Universal roasting spit set

Advertisement

Quick Links

t
Safety instructions
• Danger Risk of Injury! The meat clamps are very sharp. Proceed with particular caution when skewering the meat for roasting.
• Danger Risk of Electric Shock! The spit motor must be protected from water or steam and must not be used in the rain.
• Danger Risk of burning! Always wear oven or BBQ gloves when grilling. (Glove Category II with regard to heat protection, e.g. DIN-EN 407. Glove must
match the PSA regulation.)
• The plug of the spit motor must be connected to the mains supply via a fused power socket.
• Connection via a permanently installed cable is not permitted.
• Do not use the device if it or the mains cable show signs of damage or if the device has been dropped.
Intended Use
This roasting spit serves for the holding of meat for roasting, such as poultry or joints. The roasting spit is intended for private use only. Only use the item as
described in this operating manual. All other uses are considered improper and can lead to material damage or even to personal injuries. The manufacturer
accepts no liability for damages caused by improper use.
Before first use
Wash off possible coarse production residues using warm water. In doing so, avoid the use of cleaning agents or detergents.
Parts
Assembly
1. Fasten the motor mount (B) to the left side of the fire bowl with two sets of screws.
2. Fasten the motor (A) onto the motor mount (B).
3. Mount the spit rest (H) to the right side of the fire bowl with two sets of screws.
4. Screw the handle (J) onto the end of the main skewer (C). Use the skewer extensions included in the scope of delivery as required.
5. Slide the counterweight (F) and roll ring (I) from the tip onto the main spit (C).
Note: The counterweight (F) is placed to the right of the notch, outside the fire bowl on the counterweight holder (E). It prevents the spit from lifting. The
roll ring (I) is fixed next to the notch on the left of the spit rest (H). It prevents the rotisserie spit from turning from the motor.
6. Stick one meat clamp (D), the meat for roasting, and then the second meat clamp (D) onto the spit. Make sure the meat is as evenly distributed as
possible, in order to reduce the load on the motor.
7. Clamp the meat for roasting between the meat clamps (D) and fix these in place using the holding screws on the roasting spit.
8. Guide the roasting spit with tip into the motor driving opening and then place it on the rest.
9. Connect the mains adaptor of the motor (A) to a suitable socket.
10. To switch the motor on and off, use the toggle switch on the side of the motor.
P20134_TEPRO_8591_Grillspiess_A4_20201208_GB.indd 1
Universal Roasting Spit Set
Operating manual
A
Motor
B
Motor mount
C
Main roasting spit
D
Meat clamps x2
E
Holder for counterweight
F
Counterweight
G
Roasting spit extension x2
H
Spit rest
I
Roll ring
J
Handle
Item No. 8591
Version 2015
8/12/2020 11:08 AM

Advertisement

loading
Need help?

Need help?

Do you have a question about the 8591 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for tepro 8591

  • Page 1 Universal Roasting Spit Set Operating manual Item No. 8591 Version 2015 Safety instructions • Danger Risk of Injury! The meat clamps are very sharp. Proceed with particular caution when skewering the meat for roasting. • Danger Risk of Electric Shock! The spit motor must be protected from water or steam and must not be used in the rain. • Danger Risk of burning! Always wear oven or BBQ gloves when grilling. (Glove Category II with regard to heat protection, e.g. DIN-EN 407. Glove must match the PSA regulation.) • The plug of the spit motor must be connected to the mains supply via a fused power socket. • Connection via a permanently installed cable is not permitted. • Do not use the device if it or the mains cable show signs of damage or if the device has been dropped. Intended Use This roasting spit serves for the holding of meat for roasting, such as poultry or joints. The roasting spit is intended for private use only. Only use the item as described in this operating manual. All other uses are considered improper and can lead to material damage or even to personal injuries. The manufacturer accepts no liability for damages caused by improper use.
  • Page 2 1. A ttention: Do not submerge the motor in water or other liquids! For inquiries about spare parts or technical questions, please contact your Wipe down the housing with a damp cloth, as necessary. Make sure that no contractual partner. moisture gets inside the housing. 2. Clean the roasting spit and the meat clamps thoroughly with warm water and Subject to technical modifications and typographical errors. a little detergent after each use. Distributor 3. Dry off all the parts thoroughly after cleaning. Disposal TEST RITE tepro GmbH Carl-Zeiss-Straße 8/4 Do not under any circumstances dispose of the device in normal D-63322 Rödermark household waste! Dispose of it at an approved disposal business or at your community disposal facility. Respect the currently valid regulations. If in doubt, get in touch with your disposal facility. Technical details Item: No. 8591, Universal Roasting Spit Set Rated capacity: Nominal voltage 220 - 240 V~; 50/60 Hz P20134_TEPRO_8591_Grillspiess_A4_20201208_GB.indd 2 8/12/2020 11:08 AM...
