  • Page 1 cino xm 180 bono Operating manual Version 4 10/2004 Software version XMED 1D onwards / 29.10.2003...
  • Page 2 CINO XM 180 PB Operating manual Version XMED 1D onwards © servomat steigler 01.10.2004...
  • Page 3 CINO XM 180 PB Operating manual Version XMED 1D onwards A wide variety of Recipe Technical coffee specialities step program quality control Hot drink systems without The high quality of drinks produced with Our electronic module “E-Prom” Cappuccino are today almost the A.R.T.
  • Page 4 CINO XM 180 PB Operating manual Version XMED 1D onwards Identification label of your machine This manual is an integral part of the machine and must always be available in the vicinity of the machine for reference, till such time as...
  • Page 5 CINO XM 180 PB Operating manual Version XMED 1D onwards Subject Page Chapter Important notes General cleaning instructions Technical data General information 10-12 Overview of machine parts 13-14 Unpacking and installation Water and filter 16-18 Start-up 19-23 Lighting Installing a payment system...
  • Page 6 The installation, filling-up and cleaning must be done according to the specifications given in this manual, by our technical partner’s staff properly trained by servomat steigler. o For changing the quality of coffee, or the product quality, a readjustment by servomat’s technical partner is a necessary prerequisite.

  • Page 7: Servicing Checklist

    CINO XM 180 PB Operating manual Version XMED 1D onwards Servicing checklist Following jobs must be performed within the purview of maintenance guidelines: Which parts? What must be done? Hard water supply Check inlet valve and connections Replace the water filter cartridge for hard water...

  • Page 8: General Cleaning Instructions

    CINO XM 180 PB Operating manual Version XMED 1D onwards General cleaning instructions You can broaden the scope of cleaning the machine with the help of these cleaning instructions. These cleaning instructions constitute instructions for daily, weekly and monthly cleaning. Please follow the cleaning instructions. This would ensure more hygiene and lesser malfunctions.

  • Page 9: Monthly Cleaning

    CINO XM 180 PB Operating manual Version XMED 1D onwards Monthly cleaning This cleaning process includes the daily and weekly cleaning from item 1 to item 6. 7. Clean the product container: First of all close the red shut- off flaps on the product containers. Take out the product containers by lifting these slightly at the front and then pulling them out.

  • Page 10: Technical Data Sheet

    CINO XM 180 PB Operating manual Version XMED 1D onwards Technical data sheet Height without / with top part 770 mm / 870 mm Dimensions Width 410 mm Depth without / with doors 495 mm / 575 mm Empty 51 Kg...

  • Page 11: Rating Plate

    CINO XM 180 PB Operating manual Version XMED 1D onwards Rating plate The rating plate is an important label meant for information. Please always mention the model and machine number for any spare part order placement. The rating plate is located Manufacturer’s data...

  • Page 12: Safety Notes

    CINO XM 180 PB Operating manual Version XMED 1D onwards Safety notes This machine is manufactured keeping in mind the safety aspects. Nevertheless, independent installation and operation of the machine may only be entrusted to those persons who have completed 18 years of age. Only a person, who is...

  • Page 13: Safety Devices

    CINO XM 180 PB Operating manual Version XMED 1D onwards Safety devices • Door contact switch • Manually connected safety thermostat for the boiler • Time controlled protection for the pump • Time controlled protection for the geared motor of the coffee brewer set •...

  • Page 14: Rear Panel View

    CINO XM 180 PB Operating manual Version XMED 1D onwards Rear panel view Rear casing Additional PCB Starter (Lightning) Rectifier for the Transistor PCB grinder (Power PCB) Grinder Pump Brewer motor Valve block Fan duct Pressure boiler Compensating tank Rear casing (power module)

  • Page 15: Front View

    CINO XM 180 PB Operating manual Version XMED 1D onwards Front view Outer casing Insertion slot for coins and knob for coin Panels return (different designs) Display Door lock Keyboard for selection and programming Cup dispenser Coin return shaft Drip pan...

