AMobile PD602 User Manual

6” rugged mobile computing device
Hide thumbs

Advertisement

Quick Links

Download this manual
PD602
6" Rugged Mobile Computing Device.
User's Manual
Version 1.0
2023.11.22
I

Advertisement

loading
Need help?

Need help?

Do you have a question about the PD602 and is the answer not in the manual?

Questions and answers

Related Manuals for AMobile PD602

Summary of Contents for AMobile PD602

  • Page 1 PD602 6” Rugged Mobile Computing Device. User's Manual Version 1.0 2023.11.22...
  • Page 2 This page is intentionally left blank. - II -...
  • Page 3 Revision History Version Release Time Description 2023.10 Initial release - i -...
  • Page 4 We recommend that you keep one copy of this manual for the quick reference for any necessary maintenance in the future. Thank you for choosing AMobile products. - ii -...
  • Page 5 Contents Contents Preface ......................v Declaration of Conformity ..................v Emergency call .................... x FCC Warning: ..................... xi RoHS ......................xii SVHC / REACH ..................xii Safety Symbols ....................xiii Important Safety Instructions ................xiii Laser Safety ...................... xiv Rechargeable Battery Pack Safety ..............xiv General Cleaning Tips ..................
  • Page 6 Contents 3.1.3 Sleep Mode ..................17 3.2 Home Screen ....................18 3.2.1 Using the Quick Settings Panel ............20 3.2.2 Extending Home Screen ..............20 3.3 Using Cellular Network ................21 3.3.1 Making/Receiving Calls ..............22 3.3.2 Data Connection................22 3.3.3 Data Roaming ..................
  • Page 7 Device Storage temperature: -30° C to 70°C Working humidity 10% ~ 90%RH Hereby, AMobile Solutios Corp. Limited Taiwan Branch, declares that this Mobile Computing Device/ PD602, is in compliance with the essential Requirements and other relevant provisions of Radio Equipment Directive 2014/53/EU.
  • Page 8 Preface Charge at constant current of 0.2C until voltage reaches 4.25V, then charge at constant voltage 4.25V till charge current reduce to 0.02C. The following standards have been applied for the investigation of compliance: Use careful with the earphone maybe possible excessive sound pressure from earphones and headphones can cause hearing loss.
  • Page 9 Preface Product Name: 6" Rugged Mobile Computing Device Model No.: PD602 Brand Name: AMobile Battery: Manufacturer: Shenzhen cholipower Technology co.,Ltd Model No.: CLP1048 Rated Capacity:5000mAh 2nd 170mAh(Hot Swappable) USB Cable: Manufacturer: CHINGLUNG Model No.: 01.03.0012 Length: 1000mm ETSI EN 301 489-1 V2.2.3 ETSI EN 301 489-3 V2.3.2...
  • Page 10 Preface ETSI EN 301 908-1 V15.2.1 ETSI EN 301 908-2 V13.1.1 ETSI EN 301 908-13 V13.2.1 ETSI EN 303 413 V1.2.1 ETSI EN 300 330 V2.1.1 ETSI EN 301 893 V2.1.1 ETSI EN 300 328 V2.2.2 EN 62479: 2010 EN 50566: 2017/A1:2023 EN 50360: 2017/A1:2023 EN 62209-1: 2016 EN 62209-2: 2010...
  • Page 11 Preface Manufacturer Name: AMobile Solutions Corp Manufacturer Address: 8F.-1, No.700, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan Operation Frequency: GSM/GPRS/EGPRS 900: Tx: 880-915MHz, Rx: 925-960MHz GSM/GPRS/EDGE 850: 824-849MHz (Not used in Europe) PCS/GPRS/EDGE 1900: 1850-1910MHz (Not used in...
  • Page 12 Preface Max. RF output power: GSM900: 33 dBm WCDMA FDD Band: 24 dBm LTE FDD/TDD Band: 23 dBm WiFi (2.4G): 9.45 dBm EIRP WiFi (5G): 9.40 dBm EIRP Bluetooth: 6.48 dBm EIRP NFC: 15.38 dBμA/m The RF frequencies can be used in Europe without restriction. This product is intended for sale and application in a business environment.
  • Page 13 The URL to the full DoC https://www.amobile-solutions.com/download.htm Emergency call If any emergency arises, dial 112/911 (or other emergency call number) for emergency help. Due to the nature of cellular networking, the success of emergency call is not guaranteed. - xi -...
  • Page 14 FCC Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 15 -Consult the dealer or an experienced radio/TV technician for help. The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Mobile Computing Device PD602 model (FCC ID: 2AQ5W-PD602) has also been tested against this SAR limit. The highest reported SAR values for head, body- worn accessory, and product specific (Hotspot) are 0.78W/kg, 0.79...
  • Page 16 SVHC / REACH To minimize the environmental impact and take more responsibility to the earth we live, AMobile hereby confirms all products comply with the restriction of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration, Evaluation, Authorization, and Restriction of Chemicals) regulated by the European Union.
