Device Overview
1
Different states of the Indicator Light:
Red Light: Power on
Blue Light: Initialized successfully
3
Indicator Light/Button
1
*Short press to alarm off when
the Home Hub Pro is emitting
a sound.
Speaker
2
WAN Port
3
LAN Port
4
2
Reset Button
5
3
microSD Card Slot
6
4
HDD Slot
5 7
6
USB port
8
7
DC Input Port
9
8
9
Install the Hard Drive
Note: Please make sure your device is powered off during the installation.
Step 1:
Remove the HDD slot cover. Press the release tab on the left and hold
the hollow part on the right simultaneously as you pull out the hard drive
bracket.
Step 2:
Fix your HDD to the bracket with provided screws.
HARD DRIVE
