- Page 1 Original User Manual – A S Sand Filter System REBO Sand Filter System AR-HE-SAS350FS, AR-HE-SAB350FS, AR-HE-SAG350FS Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
- Page 2 Original User Manual – A S Sand Filter System REBO Table of Contents 1. Safety Instructions ..........3 1.1 Explanation of the symbols ......................3 1.2 General Safety Instructions ......................4 1.3 Safety Instructions for electrical devices ..................4 1.4 Functional principle of the sand filtration system................. 5 2.
- Page 3 Original User Manual – A S Sand Filter System REBO Thank you for purchasing our product. Please read the operating instructions carefully before using the product for the first time. If you give the product to a third party, this manual must be handed over with it.
- Page 4 Original User Manual – A S Sand Filter System REBO 1.2 General Safety Instructions • The sand filter can be used with a temperature > than 0°C and < than 40°C. You should never operate the filter outside of these temperatures, otherwise damage may occur. •...
- Page 5 Original User Manual – A S Sand Filter System REBO • Check the nameplate of the pump for the following: • voltage, current consumption and cycle. • The power cable, including the ground cable, must be of 245 IEC 66 quality for models. For models with an input power of less than 1 kW, the quality must be 245 IEC57.
- Page 6 The permissible temperature is >0 degrees Celsius and <40 degrees Celsius. The pump must never be operated outside these temperatures as this may cause damage. 3. Technical Data Model Description AR-HE-SAS350FS, AR-HE-SAB350FS, AR-HE- SAG350FS Flow Rate (Pump) 9.5m Designated Flow Rate 6.8m...
- Page 7 Original User Manual – A S Sand Filter System REBO 5. Assembly Carry out the following steps and the corresponding illustrations for assembly (some parts are already pre-assembled). Note: Before filling the tank with sand, the filter system should be in a fixed location. Otherwise, it may be difficult to move the unit.
- Page 8 Original User Manual – A S Sand Filter System REBO 3.) Install the drain plug. a) Put the sealing on the thread of the plug. Put the valve from the inside through the hole of the tank. b) Put the Sealing on the outer side of the drain valve. Now screw the nut with the sealing against the outer wall of the tank.
- Page 9 Original User Manual – A S Sand Filter System REBO 5.) Set the black filter pipe into the tank. Use the pattern (10) before filling in the sand. This avoids filter material inside the filter unit. Fill in Pattern. 5. ) Fill the tank with sand (max. 20kg). Take away the pattern after filling.
- Page 10 Original User Manual – A S Sand Filter System REBO Caution: Avoid breathing in dust. Use a breathing mask approved for dust, sand and eye protection when filling the tank. a) Fill the tank with 1/3 water. b) Place the sand protection on the middle shaft of the distributor. This ensures that no sand gets into the distributor unit when filling the tank.
- Page 11 Original User Manual – A S Sand Filter System REBO b) Place the valve on the tank. Install the flange clamp around the tank and the valve flange. Tighten the valve just enough to allow it to rotate on the tank for final installation. c) Align the valve so that the pump connection points to the pump motor outlet.
- Page 12 Original User Manual – A S Sand Filter System REBO 8.) Pump to 7-way-Valve a) Mount the connections with O-Ring to the exit of the pump and to the gate of the valve. b) Connect the pump with the valve (“Pump”) by the hose (18) with reducer (19) and lock it with the clamps (11).
- Page 13 Original User Manual – A S Sand Filter System REBO c) Tighten both hose clamps. 9.) Disassemble the small plug and screw in the pressure gauge with the sealing. Do not overtighten! Keep the small plug stored.
- Page 14 Original User Manual – A S Sand Filter System REBO 6. Filter Function 6.1 Connection of the Filter System Caution: Before connecting hoses to the filter and pumping, make sure that no water can flow through the inlet or return hoses connected to the pool. Some pools have valves connected, others do not.
- Page 15 Original User Manual – A S Sand Filter System REBO Exit – filtered water (towards Pool) Inlet - dirty water (from pool) 6.2 Warnings 1.) Make sure that the filter operates below the working pressure and use a pressure control valve if the system uses a booster pump.
- Page 16 Original User Manual – A S Sand Filter System REBO 7. Use 7.1 Before use 1.) Check that all connections have been made correctly and securely. 2.) Press the upper valve handle and turn it to the backwash position. 3.) Bleed and start the pump according to the pump instructions. NOTE: All suction and discharge valves must be open when starting the system.
- Page 17 Original User Manual – A S Sand Filter System REBO Backwash: For cleaning the filter. When the filter pressure gauge rises 9-10 PSI (0.55-0.69 BAR) above start-up (clean pressure). Rinse: After backwashing, set the valve to RINSE with the pump turned off. Start the pump and let it run for about 1 minute.
- Page 18 Original User Manual – A S Sand Filter System REBO 9. Maintenance 9.1 Cleaning The screen basket in the filter tank should be checked and cleaned at regular intervals. 1.) Remove the lid and lift out the basket. 2.) Remove dirt and spray with water if necessary. 3.) Check the cover gasket, grease it with silicone grease only if necessary.
- Page 19 You can obtain the addresses from your city or local government. You can find out about other return options created by us on our website www.arebos.de. The separate collection of Waste electrical or electronic equipment is intended...
- Page 20 Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
