  • Page 1 NV40MZ / NV41MZ...
  • Page 3 Preface Notebook Computer NV40MZ / NV41MZ Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the NV40MZ / NV41MZ series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup °...
  • Page 11 Preface Contents Introduction ..........1-1 MB ....................A-6 Schematic Diagrams......... B-1 Overview ..................1-1 Specifications ..................1-2 System Block Diagram ..............B-2 External Locator - Top View with LCD Panel Open ......1-4 Processor 1/12 .................B-3 External Locator - Front & Right Side Views .........1-5 Processor 2/12 .................B-4 External Locator - Left Side &...
  • Page 12 Preface Audio Codec ................. B-30 Option BOM .................B-62 M Key PCIE SSD ................. B-31 USB Charger, TPM ..............B-32 USB, LED ..................B-33 IT5570 ..................B-34 RTL8111G ................... B-35 WLAN/BT ..................B-36 RTS5227S ..................B-37 Type-C USB3.0 ................B-38 Type-C, Retimer 1/2 ..............B-39 Type-C, Retimer 2/2 ..............
  • Page 13 Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the NV40MZ / NV41MZ series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g.
  • Page 14 Introduction Specifications Processor Options Video Adapter Intel® Core™ i7 Processor Intel Iris™ Xe Graphics (i7-1165G7, i5-1135G7) i7-1165G7 (2.80GHz), TDP 28W HDR Support Intel® Core™ i5 Processor Microsoft DirectX® 12 Compatible  i5-1135G7 (2.40GHz), TDP 28W Intel UHD Graphics (i3-1115G4, Pentium Gold 7505U, Latest Specification Information Intel®...
  • Page 15 Introduction Communication Dimensions & Weight Built-In 10/100/1000Mb Base-TX Ethernet LAN 324.9mm (w) * 225mm (d) * 17.6mm (h) 1.0M HD Camera Module 1.35g (Barebone and 49WH Battery) (Factory Option) Windows Hello Camera Module WLAN/ Bluetooth M.2 Modules: (Factory Option) Intel® Dual Band Wi-Fi 6 AX200 Wireless LAN (802.11ax) + Bluetooth (Factory Option) Intel®...
  • Page 16 Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera (Factory Option) Windows Hello Camera 2. *Camera LED *When the PC camera is in use, the LED will be illuminated in white. 3. Built-In Array Microphone 4.
  • Page 17 Introduction External Locator - Front & Right Side Views Figure 2 Front View FRONT VIEW Figure 3 Right Side View 1. Speaker 2. 2-In-1 Audio Jack (Headphone / Microphone) RIGHT SIDE VIEW 3. USB 3.2 Gen 2 Type-C Port 4. USB 3.2 Gen 1 Type-A Port 5.
  • Page 18 Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. RJ-45 LAN Jack 3. USB 3.2 Gen 1 LEFT SIDE VIEW Type-A Port 4. SD Card Reader 5. Thunderbolt 4 Port with Power Delivery (DC-In)* 6.
  • Page 19 Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. RJ-45 LAN Jack 3. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...
  • Page 20 Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT5570 1 - 8 Mainboard Overview - Top (Key Parts)
  • Page 21 Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU 2. Memory Slots DDR4 SO-DIMM Mainboard Overview - Bottom (Key Parts) 1 - 9...
  • Page 22 Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. DC-In Jack 2. Power Button 3. HDMI-Out Port 4. USB 3.1 Gen 2 Type-A Port 5. USB 3.1 Gen 2 Type-C Port 6. 2-In-1 Audio Jack (Headphone / Microphone) 7.
  • Page 23 Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Fan Connector 2. CMOS Battery Connector 3. M.2 Card Connector 4. WLAN/BT Connector 5. Speaker Connecto 6. Touchpad Connector 7. Battery Connector 8. SD Card Reader 9. USB 3.1 Gen 2 Type-A Port 10.
  • Page 24 Introduction 1 - 12...
  • Page 25 Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the NV40MZ / NV41MZ series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.
  • Page 26 Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...
  • Page 27 Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a removal and/or replacement job, take the following precautions: Power Safety Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other components Warning could be damaged.
  • Page 28 Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: 1. Remove the battery page 2 - 5 To remove the Keyboard: 1.
  • Page 29 Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn off the computer, turn it over. 2. Remove screws on the bottom case (Figure 1a). a. Remove the screws. 3. Carefully lift the bottom case up from point (Figure 1b). b.
  • Page 30 Disassembly Removing the Keyboard Figure 2 Keyboard Removal Turn off the computer, turn it over, remove the battery (page 2 - Remove screws from the bottom of the computer a. Remove the screws and Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use a special eject stick press at point to un-...
  • Page 31 Disassembly Removing the System Memory (RAM) Figure 3 RAM Module The computer has two memory sockets for 260 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR4 3200MHz. The main memory can be expanded up to 32GB. The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 32 Disassembly 5. Pull the latches to release the second module if necessary. 6. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 7. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot as it will go.
  • Page 33 Disassembly Removing the Wireless LAN Module Figure 4 Wireless LAN 1. Turn off the computer, turn it over to remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 4a).
  • Page 34 Disassembly Wireless LAN, and Combo Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.
  • Page 35 Disassembly Removing and Installing the M.2 SSD Module Figure 5 M.2 SSD Module M.2 SSD Removal Procedure Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard (Figure 5a).
  • Page 36 Disassembly Removing the CCD Figure 6 CCD Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. Lift up the inner frame and run your fingers around the inner frame of the LCD panel at the points as indicated by a.
  • Page 37 Disassembly 4. Disconnect the cable (Figure 7c). Figure 7 5. Remove the CCD module (Figure 7d). CCD Removal 6. Reverse the process to install a new CCD module. (cont’d.) c. Disconnect the cable. d. Remove the CCD mod- ule.  6.
  • Page 38 Disassembly 2 - 14...
  • Page 39 Appendix A: Part Lists This appendix breaks down the NV40MZ / NV41MZ series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.
  • Page 40 Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 page A - 4 Bottom page A - 5 page A - 6 A - 2...
