Excell Queen Service Manual

Waterproof indicator

Advertisement

Quick Links

S
e
S
e
W
a
t
e
W
a
t
e
Queen/Galaxy
© Excell Precision Limited. All rights reserved Worldwide.
The information contained herein is the property of Excell Precision Limited and
is supplied without liability for errors or omissions. No part may be reproduced or
used except as authorised by contract or other written permission. The copyright
and the foregoing restriction on reproduction and use extend to all media in
which the information may be embodied.
r
v
i
c
e
r
v
i
c
e
r
p
r
o
o
r
p
r
o
o
M
a
n
u
M
a
n
u
f
I
n
d
i
f
I
n
d
i
a
l
a
l
c
a
t
o
r
c
a
t
o
r
V24. 0730

Advertisement

loading
Need help?

Need help?

Do you have a question about the Queen and is the answer not in the manual?

Questions and answers

Summary of Contents for Excell Queen

  • Page 1 Queen/Galaxy © Excell Precision Limited. All rights reserved Worldwide. The information contained herein is the property of Excell Precision Limited and is supplied without liability for errors or omissions. No part may be reproduced or used except as authorised by contract or other written permission. The copyright and the foregoing restriction on reproduction and use extend to all media in which the information may be embodied.
  • Page 2 EXCELL PRECISION CO., LTD Table of Contents SPECIAL NOTICE ......................2 Before Using the Scale ...................... 4 Instruction for Use ......................4 Preparing to use the Scale ....................4 Quick Setup Calibration ..................... 6 Chapter 1 Introduction ....................... 7 1-1 Product Features ...................... 7 1-2 Specifications ......................
  • Page 3 EXCELL PRECISION CO., LTD 3-1-3 Myanmar (viss) specification parameter table ..........44 3-1-4 CSP 03 Multi-segment Setting ..............46 3-2 03 CLn Linearity Calibration ................... 47 3-3 02 CAL Weight Calibration ..................50 3-3-1 CAL 01 Weight Calibration Setting ..............51 3-3-2 CAL 02 Manufacturing Location Gravity Setting ..........
  • Page 4 After installing the load cell, power cord hookup or replacing a new rechargeable battery, the housing must be screwed by the assigned order as shown below. Screw lightly first, then screw them tight using a 6 kgf-cm (Galaxy) or 12 kgf-cm (Queen) torsion. P.s. Please use a torsion-adjustable screw driver.
  • Page 5 EXCELL PRECISION CO., LTD Thank you for purchasing EXCELL WEIGHING INDICATOR, to help use the product properly, operate smoothly, and extend its life cycle, please read this manual carefully. Before Using the Scale In order to use this scale correctly, we suggest that you read this manual carefully.
  • Page 6 EXCELL PRECISION CO., LTD Due to the storage battery adopt the advanced free-maintaining technique, customers need not to replenish electrolyte. The scale should be recharged every 3 months to prevent failure of the internal rechargeable battery. 1. The battery should be charged for 8~10 hours.
  • Page 7 EXCELL PRECISION CO., LTD Quick Setup Calibration This page is to quickly initiate the scale, for the other functions configuration, you can refer the chapters below. Instructions: Step 1 :  Power off the scale and open the case, find the mini-jumper SWA1 on the main board.
  • Page 8 Extra-large and wide LCD display (175 x 70mm) 6 digits with 55mm height for easy weight reading  Multi-color backlight Queen with 304 stainless steel housing while Galaxy with plastic ABS housing.   Sealed to IP68 and IP69, Waterproof, mist-proof and dustproof (Only use cables of...
  • Page 9 EXCELL PRECISION CO., LTD [Standard] Power Pressure relieve valve RS-232  RS-485 is an option Load Cell Galaxy 90mm 238mm [Standard] [Option] Foot switch RS-232 RS-485 Load Cell Power Power  RS-485 and foot switch are options 02050102 ZSME300000437 02150102...
  • Page 10 EXCELL PRECISION CO., LTD 1-4 Display Description : Upper limit : Value between HI and LO : Lower limit : Unit “kilogram” : Unit “pound” : HK tael or Taiwan Tael 斤 : Counting mode indication : Zero point indication ...
