Read This First

Note

If you purchased a 1130G access point, this quick start guide refers

occasionally to an 802.11a radio. However, your 1130G access point

does not contain an 802.11a radio; it only contains an 802.11b or

802.11g radio. Please disregard the sections in your quick start guide

that refer specifically to an 802.11a radio.

You should review this table and the instructions for opening the top cover.

The table contains important information you need to know so you can

successfully configure your access point.

Setting

Password

IP address

Service Set Identifier (SSID)

Status LED

Quick Start Guide Cisco Aironet 1130AG Access Point

Default

Cisco (case sensitive)

Determined by DHCP server. See

the

"Obtaining an IP Address"

section on page 17

information.

None assigned

Status Description

for additional

Need help?

Do you have a question about the Aironet 1130G and is the answer not in the manual?

Questions and answers

Summary of Contents for Cisco Aironet 1130G

Page 1 Password Cisco (case sensitive) IP address Determined by DHCP server. See “Obtaining an IP Address” section on page 17 for additional information. Service Set Identifier (SSID) None assigned Status LED Status Description Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 2 Blue Normal operating condition, and at least one client device is associated with the access point. Light green Normal operating condition, no client devices are associated. Amber or red Error condition. See the “Checking the Access Point LEDs” section on page Radio and IP Address Configuration The access point ships with its radio disabled.You must enable them when...
Page 3 Status LED indications are not visible when the top cover is open. Follow these steps to open the top cover: 1. Put the access point on a flat surface, and grasp it with both hands, as shown in this illustration. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 4 Cable access notch and arrow OL-16709-01...
Page 5 2. Gently push the cover away from you until it stops, as shown in this illustration. 3. Remove the opening instruction label from the top cover. Note We recommend that you save the label for reference. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 6 The use of wireless devices in hazardous locations is limited to the constraints posed by the safety directors of such environments. Warnings Translated versions of these safety warnings are provided in the Cisco Aironet 1130AG Series Access Point Hardware Installation Guide. OL-16709-01...
Page 7 Warning Do not work on the system or connect or disconnect cables during periods of lightning activity. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 8 20A. Overview This guide is designed to help you minimally configure a Cisco Aironet 1130AG Series Access Point using the access point graphical user interface (GUI) through your web browser. The GUI is the primary-configuration tool.
Page 9 These documents are also available on Cisco.com. This guide provides an overview of the access point, but does not discuss mounting it. Those instructions are in the Cisco Aironet 1130AG Series Access Point Hardware Installation Guide, which is available on Cisco.com.
Page 10 Cisco IOS Software Configuration Guide for configuration Cisco Aironet Access Points Cisco Aironet Command Reference for Cisco Aironet Access Points and Bridges Mounting the access point Cisco Aironet 1130AG Series Access Point Hardware Installation Guide System requirements, Release Notes for Cisco Aironet 1130AG important notes,...
Page 11 – 2 #8 x 32 x 1-inch pan head screws • This guide • Cisco product registration and Cisco documentation feedback cards Complete these steps to prepare for installation. 1. Carefully unpack and remove the access point and hardware kit from the shipping box.
Page 12 2. Return all packing material to the shipping container, and save it. 3. Verify all the package contents, and inspect each item for damage. If any item is missing or damaged, contact your Cisco representative for support. 4. Obtain the mounting instructions by downloading the Cisco Aironet 1130AG Series Access Point Hardware Installation Guide from Cisco.com.
Page 13 Power connector Padlock post Ethernet port Mode button Keyhole slot Ethernet (E) and Radio (R) LEDs Console port Status LED Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 14 Installation Summary Installing the access point involves these operations: • Mounting the access point • Connecting power • Obtaining an IP address • Configuring power • Configuring basic settings • Configuring security settings Before you install the access point, make sure that you are using a computer connected to the same network as the access point, and obtain the following information from your network system administrator: •...
Page 15 The directional propagation can result in reduced performance, especially when using advanced features such as voice or location. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 16 When you have mounted the access point, its padlock post enables you to protect the Ethernet, power cables, and Mode button, and to lock the access point with a padlock. Detailed mounting instructions are in the Cisco Aironet 1130AG Series Access Point Hardware Configuration Guide. This document is available on Cisco.com.
Page 17 – A compliant Cisco inline power switch – A Cisco power injector with a compliant AC power module Caution If the access point receives power through PoE, the output current of the PSE cannot exceed 400 mA or 154000/Vport, whichever is smaller. The power source must comply with IEC60950.
Page 18 DHCP server, you or your network administrator can find it by querying the DHCP server using the access point’s MAC address. You can also find the access point’s IP address using Cisco’s IP Setup Utility You can download IPSU from Cisco.com.
Page 19 Assigns an IP address and subnet mask address to the BVI. Note When you have finished using the console port, you must remove the serial cable from the access point. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 20 Using a Telnet Session to Access the CLI Follow these steps to browse to access the CLI using a Telnet session. These steps are for a PC running Microsoft Windows with a Telnet terminal application. Check your PC operating instructions for detailed instructions. 1.
Page 21 1. Open your browser and enter the access point’s IP address in the address field. A login and password screen appears. 2. Enter the user name Cisco and password Cisco. The username and password are case sensitive. 3. When the access point does not receive enough power for full operations, it is in low power mode.
