- Page 1 EN User Manual | Hob HKB95820NB aeg.com\register...
- Page 2 Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................8 4. PRODUCT DESCRIPTION................13 5.
- Page 3 • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. • If the appliance has a child safety device, it should be activated.
- Page 4 • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. • If the glass ceramic surface / glass surface is cracked, switch off the appliance and unplug it from the mains. In case the appliance is connected to the mains directly using junction box, remove the fuse to disconnect the appliance from power supply.
- Page 5 2. SAFETY INSTRUCTIONS 2.2 Electrical Connection This appliance is suitable for the following markets: IE GB WARNING! Risk of fire and electric shock. 2.1 Installation • All electrical connections should be made WARNING! by a qualified electrician. • The appliance must be earthed. Only a qualified person must install this •...
- Page 6 fuses removed from the holder), earth CAUTION! leakage trips and contactors. • The electrical installation must have an The use of a gas cooking appliance isolation device which lets you disconnect results in the production of heat, moisture the appliance from the mains at all poles. and products of combustion in the room The isolation device must have a contact in which it is installed.
- Page 7 2.5 Care and cleaning • The vapours that very hot oil releases can cause spontaneous combustion. • Used oil, that can contain food remnants, WARNING! can cause fire at a lower temperature than Do not remove the buttons, knobs or oil used for the first time.
- Page 8 3. INSTALLATION Gas Installation I.S. 813 Current Editions WARNING! Table Four. Refer to Safety chapters. Location The hob may be located in a kitchen, a 3.1 Before the installation kitchen/diner or bed sitting room (with a volume greater than 20 m³), but not in a Before you install the hob, write down the bathroom or shower room.
- Page 9 Connection to the gas supply should be with find this label in the package supplied either rigid or semi-rigid pipe, i.e. steel or with the appliance. copper. If the supply gas pressure is changeable or different from the necessary pressure, you The connection should be suitable for must fit an applicable pressure adjuster on connecting to R 1/2 (1/2 BSP male thread).
- Page 10 • Make sure that there is access to the mains plug after the installation. Electrical Requirements Permanent electrical installation must agree with the latest I.E.E. Regulations and local Electricity Board regulations. For your own safety the installation must be done by a qualified electrician (e.g.
- Page 11 3.8 Assembly To replace the connection cable use only H03V2V2-F T90 or equivalent type. Make sure that the cable section is applicable to the voltage load and the working temperature. The yellow/green earth wire (B) must be approximately 2 cm longer than the live and neutral wire (A).
- Page 12 CAUTION! If a furniture unit is installed at a Install the appliance only on a worktop distance of 400 mm above the hob, with flat surface. there must be a minimum safety distance of 50 mm to the left or right 3.9 Possibilities for insertion from the edge of the hob.
- Page 13 4. PRODUCT DESCRIPTION 4.1 Cooking surface layout 4.2 Control knob Symbol Description no gas supply / off position ignition position / maximum gas supply minimum gas supply Multi Crown burner Auxiliary burner 1 - 9 power levels Semi-rapid burner Control knobs 5.
- Page 14 WARNING! Be very careful when you use open fire in If the burner accidentally goes out, turn the kitchen environment. The the control knob to the off position and try manufacturer declines any responsibility to light the burner again after minimum 1 in case of the flame misuse.
- Page 15 Burner Diameter of Burner Diameter of cookware (mm) cookware (mm) Multi Crown 180 - 300 Semi-rapid (front right) 120 - 220 Semi-rapid (rear left) 120 - 240 Auxiliary 80 - 180 Semi-rapid (rear right) 120 - 240 6.2 Suggested recipes Food categories Recipes Burner type...
- Page 16 All recipes for approximately 4 portions. For an optimal delicate cooking use the auxiliary burner. The settings suggested in the cooking table should only serve as guidelines and be adjusted depending on the rawness of food, its weight and quantity as well as on the type of gas used and the material of the cookware used to prepare the dish.
- Page 17 The shape of pan supports and the amount of burners can be different in other models of the appliance. Do not lift the pan supports at an angle, as this will put strain on the metal pins. 7.4 Cleaning the hob This can cause damage to the pins and cause them to break.
- Page 18 8.1 What to do if... Problem Possible cause Remedy There is no spark when you try to The hob is not connected to an elec‐ Check if the hob is correctly connec‐ activate the spark generator. trical supply or it is connected incor‐ ted to the electrical supply.
- Page 19 8.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send this C.
- Page 20 POWER kW MARK G30 28-30 G31 37 mbar mbar Multi Crown 3,55 Semi-rapid Auxiliary 0,33 10. ENERGY EFFICIENCY 10.1 Product Information according to EU and UK Ecodesign regulations Model identification HKB95820NB Type of hob Built-in hob Number of gas burners ENGLISH...
- Page 21 Centre rear - Semi-rapid 57.9% Right rear - Semi-rapid 58.7% Energy efficiency per gas burner Left middle - Multi Crown 56.4% (EE gas burner) Centre front - Auxiliary not applicable Right front - Semi-rapid 58.7% Energy efficiency for the gas hob 57.9% (EE gas hob) EN 30-2-1: Domestic cooking appliances burning gas - Part 2-1 : Rational use of energy -...
- Page 24 867374423-C-122024...
