer, use the paint code indicated on the model plate. The plate is located in the engine compartment.
  • Page 169 2001 Volvo S60 1. Place a strip of masking tape over the damaged surface. Pull the tape off so that any loose flakes of paint adhere to it. 2. Thoroughly mix the primer and apply it with a small brush.

  • Page 170: Maintenance And Service

    The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician. To keep your Volvo in top condition, specify time- tested and proven Genuine Volvo Parts and Accessories.
  • Page 171 2001 Volvo S60 specifications. The maintenance services outlined in this book should be performed as indicated. The extended maintenance service intervals make it even more advisable to follow this program. Inspection and service should also be performed any time a malfunction is observed or suspected. It is recommended that receipts for vehicle emission services be retained in the event that questions arise concerning maintenance.

  • Page 172: Maintenance Operation

    2001 Volvo S60 Maintenance thousand 7.5 15 22.5 30 37.5 45 52.5 60 67.5 82.5 90 miles Operation (thousand (12) (24) (36) (48) (60) (72) (84) (96) (108) (120) (132) (144) EMISSION SYSTEM MAINTENANCE Engine oil and filter Engine drive belt (accessory belt)
  • Page 173 2001 Volvo S60 Maintenance thousand 7.5 15 22.5 30 37.5 45 52.5 60 67.5 82.5 miles Operation (thousand (12) (24) (36) (48) (60) (72) (84) (96) (108) (120) (132) (144) EMISSION SYSTEM MAINTENANCE Engine Fuel line filter PCV nipple (orifice)/hoses, clean...

  • Page 174: Maintenance Schedule

    60,000 miles (96,000 km) and thereafter, at 30,000 mile (48,000 km) intervals. Cabin air filter Replace the cabin air filter with a new one at 15,000 mile (24,000 km) intervals. Volvo recommends replacing the filter more often if the car is driven under dirty and dusty condi- tions. The filter cannot be cleaned and therefore should always be replaced with a new one.
  • Page 175 The battery contains acid that is both corrosive and poisonous. It is important that the battery is handled in an environ- mentally friendly way. Let your Volvo dealer assist you. Hoisting the car If a garage jack is used to lift the car, the two jack attachments points should be used. They are specially reinforced to bear the weight of the car.
  • Page 176 2001 Volvo S60 WARNING! The car ignition system has very high voltage! The voltage in the ignition system is dangerous! Do not touch spark plugs, ignition cables or the ignition coil when the engine is running or the ignition is switched on! The ignition should be switched off when: Conducting engine tests.
  • Page 177 Changing coolant Normally, the coolant does not need to be changed. If the system must be drained, consult your Volvo retailer. NOTE: Do not top off with water only. This reduces the rust- protective and antifreeze qualities of the coolant and has a lower boiling point.
  • Page 178 2001 Volvo S60 Opening the hood Pull the lever located under the left side of the dash to release the hood lock. Lift the hood slightly. Press up the release control located under the front edge of the hood (at the center) and lift.
  • Page 179 Volvo does not recommend the use of oil additives. Volvo recommends use of oil with a quality rating equal to or higher than ILSAC GF- 2. Equivalent and better oils include ACEA A1, API SJ, SJ/ CF, and SJ/ Energy conserving. Lower quality oils may not offer the same fuel economy, engine performance, or engine protection.
  • Page 180 Changing oil and oil filter Oil and oil filter changes should be made at 7,500 mile (12,000 km) intervals. Volvo does not recommend the use of oil additives. Synthetic oil is not used when the oil is changed at the normal maintenance service intervals.
  • Page 181 2001 Volvo S60 Checking the oil level The oil level should be checked every time the car is refueled. This is especially important during the period up to the first service. CAUTION: Not checking the oil level regularly can result in serious engine damage if the oil level becomes too low.
  • Page 182 Changing coolant Normally, the coolant does not need to be changed. If the system must be drained, consult your Volvo retailer. NOTE: Do not top off with water only. This reduces the rust- protective and antifreeze qualities of the coolant and has a lower boiling point.

  • Page 183: Oils And Fluids

    Replace: Every second year or 30,000 miles (48,000 km). The fluid should be replaced once a year or every 15,000 miles (24,000 km) when driving under extremely hard conditions (mountain driving, etc.) Always entrust brake fluid changing to an authorized Volvo retailer. file:///K|/ownersdocs/2001/2001_S60/01s60_11a.htm (14 of 15)12/30/2006 3:47:11 PM...
  • Page 184 2001 Volvo S60 Power steering fluid reservoir The fluid level should always be between the MIN and MAX marks. Fluid type: ATF Replace: No fluid change required Contents Top of Page file:///K|/ownersdocs/2001/2001_S60/01s60_11a.htm (15 of 15)12/30/2006 3:47:11 PM...

