Summary of Contents for Sharp QW-HT43F393A-EN
- Page 1 Home Appliances Dishwashing User Manual Fullsize Dishwasher QW-HT43F393A-EN QW-HT43F393W-EN For Life EN - 1...
- Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
- Page 3 CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................1 1.3. During Use........................2 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Drain Hose........................6 2.5. Electrical Connection ....................7 2.6.
- Page 4 8.CLEANING AND MAINTENANCE ................. 22 8.1. Cleaning the Machine and Filters ................22 8.2. Spray Arms ........................22 9.TROUBLESHOOTING ....................23 10.PRACTICAL INFORMATION ..................25 11.THE PRODUCT FICHE ....................26...
- Page 5 1. SAFETY INSTRUCTIONS 1.1. General Safety Warnings • Carefully read all instructions before using your appliance and keep this manual for future reference. Check the machine and its packaging for any damage. Never start using a damaged machine, contact an authorised service immediately. •...
- Page 6 • Follow the instructions on installing and connecting the machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Machine should be installed by authorised service only. Check whether the indoor electrical fuse system is connected according to regulations.
- Page 7 The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position. For models with the automatic door-opening system, when the EnergySave option is active, the door will open at the end of a program.
- Page 8 keep the door open for 30 minutes after a programme is complete. Do not stand in front of the door after the auto-open signal sounds. In the case of a malfunction, repair should only be performed by authorised service personnel. Otherwise, the warranty will be void.
- Page 9 CE Declaration of Conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
- Page 10 2. INSTALLATION new hose before connecting. 2.1. Machine positioning WARNING: Connect the hose directly to the water inlet tap. The pressure When positioning the machine, place it in supplied by the tap should be a minimum an area where dishes can be easily loaded of 0.03 MPa and a maximum of 1 MPa.
- Page 11 2.5. Electrical connection WARNING: Your machine is set operates at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. The earthed plug of the machine must be connected to an earthed outlet supplied by suitable voltage and current.
- Page 12 3. TECHNICAL SPECIFICATIONS 3.2. Technical specifications 15 place Capacity settings Dimensions (mm) Height 850(mm) Width 598(mm) Depth 598(mm) Net weight 62 kg Operating 220-240V voltage / 50 Hz, frequency Total current 10(A) Total power 1900(W) 3.1. General appearance 1. Worktop Maximum: 2.
- Page 13 4. BEFORE USING If the softener salt has overflowed and you do not start the machine immediately, run THE APPLIANCE a short washing program to protect your machine against corrosion. 4.1. Preparing your Dishwasher for first use • Check whether the electricity and supply water specifications match the values indicated in the installation instructions for the machine.
- Page 14 4.3. Test Strip Run water Keep the Shake the Wait Set the hardness level of through tap strip in strip. (1min.) your machine. (1min.) water (1sec) NOTE: Level is set 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.
- Page 15 4.8. Filling the detergent The factory setting is “3”. Push the latch to open the dispenser and If the dishes are not drying properly or are pour in the detergent. spotted, increase the level. If blue stains form on your dishes, decrease level. To do Close the lid and press it until it locks in this, remove the cap and rotate the indicator place.
- Page 16 5.2. Upper Basket The upper basket includes a mechanism which enables the height of the basket to be adjusted up (1) or down (2) without having to remove the basket. Hold the basket on both sides and pull it up or push it down, ensuring both sides of the upper basket are in the same position.
- Page 17 Upper Cutlery Basket The upper cutlery basket is designed for the placement of large and small cutlery and utensils. WARNING: Knives and other sharp objects must be placed horizontally in the cutlery basket. The basket is easily removed from the...
- Page 18 5.3. Alternative Basket Loads Lower Basket Top basket Incorrect loads EN - 14...
- Page 19 6. PROGRAMME TABLE Detergent A: 5cm³ Duration Programme Description B1: 15cm³ (min) B2: 25cm³ Prewash To rinse heavily soiled dishes before a wash programme. Fast programme intended for recently used dishes which are lightly Mini 18’ soiled. Suitable for 4 place settings. Quick 30’...
- Page 20 7. THE CONTROL PANEL a- Washing Cycle symbol b- Rinse Cycle symbol c- Drying Cycle symbol d- End Cycle symbol 7.1. Starting the Machine and Selecting a Programme Press the Power On/Off button (1). Select the programme most suitable for your dishes using the Up and Down Selection buttons (6, 7).
- Page 21 to add extra drying steps to a programme in order to obtain drier dishes. The Extra Drying Indicator (13) will illuminate. 4. Press the Start/Pause button (5) to start the selected programme. The display will show ‘Program Activated’. 5. The display (21) will show the symbols corresponding to the status of the programme in operation.
- Page 22 Press the Start/Pause button (5) to start the selected programme. ‘Programme Activated’ will appear on the display. “-“ Function cannot be selected. “ ” Function can be selected. √ ** Programmes are indicated generally and may differ among models. 7.2. Changing a Programme Adding Functions to a Programme Follow the steps below to change a programme while in operation.
- Page 23 7.3. Cancelling a Programme Polish Nederlands Swedish Czech Follow the steps below to cancel a Slovene Dansk programme while in operation. Hungarian Spanish - Press and hold the Start/Pause button (5) Portuguese for 3 seconds. - The display will count down 3 seconds 2.
- Page 24 Language : English remain illuminated during this period. The Remaining Time/Delay Time (18) Indicators Water hardness : L3 display the delay time. When the delay Volume : L2 time is complete, the selected programme Brightness : L2 will start. The display will show the time remaining of the programme in operation.
- Page 25 a qualified technician if this is the case. Call Service You can find more information in the “FAILURE CODES AND WHAT TO DO” section in your user guide. Selecting Eco/Normal Mode Press the Power On/Off button to switch the machine on. NOTE: The factory default setting for Eco mode is ON.
- Page 26 8. CLEANING AND the filters. Replace the filter insert, and MAINTENANCE rotate it clockwise (4). • Never use your Dishwasher without a Cleaning your Dishwasher is important filter. to maintain the machine’s service life. • Incorrect fitting of the filter will reduce Oil and lime may build up in your the washing effectiveness.
- Page 27 9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
- Page 28 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
- Page 29 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing Separate the inlet hose from the tap and clean the filter of Insufficient water the hose.
- Page 30 11. THE PRODUCT FICHE Supplier's trade mark SHARP QW-HT43F393A-EN/ Supplier's model QW-HT43F393W-EN Capacity of dishwasher The energy efficiency class A+++ Annual energy consumption in kWh per year (AEc) ( 280 Cycle )* Energy consumption (Et) (kWh per cycle) 0,84 Off-mode power consumption (W) (Po) 0,50 Left-on mode power consumption (W) (Pı)
- Page 32 Register your product here WWW.SHARPHOMEAPPLIANCES.COM, by registering with Sharp you become part of our For Life promise to always be there for you and your appliance. Visit our website: www.sharphomeappliances.com Or contact us: Service & Support %100 recycleable paper 52221060 R30...
