SERVICE MANUAL

HR-J486EN/J486M/J683M

Regarding service information other than these sections, refer to the HR-J686M service manual (No. 82785).

Also, be sure to note important safety precautions provided in the service manual.

ESPECIFICAÇÕES

GERAL

Requisitos de Alimentação

: AC 110 V – 220 V` , 50 Hz/ 60 Hz

Consumo de energia

Sim

: HR-J683M 19 W

HR-J486M 17 W

Não

: 2.5 W

Temperatura

Em funcionamento

: 5°C to 40°C (41°F to 104°F)

Armazenagem

: –20°C to 60°C (–4°F to140°F)

Posição de Funcionamento : Apenas na horizental

Dimensões (C x A x P)

: 360 mm x 94 mm x 278 mm

Peso

: 3.3 kg

Formato

: VHS standard

Tempo máximo de gravação

: 210 min. com cassete de vídeo ST-210

: 630 min. com cassete de vídeo ST-210

VÍDEO/AUDIO

Sistema de sinal

: PAL-M- sinal de tipo cor e sinal monocromo

EIA, 525 linhas/60 campos, NTSC-sinal tipo

cor e sinal monocromo EIA, 525 linhas/60

campos (apenas para leitura)

Sistema de Gravação/

Leitura

: Cabeça DA-4 (Azimute duplo), sistema de

scan helicoidal

Racio de sinal-barulho

: 45 dB

Resolução horizental

: 230 linhas

Amplitude de frequência

Audio normal

: 70 Hz a 10,000 Hz

Audio Hi-Fi

(Apenas HR-J683M) : 20 Hz a 20,000 Hz

Entrada/Saída

: Ligações RCA (ENTRADA x 1, SAÍDA x 1)

VIDEOCASSETE

TV operation – Press and hold

TV button, then press POWER,

TV CH +/–, VOL +/–, TV/VCR

PROG.

POWER

CHECK

DISPLAY

TV/VCR

DAILY

WEEKLY

TIMER

CANCEL

ENTER

AUX

C.RESET

OSD

START

STOP

DATE

REW

PLAY

REC

STOP

PAUSE

POWER

TV CH +

VOL –

+ VOL

TV CH –

PUSH JOG

VIDEO (MONO)L—AUDIO—R

/OK

PUSH JOG

–

(The specifications shown pertain specifically to the model HR-J683M/J486M)

This service manual is printed on 100% recycled paper.

PLAY

REW

SP EP

VCR

REC

STOP/EJECT

PAUSE

SINTONIZADOR

Sistema de sintonizador

Alcançe dos canais

VHF

UHF

CATV

Saída RF

TEMPORIZADOR

Referência de relógio

Capacidade de Programa : 1 ano de temporizador

Reserva de tempo de

Memória

ACESSÓRIOS

Acessórios fornecidos

As especificações explicadas referem-se ao modo SP excepto especificado em

contrário.

O design E & O.E e especificações estão sujeitas a alteração sem aviso prévio.

M-PAL NTSC

NTSC/M-PAL

: Frequência–sintonizador sintetizado

: Canais 2–13

: Canais 14–69

: 113 Canais

: Canal 3 ou 4 (alterável; pré-ajustado

na fábrica para canal 3) 75 Ω

Não equilibrado

: Quartz

programável/8 programas

: Aprox. 6 meses.

Figura estimadas, baseada no

fornecimento de uma pilha nova; o

funcionamento concreto pode

variar.

: Cabo RF,

Unidade de controle remoto de

raios infravermelhos,

Pilha de lítio CR2025,

Pilha de tamanho "AA" x 2,

Adaptador*

* Não fornecido em certas áreas

No. 82809

September 2000
