Kurzanleitung ARE i2 Familie /
1.
Auspacken /
unpacking
Bitte überprüfen Sie, dass der Packungsinhalt unbeschädigt ist. Im Fall einer Beschädigung die Komponenten keinesfalls in
Betrieb nehmen.
Please check product for shipping damage. If damaged, do not use under any circumstances.
2.
Bestimmungsgemäße Verwendung /
Das Lesesystem ARE i2 Familie ist zur drahtlosen Identifizierung mittels zugehöriger Transponder bestimmt. Bitte verwenden
Sie das Gerät nicht in explosionsgefährdeten Räumen und auch sonst für keine Anwendung, welche nicht der eigentlichen
Anwendung entspricht.
The reading system ARE i2 family is intended to be used with appropriate transponders to identify objects via contactless
interface. Please do not use in potentially explosive areas or use it for any other application but its intended use.
3.
Sicherheitshinweise /
Für eine zuverlässige Inbetriebnahme des Lesegerätes ist das in der Bedienungsanleitung beschriebene Vorgehen unbedingt
einzuhalten. Die vollständige Bedienungsanleitung befindet sich auf der beiliegenden CD. Eine Inbetriebnahme des Gerätes
ohne Beachtung der Bedienungsanleitung ist nicht zulässig.
To securely setup the reading system, please study the complete manual which can be found on the accompanying CD.
4.
Komponenten /
components
Der Betrieb des Lesegerätes ist nur mit Originalkomponenten der AEG Identifikationssysteme GmbH zulässig (Antenne,
Spannungsversorgungsstecker, etc.)
The use of the reading system is only allowed using original components of AEG Identifikationssysteme GmbH (e.g. external
antenna, power supply plug, etc.)
5.
Inbetriebnahme /
setup
Bitte beachten Sie unbedingt die vollständige Bedienungsanleitung auf CD. Ohne Beachtung der Bedienungsanleitung auf CD
ist ein Betrieb des Gerätes weder sinnvoll noch zulässig.
Please make sure to read the entire manual on CD. Without using the manual on CD, the use of the product is neither
reasonable nor allowed.
6.
Schnittstellen /
user interfaces
Spannungsversorgung /
power
Schnittstelle / interface: RS232, Parameter 19200 Baud (8N1), Profibus (PFB) (opt.), USB (opt.)
Pinbelegung sowie Befehlssatz siehe Bedienungsanleitung auf CD /
Short instruction ARE i2 series
intended use
security hints
supply: DC +9.....30Volt, min. 1,2Watt
pin assignment and instruction set see manual on CD