  • Page 41 Figure A - 1 Top A - 3...
  • Page 42 Bottom Figure A - 2 Bottom A - 4 Bottom...
  • Page 43 Figure A - 3 LCD A - 5...
  • Page 44 Figure A - 4 A - 6 MB...
  • Page 45 Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the NV40MZ / NV41MZ notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...
  • Page 46 Schematic Diagrams System Block Diagram NV40MB/ME TigerLake U System Block Diagram 1.8VA / 1.5VS 2400/2666/3200 MHz Thunderbolt SHEET 46 DDR4 DDIA TPS65993ADYBGR RETIMER SHEET 27 3.3V,5V,3VS,5VS,CTL JHL8040R SHEET 40 SYSTEM SMBUS DDR4 DDIB SHEET 47 SHEET 38,39 HDMI SHEET 28 SO-DIMM A USB3.1 SHEET 25...
  • Page 47 EWTF02-104F4F-N 3.3VS 3.3V 100k_1%_0402_NTC R113 NV40MB 10K_04 EW TF02-104F4F-N BOARD ID THERM_VOLT BOARD_ID R111 10K_04 NV40ME/NV40MZ GPP_D11 GPP_D12 MODEL NAME 1:2 (4mils:8mils) R636 C905 Th e r m a l P C B NV40ME 3.3VS N T C 20K_1%_04 0.1u_10V_X5R_04...
  • Page 48 Schematic Diagrams Processor 2/12 U18B DDR4/LP4/LP5/LP5 CMD Flip LP4-LP5(NIL)/DDR4 (NIL)/DDR4 (IL) CP53 BT42 M_A_DQ_0_7 M_A_CLK_DDR1 DDR0_DQ0_7/DDR0_DQ0_7/DDR0_DQ0_7 DDR0_CLK_P1/DDR3_CLK_P/DDR3_CLK_P/DDR3_CLK_P CP52 BT41 M_A_DQ_0_6 M_A_CLK_DDR#1 DDR0_DQ0_6/DDR0_DQ0_6/DDR0_DQ0_6 DDR0_CLK_N1/DDR3_CLK_N/DDR3_CLK_N/DDR3_CLK CP50 BP52 M_A_DQ_0_5 DDR0_DQ0_5/DDR0_DQ0_5/DDR0_DQ0_5 NC/DDR2_CLK_P/DDR2_CLK_P/DDR2_CLK_P CP49 BP53 M_A_DQ_0_4 DDR0_DQ0_4/DDR0_DQ0_4/DDR0_DQ0_4 NC/DDR2_CLK_N/DDR2_CLK_N/DDR2_CLK CU53 CD42 M_A_DQ_0_3 DDR0_DQ0_3/DDR0_DQ0_3/DDR0_DQ0_3 NC/DDR1_CLK_P/DDR1_CLK_P/DDR1_CLK_P CU52 CD41 M_A_DQ_0_2 DDR0_DQ0_2/DDR0_DQ0_2/DDR0_DQ0_2 NC/DDR1_CLK_N/DDR1_CLK_N/DDR1_CLK...
  • Page 49 Schematic Diagrams Processor 3/12 U18C DDR4/LP4/LP5/LP5 CMD Flip LP4-LP5(NIL)/DDR4 (NIL)/DDR4 (IL) AL53 M_B_DQ_0_7 M_B_CLK_DDR1 DDR4_DQ0_7/DDR1_DQ0_7/DDR0_DQ4_7 DDR1_CLK_P1/DDR7_CLK_P/DDR7_CLK_P/DDR7_CLK_P AL52 M_B_DQ_0_6 M_B_CLK_DDR#1 DDR4_DQ0_6/DDR1_DQ0_6/DDR0_DQ4_6 DDR1_CLK_N1/DDR7_CLK_N/DDR7_CLK_N/DDR7_CLK AL50 M_B_DQ_0_5 DDR4_DQ0_5/DDR1_DQ0_5/DDR0_DQ4_5 NC/DDR6_CLK_P/DDR6_CLK_P/DDR6_CLK_P AL49 M_B_DQ_0_4 DDR4_DQ0_4/DDR1_DQ0_4/DDR0_DQ4_4 NC/DDR6_CLK_N/DDR6_CLK_N/DDR6_CLK AP53 AC42 M_B_DQ_0_3 DDR4_DQ0_3/DDR1_DQ0_3/DDR0_DQ4_3 NC/DDR5_CLK_P/DDR5_CLK_P/DDR5_CLK_P AP52 AC41 M_B_DQ_0_2 DDR4_DQ0_2/DDR1_DQ0_2/DDR0_DQ4_2 NC/DDR5_CLK_N/DDR5_CLK_N/DDR5_CLK AP50 M_B_DQ_0_1 M_B_CLK_DDR0 DDR4_DQ0_1/DDR1_DQ0_1/DDR0_DQ4_1...
  • Page 50 Schematic Diagrams Processor 4/12 SMB_DATA 1K_04 3.3VA SMB_CLK 1K_04 TBT-PCH_I2C_SDA *1K_04 R146 100K_1%_04 SPI_SCLK_R TBT-PCH_I2C_SCL *1K_04 SML0_DATA 499_1%_04 SML0_CLK 499_1%_04 U18E SMB_CLK *10K_04 R123 SW I# 3.3VA SMB_DATA SPI_SCLK_R SMB_CLK TPM(10_04)/ woTPM(15_1%_04) DJ37 DK21 *14mil_02 SPI0_CLK GPP_C0/SMBCLK SMB_CLK_DDR 25,26 SPI_HOLD#_0 R726 10_04 PCH_SPI_DQ3...
  • Page 51 Schematic Diagrams Processor 5/12 STRAP PIN Top Swap Override LOW = Disable (Default) STP_A16OVR HIGH =Enable Top Swap mode PCH_HDA_SPKR R204 *4.7K_04 3.3VS U18F PCH_GPP_B16 DC53 DR27 SSD1_PW R_DN# PCH_GPP_B18 GPP_B16/GSPI0_CLK GPP_D14/ISH_UART0_TXD DA51 DW27 dGPU_OVRM GPP_B18/GSPI0_MOSI GPP_D13/ISH_UART0_RXD DC49 DV25 GPP_B17/GSPI0_MISO GPP_D16/ISH_UART0_CTS# PCH_GPP_B22 PCH_HDA_SPKR...
