Hunter WIFI-EXT-KIT Installing

HCC - Installing Wi-Fi Antenna Extension Kit
To improve Wi-Fi visibility to the router, we recommend using the Wi-Fi extension kit (model: WIFI-EXT-KIT). This is not a signal
booster, but an option to get the antenna closer to the router. Going around corners, through obstructions, or just reducing the
distance are appropriate applications for this product.
The extension kit comes with two separate cables and mounting hardware to install in ¾" conduit. The thicker cable provides a 9'
extension, while the thinner cable is 3.5' in length.
IMPORTANT: The 3.5' length cable is not used for the HCC Controller model. Use only one cable extension, as combining the
two will incur a signal loss.
WIFI-EXT-KIT: Parts Included
Cable 9'
SMA Adapter (red cap)
Conduit Mounting Hardware
Please visit an authorized Hunter distributor near you using our interactive
Steps
Step 1: Open the FRONT PANEL to access
the antenna compartment.
Step 2: Remove the three Phillips SCREWS on
the left-hand side of the back of the panel.
Step 3: Unthread the existing antenna. Thread
on the included SMA Adapter (red cap) until
hand tightened. Next, thread on the extension
cable (9') until hand tightened. Attach the
original antenna to the other end of the cable.
Controller Models
Used for HCC [1] and ACC2
controllers.
Used only for HCC [1] model controllers.
Used for HCC [1] and ACC2
controllers.
Illustrations
Copyright 2024 Hunter Industries. All Rights Reserved.
[2] model
[2] model
Distributor Lookup [3]
