BEFORE BEGINNING YOUR INSTALLATION
Read through the instruction guide before getting started with the installation. Professional installation is recommended for
this product.
CONTENTS
Quad Trumpet Train Air Horn (Black)
200 PSI Air Compressor
5 Gallon Air Tank
12V Electric Air Valve (Solenoid)
240 PSI Pressure Gauge
170-200 PSI Pressure Switch
250 PSI Safety Valve
1/4" NPT Wing Style Drain Valve
1/4" NPT Compression Fitting for 1/4" OD Air Line
1/4" NPT Hex Head Male Plug
1/2" NPT Hex Head Male Plug x 2
1/4" OD Nylon Plastic Hose (6 Feet)
12mm Thread Sealant Tape (16 Feet)
30A In-line Fuse with Waterproof Holder
Remote Mount Air Filter
Horn Button
Mounting Hardware
The specific voltage requirement for this horn system is 12 volt DC, therefore installation must be done to a DC
power source of 12 volts.
SAFETY INSTRUCTIONS
Do not attempt to disassemble, repair or customize this product.
Avoid setting up any parts of this product where there is a risk of falling off or risk of coming in contact with water.
Avoid reaching out to touch or pick up any fallen or water submerged parts.
Never leave this product unattended during use.
Intended for use by adults only.
PAGE 1 of 6
VXO8350/4318B
INSTALLATION GUIDE
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vixen Horns VXO8350/4318B
Summary of Contents for Vixen Horns VXO8350/4318B
- Page 1 VXO8350/4318B INSTALLATION GUIDE BEFORE BEGINNING YOUR INSTALLATION Read through the instruction guide before getting started with the installation. Professional installation is recommended for this product. CONTENTS Quad Trumpet Train Air Horn (Black) 200 PSI Air Compressor 5 Gallon Air Tank ...
- Page 2 VXO8350/4318B INSTALLATION GUIDE During and immediately after use, avoid touching any part of the compressor with bare hands as it is very hot during such periods. Avoid sounding the air horn when in close range to your ear(s) or the ear(s) of others.
- Page 3 VXO8350/4318B INSTALLATION GUIDE COMPRESSOR MOUNTING Determine a dry place to mount your compressor. If you have chosen to install in the engine compartment, you should mount it as close to the front as possible to allow for maximum flow of air around compressor and also to avoid heat from the exhaust.
- Page 4 VXO8350/4318B INSTALLATION GUIDE AIR TANK MOUNTING Find a convenient mounting location in your vehicle for the air tank. Ensure ports are reachable before drilling any holes. Mark the location of holes using the mounting brackets of the air tank as a template, and then drill to size.
- Page 5 VXO8350/4318B INSTALLATION GUIDE ELECTRICAL CONNECTION COMPRESSOR The red wire of the compressor should be connected to (+) 12-volt power source. IMPORTANT: To prevent the compressor from over running and possible damage due to an air leak, connect the compressor’s red wire to a power source in the vehicle that only gets power when the vehicle’s ignition is on.
- Page 6 VXO8350/4318B INSTALLATION GUIDE MAINTENANCE Make sure that electrical and fitting connections are regularly inspected, cleaned and tightened when needed. Make sure mounting screws are regularly tightened if needed. Drain weekly, to avoid excessive buildup of condensation. Compressor features a washable air filter which should be cleaned using any mild form of liquid soap every two months if it gets dusty.