  • Page 11 EXCELL PRECISION CO., LTD Battery Status and Low Battery Warning Normal battery status: The ( ) symbol is displayed steadily, indicating current battery status from 1 block ( to 4 blocks (  When the battery status indication is full, the power is about 6.4V; Each block is about 0.2V increment/decrement.
  • Page 12 EXCELL PRECISION CO., LTD TARE|PT KEY: Tare / Pre-tare key To TARE: Place the container onto the scale, until the weight value is stable, press key for TARE|PT zero return and the NET indication is shown on the display. Place the object onto the container and the display shows the net weight value of the object.
  • Page 13 EXCELL PRECISION CO., LTD F KEY (Non approval models. For approval models, use key instead) Before using this key, need to go to FnC 12 to set F key as the following function. “MC” (Memory Clear) key: press it to erase memory directly without display the tantalization data.
  • Page 14 EXCELL PRECISION CO., LTD  The scale is not in level status. (Only if level detector equipped) Level Switch and E10 (option) To use level switch, make J1 on PCB open circuited, display shows E10 and all keys stop working in the meantime. If J1 on PCB is short circuited, all functions work normally.
  • Page 15 EXCELL PRECISION CO., LTD  Press key to back to the last screen, the display shows ZERO KEYPAD TEST MODE  Press key to enter, display shows TARE|PT Keypad’s internal code: key = 06, key= 05, TARE|PT UNIT key=04 M+|PRINT key = 03,...
  • Page 16 EXCELL PRECISION CO., LTD Chapter 2 Configurations In the weighing mode, press key (For approval models, use NET|GROSS NET|B/G instead) and keys at the same time to enter the configuration mode. ZERO The LCD shows 01 FnC. Press Press ZERO UNIT 01 FnC ...
  • Page 17 EXCELL PRECISION CO., LTD 2-1-1 FnC 01 Auto Backlight Display the last used value  Default setting = oFF key to select Press ZERO UNIT TARE|PT  backlight on Auto  automatic backlight oFF  backlight off Press TARE|PT Auto backlight function When weight >...
  • Page 18 EXCELL PRECISION CO., LTD  If backlight is on, yellow backlight is for Low value, green backlight for OK value, and red backlight for High value. 2-1-4 FnC 04 Restore to the Default Settings keys to select “rEturn”or “ForMat” ZERO UNIT ...
  • Page 19 EXCELL PRECISION CO., LTD 2-1-6 FnC 06 Hold Function Settings  When CFn 02 =1 (OIML or NTEP approval), FnC 06 is fixed to hold=0 and cannot be changed Hold function setting Display the last used value keys to select 0~5...
  • Page 20 EXCELL PRECISION CO., LTD Animal scale hold 1 Press TARE|PT Hold function setting Display the last used value key to select 4. ZERO UNIT Press key to enter the hold setting TARE|PT Press TARE|PT Allowed tolerance range keys to enter value (1%~100%)
  • Page 21 EXCELL PRECISION CO., LTD 2-1-7 FnC 07 Auto Unit Weight Averaging Setting Auto unit weight averaging setting Display the last used value Press TARE|PT key to select 0~1. ZERO UNIT  Default setting = 0 0  Enable Auto unit weight averaging 1 ...
  • Page 22 EXCELL PRECISION CO., LTD 2-1-10 FnC 12 F Key Function Settings (For approval models, use key instead) Foot switch function Display the last used value key to select F key as MC, hr or t-tP. ZERO UNIT Press TARE|PT MC  as...
  • Page 23 EXCELL PRECISION CO., LTD 2-2 02 EC External Weight Calibration Press  The calibration weight could be changed , the display TARE|PT shows the calibration value. The right digit keeps flashing. When the right digit is flashing, Press key to move...
  • Page 24 EXCELL PRECISION CO., LTD 2-3 03 rS1 RS232 Serial Interface Settings rS1 00  Return to to previous level rS1 01  Baud Rate Settings Press TARE|PT rS1 02  Communication Protocol Settings rS1 03  Output Format Settings rS1 04  Transmission Method rS1 05 ...
  • Page 25 EXCELL PRECISION CO., LTD 2-3-3 rS1 03 Output Format Settings Communication protocol setting Display the last used value key to select 0~20. Default = 0 ZERO UNIT Press TARE|PT 0  Synchronize with display 1  Gross weight 2  Net weight 3 ...
