- Page 1 Energy Storage System Heinrich-Heine-Str. 76, 02943 Weißwasser, Germany Tel : ( 0 ) 3576 2167240 Fax : ( 0 ) 3576 2167242 info@menred-ess com www.menred-ess.com...
- Page 4 Table of contents 1 Safety ..............1 1.1 Disclaimer............1.2 Environmental requirements........ 1.3 Operating precautions......... 1.4 Warning labels............ 1.5 Emergency measures........... 2 Product..............2.1 Product overview..........2.2 Appearance............2.3 Specifications............3 Storage and Transportation........3.1 Storage............... 3.2 Transportation............ 4 Installation.............. 4.1 Installation location..........
- Page 5 1 Safety Thank you for using menred GmbH products. Please read this manual carefully before using this product and always observe the safety information in this section for proper use. Installation of this product must be carried out by qualified personnel. It is strictly forbidden to install, use, disassemble or modify the product without following the instructions.
- Page 6 1.2Environmental requirements > Do not expose the battery to direct sunlight for an extended period of time. > Do not expose the battery system to liquids. > Store the battery in a dry environment with low humidity to prevent corrosion. >...
- Page 7 1.4Warning labels Label Description Symbols Do not dispose in trash Lithium ion battery can be recycled Complies with EC guidelines Certification in Australia Care and maintenance Caution, risk of danger Menred GmbH in Weißwasser, Germany...
- Page 8 1.5Emergency measures The manufacturer has designed the product to minimize potential hazards and risks by taking foreseeable scenarios into account Nevertheless in the event that the following situation arises please take the following steps ◆Leakage When electrolyte leakage or abnormal odor occurs avoid contacting the leaking liquid or gas and contact professional personnel immediately...
- Page 9 2 Product 2.1 Product overview The intended use of menred GmbH Energy Storage System (ESS) product is to provide an efficient and reliable way to store excess energy generated from renewable energy sources like solar or wind. The battery is designed to store this excess energy and release it when needed, such as during periods of high energy demand or when renewable energy sources are not available.
- Page 10 1 :Power switch 2 Negative power connector 3 Positive power connector 4 Grounding screw 5 Handle 6 Communication interface...
- Page 11 2.2.2 Dimension...
- Page 12 2.3 Specifications Model LFP.6144.W/LFP.6144.G Lithium Iron Phosphate (cobalt-free)-LiFePO4 Battery Cell 6.144kWh Energy Capacity 5.83kWh Usable Capacity 51.2Vdc Nominal Voltage 44.8Vdc-57.6Vdc Operate Voltage Range 120Amp Max Charge Current 120Amp Max Discharge Current 16pcs to 98.24kWh Max Parallel ≥ Cycle Life 6000times@0.5C&25℃ Battery discharge: -20℃...
- Page 13 3 Storage and Transportation 3.1 Storage > The storage environment should meet local regulations and standards. > The battery should be handled gently, and the battery should not be damaged. > The battery should be placed correctly according to the box markings, not upside down or sideways.
- Page 14 > The battery should avoid transportation in extreme temperatures, humidity, or vibration environments, and the best temperature is between 5-35℃. > If any leakage, deformation, or other abnormalities are found during transportation, immediately stop transportation and notify the local dangerous goods management agency. >...
- Page 15 1 Installation location ≥300mm ≥300mm ≥300mm 0≤d≤1000 ≥300mm ≥300mm ≥300mm ≥300mm ≥300mm 100≤d≤600 ≥300mm...
- Page 16 4.2 Installation tools Screw Driver Drill Wrench Pencil Tap Measure Multimeter Insulated Glove Safety Shoes Safety Goggle...
- Page 17 4.3 Installation procedures 4.3.1 Unpack Before opening the package, please check whether the outer packaging is intact. If serious packaging damage is found and the machine or parts are exposed, please immediately contact the seller or dealer to obtain after-sales support.
- Page 18 4.3.2 Wall-mounted installation Ø7 Ø5 10.5 4.3.3 Floor installation Ø7 Ø5 10.5...
- Page 19 4 Connections 4.4.1 Electrical connection 4.4.2 Communication interface Terminal Definition serial number RS485-B RS485-A CAN-H 8 7 6 5 4 3 2 1 CAN-L...
- Page 20 5 Operating guide The machine is equipped with a touch panel, and the inverter information can be configured through the control panel, meanwhile, the battery and BMS status can be viewed in real time. All of these operations can be easily performed by simply tapping the screen.
- Page 21 2 Status indication A. Working indication: when system is in working, white indication will be blink on. B. Failure Alarm: when there is a system failure, red indication will be blink on. C. Battery capacity: it is for quickly and easily read the battery capacity. Charging Discharging Status...
- Page 22 5.3 Protocol configuration Tap “ ” enter into system backend, and then tap “ ” to do the configuration as following steps. 5.3.2 Select inverter brand...
- Page 23 5.4 Battery status Here you can monitor cell status and read the system faulty if it occurs. 5.4.1 Cell voltage 5.4.2 Cell temperature...
- Page 24 5.4.3 Cell information 5.5 BMS Information Here you can monitor BMS status and read the system faulty if it occurs, “N” means normal, “Y” means failure. Tap and slide up or down to see more information.
- Page 25 Tap to see more information...
- Page 26 6 Maintenance guide The system provides two types of status indicators: LED indicator status and LCD display fault code. The LED indicator provides a simple and quick prompt, allowing users to quickly receive an alert. However, to identify the specific fault item, users need to view the three-digit fault code displayed in the lower-left corner of the LCD screen.
- Page 27 6.2 System error information and troubleshooting The system provides two types of status indicators: LED indicator status and LCD display fault code. The LED indicator provides a simple and quick prompt, allowing users to quickly receive an alert. However, to identify the specific fault item, users need to view the three-digit fault code displayed in the lower-left corner of the LCD screen.
- Page 28 Stop charging, and Over test the input current. Charging current Charge Cozy Blink Cozy Blink When it is normal, stopped protection continue to charge. Over Stop discharging, Restless Restless current Discharging and reduce the Blink Blink warning load consumption Over Stop discharging, Restless Restless...
