Summary of Contents for Aqua aquaglass SPHERE + QUAD OBSP800QBBL
- Page 2 Pleas e read these instructions in full before installing ● IMPORTANT ● If this product is installed on top of shower tray, order to achieve a better water proof function, it is strongly suggested that the tray’s threshold width is not less than 60mm. ●...
- Page 3 IDENTIFICATION OF PARTS 2ES23 2ES36 2ES22 2ES37 2ES21 2ES01 2ES02 2ES03 2ES38 2ES06 2ES29 2ES09 2ES05 2ES30 2ES40 2ES31 2ES24 2ES32 2ES08 2ES33 2ES39 2ES34 2ES35 2ES25...
- Page 4 Fixings & fittings supplied Item No.: Part Quantity Item No.: Quantity Part 2ES01 2ES28 2ES29 2ES02 2ES03 2ES30 2ES05 2ES31 2ES06 2ES32 2ES33 2ES08 ST3.9 X35 2ES09 2ES34 2ES21 2ES35 2ES22 2ES36 2ES37 2ES23 2ES24 2ES38 2ES39 2ES25 2ES26 2ES40 8FR17 2ES27 2.5 mm...
- Page 5 A:Moving Panel Size B:Fixed Panel 800x800 246/478 X:Door Opening 900x900 346/537 Recommended shower 1000x1000 446/637 head position...
- Page 6 1 ASSEMBLYINSTRUCTIONS 2ES03 2ES02 2ES08 2ES05 ST3.9X35 -Put the wall pro file(2ES03) against the wall and ensure it is vertical using a spirit level. -Mark the holes on the wall. -Drill the holes accordingly. -Insert wall plug 2ES02 into the holes. -Fasten the wall profile on the wall with screw 2ES08 and washer 2ES05.
- Page 7 2 ASSEMBLYINSTRUCTIONS 2ES29 2ES38 - Insert fixing glass panels into wall profile. Please insert the big fixing panel 2ES38 into the left wall profile. Insert small fixing panel 2ES29 into the left wall profile.
- Page 8 3 ASSEMBLYINSTRUCTIONS 2ES36 2ES37 2ES28 2ES23 -Mount the rail pro file 2ES36 on the fixing panels by assembling fixing part 2ES23 and 2ES37. -Adjust the position of fixing panels to meet the openingrequirement.Please make sure the opening on top and bottom is the same. 2ES37 A≠B A=B(-1/+1mm)
- Page 9 4 ASSEMBLYINSTRUCTIONS -Measure the rail profile and fixing panels 8FR17 2ES25 2ES06 with spirit level to make sure the rail profile is in horizontal level and fixing glass panel in vertical level. -From the inside of cabin,insert vertical sealer 2ES06 between glass and wall profile.
- Page 10 5 ASSEMBLYINSTRUCTIONS 2ES33 2ES35 2ES39 -Put silicone glue on the back of bottom aluminum strip 2ES35, sliding guide 2ES39 and cover 2ES33. -Insert bottom aluminum strip 2ES35 in to the holesof sliding guide 2ES39 and cover 2ES33. -Put them on the bottom with sliding guide 2ES39 on the big fixing glass panel and cover 2ES33 on the small fixing glass panel.
- Page 11 6 ASSEMBLYINSTRUCTIONS 2ES30 2ES32 2ES21 2ES09 2ES24 2ES22 2ES34 -Apply vertical sealer 2ES09 on the edge of big fixing glass panel.Apply magnetic strip 2ES30 on the edge of small glass panel. -Mount top roller 2ES22 and anti-jump part 2ES21 on the top of door 2ES32. -Mount handle on door 2ES32 and make sure washers on 2 sides of glass before fasten -Apply bottom sealer2ES34 on the bottom of door 2ES32.
- Page 12 7 ASSEMB LYINSTRUCTIONS 2ES40 2ES31 -Apply vertical sealer 2ES40 and magnetic strip 2ES31 on the two edge of door 2ES32. Please make sure magnetic strip 2ES31 on the handle side. -Hang door 2ES32 on the rail profile with roller on top and anti-jump part in the channel of rail profile.
- Page 13 8 ASSEMBLYINSTRUCTIONS -The roller is adjustable to make sure door is vertical in good condition. 2ES26 -Take o ffthe cover on the back of roller.Turn the but with tool 2ES26. There is 4-5mm height to adjust. Please make sure the door has good matching close for magnetic strips.
- Page 14 9 ASSEMBLYINSTRUCTIONS - Put top cover 2ES01 on the top of wall profiles. 2ES01...
- Page 15 ASSEMBLYINSTRUCTIONS -Apply silicone sealant to the outside of the enclosure. -Please note:Do not apply silicone sealant to the inside of the enclosure. Silicone(according to the thick line position) where the vertical profiles meet the wall, parts meet parts and the glass panels meet the tray. Sealant drying times may vary in cold damp conditions Cleaning and Maintenance: and will be extended where thicker beads of sealant are...