  • Page 26 EXCELL PRECISION CO., LTD Note3: = Brazil printing format If it is not Brazil version, it can only print under continuous transmition. If it is Brazil version, under decimal units mode, FnC 11 = Print and rS1 04 = _ , it can print out.
  • Page 27 EXCELL PRECISION CO., LTD T = tare + pre-tare N = net weight For example: tare 1 kg, net weight 0.2key, gross weight 1.2 kg , stable, then show as followed: 0,001.200,001.000,000.200 Take off the weight then show as followed: 0,000.000,001.000,-01.000...
  • Page 28 EXCELL PRECISION CO., LTD Note7: = Company name + F-M 10  Company name can be set in rS1 14. [Company Name] Ticket No. Date year/month/day & day/month/year (choose 1 out of 2 date formats) Time T (PT when only pre-tare, T when tare or both tare and pre-tare) Total Net (This line will only print when data is erased, showing net weight total of every count) ...
  • Page 29 EXCELL PRECISION CO., LTD Note9: = Indonesia M+ format Note10: = Indonesia M+ format Simple format: only gross weight Complete format PT. Tempo Scan Pacific Indonesia, Tbk PT. Tempo Scan Pacific Indonesia, Tbk DATE:2023/09/25 TIME: 15:16 TICKET NO.0001 Gross:+ 0.200 kg...
  • Page 30 EXCELL PRECISION CO., LTD 2-3-4 rS1 04 Transmission Method Transmission Method Display the last used value key to select. Default = ZERO UNIT Press TARE|PT = Command mode = Continuous transmission = Auto transmit when stable = RS232 is off...
  • Page 31 EXCELL PRECISION CO., LTD 2-3-7 rS1 07 Weight Band Setting for Auto Transmission Weight Band Setting for Auto Transmission Display the last used value rs1 07 must be used with rs1 06. After data has been Press TARE|PT sent once and weight is not removed, to send data again, please keep adding weight until: weight is >...
  • Page 32 EXCELL PRECISION CO., LTD 2-3-10 rS1 10 RTC Adjustment Enter date in YY/MM/DD Display the last used value key to select and use key to ZERO UNIT TARE|PT Press TARE|PT confirm and move cursor to the right. When cursor move to the rightmost end and press key to save.
  • Page 33 3. Enter rS1 14 and “input” will display and press NET|GROSS key to return), then you can input strings from the com- port test software. For example: Enter EXCELL Press TARE|PT corp.[CR][LF] and press send.
  • Page 34 EXCELL PRECISION CO., LTD Chapter 3 Service Mode Access Open the case, then switch the mini-jumper SWA1 on the main board to the ADJ position (EEPROM UNLOCKED). Turn the power on. The display shows 01 CSP. When finished, set the jumper SWA1 back to the LOCK position. If the jumper SWA1 is returned to the LOCK position during calibration, the machine exits the service mode automatically.
  • Page 35 EXCELL PRECISION CO., LTD 3-1 01 CSP Capacity Setup Press TARE|PT Input a parameter “00” ~ “03” After inputting “00”, press key to return to the TARE|PT previous step. (Exiting from capacity setup) ZERO key  Upward key (0~9 digit entry) UNIT key ...
  • Page 36 EXCELL PRECISION CO., LTD 3-1-1 CSP 01 Weight Unit Setting There is no resolution limitation when the weight units “kg, g, lb, lb/oz” are selected. The weight units ”oz, GN, dwt, and ct” are only available on indicators with less 1/10,000 external resolution.
  • Page 37 EXCELL PRECISION CO., LTD NOTE 1 The users can set up the different weight units in various orders according to their preference, and the amount of the chosen weight units can be up to 5 (a) (b) (c) (d) (e) (f) (a) ...
  • Page 38 EXCELL PRECISION CO., LTD Multi interval: Multiple segment range and each segment with its own minimum and maximum capacity and scale interval. The selection of the appropriate weighing segment is determined automatically according to the load applied, both on increasing and decreasing loads.
  • Page 39 EXCELL PRECISION CO., LTD 3-1-2 CSP 02 Customised Capacity Setting The display shows current setting is max capacity of 6 lb with 0.001 Press TARE|PT lb/division for 2 seconds. The display shows the number of weighing UNITS and the UNITS for the weight calibration set previously Refer to “Note 4”...