  • Page 16: Instructions For Installation

    CINO XM 180 PB Operating manual Version XMED 1D onwards Instructions for installation Flawless operation of the machine is guaranteed in closed rooms with a room temperature not less 5°C. The machine should not be used in rooms where there is splash water.

  • Page 17: Water Filter

    CINO XM 180 PB Operating manual Version XMED 1D onwards Quality of water The German Coffee Association e.V. has compiled the following basics for the optimisation of safety and quality . Among other things, following criteria form a prerequisite for...
  • Page 18 CINO XM 180 PB Operating manual Version XMED 1D onwards Hard water supply with water filter As a matter of rule we always recommend that a water filter be used for decalcination of water. For the hard water supply, a minimum water pressure of 1 bar Kindly note ! is absolutely necessary.
  • Page 19 CINO XM 180 PB Operating manual Version XMED 1D onwards Water system Inlet valve: The inlet valve for the water tank is suitable only for depressurised area. The inlet valve is a sensitive part when the water is not being filtered. Due to dust in the non-filtered water the valve may no more open or close.

  • Page 20: Initial Start-Up

    CINO XM 180 PB Operating manual Version XMED 1D onwards Initial Start-up Open the machine door. Now you can open the top casing cover upwards. Remove the document folder lying above the product containers. This includes: 1 piece operating manual...
  • Page 21 CINO XM 180 PB Operating manual Version XMED 1D onwards Fill-up the tumbler The tumbler station has a capacity of 180 tumblers. To the person responsible for filling-up demonstrate the correct method of filling up the tumbler station as shown below.
  • Page 22 CINO XM 180 PB Operating manual Version XMED 1D onwards Tip for the first thorough cleaning Before filling up the products ensure that the product containers are clean. There could be packaging dust. If this is so proceed as follows:...

  • Page 23: Switching On The Machine

    CINO XM 180 PB Operating manual Version XMED 1D onwards Filling the product Now fill the products as described on the product containers. First of all close the red shut-off flaps on the product containers. Open the red shut-off flaps again after fill-up.
  • Page 24 CINO XM 180 PB Operating manual Version XMED 1D onwards Cleaning with the rinsing program Press the programming button on the inner side of the door. 1=PROGR The display alternately shows: 3=FREE 2=DATI 4=CLEAN 5=MAINT. Press selection button 4 on the keyboard.
  • Page 25 CINO XM 180 PB Operating manual Version XMED 1D onwards Replacing tube lights Caution 220V power supply. Pull out the mains plug before replacing tube lights. Pull out Press the locking clip the locking clip. from the sides. Loosen screws.
  • Page 26 CINO XM 180 PB Operating manual Version XMED 1D onwards 10.1 Installing a coin changer To install a coin changer, proceed as follows: MSG holder Turn the MSG holder towards front. Tighten the screws if needed to suspend the MSG.
  • Page 27 CINO XM 180 PB Operating manual Version XMED 1D onwards 11.1 Enlarge the brewer Untwist the outlet pipe against the clockwise direction and pull it out. Untwist the inlet pipe against the clockwise direction and pull it out. Press locking angle upwards until you can loosen the brewer.
  • Page 28 CINO XM 180 PB Operating manual Version XMED 1D onwards 11.2 Brewer adjustment The dosage of the coffee quantity is limited by the size of the brewer chamber. The brewer chamber will be increased by increasing the distance between the upper and the lower brewer stamp.
  • Page 29 CINO XM 180 PB Operating manual Version XMED 1D onwards 11.3 Brewer cleaning Raw coffee contains approx. 10-15% fat and coffee wax. Even if most disappears with the roasting process, so with the time fat, wax and small coffee particles can settle on the sieves of the brewer.
  • Page 30 CINO XM 180 PB Operating manual Version XMED 1D onwards 12.1 Arrangement of product containers Product 1 Product 2 Product 3 Product 4 Product details: Coffee beans Sugar Cocoa Milk Soup Product 1 - Narrow portioning spiral - Portioning motor 85 rpm...
  • Page 31 CINO XM 180 PB Operating manual Version XMED 1D onwards 13.1 Flash Card controls No EPROM is installed in this control system. Updates are done via a “FLASH CARD”. The Flash Card controls have an internal Flash memory. FlashCard The Flash Card is a storage medium with a 1 MB memory chip.
  • Page 32 CINO XM 180 PB Operating manual Version XMED 1D onwards 13.2 What do I use the Flash Card for? You can use the Flash Card for several functions: You can program new software updates with a Flash Card on the machine.
  • Page 33 CINO XM 180 PB Operating manual Version XMED 1D onwards 13.5 General functions On pressing the programming button on the display PCB on the inner side of the door you reach the machine program. See sketch: Program button 1=PROGR On pressing the programming button following information...
  • Page 34 CINO XM 180 PB Operating manual Version XMED 1D onwards 13.6 Functioning of selection keys in programming mode Forward query and run through all menu items one after another Forward run through all options within menu Product 1 items selected with...

