it's a personal experience
WATERGAMES
Installation Guide
Push type bath filler waste + overflow
WG-81389
This instruction booklet covers models:
WG-81389
(CP, MB, MW and SBR finish options)
Vado
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel 01934 744466.
fax 01934 744345
aftersales
vado.com
@
www.vado.com
Keep for future reference
Version 1, 1-11-23
Advertisement
Related Manuals for VADO WATERGAMES WG-81389
Summary of Contents for VADO WATERGAMES WG-81389
- Page 1 Installation Guide Push type bath filler waste + overflow WG-81389 This instruction booklet covers models: WG-81389 (CP, MB, MW and SBR finish options) Vado Wedmore Road, Cheddar, Somerset, England BS27 3EB tel 01934 744466. fax 01934 744345 aftersales vado.com www.vado.com...
- Page 2 Please read these instructions carefully before starting installation and keep for future reference. Remove all packaging and check the product for missing parts or damage before starting installation. Any alterations made to this product and fittings may infringe water regulations and will invalidate the guarantee.
- Page 3 1mm - 11mm 32mm 70mm 920mm G1.1/2”...
- Page 4 Inlet elbow Overflow/waste assembly Rubber seal Overflow housing Overflow fascia Inlet elbow Hex key socket Outlet and Inner overflow pipe overflow slots Hex key Collet Outer overflow pipe The length of the overflow pipe can be adjusted by pulling apart or pushing together the inner and outer overflow pipes.
- Page 5 Plug Seal Waste flange with seal Push down to open the plug. Push down again to close the plug. Overflow pipe Seal Compression Overflow/waste Washer assembly Seal Push the seal onto the waste assembly From below push the assembly up under the hole in the bath, and hold in place. From inside the bath screw the waste flange into the assembly and tighten by hand, (do not over tighten as this may damage the parts and/or the bath).
- Page 6 E&OE. NOTES: [1] Labour via our engineer network is only available in the UK. Attendance by a VADO engineer or sub-contract engineer will be under our standard terms and conditions. [2] VADO reserves the right to charge in advance for a product (or replacement part) pending collection and investigation (at VADO expense) to confirm a defect is due to a manufacturing issue.
