- Page 2 6.0 CALIBRATION 7.0 FIELD TROUBLE SHOOTING GUIDE All ADTECH instruments are calibrated per your instructions This section offers a simple, first level trouble-shooting aid for at the factory. A calibration sticker located on the unit identifies an apparent instrument malfunction.
- Page 3 8.0 TABLES, OUTLINE/ MOUNTING INPUT CONTROLS � SENSITIVITY 16 POSITION SWITCH HYSTERESIS SWITCH FREQUENCY• RANGE Hz 30,000 15,000 7 ,500 3,750 1,1175 937.5 ZERO SPAN 4611.11 234.4 117.2 511.59 29.30 • Select the frequency range that is just equal to higher than the desired input full scale.
- Page 4 9.0 SPECIFICATIONS INPUT/OUTPUT INPUT SIGNALS a. Voltage (Amplitude): 10 mv to 100 vrms (0-5 KHz) 50 mv to 50 vrms (5 KHz to 30 KHz) b. Contact: Dry, 2 ma@ 24 vac rating c. Frequency Range: 0-30 Hz to 0-30 KHz Full Scale d.
