Serial No.______________

CENTREX 2000

OWNER'S MANUAL

CENTREX 2000

CENTREX 2000 NE

Certified to NSF/ANSI Standard 41

Need help?

Do you have a question about the CENTREX 2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sun-Mar CENTREX 2000

Page 1 Serial No.______________ CENTREX 2000 OWNER’S MANUAL CENTREX 2000 CENTREX 2000 NE Certified to NSF/ANSI Standard 41...
Page 2 CCEB-02510 Centrex 2000 115V CCNB-02540 Centrex 2000 NE CCEB-02515 Centrex 2000 230V RATED CAPACITY Residential & Continuous Use CENTREX 2000: 4 Adults CENTREX 2000 NE: 3 Adults Weekend & Vacation Use CENTREX 2000: 7 Adults CENTREX 2000 NE: 5 Adults...
Page 3 TABLE OF CONTENTS The CENTREX 2000 Toilet Compost Troubleshooting The Patented Bio-Drum Compost Finishing Drawer Evaporation Chamber How Composting Works Mechanical Troubleshooting What’s In the Box? Parts and Functionality Installation FAQ Rough-In Diagrams CLEANING THE EVAPORATION Installation Specifications CHAMBER Space Required and Other...
Page 4 If the safety drain is connected, the liquid will start to flow out of the safety drain when the level of liquid in the evaporation chamber has reached 4 cm (1.6”) deep. The electric Centrex 2000 has a heating element in a separate, sealed department, which is located under the evaporation chamber which will assist with evaporation.
Page 5 Sun-Mar Bio-drums™ turn the entire pile mixing air into the compost. The addition of Compost Sure adds porosity to the pile, creating small air pockets throughout your compost.
Page 6 • Turn the handle in a clockwise direction. This is how you will mix and aerate the contents of the Bio-drum™. • Plug the toilet’s electrical cord (CENTREX 2000 electric) into a standard three-prong electrical outlet and feel the air movement from the vent outlet at the front of the unit to ensure the vent system is working properly.
Page 7 Yes. If the vent ends under the eave, the air 13) The CENTREX 2000 is installed in an from the vent will downdraft over the property, area that can get below 55° F (13° C) at possibly causing a urine smell to occur.
Page 8 CENTREX 2000 ROUGH IN DIMENSIONS...
Page 9 (CENTREX 2000 NE) Venting consists of 4” PVC sewer pipe. Schedule 40 pipe should not be substituted as it is too heavy to be supported by the top of the unit.
Page 10 Guy wires may be necessary. (CENTREX 2000/CENTREX 2000 NE) ABSOLUTELY NO HORIZONTAL SECTIONS ANYWHERE IN THE VENT STACK. Installing a horizontal section vastly reduces the air flow and may result in odor inside of the building.
Page 11 Installation should be in accordance with applicable local regulations. Installing The Waste Pipe The waste pipe that is required is 3” ABS schedule 40 pipe of the appropriate length for your installation. Sun-Mar does not recommend a waste pipe in excess of 15 feet.
Page 12 Initial Start-Up When you are initially starting up your Sun-Mar composting toilet, or restarting the compost after completely emptying the drum, follow these guidelines. Place Compost Sure Blue into a bucket Pour one complete bag into the bucket. Add 2 quarts/litres of water and 2 tablespoons/30 ml of Compost Quick and 2 Tablespoons of Microbe Mix to the bucket.
Page 13 Ongoing Toilet Maintenance...
Page 14 CAUTION 1) Do NOT add chemicals, plastics, glass, metals, diapers or feminine hygiene products to the compost. 2) Do NOT add plastic, glass, metal, cleaning fluids, cigarettes. Add only waste and Compost Sure bulking material. 3) Do NOT add Kitchen or garden waste, as they may attract pests. 4) Do NOT add baby wipes, diapers or feminine paper products.
Page 15 Removing Compost from the Patented Bio-drum ™ Periodically you will need to remove compost from the Bio-drum™. When the Bio-drum™ is half full (about 9 inches from the bottom of the drum door) it is time to remove some compost. Pull the drum locker button out as far as possible (located on the handle side of the composter).
Page 16 Springtime Start Up [Seasonal Users] Empty Compost from Last Season Before your first use of the toilet, extract compost from the Bio-drum™ by releasing the drum locker then rotate the handle counter-clockwise giving the drum one complete revolution only. Compost from the drum will drop into the finishing drawer.
Page 17 Once flies have taken up residence in the compost, you will have to treat the compost in order to kill them. There are several products that are effective for killing insects in the compost that will not slow down the composting action. Contact Sun-Mar customer service department for more information.
Page 18 (CENTREX 2000 NE) Check for competing appliances (i.e. wood stove), downdraft, a bend in the vent stack, or the vent is not installed above the highest peak of the roof.
Page 19 (NOT in the liquid). If there is no warmth rising from the base of the toilet, your heating element is not working. Call Sun-Mar customer service department with the serial number of your toilet which is located on the front cover of this manual.
Page 20 If you have any questions, please call Sun-Mar’s customer service department, 1 888 341 0782 ext. 1018 before proceeding with any mechanical repairs. The serial number of your composting toilet will be...
Page 21 CLEANING THE EVAPORATION CHAMBER Cleaning the evaporation chamber is required periodically for all composting toilet systems. This process prevents the accumulation of debris in the evaporation chamber that will possibly slow evaporation speeds or clog the safety drains that assist in evacuating effluent. If your system is only used for seasonal use, we recommend cleaning the evaporation chamber of debris at Spring time start up and part way through the season in August, whereas, if this is your primary toilet, this process will be recommended every 2 –...
Page 22 CENTREX 2000 EXPLOSION DIAGRAM 1) Waste Pipe Cover Plate 11) Drain Assembly 21) Drum Locker Knob 2) Centrex 2000 Access Port 12) Centrex 2000 Finishing Drawer 22) Air Intake Vent (Not visible) 3) Shaft Assembly Bearing 13) Power Box Assembly...
Page 23 2000 NE for use without water. Ideal where water supply is limited or low output is desired 12 Volt DC Fan (CENTREX 2000 NE) Optional 12 Volt DC fan may be required if there are bends in the vent stack, competing appliances, or downdraft from prevailing winds.
Page 24 Product Info: (905) 332-1314 - Fax: (905) 332-1315 – Customer Service: 1-888-341-0782 Ext 1018 E-mail: compost@sun-mar.com www.sun-mar.com 600 Main St. 5370 South Service Rd. Tonawanda, N.Y. Burlington, ON 14150-0888 L7L 5L1 U.S.A. CANADA PO-MANU0-0814XX March 2024 Rev.D21...
Page 25 SUN-MAR WARRANTY REGISTRATION Complete and return this warranty to register your unit in the Sun-Mar warranty database. Be sure to include your email address if you would like to receive Sun-Mar newsletters and promotions. You can also register online at sun-mar.com/online-warranty-registration/...
