- Page 1 Repair Guide Basic Model HW-Q600B/ZA Applicable Mode HW-Q6*B HW-Q6**B Ver.1.0...
- Page 2 Contents 1. Precautions 1-1. Safety Precautions ..........................1-1 1-2. Servicing Precautions ..........................1-3 1-3. Precautions for Electrostatically Sensitive Devices (ESDs) ............1-4 1-4. Installation Precautions ........................1-5 2. Disassembly and Assembly 2-1. Disassembly ...............................2-1 2-1-1. Separate Rear case Assy......................2-1 2-1-2. Separate the Main ASSY KIT.....................2-2 2-1-3.
- Page 3 Samsung- authorized service provider. Any damage or defect to product resulting from a repair, or an attempt to repair, the product by any person other than a Samsung certified service provider will not be covered by the warranty.
- Page 4 Samsung’s liability in any case shall be limited to the greatest extent permitted by law. Samsung reserves the right, at its sole discretion, to change, modify, add or remove portions of any part of this manual at any time. It is your responsibility to check the manual periodically for changes. Your use of the manual...
- Page 5 Precautions 1. Precautions • Follow these safety instructions while servicing the ESD to prevent damage and to protect against potential hazards such as electrical shock and X-rays. • For continued safety, do not attempt to modify the circuit board. • Disconnect the AC power and DC power jack before servicing. Warning •...
- Page 6 Precautions 5. Insulation Resistance Cold Check: Antenna (1) With the unit’s AC plug disconnected from the AC source, Terminal connect an electrical jumper across the two AC prongs. (2) Set the power switch to ON. Exposed (3) Measure the resistance between the shorted AC plug and Metal Part any exposed metallic parts.
- Page 7 Precautions 1-2. Servicing Precautions • An electrolytic capacitor installed with the wrong polarity might explode. Warning • Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. Caution • If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.
- Page 8 Precautions 1-3. Precautions for Electrostatically Sensitive Devices (ESDs) • Some semiconductor (“solid state”) devices are easily damaged by static electricity. Such components are called Electrostatically Sensitive Devices (ESDs). Examples include integrated circuits and some field- effect transistors. The following techniques will reduce the occurrence of component damage caused by static electricity. 1.
- Page 9 5. Installing the product in a special place like below rather than normal environment may cause serious quality concerns due to its special conditions. If this is the case, make sure to contact a local Samsung service center before installing the product.
- Page 10 Disassembly and Assembly 2. Disassembly and Assembly • As this product has parts that are sensitive to static electricity, be careful when handling them. Warning 2-1. Disassembly • Disconnect the product from the power source before disassembly. • Follow these directions carefully; never use metal instruments to pry apart the cabinet. Caution •...
- Page 11 Disassembly and Assembly 2-1-2. Separate the Main ASSY KIT • Detach cables and remove screws. Remark - P/N : AH81-09811A , Type: 3.0mm*10mm (silver) FFC Cable • Lift the MAIN ASSY KIT upward. Remark • Separate the two cables from the MAIN ASSY KIT. Remark Separate the Assy PBA MAIN PCB 2-1-3.
- Page 12 Disassembly and Assembly Remark • Separate the MAIN PBA from the Bracket. 2-1-4. Separate the BT Module and Wireless Module from the Bracket • Separate the BT Module from the Bracket. And Remove 1 screw and unlock the FFC cable. - P/N : AH81-09810A , Type: 3.0mm*8.0mm (silver) BT Module Screw...
- Page 13 Disassembly and Assembly 2-1-5. Separate the Assy PBA AMP PCB • Remove 5 screws, Remove AMP PBA from Bracket. Remark - P/N : AH81-09810A , Type: 3.0mm*8.0mm (silver) 2-1-6. Separate the ASSY DECO-BUTTON • Remove 3 screws, Remove 2FFC cables. Remark - P/N : AH81-13954A , Type: 2.0mm*6.0mm (black) Assy SPK SUB...
- Page 14 Disassembly and Assembly 2-1-7. Separate the ASSY OLED • Remove 3 screws. Remove ASSY COVER SIDE R. Remark - P/N : AH81-09811A, Type: 3.0mm*10mm (silver) It will be impossible to reuse the "COVER SIDE R ② ① " once it is separated due to the double-sided ta pe will lose its adhesion.
- Page 15 Disassembly and Assembly 2-2. Assembly • Please assemble in reverse order of disassembly steps. • The exterior may differ depending on the product. Note ※ Cautions 1. Check if the MAIN PCB and AMP PCB are properly connected. If the connection is incorrect, the PCBs may be damaged. The power may not turn on, or abnormal operation may occur.