  • Page 52 Schematic Diagrams Processor 6/12 HDA_SDO/HDA_SYNNC/HDA_BCLK/HDA_RST# CAP should be close PCH Trace Length <1" RB751S-40G 1K_04 R617 ME_W E U18G *2p_25V_NPO_02 C662 *2p_25V_NPO_02 C661 *2p_25V_NPO_02 C664 HDA_BITCLK#L 33_04 R648 DW15 DR38 HDA_BITCLK GPP_F8/I2S_MCLK2_INOUT GPP_R0/HDA_BCLK/I2S0_SCLK HDA_SYNC#L 33_04 R646 DW24 DU37 GPP_D19/I2S_MCLK1 GPP_R1/HDA_SYNC/I2S0_SFRM HDA_SYNC HDA_SDOUT#L DT37...
  • Page 53 Schematic Diagrams Processor 7/12 U18I SATA1_TXP *0.01u_16V_X7R_04 PCIE12_TXP/SATA1_TXP USB2P_10 USB_PP10 SATA1_TXN *0.01u_16V_X7R_04 USB_PN10 PCIE12_TXN/SATA1_TXN USB2N_10 C610 *0.01u_16V_X7R_04 SATA1_RXP SATA1_RXN PCIE12_RXP/SATA1_RXP C611 *0.01u_16V_X7R_04 PCIE12_RXN/SATA1_RXN USB2P_9 USB2N_9 PCIE_TXP11_W LAN PCIE11_TXP/SATA0_TXP BASE_U-Port Disabled--TGL EDS 576591 PCIE_TXN11_W LAN PCIE11_TXN/SATA0_TXN USB2P_8 WLAN PCIE_RXP11_W LAN PCIE11_RXP/SATA0_RXP USB2N_8 PCIE_RXN11_W LAN PCIE11_RXN/SATA0_RXN...
  • Page 54 Schematic Diagrams Processor 8/12 U18J 1.8VA 1.8VA DK47 CNVI_W T_D1P CSI_F_DP_1 CNVI_WT_D1P DM47 CSI_F_DN_1 CNVI_WT_D1N CNVI_W T_D1N DN49 CNVI_W T_D0P CSI_F_DP_0 CNVI_WT_D0P DR49 R424 CNVI_W T_D0N CSI_F_DN_0 CNVI_WT_D0N DN45 CSI_F_CLK_P CNVI_WT_CLKP CNVI_W T_CLKP DN47 *4.7K_04 *4.7K_04 CNVI_W T_CLKN CSI_F_CLK CNVI_WT_CLKN CNVI_RGI_DT CNVI_BRI_DT DU43...
  • Page 55 Schematic Diagrams Processor 9/12 Tiger Lake U K/20 POWER CONTROL TBTA-PCH_I2C_INT R328 *100K_04 3.3VA R853 *0_04 SYS_RESET# PW R_BTN# 10K_04 R180 *100K_04 R852 0_04 3.3VS VDD3 SYS_PW ROK AC_PRESENT *3.3K_1%_04 R179 100K_04 PCH_PW ROK R817 *10K_04 LOW-> 3.3 V R158 *10K_04 HIGH->...
  • Page 56 Schematic Diagrams Processor 10/12 VCCPGPPR_3P3_1P8 1.8VA U18M U18N VCCIN_AUX 1.8VA VCC_IN VCC_IN VCORE SVID R206 *0_04 c p u ( T O P AB12 CY18 3.3VA VCCIN_1 VCCIN_66 VCCIN_AUX_1 VCCPRIM_1P8_1 AC10 CY20 VCCIN_2 VCCIN_67 VCCIN_AUX_2 VCCPRIM_1P8_2 R208 0_04 C124 C121 C644 C108 AE10...
  • Page 57 Schematic Diagrams Processor 11/12 VCCIO_OUT U18O U18P U18Q U18R VCCSTG_OUT VDDQ PC14 0.1u_10V_X5R_04 AA39 BY44 CY44 DP53 VDD2_1 VCCSTG_OUT_1 VSS_223 VSS_289 VSS_109 VSS_169 VSS_2 VSS_46 AB40 AF12 BY45 CY45 DR11 VDD2_2 VCCSTG_1 VSS_224 VSS_290 VSS_110 VSS_170 VSS_3 VSS_47 AC39 AD12 BY47 CY47 DR16...
  • Page 58 Schematic Diagrams Processor 12/12 CFG[0]: Stall reset sequence after U18T PCU PLL lock until de-asserted: CFG_15 RSVD_TP_7 — 1 = (Default) Normal Operation; No R103 *1K_04 CFG14 CFG_14 RSVD_TP_8 stall. CFG_13 CFG_12 RSVD_TP_9 — 0 = Stall. CFG_11 RSVD_TP_10 CFG_10 CFG[1]: Reserved configuration...
  • Page 59 Schematic Diagrams VGA PCI-E, Straps, XTAL 1V8_AON HCB1608KF-300T60 GPU_PLLVDD NV3V3 PEXVDD 1uF x 3 1V8_RUN PEXVDD 4.7uF x 2 Under GPU U20Q Place near GPU R689 R688 PEXVDD 10uF x 2 C308 C323 C242 C307 C256 C318 COMMON *10K_04 10K_04 U20A PEXVDD 22uF x 2 Place between...
  • Page 60 Schematic Diagrams VGA Frame Buffer Interface U20B U20C COMMON 2/17 FBA 3/17 FBB COMMON FBA_D[31:0] FBB_D[31:0] FBA_D[31:0] FBB_D[31:0] FBA_D0 FBB_D0 FBA_D0 FBB_D0 FBA_D1 FBB_D1 FBA_D1 FBB_D1 FBA_D2 FBB_D2 FBA_D2 FBB_D2 FBA_D3 FBB_D3 FBA_D3 FBB_D3 FBA_D4 FBB_D4 FBA_D4 FBB_D4 FBA_D5 FBB_D5 FBA_D5 FB_REFPLL_AVDD FBB_D5...
