Operator's manual (EPA II, CARB II)

227R 227RD 232R

232RD 235R

Please read these instructions carefully and make

English

sure you understand them before using the machine.

Need help?

Do you have a question about the 227R and is the answer not in the manual?

Questions and answers

Summary of Contents for Jonsered 227R

Page 1 Operator's manual (EPA II, CARB II) 227R 227RD 232R 232RD 235R Please read these instructions carefully and make English sure you understand them before using the machine.
Page 2 SYMBOL EXPLANATION Symbols Always wear approved protective WARNING! Clearing saws, gloves. brushcutters and trimmers can be dangerous! Careless or incorrect use can result in serious or fatal injury to the operator or others. Use anti-slip and stable boots. Read through the Operator‘s Manual carefully and understand the content before using the machine.
Page 3 What is what on the brushcutter? ........17 Your warranty does not cover damage or ASSEMBLY liability caused by the use of non- Assembling the handlebars (227R/RD, 232R/RD) .... 18 authorized accessories or replacement Assembling the handlebars (235R) ........18 parts.
Page 4 SAFETY INSTRUCTIONS Personal protective equipment The machine‘s safety equipment IMPORTANT INFORMATION This section describes the machine‘s safety equipment, its function and how checks and maintenance are carried out to • Incorrect or careless use of a clearing saw, ensure that it operates correctly. (See the chapter “What is brushcutter or trimmer can turn it into a dangerous what“...
Page 5 SAFETY INSTRUCTIONS 2. Stop switch 4. Anti-vibration system The stop switch should be Your machine is equipped used to stop the engine. with an anti-vibration system that has been designed to give as vibration-free and comfortable usage as possible. The use of incorrectly wound cord or blunt, incorrect cutting equipment (incorrect type or incorrectly...
Page 6 SAFETY INSTRUCTIONS 6. Muffler 7. Cutting equipment The muffler is designed to give the lowest possible noise 1) Clearing blades are level and to direct the intended for cutting wood. engine‘s exhaust fumes away from the operator. Muffler fitted with catalytic converter is also designed to reduce harmful exhaust components.
Page 7 SAFETY INSTRUCTIONS Control, maintenance and service of • See section "Start". Start the machine and apply full the machine‘s safety equipment throttle. Release the throttle and check that the IMPORTANT INFORMATION cutting equipment stops and remains at a standstill. • All service and repairs to the machine require If the cutting equipment special training.
Page 8 SAFETY INSTRUCTIONS 3. Cutting 5. Muffler attachment guard 1. Never use a machine that has a defective muffler. • Check that the guard is undamaged and not 2. Check regularly that the cracked. muffler is secure. • Replace the guard if it has 3.
Page 9 SAFETY INSTRUCTIONS 6. Cutting equipment 7. Quick-release This section describes how through correct maintenance and • Check that the harness through using the right type of cutting equipment you can: straps are correctly • Reduce the machine‘s tendency to kickback positioned.
Page 10 SAFETY INSTRUCTIONS Cutting equipment Sharpening the grass blade IMPORTANT INFORMATION • See the cutting The section describes how through correct mainte- equipment’s packaging for nance and through using the right type of cutting correct filing instructions. equipment you can reduce the machine‘s tendency to kickback, obtain maximum clearing capacity and increase the service life of the cutting equipment.
Page 11 SAFETY INSTRUCTIONS General safety instructions Fuel safety IMPORTANT INFORMATION • Always use a fuel container • The machine is only designed for trimming grass, with an anti-spill valve. brush cutting and/or forestry clearing. • The only accessories to be used with the engine •...
Page 12 SAFETY INSTRUCTIONS General working instructions 4. Take great care when cutting a tree that is subject to tension. A tree that is IMPORTANT INFORMATION under tension can spring back to its original position • This section takes up the basic safety precautions both before and after being for working with the clearing saw and trimmer.
Page 13 SAFETY INSTRUCTIONS Adjusting the harness and clearing saw Correct height 1) Forestry clearing Adjust the carrier strap so WARNING! When working with the clearing saw it that the suspension hook should always be hooked in the harness. If comes approximately 10 this is not done, you cannot control the cm under the hip.
Page 14 SAFETY INSTRUCTIONS Clearing‘s ABC Forestry clearing using a saw blade Always use the correct equipment. Always have well adjusted equipment. • When applying the blade Follow the safety instructions. to heavier stems the risk of Organise the work well. kickback increases. You Always use full throttle when applying the blade.
Page 15 SAFETY INSTRUCTIONS • Large stems must be cut Brush cutting using a grass blade from two sides. Determine in which • A blade is used for all direction the stem types of high or thick should fall. First apply grass. the saw to the felling side.
Page 16 SAFETY INSTRUCTIONS Grass clearing Trimming • The trimmer is ideal to using the trimmer cut grass that is difficult head and plastic to reach using a normal knifes lawn mower. Keep the cord parallel to the • Hold the trimmer head ground when cutting.
