Medequip TOI729 Assembly Instructions And User Manual

Fixed Arm Adjustable Height Commode - TOI729
Assembly Instructions and User Guide
Thank you for choosing the Fixed Arm Adjustable Height Commode. This user guide should be read carefully
before use as it contains important information about the products safe operation and maintenance.
WARNING: Max User Weight: 165kg (26st)
This product has been designed specifically to aid toileting requirements and consists of a coated tubular frame
with a cushioned over seat and back rest, covered in a flame retardant, waterproof vinyl covering as well as a
plastic hinged toilet seat and 5 litre pan and lid.
Assembly Instructions
• Carefully unpack and examine the product to ensure it is complete.
• Before use, check for any signs of damage e.g. cracked weld, flaking of paint, bent tube. If you spot any of
these issues, please contact your local MedeQuip office and refrain from using the product.
Do Not Attempt To Use If Product Is Damaged.
Operation Instructions
• Ensure legs of the commode are all set to the same height (see height adjustment)
• Please empty the potty at regular intervals and be aware of its maximum capacity of 5 litres.
• Do not attempt to move the commode whilst occupied or in use.
• To locate the potty in the commode, raise the toilet seat to a vertical position.
• By holding the sleeve or potty place on the support brackets ensuring an accurate location of the wide brim
on the brackets.
Medequip Assistive Technology Ltd Unit 2, Heathrow Summit Centre, Skyport Drive, Harmondsworth, UB7 0LJ
Tel: +44 (0) 208 750 1580 Fax: +44 (0) 208 759 2345 website: www.medequipuk.com
Product Details and Dimensions
WIDTH
DEPTH
SEAT WIDTH
SEAT DEPTH
SEAT HEIGHT MIN
SEAT HEIGHT MAX
WIDTH BETWEEN ARMS
WEIGHT CAPACITY
500 mm
520 mm
410 mm
410 mm
470 mm
622 mm
505 mm
165 kg (26st)