  • Page 61 Schematic Diagrams VGA Frame Buffer A . 1 1 / 2 8 j a c k y FBVDDQ 15,17 FBA_CMD[33:0] FBA_CMD13 FBA_VREFC CA0_A VREFC FBA_VREFC FBA_CMD15 CA1_A FBA_CMD0 CA2_A FBA_CMD9 CA3_A FBA_CMD11 CA4_A FBA_D[31:0] FBA_CMD12 CA5_A FBA_CMD3 CA6_A FBA_CMD4 CA7_A COMMON FBA_CMD6 CA8_A...
  • Page 62 Schematic Diagrams VGA Frame Buffer A M10C M10D 15,16 FBA_CMD[33:0] FBA_CMD29 FBVDDQ CA0_A VREFC FBA_VREFC FBA_CMD31 CA1_A FBA_CMD16 CA2_A FBA_CMD25 C698 CA3_A FBA_CMD22 0.01u_16V_X7R_04 CA4_A FBA_D[63:32] FBA_CMD21 NV_VRAM CA5_A FBA_CMD24 CA6_A M10B FBA_CMD23 COMMON CA7_A M10A FBA_CMD26 CA8_A FBA_CMD17 NORMAL CA9_A FBA_CMD30 NORMAL...
  • Page 63 Schematic Diagrams VGA Frame Buffer B FBVDDQ 15,19 FBB_CMD[33:0] FBB_CMD13 FBB_VREFC CA0_A VREFC FBB_VREFC FBB_CMD15 CA1_A FBB_CMD0 CA2_A FBB_CMD9 FBB_D[31:0] CA3_A FBB_CMD11 CA4_A FBB_CMD12 CA5_A FBB_CMD3 CA6_A COMMON FBB_CMD4 CA7_A FBB_CMD6 NORMAL CA8_A FBB_CMD5 NORMAL CA9_A FBB_CMD8 CABI_A FBB_D0 FBB_D26 FBB_CMD7 DQ0_A DQ0_B...
  • Page 64 Schematic Diagrams VGA Frame Buffer B 15,18 FBB_CMD[33:0] FBB_CMD29 CA0_A VREFC FBB_VREFC FBB_CMD31 FBVDDQ CA1_A FBB_CMD16 CA2_A FBB_CMD25 C581 CA3_A FBB_CMD22 0.01u_16V_X7R_04 FBB_D[63:32] CA4_A FBB_CMD21 NV_VRAM CA5_A FBB_CMD24 CA6_A FBB_CMD23 CA7_A FBB_CMD26 COMMON CA8_A FBB_CMD17 NORMAL CA9_A FBB_CMD30 CABI_A FBB_CMD33 NORMAL CKE_A FBB_D50...
  • Page 65 Schematic Diagrams VGA I/O U20M U20L Hotplug Detection COMMON COMMON 6/17 IFPC 7/17 IFPD R160 1K_1%_04 IFPCD_RSET HDMI HDMI IFPC_AUX_SDA IFPD_AUX_SDA IFPC_AUX_SCL GPU_PLLVDD IFPD_AUX_SCL 40 mil IFPC_L3 IFPD_L3 IFPCD_PLLVDD IFPC_L3 IFPD IFPD_L3 Under GPU C288 TXD0 IFPC_L2 TXD0 IFPD_L2 TXD0 IFPC_L2 IFPD_L2 TXD0...
  • Page 66 Schematic Diagrams NVIDIA Power Sequence 3.3V NV_FBVDDQ_EN FBVDDQ_EN NV_EN_DOW N VIN_DOWN PEX_VDD_EN NV_PEXVDD_EN NV_NVVDDS_EN NV_OVERT# OVERT# NVVDDS_EN 1V8_AON_PW RGD SUSB# NVVDD_EN NV_NVVDD_EN 54,55 NVVDD_PW RGD 14,54 NVVDD_PW RGD NVVDDS_PWRGD 3V3_SYS_EN NV_NV3V3_EN 20,33 GC6_FB_EN GC6_FB_EN 1V8_MAIN_EN NV_1V8RUN_EN 55,59 GC6_FB_EN_PCH GC6_FB_EN_PCH 1V8_AON_EN NV_1V8AON_EN 10,30,31,33,34,35,36,39 BUF_PLT_RST#...
  • Page 67 Schematic Diagrams NVIDA GPIO Level Shift NVIDIA GPIO LEVEL SHIFT 3.3VS 3.3VS R691 100K_04 1V8_AON R717 1V8_MAIN_EN_R 1V8_MAIN 100K_04 Q15A SM2004KDW H GC6_FB_EN NVVDD NVVDDS VR Complex Q15B SM2004KDW H 1V8_MAIN_EN PEX&1.05V FBVDD/Q 1V8_MAIN_EN 20,21 Sheet 22 of 61 1.8V R692 *0_04 NVIDIA GPIO Level GPU_PWR_EN...
  • Page 68 Schematic Diagrams VGA PWR, GND, NC U20E NVVDD NVVDD U20D U20G U20F COMMON COMMON NVVDD COMMON 9/17 XVDD COMMON 13/17 NVVDD AA12 16/17 GND_2/2 15/17 GND_1/2 CONFIGURABLE AA14 AG11 AL18 POWER AA16 U20H CHANNELS AA19 AL20 XVDD AA21 AL21 FBVDDQ XVDD AA23 AL23...
  • Page 69 Schematic Diagrams VGA NVVDD Coupling FBVDDQ 10uF x 6 FBVDDQ 1uF x 12 FBVDDQ 22uF x 5 NVVDD 10uF x 34 NVVDD 0.1uF x 13 NVVDD 22uF x 15 Place Under GPU FBVDDQ FBVDDQ 10uF x 2 1uF x 6 Partition A NVVDD Place Under GPU...