Page 17 WHAT IS WHAT? What is what on the brushcutter? 1. Blade 17. Clutch cover 2. Grease filler cap 18. Handlebar adjustment 3. Angle gear 19. Locking nut 4. Blade guard 20. Support flange 5. Shaft 21. Support cup 6. Handlebars 22.
Page 18 ASSEMBLY Assembling the handlebars Assembling the handlebars (235R) (227R/RD, 232R/RD) • Remove the screw at the rear of the throttle handle. • Remove the screw at the rear of the throttle • Slide on the throttle handle. handle on the right-hand side of the handlebars, (see •...
Page 19 ASSEMBLY Assembly of the blade and trimmer Assembling the blade guard and head clearing blade It is extremely important • Fasten the bracket(H) that the disc drive’s/support using the four screws (I). flange’s guide engages correctly in the cutting • The guard (A) is fitted equipment’s centre hole using 4 screws (L) as set when assembling the cutting...
Page 20 Assembling the spray guard and Assembling the spray guard and trimmer head Superauto II trimmer head Trimmy SII (235R) (227R/RD, 232R/RD) • Fit the guard (A) intended for use with the trimmer • Fit the guard (A) intended head. Secure using four...
Page 21 ASSEMBLY Assembling and dismantling the Adjusting the harness and clearing two-part shaft (227RD, 232RD) Assembling: WARNING! When working with the clearing saw it • Make sure the handle is should always be hooked in the harness. loose. If this is not done, you cannot control the clearing saw safely and this can result in injury to yourself or someone else.
Page 22 FUEL HANDLING Fuel mixture Mixture NOTE! • Always mix gasoline and oil in a clean container intended The machine is fitted with a two-stroke engine and must for fuel. always be run on a mixture of gasoline and two-stroke oil. It is •...
Page 23 START AND STOP Cold engine Control before starting IGNITION: Set the stop switch to the start position. For reasons of safety follow CHOKE: Set the choke these recommendations! control in the choke position. • Check the blade to ensure AIR PURGE: Press the air that no cracks have formed purge diaphragm repeatedly at the bottom of the teeth...
Page 24 MAINTENANCE Carburetor Basic setting • The carburetor is set to its basic setting when test run at the Your Husqvarna product has been designed and factory. The basic setting should be kept during the manufactured to specifications that reduce harmful machine‘s first working hours.
Page 25 MAINTENANCE Final setting of the idling speed T Correctly adjusted carburetor Adjust the idling speed with A correctly adjusted carburetor means that the machine the screw T, If it is necessary accelerates without hesitation and the machine 4-cycles a to readjust. First turn the little at max speed.
Page 26 MAINTENANCE Muffler Cooling system NOTE! To maintain as low opera- Some mufflers are fitted with a catalytic converter. See ting temperature as possible “Technical data” to see whether you clearing saw is fitted with a the engine is equipped with catalytic converter.
Page 27 MAINTENANCE Air filter Spark plug The air filter should be The condition of the spark cleaned regularly removing plug is affected by: dust and dirt to avoid: • An incorrect carburetor • carburetor malfunction setting. 0,5 mm • starting problems •...
Page 28 MAINTENANCE Sharpening the clearing blade NOTE: Use only HUSQVARNA replacement parts. Use of other brands of replacement parts can cause damage to your unit or injury to the operator or others. Your warranty does WARNING! not cover damage or liability caused by the use of accessories Incorrect cutting equipment or an and/or attachments not specifically recommended by incorrectly sharpened blade increases...
Page 29 TECHNICAL DATA Technical data 227R/RD 232R/RD 235R Engine Cylinder capacity, cu. in/cm 1,64/26,9 1,88/30,8 2,21/36,3 Cylinder bore, inch/mm 1,38/35 1,38/35 1,50/38 Stroke length, inch/mm 1,10/28 1,26/32 1,26/32 Idling speed, rpm 2 700 2 700 2 700 Recommended max. speed, rpm...
Page 30 TECHNICAL DATA Type Approved accessories 227R/RD Cutting attachment Centre hole in blades Ø 20 mm guard Art No. Threaded blade axle M10 Grass 255-4 (∅ 255 4-teeth) Grass blade 503 74 40-01 Grass 255-8 (∅ 255 8-teeth) 503 74 40-01 Multi 255-3 (∅...
Page 31 EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND WHAT IS COVERED REPAIR OR REPLACEMENT OF PARTS OBLIGATIONS Repair or replacement of any warranted part will be The EPA (The US Environmental Protection Agency), performed at no charge to the owner at an approved Environment Canada and Husqvarna Forest &...
Page 32 Super Auto II Super Auto II 1 " 4,0 m 15 cm ~2,0 m 6 " 6,5 ' 15 cm 6 " – English...
Page 33 Tri Cut >20mm >20mm 6 Nm X 10 English –...
Page 34 Trimmy H II 15 cm 6" 7,5 m ~ 3,7 m 15 cm 6" – English...
Page 35 Trimmy Hit “Click” 7,0 m 12 cm 5" ~ 3,5 m “Click” ~ 15 cm " 15 cm 6 " English –...
Page 36 Trimmy Hit Junior 5,75 m 15 cm 6" ~ 2,8 m 15 cm 6" 15 cm “Click” 6" – English...
Page 37 Trimmy Hit Pro 7,5 m 15 cm 6" ~ 3,7 m 15 cm 6" 15 cm “Click” 6" English –...
Page 38 Trimmy Hit VI 7,0 m 12 cm 5" ~ 3,5 m ~ 15 cm “Click” 15 cm – English...
Page 39 Trimmy SII 7,0 m 12 cm 5" ~ 3,5 m ~ 15 cm "Clic" 35-50 NM English –...
Page 40 Trimmy SII ~ 15 cm ~ 15 cm 502 26 04-01 502 25 56-01 502 25 53-01 729 53 27-71 (x3) 738 21 03-04 502 26 24-01 (x2) 740 43 14-00 502 26 03-01 502 25 52-01 502 26 01-01 735 31 19-00 502 27 07-01 502 26 86-01...
Page 41 English –...
Page 42 ´+H'=¶5@¨...
Page 43 English –...
Page 44 114 00 72-95 ´+H'=¶5@¨ 2002W07...
