Asaklitt CO012 Manual

Rechargeable torch
Art. no. 31-7328-1 Model CO011
31-7328-2 CO012
Please read the entire instruction manual before using the
product and then keep it for future reference. We accept no
liability for any errors in the text or images and we reserve the
right to make any necessary changes to technical data. If you
have technical problems or other questions, please contact our
customer service team.
Product description
1
1. Torch housing with focus function 4. On/off switch
2. USB-C input 5. Battery cover
3. Wrist strap hole 6. LED indicator
Charging
Note: Charge the torch for 1 hour before you use it for the first time.
1. Unscrew the battery cover to
access the USB-C input (2) and
LED indicator (6).
2. Connect the USB-C cable
supplied to the USB-C input and
to any USB charger.
3. The LED indicator is red when the torch is charging.
It changes to green when the battery is fully charged.
Using the torch
The torch has 3 different light intensities. Press the on/off switch
(4) to toggle between the following light intensities:
31-7328-1: 1200 lm  400 lm  200 lm  Off
31-7328-2: 1500 lm  600 lm  300 lm  Off
Note: After 6 seconds of inactivity, the torch will switch off
the next time you press the on/off switch.
Note! After 5 min with the highest intensity, the torch will
automatically change to the middle intensity to save on battery.
Turn the housing to focus
the light beam.
2
3
Replacing the battery
4
6 5
Unscrew the battery cover (5).
Remove the old battery and insert a
new one.
31-7328-1: 21700, 3.7 V, 4000 mAh
31-7328-2: 26650, 3.7 V, 4000 mAh
Screw the cover back on.
Note: The battery's minus terminal should face the battery cover.
Responsible disposal
This symbol indicates that the product should not
be disposed of with general household waste. This
applies throughout the entire EU. In order to prevent
any harm to the environment or health hazards
caused by incorrect waste disposal, the product
must be handed in for recycling so that the materials
can be disposed of in a responsible way. To recycle the product,
take it to your local recycling facility or contact the retailer. They
will ensure that the product is disposed of in a way that does not
harm the environment.
ENGLISH
Specifications
31-7328-1
Charging voltage 5 V DC, 1 A (adapter sold separately)
approx. 6.5 hours
Charging time
IP rating IP44
Battery 1 × 21700, 3.7 V, 4000 mAh Li-ion
Luminous flux 200 − 1200 lm
Dimensions Diameter 37 mm x 141 mm
Weight 212 g
31-7328-1
Luminous flux Operating time
200 lm 10 hours
400 lm 5 hours
1200 lm 3 hours
31-7328-2
Charging voltage 5 V DC, 2 A (adapter sold separately)
Charging time approx. 4.5 hours
IP rating IP44
1 × 26650, 3.7 V, 4000 mAh Li-ion
Battery
Luminous flux 300 − 1500 lm
Diameter 45 mm x 167 mm
Dimensions
Weight 335 g
31-7328-2
Luminous flux Operating time
300 lm 12 hours
600 lm 6 hours
1500 lm 3 hours