Page 22 Note To verify switch status, you will need to use the switch’s CLI. See the Cisco IOS software configuration guide for your switch. Power Source System Power Settings Switch Status Cisco PSE Power Settings: Power power inline supporting Cisco Negotiation selected...
Page 23 AC power adapter No configuration requirement Please check the release notes for your power sourcing equipment to determine which Cisco IOS version supports Cisco Intelligent Power Management. For some PSEs, support for Cisco Intelligent Power Management may not be available yet.
Page 24 1. Open your browser and enter the access point’s IP address in the address field. A username and password screen appears. 2. Enter the username Cisco and password Cisco. The username and password are case sensitive. 3. Press Enter. The Summary Status page appears.
Page 25 4. If required, configure the power settings as described in the previous section. Otherwise, Click Express Setup. The Express Setup page appears. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 26 OL-16709-01...
Page 27 Default: DHCP Option Description DHCP IP address is automatically assigned by the network DHCP server. Static IP The access point uses an IP address that you enter in the IP Address field. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 28 IP Address This setting assigns or changes the access point IP address. If DHCP is enabled, the access point obtains its IP address from your network DHCP server. You can assign a static IP address in this field. IP Subnet Mask The IP subnet mask identifies the subnet on which the access point resides.
Page 29 Simple Network Management Protocol (SNMP) used to manage the network on which the access point resides. Attribute Description Read-Only Access point allows only SNMP read access. Read-Write Access point allows read and read write access. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 30 Radio 802.11G and 802.11A Setup Sections Note The following radio settings must be applied separately to each radio: Radio0—802.11G and Radio1—802.11A. Role in Radio Network This setting determines what function the access point performs in the wireless network. Options: Access Point root or Repeater non root Default: Access Point root Option Description...
Page 31 Note For more information on this setting, see the Cisco IOS Software Configuration Guide for Cisco Aironet Access Points or the Cisco Aironet Command Reference for Cisco Aironet Access Points and Bridges. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 32 Aironet Extensions By default, the access point uses Cisco Aironet 802.11 extensions to detect the capabilities of Cisco Aironet client devices and to support features that require specific interaction between the access point and associated client devices. Aironet extensions must be enabled to support...
Page 33 Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 34 Understanding Express Security Settings When the access point configuration is set to factory defaults, the first SSID that you create by using the Express Security page overwrites the default SSID, which has no security settings. The SSIDs that you create appear in the SSID table at the bottom of the page.
Page 35 > SSID Manager. • You cannot configure combinations of authentication types on the same SSID (such as MAC address authentication and EAP authentication). To configure combinations of authentication types, choose Security > SSID Manager. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 36 The Express Setup screen sections and configurable settings are identified and briefly described below. SSID Configuration SSID The SSID is a unique identifier that clients use to associate with the access point. The SSID helps client devices distinguish between multiple wireless networks in the same vicinity.
Page 37 Specifies the VLAN that normally transmits and receives administrative data. Note After you have enabled a VLAN and assigned an identification number, check the Native VLAN check box to designate it as the native VLAN. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 38 There are two different lengths for WEP keys: 40-bit and 128-bit (hexadecimal or ASCII characters. Cisco access points use hexadecimal characters. Client adapters may use either, depending on how the vendor chooses to configure them.
Page 39 (server authentication port 1645). Note For detailed information about security and security settings, see the Cisco IOS Software Configuration Guide for Cisco Aironet Access Points. Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 40 If you do experience difficulty, the following sections provide basic troubleshooting information. Before contacting Cisco, look for a solution to your problem in this guide or the troubleshooting chapter of the Cisco Aironet 1130AG Series Access Point Hardware Installation Guide.
Page 41 Transmitting or receiving green radio packets. Blinking dark Green or Blinking Software upgrade in progress. blue blinking green or off green Amber Various Various IOS errors Blinking red Various Various Boot loader errors Quick Start Guide Cisco Aironet 1130AG Access Point...
Page 42 For more details on these LED status codes, see the “Troubleshooting” chapter of the Cisco Aironet 1130AG Series Access Point Hardware Installation Guide. Checking Basic Settings Mismatched basic settings are the most common causes of lost connectivity with wireless clients. If the access point does not communicate with client devices, check the following areas.
Page 43 However, the access point does not need to use WEP Key 3 as the transmit key. Refer to the Cisco IOS Software Configuration Guide for Cisco Aironet Access Points for instructions on setting the access point WEP keys.
Page 44 Note These steps reset all configuration settings to factory defaults, including passwords, WEP keys, the IP address, and the SSID. Using the MODE Button Follow these steps to delete the current configuration and return all access point settings to the factory defaults by using the MODE button: 1.
Page 45 Enter. An Enter Network Password screen appears. 3. Enter the username Cisco in the User Name field. 4. Enter the password Cisco in the Password field and press Enter. The Summary Status page appears. 5. Click System Software. The System Software screen appears.
Page 46 The Declarations of Compliance for this product relevant to the European Union and other countries following EU Directive 1999/5/EC (R&TTE Directive) can be found in the Cisco Aironet 1130AG Series Access Point Hardware Installation Guide. This guide is available on Cisco.com.