  • Page 17 Preface Important Safety Instructions Read these safety instructions carefully: 1. Read all cautions and warnings on the device. 2. Dropping it or letting it fall may cause damage. 3. Make sure the correct voltage is connected to the device. 4. For pluggable device, the socket outlet should be near the device and should be easily accessible.
  • Page 18 Preface To prevent possible hearing damage, do not listen at high volume levels for long periods Laser Safety The device's barcode scanner that uses laser lights is a class 2 laser product. DO NOT stare into the laser beams or point the laser beam at anyone's eyes when the barcode scanner is in operation.
  • Page 19 Preface If you are putting away the device for more than three months, it is recommended that get recharged every three months. If you store with an uncharged battery, it could fall into a deep worn-out state which would render it incapable of holding any charge.
  • Page 20 Preface You may need the following precautions before you begin to clean the device. When you clean any single part or component for the device, please thoroughly read and understand the details below. 1. We strongly recommended that you should shut down the system before you start to clean any single components.
  • Page 21 Preface • Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas in your keyboard, mouse, and other locations. • Foam swabs: Whenever possible, it is better to use lint-free swabs such as foam swabs.
  • Page 22 You can download the related technical documents such as datasheet and user’s manual as well as driver on our website. Please do not hesitate to call or e-mail our customer service when you still cannot get the information you need. http://amobile-solutions.com/web_en/contact.php E-mail: support@amobile. com.tw - xviii -...
  • Page 23 Preface Warranty This product is warranted to be in good working order during the warranty period. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
  • Page 24 This page is intentionally left blank. - xx -...
  • Page 25 <NCC 警語> 低功率射頻器材技術規範 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更 頻率、加大功率或變更原設計之特性及功能。低功率射頻器材之使用不得影響飛航 安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得 繼續使用。前述合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器 材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 應避免影響附近雷達系統之操作。 高增益指向性天線只得應用於固定式點對點系統。 減少電磁波影響，請妥適使用 SAR警語：「SAR 標準值：2.0 W/kg，送測產品實測值：_1.739_W/kg。」 視力警語「使用過度恐傷害視力」(具螢幕適用)。 視力注意事項(具螢幕適用)： （1） 使用30 分鐘請休息10 分鐘。 （2） 未滿2 歲幼兒不看螢幕，2 歲以上每天看螢幕不要超過1 小時。 記憶體容量資訊：內建主記憶體硬體容量： _4_ GB，使用者可使用主記憶體容量 至少： _1.7_ GB，可擴充記憶卡支援： _512_ GB以下。 - 21 -...
  • Page 26 Efforts should be made to avoid interfering with the operation of nearby radar systems. <Battery usage warning> Please use the original PD602 battery to avoid the risk of explosion. Adhere to local regulations when disposing of the battery. Do not disassemble, open, short circuit, or damage the battery.
  • Page 27 Chapter Introduction Chapter 1 Introduction - 23 -...
  • Page 28 Introduction 1.1 Product Highlights • PD602(4G) enabled rugged handheld device to benefit from speedy wireless communication. • PD602(4G)MediaTek MT8781 Octa-core (2xCortex A76 2.2GHz+ 6x Cortex A55 2.0GHz) • Support Android™ 13 • 6" IPS TFT LCD 720 x 1440 (FHD) •...
  • Page 29 Introduction 1.2 Package Contents Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: 6" Rugged Mobile Computing Device USB Cable USB Cable User Manual...
  • Page 30 Introduction 1.3 Parts of the Device Barcode Reader POGO Pins Receiver LED Indicator Front Camera P/L Sensor Rear Camera MIC. Power Key Flash Light SIM Card Fn Key Volume Keys Trigger Key Trigger Key 6” Display Battery Cover Battery Cover Latch Speaker Hand Strap Attachment Point 15.8...
  • Page 31 Introduction 1.4 Dimensions 15.8mm 81mm - 27 -...
  • Page 32 Introduction 1.5 Specifications Durability Features IP-67 and 1.5M with bump 1.5M (5ft.) drop-resistance System MTK 8781 2 x A76 2.2GHz + 6 x A55 2.0GHz Android™ 13 Memory Storage 64GB Integrated microphone Audio Integrated speaker Peripherals and Devices Camera Front: megapixel camera Rear:13.0 megapixel AF Accelerometer (G-sensor)
  • Page 33 Introduction Battery Capacity Main 5000mAh 2nd 170mAh (Hot Swappable) Battery Life Up to 8 hours battery life Charging 12V/1.5A Power Input USB Type-C Mechanical & Environmental Storage Temp. -30°C ~ 70°C (-22°F ~ 158°F ) Operating Temp. -10 ~ 50°C (14°F ~ 122°F ) 184 x 81 x 15.8 mm (7.2”...