  • Page 70 Schematic Diagrams DDR4 SO-DIMM A SO-DIMM A VDDQ VDDQ_VTT J_DIMMAA J_DIMMAB M_A_CLK_DDR0 CK0_T M_A_DQ_7_2 VDD19 2.5V M_A_DQ_7_4 M_A_CLK_DDR#0 CK0_C VDD18 M_A_DQ_7_5 M_A_CLK_DDR1 CK1_T VDD17 M_A_CLK_DDR#1 M_A_DQ_7_0 CK1_C VDD16 VPP2 M_A_DQ_7_3 VDD15 VPP1 M_A_DQ_7_6 M_A_CKE0 CKE0 VDD14 M_A_DQ_7_7 M_A_CKE1 CKE1 VDD13 3.3VS M_A_DQ_7_1 VDD12...
  • Page 71 Schematic Diagrams DDR4 SO-DIMM B SO-DIMM B VDDQ_VTT VDDQ J_DIMMBA J_DIMMBB M_B_CLK_DDR0 M_B_DQ_5_5 CK0_T VDD19 2.5V M_B_CLK_DDR#0 CK0_C M_B_DQ_5_7 VDD18 M_B_CLK_DDR1 CK1_T M_B_DQ_5_0 VDD17 M_B_DQ_5_2 M_B_CLK_DDR#1 CK1_C VDD16 VPP2 M_B_DQ_5_6 VDD15 VPP1 M_B_CKE0 CKE0 M_B_DQ_5_4 VDD14 M_B_CKE1 CKE1 M_B_DQ_5_3 VDD13 3.3VS M_B_DQ_5_1 VDD12...
  • Page 72 Schematic Diagrams Panel PANEL CONNECTOR (For coaxial cable) PANEL POWER eDP panel 30PIN PLVDD J_LCD1 HCB1608KF-121T30 C569 1u_6.3V_X5R_02 EDP_TXN0 C571 0.1u_10V_X5R_04 EDP_TXN_0 EDP_TXP0 C576 0.1u_10V_X5R_04 EDP_TXP_0 EDP_TXN1 C577 0.1u_10V_X5R_04 EDP_TXN_1 EDP_TXP1 C580 0.1u_10V_X5R_04 EDP_TXP_1 EDP_TXN2 C582 0.1u_10V_X5R_04 GND1 EDP_TXN_2 EDP_TXP2 GND1 C584 0.1u_10V_X5R_04...
  • Page 73 Schematic Diagrams HDMI HDMI CONNECTOR ( W/O LEVELSHIFT) HDMI_5VS 100mA VOUT C728 C725 J_HDMI1 HDMI HDMI C128G1-K1909-L APL3517A HDMI HDMI_HPD-C R226 HDMI 20K_04 HOT PLUG DETECT BY PLATF R O M R693 DDC/CEC GND HDMI_SDA-C BY PLATF R O M HDMI HDMI_SCL-C *150_1%_04...
  • Page 74 Schematic Diagrams Audio Codec *HCB1005KF-121T20 AUDIO CODEC ALC293D C506 0.1u_25V_X5R_04 C516 0.1u_25V_X5R_04 HEADPHONE_R R433 0_04 HEADPHONE_L CLOSE TO CODEC AUDG AUDG MIC1_VREFO_L SLEEVE Closed to ALC269VC2 Pins. > E >K' /'/d > SPKOUTL-_L 4R: 40mils RING2 SPKOUTL- 5VS_AUD 8R: 20mils R444 *0_04 HCB1005KF-121T20...
  • Page 75 Schematic Diagrams M Key PCIE SSD NGFF_M (M2) SSD (PCIE 4X) 3.3VS >120 mil R485 SSD1_3.3VS SATAGP1 J_SSD1 10K_04 C543 C542 C534 C528 H: PCIe(only) GND13 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 10u_6.3V_X5R_04 10u_6.3V_X5R_04 GND12 3.3V8 GND11 3.3V7 R484 1K_04 PCIE_SATA1 FOR OPTANE SUPPORT SATAGP1 PEDET(NC-PCIe/GND-SATA) 3.3V6...
  • Page 76 Schematic Diagrams USB Charger, TPM USB 3.0 port (CHARGER) VDD5 USBVCC_CH USB PORT Charge USB3.0 Max Trace length Smart CDP 80 mil Follow Design Guide pin8 pin4 Function VOUT 80 MIL C769 22u_6.3V_X5R_06 USBVCC_CH C770 22u_6.3V_X5R_06 DCP autodetect with C785 CLOSE TO CONNECTOR mouse/keyboard wake up C771...
  • Page 77 Schematic Diagrams USB, LED 3.3V 3.3V R228 *4.7K_04 R229 *0_04 R236 4.7K_04 R238 *0_04 with Redriver R237 4.7K_04 R239 *0_04 C372 C344 C371 R259 *4.7K_04 R261 2K_1%_04 0.01u_16V_X7R_04 0.1u_6.3V_X5R_02 1u_6.3V_X5R_02 R260 *4.7K_04 R262 0_04 I2C_SDA_20 I2C_SCK_20 USB CONNECTOR SIDE PCH SIDE USB3_TXN1_R USB3_TXN1_RM USB3_1TXNM...
  • Page 78 R362 0_04 IT5570 ESPI_RESET_N MODEL_ID Voltage R355 75K_04 KBC_AVDD VDD3 10,21,30,31,34,35,36,39 BUF_PLT_RST# R347 *62K_1%_04 NV40ME(G62) 3.3V MODEL_ID R437 10K_04 HCB1005KF-121T20 NV40ME/NV40MZ NV40MB(G61) VDD3 VDD3 R436 10K_04 C395 C464 C406 C400 C448 NV40MB/NV40MZ NV40MZ(UMA) 1.65V 10u_6.3V_X5R_06 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 C411...
