COFRE 260
INSTALLER AND USER'S MANUAL
v2.2
REV. 10/2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the COFRE 260 and is the answer not in the manual?

Questions and answers

Summary of Contents for Motorline professional COFRE 260

  • Page 1 COFRE 260 INSTALLER AND USER’S MANUAL v2.2 REV. 10/2024...
  • Page 2 00. CONTENT 01. SAFETY INSTRUCTIONS This product is certified in accordance with European Community INDEX (EC) safety standards. This product complies with Directive 2011/65/EU of the European . SAFETY INSTRUCTIONS | pág .B Parliament and of the Council, of 8 June 2011, on the restriction .
  • Page 3 01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. • If the power cable is damaged, it must be replaced by the Read all instructions carefully before beginning the installation/ manufacturer, after-sales service or similarly qualified personnel usage procedures and keep this manual in a safe place that it can...
  • Page 4 01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS the power supply cable. Please note that all the cables must enter conditions have been met. the control board from the bottom. • In the event of tripping of circuits breakers of fuse failure, locate •...
  • Page 5 Safe cover Motor TUB M MT The COFRE 260 is an automated awning equipped with a safe to protect the fabric. It Safe side support Manual safety crank features articulated arms with a double cable, ensuring greater durability and safety.
  • Page 6 03. INSTALLATION 03. INSTALLATION PRE-INSTALLATION INFO WALL WITHOUT CONDITIONS FOR INSTALLATION AWNING Wedge WALL WITH CHOCKS NECESSARY FOR INSTALLATION AWNING Before starting the installation, check the wall leveling. If the wall is not flat, create chocks in order to level perfectly the awning For a correct operation of the awning, the measure A can not be changed.
  • Page 7 03. INSTALLATION 03. INSTALLATION CEILING 100mm 300mm 02 - Take the measurement at the location where the awning will be applied. Pay attention to the leveling of wall brackets (nº8) for fixing the awning. 03 - With the help of a pencil or marker, identify the drilling points for the placing of the wall brackets (nº8).
  • Page 8 03. INSTALLATION 03. INSTALLATION CEILING INSTALLATION INCLINATION ARMS REGULATION Area of assistance during joint regulation. Area of assistance during the inclination arms regulation. RELIEVE 1 ARM EACH TIME OPTION 1 OPTION 2 Make the fixation on the consoles (nº21) using one of the two options identified in the images 14 and 15 (use M12 screws with washers).
  • Page 9 03. INSTALLATION 03. INSTALLATION ARTICULATION ADJUSTMENT MANUAL RELEASE The awning is prepared for, in case of power failure or other situation that prevents the electrical operation of the equipment, it is possible to make the opening or closing manually by using the crank (nº20). Crank Place the handle as shown in the image 24 and turn it to open/close the awning.
  • Page 10 03. INSTALLATION 03. TROUBLESHOOTING FABRIC REGULATION FINAL CONSUMERS AND SPECIALIZED TECHNICIANS INSTRUCTIONS If you detect any anomalies in the Problems Behavior Procedure fabric winding (total closure of a side only), make the opening of the awning • Check the installation measures. The awning is not secure •...
