7. THE CONTROL PANEL

3 4 5
1
8 9 10 11
17 18 19
a
1. On/Off button
2. Confirmation button
3. Option button
4. Delay button
5. Start/Pause button
6. Up Selection button
7. Down Selection button
8. Extra Hygiene Indicator
9. Tablet Indicator
10. Half Load Indicator
11. Extra Fast Indicator
12. Extra Silent Indicator
13. Extra Drying Indicator
14. Salt Level Warning Indicator
15. Rinse Aid Level Warning Indicator
16. Child Lock Indicator
17. Delay Indicator
18. Remaining Time/Delay Time Indicator
19. Programme Number Indicator
20. Display Information Line
21. Washing Cycle Progress Indicators
6 7 8
2
12 13
14 15
20 21
b c d
22
a- Washing Cycle symbol
b- Rinse Cycle symbol
c- Drying Cycle symbol
d- End Cycle symbol
7.1. Starting the Machine and
Selecting a Programme
1. Press the Power On/Off button (1).
2. Select the programme most suitable
for your dishes using the Up and Down
16
Selection buttons (6, 7). These buttons
are used to browse the Programme,
Additional Functions, Delay and
Settings menus.
3. Additional functions (8, 9, 10, 11, 12,
13) can also be selected using the
Option button (3).
NOTE: Select the Extra Hygiene
function to increase the wash temperature,
for a maximum hygiene washing operation.
The Extra Hygiene Indicator (8) will
illuminate.
NOTE: Select the Tablet Detergent
function when using a combined detergent
that contains salt, rinse aid or other extras.
The Tablet Detergent Indicator (9) will
remain on for as long as it is selected.
NOTE: Select the Half Load function
to choose which area of the dishwasher
contains dishes to be washed. You can
select both baskets, the upper basket only,
or the lower basket only. Press the button
until the symbol corresponding to the
basket containing the dishes to be washed
illuminates. The Half Load Indicator (10) will
illuminate while this function is in operation.
Dishes placed in other areas will not be
washed.
NOTE: Select the Extra Fast function
to decrease the duration of a programme,
providing more economical water usage.
The Extra Fast Indicator (11) will illuminate.
NOTE: Select the Extra Silent function
for a more sensitive and silent washing
operation. The Extra Silent Indicator will
illuminate (12).
NOTE: Select the Extra Drying function
EN - 16
