Reset to Default Settings
The router will be RESET to FACTORY DEFAULT by pressing the RESET
button on the top of the router for 3 seconds.
The router must be reconfigured after reset.
Power Details
Input Voltage
Maximum Input Power
Maximum Input Current
Internal Voltage Protection
Reverse Polarity Protection
Isolation
General Specifications
USB
Processor
Digital Input for Local Control
Operating Temperature Range
Storage Temperature Range
Relative Humidity
Operating Altitude
Storage Altitude
Environmental Air
EMI FCC CFR47 Part 15, EN55022/CISPR22, Class B
EMS IEC61000-4-2 (ESD): ± 8kV (contact), ± 15kV (air)
IEC61000-4-4 (EFT): Power Port ± 4kV; Data Port: ± 2kV
IEC61000-4-5 (Surge): Power Port: ± 2kV/DM, ± 4kV/CM;
RoHS and WEEE
Packaging and Protection
Mounting
Dimensions
Weight
Interface
Certification CE, cULus, RoHS, REACH, AT&T (SE-SL3011-4G), FCC
Warranty
Agency Approvals
SAFETY NOTICE: The StrideLinx VPN router allows the user to connect to remote
industrial controls equipment from Ethernet, Wi-Fi, or cellular network connections.
The remote user may fully operate and monitor the local control system and affect
the function and control of the application just as the local operator controls it.
Proper Control, Security and Safety Procedures should be considered and imple-
mented when utilizing the remote access feature.
Additional Help and Support
• For additional product support, specifications, and
installation, a User Manual, SE-SLVPN-USER-M, is available
as a downloadable PDF file from the Online Documentation
area of www.AutomationDirect.com
• For additional technical support and questions, call our
Technical Support team @ 770-844-4200.
Copyright 2017–2024, AutomationDirect.com Incorporated/All Rights Reserved Worldwide
Class 2 LPS Power Supply, 12-24 VDC
10W
2A
29V max
Yes
1.5 kV
USB 2.0 (for configuration only)
MIPS 800MHz
Yes
-20°C to +65°C [-4°F to +149°F]
-20°C to +65°C [-4°F to +149°F]
10 to 95% non-condensing
Up to maximum 2000m
Up to maximum 3000m
For use in Pollution Degree 2 Environment.
No corrosive gases permitted.
IEC61000-4-3 (RS): 10V/m (80MHz ~ 2GHz)
Data Port ± 2kV
IEC61000-4-6 (CS): 10V (150kHz ~ 80MHz)
RoHS (Pb free) and WEEE compliant
Metal case, IP20
DIN rail
111 x 95 x 28mm (excluding DIN rail clip)
270–310 gram
Browser (Unsecure)
2 years
UL/cUL 60950-1, CE
ITE
E495151
Ethernet ports
Port Type
Auto-Crossover Yes, allows you to use straight-through or crossover wired cables
Auto-Sensing Operation
Auto-Negotiating Speed
Flow Control
Operating Mode
Devices Supported
Protection
Cable Requirements
Max. Cable Distance
WiFi Specifications (P/N SE-SL3011-WF Only)
WiFi IEEE 802.11 Version
WiFi Modes
Speed
Antenna Connection
Antenna Connector Torque
FCC ID
4G LTE Specifications for SE-SL3011-4G Only
Protocols and
Frequencies (AT&T)
Speed
Antenna Connection
Antenna Connector Torque
SIM size
FCC ID
4G LTE Specifications for SE-SL3011-4GG Only
Protocols and LTE FDD: B1,B2,B3,B4,B5,B7,B8,B12,B13,B18,B19,B20,B25,B26,B28
Frequencies (Global)
Speed
Antenna Connection
Antenna Connector Torque
SIM size
FCC ID
Warning for WiFi and 4G models:
The antenna used with this transmitter must be installed with a separation distance
of at least 20cm from all persons and must not be co-located or operated in
conjunction with any other antennas or transmitters. Only an antenna tested with the
wireless transmitter or a similar antenna with equal or lesser gain may be used.
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
2
RoHS Compliant
Model SE-SL3011-4G Only
Ethernet Interface
Five GbE (4x LAN, 1x WAN)
Shielded RJ45
Yes, full and half duplex
Yes
Automatic
Store and forward wire speed switching, non-blocking
All IEEE 802.3 compliant devices are supported
Built-in 1.5 kV magnetic isolation
Twisted pair (Cat5e or better) (shielded recommended)
100 meters
b/g/n
Station (Client) Mode and Access Point
72 Mbps
RP-SMA plug (male)
3–5 lb·in [0.3–0.6 N·m]
XPYLILYW1
LTE-FDD - B2, B4, B12
WCDMA - B2, B4, B5
LTE-FDD: Max. 150 Mbps (DL)/Max. 50 Mbps (UL)
WCDMA: Max. 384 kbps (DL)/Max. 384 kbps (UL)
Two (2) SMA plugs (male)
3–5 lb·in [0.3–0.6 N·m]
Standard SIM (2FF)
XMR201605EC25A
LTE TDD: B38,B39,B40,B41
WCDMA: B1,B2,B4,B5,B6,B8,B19
GSM: B2,B3,B5,B8
GPRS: B2,B3,B5,B8
LTE-FDD: Max. 150 Mbps (DL)/Max. 50 Mbps (UL)
LTE-TDD: Max. 130 Mbps (DL)/Max. 30 Mbps (UL)
WCDMA: Max. 384 kbps (DL)/Max. 384 kbps (UL)
GSM (EDGE): Max. 296 kbps (DL)/Max. 236.8 kbps (UL)
GPRS: Max 107 kbps (DL)/Max. 85.6 kbps (UL)
Two (2) SMA plugs (male)
3–5 lb·in [0.3–0.6 N·m]
Standard SIM (2FF)
XMR201903EG25G
