- Page 1 Top Bend Neon – RX2CC0TC-A 1616-24V Flexible Top Bend Planar Neon Strip For IP66 Application Technical Application Guide Version: 7.0 Issued on: August 16 , 2023...
- Page 2 RX2CC0TC-A 1616-24V Flexible Top Bend Planar Neon Strip of IP66 1616-24V Flexible Top Bend Planar, 14W/m constant voltage Neon Strip. Neon is featured in IP66 protection and great UV resistance, so High light transmission it can be exposed to intense sunlight without yellowing and aging for a long time.
- Page 3 RX2CC0TC-A 1616-24V Flexible Top Bend Planar Neon Strip For IP66 1616-24V Planar Neon Strip year warranty Dimensions (L x W x H) Cutting unit Number of LEDs RX2CC0TC-A 5000*16*16mm 36/ft 196.85*0.63*0.63inch 50mm 1.97inch 120/m Unit: mm R≥150mm Top Bend Bending Diameter Sectional view Basic Parameters：...
- Page 4 RX2CC0TC-A 1616-24V Flexible Top Bend Planar Neon Strip of IP66 Profile Drawings Unit: mm [inch] Light Distribution Packaging Diagram Reel the Neon strip Put into the antistatic bag Put into the inner box Seal the inner box Pack into the outer carton Put into the outer carton Copyright RISHANGOPTOELECTRONICS CO.,LTD.
- Page 5 RX2CC0TC-A 1616-24V Flexible Top Bend Planar Neon Strip of IP66 Connection Instruction “+”: RED WIRE “-”: BLACK WIRE Note：Please make sure the poles of the product are correctly connected to those of the power supply. Installation of clip Use screws to fix the clips or carriers on the mounting position. 3 clips can be used for 1m.
- Page 6 RX2CC0TC-A 1616-24V Flexible Top Bend Planar Neon Strip of IP66 Attention Cutting Methods Do not bend the Neon less than 150mm. No stretching. No twisting. No trampling. Copyright RISHANGOPTOELECTRONICS CO.,LTD. All Rights Reserved Rev: 7.0...
- Page 7 • All Illustrations in this specification are for reference only. • This product is subject to change or modification without prior notice. • RISHANG OPTOELECTRONICS CO., LTD. Reserves the right of a final explanation for this specification. Revision History...