  • Page 79 Schematic Diagrams RTL8111G LAN (RTL8111H LDO MODE ONLY) S H O R T (W>60mil R747 0_06 VDD10 L<200mil) REGOUT VDD10 (>60mil) C773 *SW F2520CF-4R7M-M C747 C742 R321 2.49K_1%_04 0.1u_6.3V_X5R_02 *4.7u_6.3V_X5R_06 *0.1u_6.3V_X5R_02 2015/11/26 RTL8111H L D O L a , C a , C b Mode : La , Ca , Cb , Ra , C c...
  • Page 80 Schematic Diagrams WLAN/BT CNVI WLAN/BT J_W LAN1 >40 mil GND13 3.3V3 W LAN_3.3V W T_CLKP CNVI_W T_CLKP WT_CLKP 3.3V2 W T_CLKN CNVI_W T_CLKN WT_CLKN PEWAKE1_N 11/14 W T_D0P GND12 CLKREQ1_N CNVI_W T_D0P WT_D0P PERST1_N W T_D0N CNVi CNVI_W T_D0N WT_D0N REFCLK0 NEW PART GND11...
  • Page 81 Schematic Diagrams RTS5227S BUF_PLT_RST# RTS5227S 10,21,30,31,33,34,35,39 BUF_PLT_RST# PCIE_RXN9_CARD PCIE_RXN9_CARD PCIE_RXP9_CARD PCIE_RXP9_CARD CLK_PCIE_CARD# CLK_PCIE_CARD# CLK_PCIE_CARD CLK_PCIE_CARD PCIE_TXN9_CARD PCIE_TXN9_CARD PCIE_TXP9_CARD PCIE_TXP9_CARD CARD_CLKREQ# CARD_CLKREQ# PCIE_W AKE# 10,30,33,34 PCIE_W AKE# SP7: internal pull-down 200k micro SD socke t , 3.3VS SD_WP(#29) G N D 3V3AUX 3V3AUX SD_W P#...
  • Page 82 Schematic Diagrams Type-C USB3.0 TYPE C USB3.0 3.3V 3.3V 3.3V_PA1 3.3V_PB1 USBVCC3.1_1 J_TYPEC1 100 MIL UCF3T-21S01-0P11 HCB1005KF-121T20 HCB1005KF-121T20 TYPEC USB3.1 C817 C816 C861 C811 C818 C853 C364 C745 C382 C412 A_UTXP_SW 1_J A_URXP_SW 1_J TYPEC USB3.1 TYPEC USB3.1 TX0_P RX0_P A_UTXN_SW 1_J A_URXN_SW 1_J C790...
  • Page 83 Schematic Diagrams Type-C, Retimer 1/2 +VCC3P3_LC_TCP0 +VCC0V9_SVR_TCP0 +VCC3V3_SX_TCP0 +VCC3V3_SX_TCP0 +VCC3V3_SVR_TCP0 U15D +VCC3V3_SVR_TCP0 INS16840369 U15C +VCC3P3A_SVR_TCP0 C876 SVR_VSS_2 VCC3P3_SX INS16840509 C843 C901 C855 C856 C862 SVR_VSS_1 +VCC3P3_ANA_TCP0 2.2u_6.3V_X5R_04 VCC3P3_ANA VCC3P3_SVR 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 VCC3P3_LC VCC3P3_SVR VSS_ANA VSS_ANA +VCC0P9_SVR_TCP0_PHASE SVR_IND_2 VCC3P3A VSS_ANA VSS_ANA C866 C869 SVR_IND_1...
  • Page 84 Schematic Diagrams Type-C, Retimer 2/2 U15B U15A INS16842080 INS16841958 TBT_EE_CLK EE_CLK I2C_SDA RETIMER_I2C_SDA TBT_EE_CS_N ALL THESE CAPS ARE STUFFED EE_CS_N I2C_SCL RETIMER_I2C_SCL TCP0_TX0_C_DP TBTA_TXRX1_P_R TBT_EE_DI C533 0.22u_10V_X5R_02 TCP0_TX0_DP ASSRXP1 BSSRXP1 EE_DI I2C_INT RETIMER_I2C_INT TCP0_TX0_C_DN TBTA_TXRX1_N_R TBT_EE_DO TC_RETIMER_FORCE_PW R C532 0.22u_10V_X5R_02 TCP0_TX0_DN ASSRXN1 BSSRXN1...
  • Page 85 Schematic Diagrams Type-C Con VCC3V3_PD R337 *0_04 TBTA_VBUS VBUS Source 5V,3A TBT_PA_VBUS HCB2012KF-800T80 80Ohm, 0.01Ohm DCR, 8A Idc MTDK5S6R main:6-21-B4K20-024 Q38A second: 6-21-B4K60-024 ACE_I2C_SDA2 R814 C559 J_TYPEC2 SMD_VGA_THERM 20,33 DX07S024JJ2 10K_04 1u_25V_X5R_06 TBTA_TX_1_P TBTA_TXRX_1_P TBT_RESET_N LDO_3V3 GPIO0_TBT_RESET_N TBTA_TX_1_N TX0_P RX0_P TBTA_TXRX_1_N TX0_N RX0_N...
  • Page 86 Schematic Diagrams Conn Fan, CCD, TP, LED KB TP Connect TP_VCC TP_VCC TP_VCC To T/P TP_VCC R803 *20mil short-p 3.3VS J_TP1 R427 C841 C842 T / P C836 TP_SMB_DATA_JJ 10K_04 R421 R420 R801 R802 1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 TP_SMB_CLK_JJ Q37A *10u_6.3V_X5R_04 SM2004KDW H 1K_04 1K_04 10K_04...
  • Page 87 Schematic Diagrams AC-In DC_JACK_R EMI Check MDU1721 PDC3906Z JDC_AC J_DC_IN1 ULTRASO-8 5.0A JDC_AC EML1 HCB2012KF-800T80 PC118 PC119 PR220 PR219 PD in PC122 PC121 PC123 PC120 4.7_06 4.7_06 SMAJ20A PR37 PN = 6-20-B3J00-003 100_06 Value = 2DC3061-045111F PC124 PCB Footprint = 2DC3061-045111F PD in PC125 PR38...