  • Page 185: Wiper Blades

    2001 Volvo S60 2 0 0 1 VOLVO pg. 175 Wiper blades Replacing windshield wiper blades 1. Lift the wiper arm off the windshield and hold the blade at a 45¡ to the arm. Press the end of the plastic clip located on the arm.
  • Page 186 2001 Volvo S60 leave marks on the windshield or fail to wipe efficiently and cleanly. To obtain maximum lifetime from a set of wiper blades, clean them with a stiff- bristle brush and warm, soapy water as part of a normal car wash.
  • Page 187 2001 Volvo S60 Check the fluid level in each cell in the battery every 6 months or every 7,500 * miles (12,000 km). The fluid should be at the level shown in the illustration above (A)**. Use a screw driver to open the caps and a flashlight to inspect the level.
  • Page 188 2001 Volvo S60 Replacing the battery Switch off the ignition. Remove the retaining bracket and unscrew the cover over the battery. Wait at least 5 minutes after file:///K|/ownersdocs/2001/2001_S60/01s60_11b.htm (4 of 21)12/30/2006 3:47:13 PM...
  • Page 189 2001 Volvo S60 switching off the ignition before disconnecting the battery so that all information in the car's electrical system can be stored in the control modules. Disconnect the negative (ground) cable first. Disconnect the positive cable and pull the ventilation hose (see next page) from the battery.
  • Page 190 (see illustration). Be sure the ventilation hose is free of debris. Only use replacement batteries equipped with a ventilation hose. Consult your Volvo retailer. pg. 179 Bulbs The following bulbs are used in the car: 1.
  • Page 191 2001 Volvo S60 Replacing high/ low beam headlight bulbs The headlight bulbs must be replaced from the engine compartment. CAUTION: - Do not touch the glass on halogen bulbs with your fingers. Grease, oil or any other impurities can be carbonized onto the bulb and cause damage to the reflector.
  • Page 192 Reinstall the plastic cover and turn it clockwise until it is correctly in place (4). "TOP" must be upward. NOTE: The vertical aim of the headlights should be adjusted by a Volvo retailer. Side marker lights Open the front door halfway.
  • Page 193 2001 Volvo S60 From the inside of the fender, push the lamp housing out. Turn the bulb holder 1/ 4 turn counter- clockwise and pull it out from the lens. Remove the defective bulb by pulling it straight out. Insert a new bulb.
  • Page 194 2001 Volvo S60 Replacement of front parking light bulb Switch off all lights and turn ignition key to position 0. Remove the low beam cover by twisting counterclockwise. Pull out the bulb and its socket. Replace bulb. Press the bulb and its socket back into place.
  • Page 195 2001 Volvo S60 Switch off all lights and turn ignition key to position 0. Remove the radiator hose (1) from the radiator. Remove the screw (2) to the filler pipe. Pull the pipe (3) straight up. Remove the ventilation hose (4) from the pipe.
  • Page 196 2001 Volvo S60 Switch off the ignition. Turn the bulb holder slightly counter- clockwise to release it. Replace the bulb. The shape of the foot of the bulb corresponds to the shape of the bulb holder. Reinstall the bulb holder by turning it slightly clockwise. "TOP" on the holder should be upward.
  • Page 197 2001 Volvo S60 These bulbs are of a special type. We recommend that you ask your Volvo retailer to replace this bulb. pg. 184 Bulbs License plate lights Switch off the ignition. Loosen the screws with a torx screw- driver.
  • Page 198 Press the lens back into place. pg. 185 Bulbs Front courtesy lights These bulbs may be difficult for you to replace yourself. We recommend that you let an authorized Volvo retailer replace these bulbs if necessary. file:///K|/ownersdocs/2001/2001_S60/01s60_11b.htm (14 of 21)12/30/2006 3:47:13 PM...
  • Page 199 These bulbs may be difficult for you to replace yourself. We recommend that you let an authorized Volvo retailer replace these bulbs if necessary. NOTE: Other bulbs may be difficult for you to replace yourself. Let an authorized Volvo retailer replace these bulbs if necessary.
  • Page 200 (see next page) to see if it is broken. If so, put in a new fuse of the same color and amperage (written on the fuse). Spare fuses are stored in the fuse box in the passenger compartment. If fuses burn out repeatedly, have the electrical system inspected by an authorized Volvo retailer.
  • Page 201 2001 Volvo S60 Relay/ Fuse box in the engine compartment When replacing fuses, be sure to replace a blown fuse with a new one of the same color and amperage (written on the fuse). Fuses in the engine compartment Amperage...
  • Page 202 2001 Volvo S60 11 A/ C compressor. Ignition coils. Electric fan 12 Brake light contact 13 Windshield wipers 14 ABS/ DSTC 16 Windshield wipers, Headlight washers (certain models 15 19 ABS/ DSTC 22 Starter motor 23 Engine control module pg. 188 Fuses Fuses in the passenger compartment Fuses are located inside the access panel on the end face of the dashboard.
  • Page 203 2001 Volvo S60 5 Power driver's seat. 6 Power passenger seat . 7 Heated seat, front left (option) . 8 Heated seat, front right (option). 9 ABS 10 Left high beam . 11 Right high beam. 12 Headlight wipers (certain models) .
  • Page 204 2001 Volvo S60 38 . pg. 189 Fuses Fuses in the cargo compartment Amperage 1 Rear electronic module, Cargo compartment lighting....10 2 Rear fog light ................10 3 Brake light..................15 4 Backup lights ................10 5 Rear window defroster, Relay 15I (accessories)......5 6 Trunk lid opener................
  • Page 205 2001 Volvo S60 7 Folding head restraints ..............10 8 Central locking rear doors, Fuel filler door ........15 9 Trailer hitch (30 feed) (accessory) ..........15 10 CD changer. CD ROM. VNA. Antenna ........10 11 Electronic module, accessories ............. 15 12 ......................

