AP-12SC Bluetooth LE Module User's Manual Ver0.3
User's Manual
Bluetooth LE 5 Module
Model Name: AP-12SC
VERSION: 0.3
Rd., XizhiDist, New Taipei City 22102, Taiwan
20F-B, No.98, Sec. 1, Xintai 5
th
TEL: 886-2-28961888 FAX: 886-2-28961899
https://www.btc.com.tw/SCS/IOT/iot_en.php
Advertisement
Related Manuals for BTC AP-12SC
Summary of Contents for BTC AP-12SC
- Page 1 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 User’s Manual Bluetooth LE 5 Module Model Name: AP-12SC VERSION: 0.3 Rd., XizhiDist, New Taipei City 22102, Taiwan 20F-B, No.98, Sec. 1, Xintai 5 TEL: 886-2-28961888 FAX: 886-2-28961899 https://www.btc.com.tw/SCS/IOT/iot_en.php...
- Page 2 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 TABLE OF CONTENTS 1. INTRODUCTIONS AND SCOPE 2. FEATURES 3. MECHANICAL CHARACTERISTICS 4. EXTERNAL DIMENSION 5. PIN ASSIGNMENT AND DESCRIPTION 6. HARDWARE ARCHITECTURE LOCK IAGRAM YSTEM RCHITECTURE 7. ELECTRICAL CHARACTERISTICS 7.1 V OLTAGE PECIFICATION 7.2 T...
- Page 3 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 1. INTRODUCTIONS AND SCOPE AP-12SC is a Bluetooth low energy(BLE) module. It uses Realtek Semiconductor BLE controller RTL8762CMF, which is an ultra−low−power chipset. AP-12SC is designed for high performance wearable, medical, industrial and consumer applications. The module integrates antenna and...
- Page 4 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 2. FEATURES 2.1 General Bluetooth 5.2 Certified with LE 2Mbps Support Build in Arm Cortex−M4F Processor Build in 40MHz system clock crystal Bluetooth Transceiver Transmitting Power: −20 to +7.5 dBm Transmitting Distance: 100m (no disturbance) RX Sensitivity -97dBm (BLE min) Support Lower Voltage to 1.8V...
- Page 5 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 3. MECHANICAL CHARACTERISTICS 3.1 Weight and Dimension Weight: 0.8g Dimension: 17.1mm x 11.15mm x 2.7(L x W x H, with metal cover) 3.2 Module Picture Reference picture below(without shielding cover): Top Side Bottom Side...
- Page 6 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 4. EXTERNAL DIMENSION 4.1 Outline Dimension of PCBA (unit: mm)
- Page 7 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 5. PIN ASSIGNMENT AND DESCRIPTION 5.1 Pin Assignment Top Side View...
- Page 8 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 5.2 Pin Descriptions Symbol Pull Description RFIO BT RX/BT TX interface HW_RST_N Hardware reset pin; low active P4_3 General purpose IO 8mA driving capacity with wakeup function with internal strong/ weak pull-up and...
- Page 9 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 32K_XI A/IO 32k crystal input or external 32k clock input(optional) P3_1 General purpose IO 8mA driving capacity with wakeup function with internal strong/ weak pull-up and pull-down HCI_UART_RX P3_0 General purpose IO 8mA driving capacity...
- Page 10 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 6. HARDWARE ARCHITECTURE 6.1 Block Diagram Hardware block of AP-12SC is illustrated. ．Rich peripherals ．Flexible RAM configuration ．Power Management Unit ．Clock Management Unit ．BLE module 6.2 System Architecture Brand Name Model Name Antenna...
- Page 11 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 7. ELECTRICAL CHARACTERISTICS 7.1 Voltage Specification Symbol: VBAT Power supply voltage range: 1.8~3.6V Build in internal LDO regulator to provide stable power to the digital core and radio circuit 7.2 Temperature Specification Functional temperature range: -40°C ~ 105°C Storage temperature range: -55°C~125°C...
- Page 12 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 resister(KOhm) weal pull = 1.8V 20/200 Strong pull/ weal pull = 3.3 5/50 Strong pull/ weal pull V = 1.8 2.5/25 Strong pull/ weal pull V Input high PAD configured current(uA) as input mode...
- Page 13 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 8. FOOTPRINT Make sure no ground pad is in the keep out area. If PCB is multi layer, there should be no ground pad in each layer inside keep out area unit : mm...
- Page 14 Behavior Tech Computer Corp. Device Model Name AP-12SC Device Description AP-12SC is a Bluetooth low energy (BLE) module. It uses REALTEK BLE controller RTL8762C, which is an ultra-low-power, highly flexible multi-protocol 2.4 GHz radio chipset. AP-12SC is designed for high-performance wearable, medical, and industrial applications.
- Page 15 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 10. CERTIFICATION 10.1 Certification AP-12SC is compliant with FCC, NCC, CE certification 10.2 FCC Statement FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two...
- Page 16 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 用。前述合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合 法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 此模組於取得認證後將依規定於模組本體標示審驗合格標籤,並要求平台廠商於平台 上標示本產品那含發射器模組 。...
- Page 17 Labeling and User Information Requirements The AP-12SC module has been labeled with its own FCC ID number, and if the FCC ID is not visible when the module is installed inside another device, then the outside of the finished product into which the module is installed must display a label referring to the enclosed module.
- Page 18 FCC multi-transmitter product procedures. AP-12SC: These modules are approved for installation into mobile host platforms atleast 20cm away from the human body.
- Page 19 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 12. SHIPPING PACKAGE Packed by tray, 80pcs modules per tray (T.B.D) MOQ 1200pcs MPQ 80pcs Carton and labels (T.B.D)
- Page 20 AP-12SC Bluetooth LE Module User’s Manual Ver0.3 13. VERSION CHANGE LIST 2023/03/06 Version 01 Release 2023/03/20 Version 02 Release 2023/04/27 Version 03 Release ...