  • Page 35: Program Overview

    CINO XM 180 PB Operating manual Version XMED 1D onwards 13.4 Program overview On pressing the programming button and then entering the code you get into programming mode. Using the selection buttons – 1 - and – 2 – you can go to the individual menus.
  • Page 36 CINO XM 180 PB Operating manual Version XMED 1D onwards Programming the quantity of product 14.1 and water For altering the portioning proceed as follows: Press the programming button. The display shows 1=PROGR alternately the program menu: 3=FREE 2=DATI 4=CLEAN 5=MAINT.

  • Page 37: Exiting The Programming Mode

    CINO XM 180 PB Operating manual Version XMED 1D onwards 14.2 Can mode Now with the new option “Can mode” in XM 180 you can refer to each product as a can. For programming the portions proceed as explained earlier in section 14.1.
  • Page 38 CINO XM 180 PB Operating manual Version XMED 1D onwards 14.4 Portioning of coffee The portion of coffee is manually set though the portioning unit. You have the option to set the portion from 5.5 gr. to approx. 8.0 gr. To check the portioning kindly proceed as follows:...
  • Page 39 CINO XM 180 PB Operating manual Version XMED 1D onwards Setting for the degree of grinding of 14.5 coffee You can vary the gap between the grinding disks by turning the adjusting rings, it determines the degree of grinding of coffee.
  • Page 40 CINO XM 180 PB Operating manual Version XMED 1D onwards 15.1 Explanation on portioning list For each button you have the option to change the FUNCTIONING portioning of the time of the product motor, mixer motor and valve required and controlled for the purpose.
  • Page 41 CINO XM 180 PB Operating manual Version XMED 1D onwards Portioning list XMED 1D – 29-10-03 15.2 with can mode option Standard data Your Data Your Data Recommended portioning Product 3 = Whitener Produkt 3 = Topping Time Gram Time...
  • Page 42 CINO XM 180 PB Operating manual Version XMED 1D onwards 15.2 Portioning list XMED 1D – 29-10-03 with can mode option Standard data Your Data Your Data Dosiervorschlag Product 3 = Whitener Product 3 = Topping Time Gram Time Gram...
  • Page 43 CINO XM 180 PB Operating manual Version XMED 1D onwards 16.1 Price allocation The machine allows 10 price allocations which are assigned permanently to 10 selection buttons. You can sell at 10 different prices. Price 1 Button 1 preselection sugar – no price setting...

  • Page 44: Boiler Temperature

    CINO XM 180 PB Operating manual Version XMED 1D onwards 17.1 Boiler temperature In programming using button -1 select the list “Programming temperature”. PROGRAMMING - - - - The display shows: -TEMPERATURE - - - - Now, press button -2-. The display shows:...