  • Page 88 Schematic Diagrams LED, LID SW LED function : LED_BAT_CHG LED_PW R 33,43 LED_BAT_FULL LED_ACIN 33,43 LED1 LED2 LED3 CLEVO POWER VAIO POWER ESD73034D LED2 LED3 VAIO R842 POWER ON LED R844 R845 R838 R839 1.5K_04 / AC IN VAIO 220_04...
  • Page 89 Schematic Diagrams VCCIN VCCST VR_EN PR25 10K_04 *CV-40mil 3.3V PC10 *0.1u_16V_X7R_04 DEFAULT SHORT 10,27,33 ALL_SYS_PW RGD PC12 3.3V PR26 PR27 PR28 PR29 0.1u_10V_X7R_04 *75_04 45.3_1%_04 *100_04 100_04 PR215 *100_04 H_PROCHOT# PR203 PR214 0_04 H_CPU_SVIDCLK PR213 0_04 1K_1%_04 H_CPU_SVIDALRT# PR212 0_04 H_CPU_SVIDDAT PR24 2_06...
  • Page 90 Schematic Diagrams VCCIN Aux 200_1%_04 330p_50V_NPO_04 10K_1%_04 *20mil short-p AUX_VCC_SENSE PC72 330p_50V_NPO_04 *20mil short-p AUX_VSS_SENSE PR164 PC74 14.3K_1%_04 47p_50V_NPO_04 PR162 33.2K_1%_04 PR163 PC75 6.19K_1%_04 0.1u_16V_X7R_04 PR167 3.01K_1%_04 PR18 *20mil short-p PR296 10K_04 PJ25 *CV-40mil 3.3V PR295 0_04 PC65 PC79 PC64 1.8VA_PW RGD PR171 PC90...
  • Page 91 Schematic Diagrams 1.8VA, 1.5VS VREG5 1.8VA PU18 PR115 AOZ2261NQI-11 0_06 PC179 PC170 PC175 3.3VA PC205 4.7u_6.3V_X5R_04 PR261 180K_1%_04 PR114 PR271 0_06 PC204 0.1u_16V_X7R_04 10K_1%_04 1.8VA_PWRGD PGOOD 1.8VA_PW RGD PR108 *10K_1%_04 VREG5 1.8VA PS_1V8_PFM POW ER 1.8VA PFM* POW ER 1.8VA PR263 POW ER 1.8VA PL12...
  • Page 92 Schematic Diagrams 3.3V, 5V, 3VS, 5VS, CTL DD_ON# SUSB VDD3 VDD3 R302 R687 100K_04 10K_04 SUSB SUSB DD_ON# DD_ON# 2SK3018S3 2SK3018S3 C752 10,31,46,48,51 SUSB# DEL J9 C722 31,33,37,49 DD_ON *CV-40mil *30p_25V_NPO_02 *0.1u_6.3V_X5R_02 R310 JUMP-1MM R690 0905 change footprint 100K_04 100K_04 C783 1000p_50V_X7R_04 C851...
  • Page 93 Schematic Diagrams V1.05A / VNN PR194 V1.05A BYPASS RAIL 3.3_06 PR218 0_04 V1.05A_EN PR207 0_04 PART NUMBER !LPM VOUT (V) PC105 V1.05A_EXT_OUT VCC_V1P05EXT_1P05 0.22u_10V_X5R_04 0(LPM) 1.05V CIHP-0420-1R0-M PJ19 1.05V 1.05V PC114 PC108 PC261 PC262 PC107 0.96V PC92 PC95 PC97 4.7u_25V_X5R_08 4.7u_25V_X5R_08 0.1u_25V_X7R_06 0.96V...
  • Page 94 Schematic Diagrams VDD3, VDD5 EN_3V PJ12 PR273 PR274 XLP_OUT DEFAULT SHORT 39K_1%_04 51K_1%_04 PJ11 EN_3V EN_5V PC232 *CV-40mil 1000p_50V_X7R_04 VREG3 PU20 2.5A PC223 PC224 PC225 PC208 PC213 PC244 PC243 PC250 PC207 VDD3 1u_6.3V_X5R_04 VREG3 PGOOD PC221 PR280 0_06 PR282 0_06 VBST2 VBST1 PC217 0.1u_10V_X7R_04...
  • Page 95 Schematic Diagrams VDDQ, VDDQ_VTT, 1.8VA PC227 PC229 PC228 VDDQ_R *RB0540S2 VDDQ_VTT(0.6V) G5616BRZ1U VDDQ(1.2V) 4/12 power change , layout PC47 VDDQ_VBST DEFAULT PC46 10u_6.3V_X5R_04 VDDQ_VTT VLDOIN VBST SHORT 0.1u_10V_X7R_04 DEFAULT PR121 VTT_MEM_R VDDQ_DRVH VDDQ_DRVH_R VDDQ SHORT DRVH VDDQ_R PL14 0_04 PJ23 PR119 BCIHP0730-1R0M *20mil short-p...
  • Page 96 Schematic Diagrams 2.5V, VCCST, VCCSTG VCCSTG VCCST VCC1P05_OUT_FET VCCSTG VCCST 60mA+150mA(VCCPLL) = 210mA VCC1P05_OUT_FET 20mA PU10 VCCSTG VOUT VCCST_OUT C633 C627 C636 VOUT *10u_6.3V_X5R_06 1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 C642 C635 C643 *10u_6.3V_X5R_06 1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 R630 VDD3 *33_04 R610 VDD3 *33_04 R616 *100K_04 R609 *MTDK3S6R VDD3...
  • Page 97 Schematic Diagrams Charger, AC-In SMART CHARGER OZ26786 PD13 PD14 MDL914S2 MDL914S2 PQ18 MDU1512 PQ17 ULTRASO-8 PDC3906Z PRS1 HCB2012KF-800T80 0.01_1%_32 PC214 PC235 PC215 PC218 PC245 PC226 PC237 PC242 PC238 PC240 PC219 PR130 PC55 PR279 PR277 3.3_06 1u_25V_X5R_06 PR125 PC220 PC247 PC241 PC246 PR287 PR286...