  • Page 206: Specifications

    192 Label information 1 Vehicle Emission Control Information Your Volvo is designed to meet all applicable emission standards, as evidenced by the certification label on the underside of the hood. For further information regarding these regulations, please consult your Volvo retailer.

  • Page 207: Dimensions / Weights

    6 Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.
  • Page 208 2001 Volvo S60 Dimensions Length 180 in. (458 cm) Width 71 in. (180 cm) Height 56.2 in. (143 cm) Wheelbase 107 in. (272 cm) Front track 61.5 in. (156 cm) Rear track 61.4 (156 cm) Turning circle, between curbs 35.4- 38.7 ft. (10.8- 11.8 m) Cargo capacity, trunk SAE V1 - 13.9 (394)
  • Page 209 2001 Volvo S60 Canada 1010 kg Permissible axle weights, rear * All models USA 2220 lbs (1007 kg) Canada 1010 kg Curb weight 5 cyl. USA 3220- 3330 lbs (1461- 1510 kg) Canada 1470- 1515 kg 5 cyl. turbo USA 3370- 3470 lbs (1529- 1547 kg) Canada 1535- 1580 kg Max.

  • Page 210: Lubricants, Cooling System

    Volvo does not recommend the use of oil additives. Transmission Oil grade: Manual: Volvo synthetic transmission oil 97308 Automatic: Volvo transmission oil 1161540- 8 Different types of oil should never be mixed. Power steering Grade: ATF file:///K|/ownersdocs/2001/2001_S60/01s60_12.htm (5 of 11)12/30/2006 3:47:15 PM...

  • Page 211: Three Way Catalytic Converter

    2001 Volvo S60 Brake fluid Fluid type: Brake fluid DOT 4+. Cooling system Type Positive pressure, closed system. Coolant Volvo original coolant/ antifreeze Volume 5 cyl. non- turbo 8.5 US qts. (8.0 liters) 5 cyl. turbo 9.3 US qts (8.8 liters) pg.
  • Page 212 2001 Volvo S60 Wheel dimension 15" 16" Rim diameter (mm) tire side diameter(mm) 0.1°± 0. Toe- in front (degrees) 0.1°± 0. 1° 1° 0.2°+± 0.2+± 0. Toe- in rear (degrees) 0.2° 2° Toe- in front (mm) rim measurement 2. 2± 0. 7 2.3±...

  • Page 213: Electrical System

    2001 Volvo S60 Trunk lighting SV 8.5 Glove compartment lighting 2 W BA 9 s Vanity mirror 1.2 W SV 5.5 pg. 199 Electrical system Electrical system 12- volt system with voltage controlled generator. Single wire system in which the chassis and engine block are used as conductors, grounded on the chassis.

  • Page 214: Engine Specifications

    2001 Volvo S60 WARNING! The distributor ignition system operates at very high voltages. Special safety precautions must be followed to prevent injury. Always turn the ignition off when: áReplacing distributor ignition components e. g. plugs, coil, etc. áDo not touch any part of the distributor ignition system while the engine is running. This may result in unintended movements and body injury.