  • Page 34 1.6 Label Location The label is on the middle frame of device, the user need to remove battery door and battery - 30 -...
  • Page 35 Getting Started Chapter Getting Started Chapter 2 Installation - 31 -...
  • Page 36 Getting Started 2.1 Installing microSD and SIM Card To install the microSD card and/or SIM card: Figure 2-1 Figure 2-2 Pull out the plug Lift using your nails through the groove. Figure 2-3 Figure 2-4 Take out the SIM Tray when it As the diagram shown, insert pops up.
  • Page 37 Be sure to charge the battery to full when you are charging it for the first time. Caution: Do not charge the PD602 via computer USB connection due to that the voltage output from computer USB is not enough to charge the device.
  • Page 38 Getting Started LCD STATUS Indicator The PD602 is not charging or nor cor- rectly connected Solid Red Battery charged 0~89% Green Battery Charger90~100% 2.3 Installing/Replacing the Battery Please contact qualified service personnel for battery replacement. 2.4 Optimizing Battery Life To optimize the operating time of the battery, it is recommended that you do the following: •...
  • Page 39 Using the Device Inserting the standard Battery Pack into the device: 1. Disconnect AC adapter and power cord from the device. 2. Turn the device over, back facing up. 3. Locate the Battery Lock Latch and push it to the "Unlocked" position. 4.
  • Page 40 Using the Device Chapter Using the Rugged Mobile Computing Device Chapter 3 Using the Device - 36 -...
  • Page 41 3.1 Using Touch Screen The PD602 comes with a projected capacitive multi-touch screen. Touch control is the main way to interact with the PD602. Users are able to manipulate icons, graphic buttons, menus, the onscreen keyboard or any onscreen items with touch control.
  • Page 42 Using the Device 3.1.2 Text Input The PD602 doesn't have a physical keyboard to receive user's text input. To input text on the device, it relies on the "onscreen keyboard" featured by the operating system. An "onscreen keyboard" is a virtual keyboard with most of the standard keys.
  • Page 43 Using the Device 3.2 Home Screen The Home screen provides you with an instant access to device status, notifications, application shortcuts, folders and widgets. Simply tap an item and you can launch the associated application. You can also add desired items to the Home screen, extend the Home screen or personalize the wallpaper to tailor it to your personal needs.
  • Page 44 Using the Device The table below describes the elements on a typical Home screen: Element Descriptions • Tap an item on this screen to launch that item. • To delete an icon or widget, tap and drag the item to the top of the screen until the Remove bar appears on the top of the screen.
  • Page 45 Using the Device 3.2.1 Using the Quick Settings Panel Swiping down the Status Bar will bring up a Quick Settings panel where you can quickly access some most commonly used settings and features. To enable/ disable a feature or switch between available options , simply tap the intended tile.
  • Page 46 Using the Device 3.3 Using Cellular Network After you insert the SIM card(s) to the PD602 for the first time and power on the PD602, depending on your mobile network carrier you might be guided to activate the account and connect to your mobile network. If you are asked for a PIN to unlock the SIM card when powering on the PD602, contact your cellular network carrier for the default PIN.
  • Page 47 Using the Device 3.3.1 Making/Receiving Calls After you activate your SIM card(s), the PD602 auto-connects to your cellular network when it powers on. You can start to use the phone service. Using phone service, e.g., making or answering a call, is similar to the way you use a mobile phone.
  • Page 48 Using the Device 3.3.3 Data Roaming When the PD602 moves to where your cellular network is not available, data roaming connects the PD602 to other service providers. This is often useful abroad if you want to keep receiving data across networks. However, the mobile rates can substantially increase as the costs for accessing the Internet are particularly high.
  • Page 49 The PD602 needs to be configured including such key to connect to a hotspot. Follow the guide below to connect the PD602 to your wireless local area network: Note: Turn off Wi-Fi when it isn’t used to extend battery life.
  • Page 50 (Ask your network administrator for details.) If the PD602 detects a network previously connected to, the PD602 auto- connects to it. Once a Wi-Fi network is connected, it displays as “connected” on the Wi-Fi settings screen.
