Rishang Crystal Series Manual

Model and Specification
Series Crystal Series
Model
R6060BA R6060BA
Part Number R6060BA-1 R6060BA-3
Quantity(pcs)
4 2
R ated Power( ) W
6.6 3.3
Color:
Input Voltage(V AC):
Working Voltage(V DC):
Operating Temperature (℃[°F]):
Storage Temperature (℃[°F]):
Dimension and Connection Illustration
1000[39.37] 72[2.83]
L
Fig.1 R6060BA-3: L=300[11.81]
R6030AA-4: L=500[19.69]
Fig.2 R6060BA-1 : L=300[11.81]
R6030AA-2: L=500[19.69]
Installation and Use
1. Product Parts:
R6030AA R6030AA
R6030AA-2 R6030AA-4
4 2
LED Strips
13.2 6.6
Monochrome
100~240
12
L-connector
0 40[32~104] ～
2. Installation Guide:
-20～60[-4~140]
Connecting Modes between the Strips
01
Unit:mm[in]
1200[47.24]
02
03
04
SMPS Line Connector
T-connector Cross-connector
The line pins of any strips can be
connected to the line holes of
strips.
The line pins or line holes of
L-connectors can be connected
to those of strips.
The line pins or line holes of
T-connectors can be connected
to those of strips.
The line pins or line holes of
Cross-connectors can be
connected to those of other
strips.
The line pins of any strips can be
05
connected to the line holes of
any strips and other line holes of
other strips.
Installation Procedures
Clean the mounting surface
01
before installing and confirm
the installation position and
quantity .
Peel off the adhesive tape
02
gradually, and stick strips on the
mounting surface.
Choose the connecting mode
03
between the LED strips.
Plug the interface of the strip
04
into the Power Supply.
Note: Don't plug the SMPS
connector reversely!
Turn off the switch, and energize
05
the power supply, then you can
control the LED strip with the
switch.
Note: Keep the switch, the power supply
and the controller out of reach of children.
