- Page 1 LFP.6144.W Series 51.2V LifePO4 Battery Installation Guide for EU & APAC Version 1.1...
- Page 2 The content in this document is believed to be accurate and reliable at the time of publication. However, MENRED ESS assumes no responsibility for any issues arising from the use of this material. MENRED ESS reserves the right to make changes to the content, specifications, or design of the product or document without prior notice.
- Page 3 Version 1.1, November 2024 Contents Disclaimers ..................1 Important Notice ................1 Choose and set up the installation location .........3 Requirements ................. 3 Restricted locations ................ 3 Clearance ..................3 Dimensions ..................5 Residential barrier ................5 Install the battery ................6 Configurations ................
- Page 4 Version 1.1, November 2024 Choose and set up the installation location Follow these requirements when choosing an installation site General guidelines and requirements The battery may be installed in an indoor location. The battery must be secured to a wall using the supplied mounting bracket and the installation location must be adjacent to a wall.
- Page 5 Version 1.1, November 2024 Sites exposed to direct sunlight or sites where the ambient temperature may exceed the specified maximum temperatures Near flammable materials or gases or explosive environments Clearance Observe the following minimum clearance: 20 cm from all sides of the battery module 30 cm from another battery moudle or any heat source, such as water heater unit, gas-fueled heater, air contitioning unit or any other equipment 100 cm from emergency exits...
- Page 6 Version 1.1, November 2024 Width Height Depth Battery Module 600mm 440mm 210mm Battery Dimensions Residential barrier To prevent the spread of fire, install a non-combustible barrier on the opposite side of the wall or structural surface where the battery is mounted. If the installation surface is not made of non-combustible material, a non- combustible barrier should be placed between the battery and the wall or structural surface.
- Page 7 Version 1.1, November 2024 Install the battery CAUTION! Before install modules, ensure that the battery power is off on all modules. Configurations The system features a modular and scalable design, allowing additional battery modules to be added as needed. Up to 16 battery modules can be paralleled, expanding the total system capacity to 98.24kWh.
- Page 8 Version 1.1, November 2024 Battery Module Description The images below provides an overview of the components in a single battery module. Battery Module Lifepo4 Battery 51.2V Installation Guide...
- Page 9 Version 1.1, November 2024 DC Bat - Connector Dip Switch DC Bat + Connector Reset Button Grounding Terminal COMM1 Communication Socket Power Button COMM2 Communication Socket CAN / RS485 Communication Socket Side View Front View Battery Module(LFP.6144.W) - Physical Overview Lifepo4 Battery 51.2V Installation Guide...
- Page 10 Version 1.1, November 2024 Parallel Capacity and Charge/Discharge Power The images below illustrate a connection method that scales both energy storage capacity and charge/discharge power master slave 1 slave 2 slave 15 Lifepo4 Battery 51.2V Installation Guide...
- Page 11 Version 1.1, November 2024 DC Bat+ Cable (Battery - Inverter) DC Bat- Cable (Battery - Inverter) Communication Cable (Master Battery CAN / RS485 Communication Socket - Inverter) Communication Cable (Master Battery COMM1 Communication Socket - #1 Slave Battery COMM2 Communication Socket) Communication Cable (#1 Slave Battery COMM1 Communication Socket - #2 Slave Battery COMM2 Communication Socket)
- Page 12 Version 1.1, November 2024 Parallel Capacity, not Parallel Charge/Discharge Power The images below illustrate a connection method that increases total energy storage capacity while keeping the system's charge/discharge power unchanged . master slave 1 slave 2 slave 15 Lifepo4 Battery 51.2V Installation Guide...
- Page 13 Version 1.1, November 2024 DC Bat+ Cable (Master Battery - Inverter) DC Bat- Cable (Master Battery - Inverter) Communication Cable (Master Battery CAN / RS485 Communication Socket - Inverter) Communication Cable (Master Battery COMM1 Communication Socket - #1 Slave Battery COMM2 Communication Socket) Communication Cable (#1 Slave Battery COMM1 Communication Socket - #2 Slave Battery COMM2...
- Page 14 Version 1.1, November 2024 Parallel CAN Communication Dial Settings Refer to the CAN communication dialing summary table to select the appropriate dial settings. Lifepo4 Battery 51.2V Installation Guide...
- Page 15 Version 1.1, November 2024 Lifepo4 Battery 51.2V Installation Guide...
- Page 16 Version 1.1, November 2024 Lifepo4 Battery 51.2V Installation Guide...
- Page 17 Version 1.1, November 2024 Lifepo4 Battery 51.2V Installation Guide...