  • Page 51 5. Tap Save. The PD602 then proceeds to connects to the Wi-Fi network. Any credentials entered are saved so the PD602 automatically connects it the next time the PD602 gets it within the range. - 47 -...
  • Page 52 Using the Device 3.4.3 Connecting to a Wi-Fi Network by WPS Wi-Fi Protected Setup (WPS) is a feature that allows WPS-compliant devices to connect to each other instantly in a secure way. As the WPS devices automatically configure the SSID and WPA security key, it eliminates the need for users to manually enter the SSID and password.
  • Page 53 Using the Device 4. WPS authentication process will start. When the authentication is done, you will be prompted that connection is successful. - 49 -...
  • Page 54 3.4.5 Making Your Device a Wi-Fi Hotspot When the PD602 is connected to a 4G network, you can share the connection with your laptop or other devices by making your G47 a Wi-Fi hotspot. To do so: 1. Swipe down the Status bar and tap SETTINGS | NETWORK & INTERNET | Hotsport &...
  • Page 55 Bluetooth-capable to synchronize data with other Bluetooth-capable devices such as PCs, laptops, hands-free, headsets, printers, PDAs and cell phones. Before the PD602 can connect a Bluetooth device, it needs to pair with that device. Such “pairing” involves the authentication between them to justify their accesses to each other.
  • Page 56 3. If the Bluetooth device you want to pair with is not displayed in the AVAILABLE DEVICES list, tap Pair new device. The PD602 proceeds to scan for any Bluetooth device in range. Then it displays the names of the device(s) found.
  • Page 57 Using the Device On the device to pair with, a dialog box appears requesting to enter or verify the pairing code. The passkey entered or shown on the PD602 and the Bluetooth device must be the same. If you’re prompted to enter a pin code, try entering 0000 or 1234 (the most common pin code), or look up in the documentation that came with the other Bluetooh device to learn its pin code.
  • Page 58 From the Bluetooth settings page, tap the menu icon on to get the following options: 1. Device name: Allows you to edit the Bluetooth name of the PD602 that will be shown to others when they try to search for it.
  • Page 59 Using the Device 3.6 Using the Location Feature The PD602 features positioning function to identify your location. It allows location-based Apps to collect and use your location information to provide location-related service. For example, a third-party App might want to pinpoint a vehicle’s location so as to provide a more efficient route for the driver upon traffic...
  • Page 60 Using the Device • Battery saving: This mode uses Wi-Fi and cellular networks to determine your location. Select this mode if you need to extend the battery life. • Device only: This mode determines your location using GPS only. Without using Wi-Fi and cellular networks to improve the startup process, it takes longer to determine the location.
  • Page 61 Using the Device When taking a photo: • To zoom in and out, place two fingers apart or together. • When you frame your subject on the screen, the camera will Auto Focus on the center of the screen with a focus indicator. To manually make a focus, tap the target or area that you want to focus on.
  • Page 62 4 centimeters. The NFC detection area is at the back side of the PD602. When you tap other NFC devices, tags, or readers, the NFC areas of both devices should be close to one another so that the connection can be established.
  • Page 63 3. Make sure the screen of both devices are unlocked, then touch the devices together, back to back. 4. On the PD602, you will hear a sound and be prompted a message "Touch to beam". Touch the screen of the PD602 to begin the beaming process.
  • Page 64 1. Find the black striped button on both sides of the PD602 device. 2. Press both the black striped button and the orange button simultaneously.
  • Page 65 If you encounter difficulties reading data, you can follow these steps to set the barcode specifications and attempt to read the data again: 1. Locate the "Barcode I-CON" on the top of the PD602 main screen. 2. Tap to enter "Barcode service is running."...
  • Page 66 Using the Device 3.9.3 Supported Barcode Formats 2D Model Type Formats Code 39, Code 128, Linear PDF417, QR Code, Aztec, Codablock-F, 2D Stacked Data Matrix 2D Matrix 100% UPCA Product code Australian Post Standard Customer, Planet Code 12, Royal mail 4-State, Postal USPS PostNet 5, USPS PostNet 9, USPS PostNet 11, UPU S10, - 62 -...
