Summary of Contents for Osenous SV-TCN
- Page 1 Model: SV-TCN User Manual Milaimore WiFi trail camera www.osenous.com...
- Page 2 . If you have any questions, feel free to contact us . We will reply to you in 24 hours. Access User Guide IOS / Android Milaimore Customer Service EMAIL : support@osenous.com WEB : www.osenous.com We will offer QUICK REPLACEMENT or FULL REFUND referring to any issues.
- Page 3 Table of Contents TABLE OF CONTENTS Package Includes Camera Overview Quick Start 06/07 Installation Camera Operation 09/13 Parameter Settings Using the Wall Bracket 15/18 WiFi Feature APP Function Settings Reviewing Your Photos/Videos 21/23 Trouble Shooting/FAQ...
- Page 4 Package Includes PACKAGE INCLUDES 1.WiFi Trail Camera 2.User Manual 3.32GB Micro SD Card 4.Fixed Bracket 5.Mounting Strap 6.Allen Wrench 7.Screw Plug Kit 8.USB Cable...
- Page 5 Camera Overview Infrared light WIFI Indicator Infrared light PIR indicator Lens Lock hole Lock hole Microphone Fixing nut PIR & sensor SHOT button Battery pack Right button Up button MENU button Left button REPLAY button Down button OK button USB interface TF slot DC INPUT Fixing nut...
- Page 6 + - + - MENU Quick Start REPLAY Install Batteries Insert a Micro SD Memory Card ON TEST MENU SHOT REPLAY Switch to TEST Mode Press MENU to Enter Setting MENU SHOT ON TEST OFF REPLAY Format Memory Card Factory data reset ON TEST OFF Settings Settings...
- Page 7 Installation LOADING BATTERIES - + - 1.Open the two latches on the right side of the trail camera, and to ensure maximum battery life, you should install 8 new 1.5V AA alkaline batteries into the battery slot.(Shift out Time and Date when the battery will reset the camera) 2.Recommend using a brand new battery.
- Page 8 Installation INSTALL THE SD CARD 1.The camera uses a Micro SD card(TF card) to save your photos (.jpg format) or videos (.avi format). Micro SD to a maximum 128GB are supported. 2.Formatting the micro SD card before using it for the first time. This can be done in “Format memory card”...
- Page 9 Camera Operation THREE BASIC OPERATION MODES The OFF mode is the safe mode when any actions need to be taken (e.g. Replacing the micro SD card or batter- mode ies, or transporting the device). In TEST mode, you can check and change the settings TEST of the camera by using its built-in LCD screen.
- Page 10 Parameter Settings SETTINGS Options: [Photo]: Capture photos with motion detection. [Video]: Capture videos with motion detection. Mode [Photo & Video]: Capture both photos and videos with motion detection. 1.The PIR Interval refers to is the time delay between one shot and the next. It is different from the trigger speed of a trail camera(the trigger speed is the amount of time it takes for the trail camera to take and record the photo once the camera detects an animal).
- Page 11 Parameter Settings SETTINGS Selects how many photos will be taken in sequence Capture per trigger.(Burst Images) Options:[1 photo]/[2 photos]/[3 photos]]. Set the length of each video clip recorded Video each time when motion is detected. Length Options:3-59 seconds or 1-10 minutes. Set the video resolution.
- Page 12 Parameter Settings SETTINGS Set resolution for still photos. The higher resolution, the Photo better image quality, but takes more power and storage Size space. Options:[48PM/32PM/24PM/20M/16PM/12M/8M/5M] Software Look up the firmware information of the camera. Opening this function, you'll be able to record sound while Audio recording a video.
- Page 13 Parameter Settings SETTINGS You can set the camera to start recording at a specifific clock time(Make sure you set the date and time of the camera accurately before using this setting). Select ON and set Start and Stop time for the active phase. The Timer settings made here apply to every day monitoring.
- Page 14 Parameter Settings SETTINGS Restore all camera settings to the factory default settings except time and date. Default Options:[Yes]/[No].
- Page 15 Using the Wall Bracket USING THE WALL BRACKET 1.Mark the drill holes by holding the foot of the wall bracket at the desired mounting location and marking the hole positions. 2.Use a drill with a 6 mm drill bit to drill the required holes and insert the plugs and insert the wall plugs flush with the wall.
- Page 16 WiFi Feature WIFI FEATURE NOTE ● APP Compatibility: Requires IOS13.0 or later,Android 10.0 or later. Compatible with iOS/Android/iPad/Tablet. ● When connected with Wi-Fi, make sure to keep the cell phone and the camera as closer as possible. The stronger and more stable the Wi-Fi signal is, the faster the download speed will be.
- Page 17 WiFi Feature WIFI CONNECTED STEPS 1.Make sure that the micro SD card and battery are properly installed in the trail camera. And the camera switch is in "ON" mode. (If adjust from "TEST" mode to "ON" mode, you need to wait for the end of the 3-second countdown on the screen.) 2.Download "VENARI"...
- Page 18 WiFi Feature 3.Open the "VENARI" APP and click the "Add camera", then click the "Step 1: Connect camera bluetooth" and select the option named "Hownic" in the Bluetooth list that appears in the app. The app will display "Turn on WiFi successfully, please connect to the camera", meanwhile, The trail camera screen will light up and go off immediately.
- Page 19 WiFi Feature After the camera is connected, the WIFI information bar of the camera will be kept on the mobile APP for the next use. WIFI WORKING PRINCIPLES 1.The trail camera's WiFi can not hook to internet. It is not a webcam or cellular camera.
- Page 20 App Function Setting REVIEWING ON THE CAMERA SCREEN After WIFI is connected, please turn back to APP main page.Now all remote functions are available for you! If you change the camera settings, please click the shutdown button in the upper right corner of the APP to save the settings.The trail camera will shoot according to the mode set by the APP.
- Page 21 Reviewing Your Photos/Videos REVIEWING ON THE CAMERA SCREEN ● Press the REPLAY key to enter image review mode. ● Press the UP/DOWN key to scroll through your photos or videos. ● Press the MENU key to enter the playback menu, you can select "Delete current fifile", "Delete all fifiles", "Activate slide show".
- Page 22 Trouble Shooting/FAQ WiFi Function Doesn't Work: 1. Check the batteries: Cameras stop work when the battery percentage becomes very low. 2. Make sure that the camera switch is in ON mode, and turn on the Bluetooth and WiFi on the phone. Then follow the steps to connect the phone. 3.
- Page 23 Trouble Shooting/FAQ Photos Did Not Capture any Subjects of Interest/ Too Many Photos： 1. Check the PIR sensitivity parameter setting. In warm environmental conditions, set the PIR sensor sensitivity to "High". In cold weather use,set the PIR sensor sensitivity to "Low". 2.
- Page 24 Trouble Shooting/FAQ Camera Stops Taking Or Won’t Take Photos/Videos： 1. Check Micro SD Card. a. Wrong type of micro SD card. Micro SD/SDHC/SDXC class 6 or higher speeds, up to 128GB are supported. b. Format the micro SD card. If the card is full, the camera will stop taking images.