  • Page 45: Machine Number

    CINO XM 180 PB Operating manual Version XMED 1D onwards 18.1 Machine number In programming select button –1- select the PROGRAMMING - - - - list “Miscellaneous programming”. The display shows: - MISCELLANEOUS - machine code Press button –2-. The display shows: Here you can enter the machine number.
  • Page 46 CINO XM 180 PB Operating manual Version XMED 1D onwards 18.4 Fan after-run time Press button –2-. The display shows: Here you can set the after-run time of the fan, fan time how long should the fan run after the product has been min.
  • Page 47 CINO XM 180 PB Operating manual Version XMED 1D onwards 18.10 Active Snack Press button –2-. The display shows: habil. snack You have the option to connect our Snack Mini as a slave 0 = no 1 =yes device to the XM 180. For this you need a snack slave-kit .
  • Page 48 CINO XM 180 PB Operating manual Version XMED 1D onwards 19.1 Display temperature These options are important and useful tools for the service engineer. Now, press button -2-. The display shows: HABIL. DISPLAY 1 = permanent temperature display on the display TEMPERA.

  • Page 49: Cumulative Counter

    CINO XM 180 PB Operating manual Version XMED 1D onwards 20.1 Cumulative counter Press button 2. The display shows: TOTAL SELECTIONS This counter registers all sales in the sales mode, free sale mode and can mode. This counter status cannot be reset.
  • Page 50 CINO XM 180 PB Operating manual Version XMED 1D onwards 21.1 MDB Parameter Change the MDB settings according to the following table. PROGRAMMING - - - - - MDB - - - - - - - - - - - - Use button 2 to move in the CODE area and with buttons 4 and 5 change the values.

  • Page 51: Clock Functions

    CINO XM 180 PB Operating manual Version XMED 1D onwards 22.1 Clock functions Press button 1. The display shows: PROGRAMMING - - - - CLOCK The machine has an internal clock . You have the option to set various switching functions. The clock becomes active only after you have entered the time.
  • Page 52 CINO XM 180 PB Operating manual Version XMED 1D onwards 22.5 Time Press button 2. The display shows: HOUR: Here you can set the current time. 00:00 22.6 Press button 2. The display shows: DAY: Here you can enter the current date.
  • Page 53 CINO XM 180 PB Operating manual Version XMED 1D onwards 23.1 Error messages XM The machine stores the last 20 error messages. The REGISTRATION Individual error messages can be deleted by pressing OUT OF SERVICE button -4-. n. 1 OFF 31B Now, press button -2-.

  • Page 54: Service Messages

    CINO XM 180 PB Operating manual Version XMED 1D onwards 24.1 Service messages The machine has service counters that help in flawless servicing and inspection of the machine. The counters are activated as follows: 24.2 Service messages PROGRAMMING Now, press button -1-. The display shows:...
  • Page 55 CINO XM 180 PB Operating manual Version XMED 1D onwards 24.2 Service messages BREWER COUNTER The counter now registers all sales. It counts back up to value cnt. brewer cof. “2”. As soon as the counter reaches 2 its value remains unchanged and it is still possible to sell.
  • Page 56 CINO XM 180 PB Operating manual Version XMED 1D onwards – – 25.1 Error messages Display CODE Cause Fault elimination SERVICE Refill cups OFF 1 No cups Photocell defective / replace Cup type not suitable SERVICE Payment system malfunction Incorrect payment system...
  • Page 57 CINO XM 180 PB Operating manual Version XMED 1D onwards – – 25.1 Error messages Display CODE Cause Fault elimination The brewer does not move to Check the microswitch on the SERVICE its end position. brewer motor OFF 8 Voltage for brewer motor...
  • Page 58 CINO XM 180 PB Operating manual Version XMED 1D onwards – – 25.1 Error messages Display CODE Cause Fault elimination 24 Volt Voltage supply not Transformer is defective SERVICE available OFF 24 A Transformer plug is defective Strip conductors on the CPU...
  • Page 59 CINO XM 180 PB Operating manual Version XMED 1D onwards – – Causes of malfunctions without error 25.2 messages For the malfunctions described here no error messages are displayed on the display unit. Fault Possible cause Solution Check input voltage and...
  • Page 60 Ihr Service und Beratungspartner 89179 Beimerstetten, Robert Bosch Str. 3...