  • Page 215: Volvo On Call

    1-800-263-0475 Mechanic certification Volvo supports Voluntary Mechanic Certification by the A. S. E. (pertains to the USA only). Certified mechanics have demonstrated a high degree of competence in specific areas. Besides passing exams each mechanic must also have worked in the field for two or more years before a certificate is issued.
  • Page 216 2001 Volvo S60 Contents Top of Page file:///K|/ownersdocs/2001/2001_S60/01s60_12.htm (11 of 11)12/30/2006 3:47:15 PM...
  • Page 217 2001 Volvo S60 2 0 0 1 VOLVO Index pg. 203 Index A/ C (air conditioning) Accessory bracket Adjustable steering wheel Advanced User Mode (AUM) - radio Air bags - dual threshold/ stage Air distribution Air filter Air quality sensor...
  • Page 218 2001 Volvo S60 Automatic transmission - kickdown Auxiliary lamps Average speed Back up light Backrest Bass Battery Battery - replacing Belt check Booster cushion Booster cushion (integrated) Bottle holder Brake circuit Brake fluid Brake light Brake system Bulbs Capacities Cargo compartment...
  • Page 219 2001 Volvo S60 Child safety Child safety locks Child seat (Isofix fasteners) Cigarette lighter Climate control systems -general information Clock Coat hanger Coin compartment Cold weather precautions Coolant 169, Coolant - changing Coolant - checking level of Cooling system Courtesy light...
  • Page 220 2001 Volvo S60 Electric socket Electrical system Electrically operated windows Engine - starting Engine compartment Engine oil Engine oil, capacity Engine specifications Engine oil - checking Environment Federal Clean Air Act FIX NEXT SERVICE Floor mats Fog lamp Front seat - backrest...
  • Page 221 2001 Volvo S60 Geartronic Geartronic - kickdown Geartronic - manual shifting General information Generator Generator warning light Glove compartment Glove compartment - locking Grocery bag holder Handling Hazard warning flashers Head restraint - center, rear Headlight washer Headlight wiper blades...
  • Page 222 2001 Volvo S60 Integrated booster cushion Interior Interior lighting Intermittent wiping Introduction Isofix fasteners (child seats) Jack Jump starting Keylock Keys Kickdown LED illumination Lighting panel Load carriers Locking Locking steering wheel Locks Long distance trips Long loads - carrying...
  • Page 223 2001 Volvo S60 Normal turns (direction indicators) Occupant safety Octane rating Odometer Oil pressure Oil quality Oil viscosity Opening/ locking the trunk 133, P Park Paint Paint - color code Paintwork damage Parking brake Parking lights Pen holder Polishing Power seat...
  • Page 224 2001 Volvo S60 Rear suspension Rear window defroster Rearview mirror/ door mirrors Recirculation REDUCE SPEED Refrigerant (A/ C system) 126 , 127 Refueling Remote control - central locking system Replacing the battery Reporting safety defects Reverse gear inhibitor Roadholding Roof racks (load carriers)
  • Page 225 2001 Volvo S60 Spare tires Spare wheel Spark plugs Specifications Speedometer Spoiler lamps Stability system Start inhibitor (immobilizer) Starter switch and steering wheel lock Starting the car 34, 37, STC (Stability Traction Control) Steering wheel adjustment Steering wheel lock Stone chips...
  • Page 226 Uniform Tire Quality Grading Unlocking Unlocking the trunk Vanity mirror Vehicle Identification Number (VIN) Vehicle loading VIN (Vehicle Identification Number) Volvo and the environment Volvo On Call W - Winter Warning symbol in center of dashboard Warranties Washer fluid reservoir Washing the car...
  • Page 227 Your car is equipped with a sophisticated electronics system Any repairs, maintenance or fault tracing on this system should be done by an authorized Volvo retailer only Please consult your Volvo retailer if you have any questions before connecting accessory or optional equipment to the vehicle's electrical system...
  • Page 228 2001 Volvo S60 The following should be checked regularly:* 1. Washer fluid reservoir should be filled with water and solvent (wintertime: windshield washer anti- freeze). See page 149. 2. Power steering - When cold, the level must not be above the COLD mark and when hot it must not be above the HOT mark.
  • Page 229 2001 Volvo S60 pages 179 - 183 for more information on replacing bulbs. Contents Top of Page file:///K|/ownersdocs/2001/2001_S60/01s60_13.htm (13 of 13)12/30/2006 3:47:17 PM...
