Cherry AK-930-U Series Instructions And Safety Information

Instructions and Safety Information
AK-930-U series
The contactless chip card reader AK-930-UA-B is a USB smart card reader developed
based on 13.56MHz contactless technology. The integrated chipset received NFC
Forum Certification which proves the device is interoperable with other NFC devices
and can fulfil all three modes of NFC: card reader/writer, card emulation, and peer-to-
peer communication. The device is therefore suitable for a wider range of NFC
applications, such as smart posters, file exchange, and so forth. The device supports
ISO 14443 Type A and B Cards; MIFARE, Felica, and ISO 18092-compliant NFC
tags; and other NFC devices with an access speed of up to 424 Kbps.
Delivery Content:
1x User Instruction
1x Cable chip card reader
Manufacturer:
Cherry Digital Health GmbH Web: www.cherry.de
Cherrystraße 2 Tel: +49 (0) 9643-2061-100
D-91275 Auerbach/OPf.
Legal information:
The product complies with the Directive 2014/53/EU (RED). The full text of the EU
declaration of conformity is available at the following internet address:
http://www.cherry.de/compliance
FAQ/Errors
No function Please plug the NFC reader off and on again
If the product has other defects please contact us.
Please hold this information ready when you contact us:
- Article and serial number of the product
- Name and producer of your PC/notebook or motherboard
- Operating system and if installed version of the service pack
Electrical and electronic equipment (EEE) is marked with the symbol of the crossed-out wheeled bin
indicating the requirement not to dispose of waste electrical and electronic equipment
(WEEE) as unsorted municipal waste and to collect such WEEE separately. Final users
of WEEE from private households shall be able to return WEEE as per EU country local
regulations into established collection facilities free of charge. Please consult your
municipal waste department for detailed advice on separate collection of WEEE.
The packaging material used with this product is identified as PAP-20 and LDPE-04. Please follow the
rules of your local community on collection of used packaging.
Technical data
General characteristics
Article identifier
Model
Dimensions
Weight
Temperature range
Firmware upgrade
Optical / acoustic indicators
Approvals
USB interface
Power supply
Power consumption
Interface
Protocol
Cable length
Contactless chip card interface
Conformities, protocols
Radio frequency
Maximum transmission power
Distance between card and reader
Transfer speed reader to card
Antenna size
System interfaces
Application interfaces
Operating system device drivers
Optical / acoustic indicators
Reader is connected via USB
Stand-by operation
Card recognized
Card read/write operation
Card removed
All rights reserved. Copy or duplication, except for personal use, not permissible without specific prior
written consent by Cherry Digital Health GmbH. Contents are subject to change without notice. Errors
excepted. Copyright by Cherry Digital Health GmbH.
Version 20241115
AK-930-UA-B
C806A
ca. 140mm x 118mm x 22mm
approx. 216g
Storage:-20 °C to+ 60 °C, Operation:0 °C to+ 50 °C
supported
Green LED & Buzzer
CE, RoHS 2, REACH SVHC
5V via USB
Max. 200mA
USB 2.0 full speed (12MBit / s)
USB CCID
approx. 1,8 m
ISO 14443 Type A & B, T=CL
MIFARE Classic Card, T=CL
ISO 18092, NFC Tags
FeliCa
13,56 MHz
0,06 mW = -12,2 dBm EIRP
approx. 12 mm for ISO 14443 Type A
106 / 212 / 424 KBit/s
50 mm x 40 mm
PC/SC, CT-API, CCID & ICCD
Windows® XP / Vista® / 7 / 8 / 8.1 / 10,
Windows® Server 2003 / 2008 / 2012 / 2016
Linux®, Mac OS®, Solaris, Android™ 3.1
LED lights up in orange for 1 sec., acoustic sound,
device enters stand-by mode
No visual indication on the device
Green LED is permanently on, acoustic sound
Green LED flashes during data transmission
Green LED turns off, device enters stand-by mode