  • Page 98 Schematic Diagrams 3.3VA, NV3V3 NV3V3 ,10u c 2nd source G5016 EM5290 VDD3 Sheet 53 of 61 3.3V PCBfootprint: TDFN14-2X3MM-A C469 FA7601 3.3VA, NV3V3 NV3V3 C470 1u_10V_X5R_02 3.3VA 10u_6.3V_X5R_04 POW ER NV3V3 3.3VA OUT2 OUT1 OUT2 OUT1 VDD3 C463 C459 C458 R684 100p_50V_NPO_04 R677...
  • Page 99 Schematic Diagrams NVVDD1 Q28A Q28B *MTDK3S6R *MTDK3S6R NVVDD NVVDD I2CC_SCL_P R746 0_04 NVVDD 33,52 SMC_BAT I2CC_SDA_P R740 0_04 NVVDD 33,52 SMD_BAT NVVDD NVVDD *MTDK3S6R *MTDK3S6R Q26A Q26B NVVDD C772 *0.1u_25V_X5R_04 N H 5 0 R A N H 7 0 R A Q R749 *0_04 EC_GPIO...
  • Page 100 Schematic Diagrams NVVDD2 PWR_SRC_NV PC172 PC176 EMC2 0.1u_25V_X5R_04 PC151 1u_25V_X7R_06 M-C0603 PU13 M-C0603 3.3V PC152 1u_25V_X7R_06 GPU DECOUPLING NVVDD_DRMOS_VCC PR253 0_06 NVVDD PC157 EM-22BM66VC1 PR246 1u_6.3V_X6S_04 MP86941GQVT-Z 330uF_2V_5*5*4.2 x 6 pcs 2K_04 PR235 AGND NVVDD 2.2_06 NVVDD SYNC VTEMP/FLT NVVDD_DRMOS_VTEMP 54,55 NVVDD NVVDD...
  • Page 101 Schematic Diagrams PEX_VDD PU11 PEX_VDD PW R_SRC_NV_FB PR223 AOZ2261NQI-11 0_06 PEXVDD PEXVDD 3.3V PEXVDD PC142 PC143 PC141 PC144 4.7u_6.3V_X5R_04 PR225 PR229 100K_1%_04 *10K_1%_04 PR224 0_06 PC139 0.1u_16V_X7R_04 PEXVDD PEX_VDD_PW RGD PEXVDD PGOOD PEX_VDD_PW RGD PEXVDD 1.05V PR49 *10K_1%_04 PEXVDD PEXVDD PEXVDD PEXVDD PEXVDD...
  • Page 102 Schematic Diagrams FBVDDQ MP2988_FB_PWM1 PR78 0_04 FBVDD_PHASE1_PWM MP2988_FB_SDA PWM1 PR56 0_04 20,54 I2CC_SDA_P 1.2V~1.35V MP2988_FB_PWM2 PR81 0_04 FBVDD_PHASE2_PWM PWM2 FBVDDQ MP2988_FB_SCL PR55 0_04 20,54 I2CC_SCL_P PWM3 MP2988_FB_EN PR58 10K_04 NV_FBVDDQ_EN FBVDDQ FBVDDQ PR72 *10K_1%_04 FBVDDQ FBVDDQ PC117 PC137 PC136 NV3V3 PGOOD EC_GPIO 33,54...
  • Page 103 Schematic Diagrams DGPU Power Measurement Pre-Filter Switch NV3V3 VDD3 PW R_SRC_NV R780 R779 0_04 *0_04 PC180 NCP45492 NCP45492 Total Power 6/05 update POW ER VCORE PW R_SRC_NV_FB QFN32 C456 0.400 COMMON 1u_6.3V_X6S_04 NVVDD PWR_SRC_VINP_R PFM_CH1_BS_IN1 U812_VCC R768 75K_1%_04 NCP45492 BS_IN1 NCP45492 SMDRL1632L4-R005-FNH COMMON...
  • Page 104 Schematic Diagrams 1V8_AON/RUN, NV3V3 1.8VA 1.8VA C813 C788 C787 FA7601 10u_6.3V_X5R_06 10u_6.3V_X5R_06 *10u_6.3V_X5R_06 POWER 1V8 1V8_AON 1V8_RUN POWER 1V8 POWER 1V8 1V8_AON 1V8_RUN OUT1 OUT2 OUT1 OUT2 PR116 10K_04 1V8_AON_PWRGD C798 C797 POWER 1V8 100p_25V_NPO_02 100p_50V_NPO_04 POWER 1V8 POWER 1V8 1V8_AON_ON 1V8_RUN_ON R241...
  • Page 105 Schematic Diagrams Power Sequence NV40MB/ME Power On Sequence POWER SEQ. G3 to S0 VCC_RTC RTC BAT plug in RTCRST# 19.64ms VDD3 PWR_SW# VA_EC_EN 3.3VA 578.5us 1.8VA 883.5ms G3 to Power on 3.36ms VCCIN_AUX VNN_BYPASS 8.12ms 14.02ms V1.05A_EXT_OUT Sheet 60 of 61 RSMRST# 80.94ms 83.27ms...
  • Page 106 Schematic Diagrams Option BOM PWR U6+2 (must add PWR4+2) PWR U4+2 PWR U2+2 10u_6.3V_X5R_04 6-07-10611-2A0 PR108 53.6K_1%_04 6-13-53621-28C PR108 107K_1%_04 6-13-10731-28C 10u_6.3V_X5R_04 6-07-10611-2A0 PC49 390p_50V_X7R_04 6-07-39124-3A0 PC49 220p_50V_NPO_04 6-07-22134-1A0 10u_6.3V_X5R_04 6-07-10611-2A0 PR30 1.47K_1%_04 6-13-14711-28B PR30 1.47K_1%_04 6-13-14711-28B 10u_6.3V_X5R_04 6-07-10611-2A0 EMC4 0.01u_50V_X7R_04 6-07-10324-3A0 PR121...
