- Page 1 Air conditioner User manual AC***DN6DCG • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this manual carefully and retain it for future reference.
- Page 2 Contents Safety Information Safety Information At a Glance Indoor Unit Overview Operation Features Operating temperature and humidity Cleaning and Maintenance Cleaning and Maintaining Cleaning the indoor unit exterior • Removing the air filter Cleaning the air filter • Reinstalling the air filter Periodic maintenance Troubleshooting 2 English...
- Page 3 Safety Information California Proposition 65 Warning (US) Cancer and Reproductive Harm - WARNING: www.P65Warnings.ca.gov. Before using your new air conditioner, please read this manual thoroughly to ensure that you know how to operate the extensive features and functions of your new appliance safely and efficiently. Because the following operating instructions cover various models, the characteristics of your air conditioner may differ slightly from those described in this manual.
- Page 4 Safety Information Follow directions. Do NOT attempt. Make sure the machine is grounded to prevent electric shock. Cut off the power supply. Do NOT disassemble. Symbol Meaning Flammable gas Flammable materials Refrigerant Refrigerant safety group Safety Group Read operating manual Refer to operating manual Read service manual 4 English...
- Page 5 FOR INSTALLATION WARNING Use the power line with the power specifications of the product or higher and use the power line for this appliance only. In addition, do not use an extension line. • Extending the power line may result in electric shock or fire. •...
- Page 6 Safety Information This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line. • Failure to do so may result in electric shock, fire, an explosion, or other problems with the product. CAUTION Install your appliance on a level and hard floor that can support its weight.
- Page 7 Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a metal object, place a heavy object on the power line, insert the power line between objects, or push the power line into the space behind the appliance.
- Page 8 Safety Information To reinstall the air conditioner, please contact your nearest service center. • Failing to do so may result in problems with the product, water leakage, electric shock, or fire. • A delivery service for the product is not provided. If you reinstall the product in another location, additional construction expenses and an installation fee will be charged.
- Page 9 • Since this may be dangerous due to a lack of oxygen, open a window at least once an hour. Do not use means to accelerate the defrost operation or to clean, other than those recommended by Samsung. Do not pierce or burn. Be aware that refrigerants may not contain an odor.
- Page 10 Safety Information CAUTION Do not place objects or devices under the indoor unit. • Water dripping from the indoor unit may result in fire or property damage. Check that the installation frame of the outdoor unit is not broken at least once a year. •...
- Page 11 Do not spray volatile material such as insecticide onto the surface of the appliance. • As well as being harmful to humans, it may also result in electric shock, fire or problems with the product. Do not drink the water from the air conditioner. •...
- Page 12 Safety Information FOR CLEANING WARNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner, alcohol or acetone to clean the appliance. • This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, cut off the power supply and wait until the fan stops.
- Page 13 Indoor Unit Overview Square panel Circular panel 01 Display 02 Remote control sensor (behind the front grille) 03 Air outlet 04 Front grille / Air filter (behind the front grille) NOTE • For information on how to operate the product, see the user manual for the remote control.
- Page 14 Operation Features Operating temperature and humidity OPERATIONAL TEMPERATURE INDOOR MODEL MODE HUMIDITY INDOOR OUTDOOR 64 ℉ to 90 ℉ -4 ℉ to 122 ℉ Cool 80% or less AC018DN6DCG (18 ℃ to 32 ℃) (-20 ℃ to 50 ℃) AC024DN6DCG 86 ℉...
- Page 15 Cleaning and Maintaining Cleaning the indoor unit exterior Wipe the surface of the unit with a slightly wet or dry cloth when needed. Wipe off dirt from odd-shaped areas by using a soft brush. CAUTION • Do not use alkaline detergent, sulphuric acid, hydrochloric acid, or organic solvents (such as thinner, kerosene, and acetone) to clean the surfaces.
- Page 16 Cleaning and Maintaining Cleaning the air filter NOTE • Clean the air filter once every two weeks. • Spray water or use a vacuum cleaner to remove dust. • After removing dust, dry the air filter completely. – Avoid direct sunlight. Failure to do so may deform the air filter. Reinstalling the air filter 16 English...
- Page 17 After cleaning and reassembling the air filter, be sure to reset the filter-cleaning reminder as follows : • Indoor unit with the wired remote control: a. Press the button to display the Option menu. b. Press the button to select Filter Reset and press the button.
- Page 18 Cleaning and Maintaining Periodic maintenance Requires qualified Unit Maintenance item Interval technicians Clean the air filter. At least once a month Clean the condensate drain pan. Once a year Required Indoor unit Clean up the heat exchange. Once a year Required Clean the condensate drainpipe.
- Page 19 Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expense. Problem Solution The air conditioner does • Because of the protective mechanism, the appliance does not start not operate immediately operating immediately to keep the unit from overloading. The air after it has been conditioner will start in 3 minutes.
- Page 20 Cleaning and Maintaining Problem Solution • Ensure the remote control is charged. • Make sure that nothing is blocking the remote control sensor. The wireless remote • Check whether any strong lighting sources are near the air conditioner. control does not operate. Strong light which comes from fluorescent bulbs or neon signs may interfere with the remote control.
- Page 21 Problem Solution • In the Cool mode, cool air does not come out if the set temperature is higher than the current temperature. – Remote control: Press the Temperature button on the remote control. Then rotate the Wheel until the set temperature (minimum: 64℉(18℃)) is set to lower than the current temperature.
- Page 22 Cleaning and Maintaining Problem Solution • If the air conditioner is running in a smoky area or if there is a smell entering from outside, ventilate the room properly. • If both indoor temperature and indoor humidity are high, operate the air conditioner in the Clean or Fan mode for 1 to 2 hours.
- Page 23 Memo English...
- Page 24 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT AMERICA 888-699-6067 (Samsung HVAC) www.samsunghvac.com...