  • Page 40 EXCELL PRECISION CO., LTD Cont The display shows current setting Press TARE|PT is max capacity of 12 lb with 0.005 lb/division for 2 seconds. apacity +1d and UNITS weight for 2 seconds. To setup 2 weight unit for max capacity of 6000g with 1g/division Enter 006000 ...
  • Page 41 EXCELL PRECISION CO., LTD NOTE 4 (a) (b) (a)  The number of the weight units (Max: 5, key in 1 ~ 5) (b)  The weight unit for weight calibration (choose from “kg”, “g”, “lb”, key in 0, 1, or 2) Parameter description: 0 ...
  • Page 42 EXCELL PRECISION CO., LTD  Enter the maximum capacity 019200 at (c) ~ (h)  Enter the mass value 019200 at (i) ~ (n) ”oz” : Calibration weigh 12 lb = 192.00 oz , Take 200.00 oz as the maximum capacity 200.00 oz / 0.05 oz (the maximum Capacity / division)
  • Page 43 EXCELL PRECISION CO., LTD (s)  Save the weight units at preferred slots (no more than the number of set weight units) Parameter description: 1  the first slot (the weight calibration unit) 2  the second slot 3  the third slot 4 ...
  • Page 44 EXCELL PRECISION CO., LTD Customized Capacity Setting- How to Revise To revise customized setting, please follow the steps below The display shows current setting is max capacity of 12 lb with Press TARE|PT 0.005 lb/division for 2 seconds. Display shows parameter settings According to from last time.
  • Page 45 EXCELL PRECISION CO., LTD 3-1-3 Myanmar (viss) specification parameter table 3.0000kg/0.0002kg 1.8000viss/0.0001viss 6.0000lb/0.0005lb 3.0000kg/0.0002kg 6.0000lb/0.0005lb Max capacity  1.8000viss/0.0001viss 1.8000viss 3kg=  1.8367viss 6.0000kg/0.0005kg 3.6000viss/0.0002viss 12.000lb/0.001lb 6.0000kg/0.0005kg 12.000lb/0.001lb Max capacity  3.6000viss/0.0002viss 3.6000viss 6kg=  3.6734viss 15.000kg/0.001kg 9.0000viss/0.0005viss 30.000lb/0.002lb 15.000kg/0.001kg 30.000lb/0.002lb...
  • Page 46 EXCELL PRECISION CO., LTD 60.000kg/0.005kg 36.000viss/0.002viss 120.00lb/0.01lb 60.000kg/0.005kg 120.00lb/0.01lb Max capacity  36.000viss/0.002viss 36.000viss 3kg=  36.734viss 150.00kg/0.01kg 90.000viss/0.005viss 300.00lb/0.02lb 150.00kg/0.01kg 300.00lb/0.02lb Max capacity  90.000viss/0.005viss 90.000viss 150kg=  91.836viss 300.00kg/0.02kg 180.00viss/0.01viss 600.00lb/0.05lb 300.00kg/0.02kg 600.00lb/0.05lb Max capacity  180.00viss/0.01viss 180.00viss ...
  • Page 47 EXCELL PRECISION CO., LTD 3-1-4 CSP 03 Multi-segment Setting Select the desired unit for setting. All the units which set at Press TARE|PT could be selected to set the interval point. Refer to Note 1 on page 13 for unit setting.
  • Page 48 EXCELL PRECISION CO., LTD 3-2 03 CLn Linearity Calibration  After linearity calibration, it is necessary to re-calibrate the weight.  Weight calibration should be included in linearity calibration. The last point of linearity calibration with plastic platter or The first point of linearity calibration with aluminum support.
  • Page 49 EXCELL PRECISION CO., LTD  Weight factor The weight factor is a single hexadecimal number which represents the value of the next weight compared to the size of the first weight applied to the scale. The weight factor is arranged as follows:- 1 = The weights are equal.
  • Page 50 EXCELL PRECISION CO., LTD Ex3: 30kg (5kg, 5kg ,10kg, 10kg) Display Key Press Note 03 CLn TARE Into linearity calibration TARE First point (zero), remove weigh pan and press the Tare key L1 1 TARE Put 5kg on and press the Tare key...
  • Page 51 EXCELL PRECISION CO., LTD 3-3 02 CAL Weight Calibration Press TARE|PT Input a parameter “00” ~ “02” ZERO key  Upward key (0~9 digit entry) UNIT key  Downward key (0~9 digit entry) TARE|PT key  Move cursor rightward NET|GROSS key  Move cursor leftward After inputting “00”, press...
  • Page 52 EXCELL PRECISION CO., LTD 3-3-1 CAL 01 Weight Calibration Setting Press key, the display TARE|PT shows the calibration value (the maximum capacity of 1 unit setting) and unit. The right digit keeps flashing. Press NET GROSS key to  The calibration value could be move the flashing digit to changed.
  • Page 53 EXCELL PRECISION CO., LTD 3-3-2 CAL 02 Manufacturing Location Gravity Setting  The gravity value should be among the value of Equator and Polar. Equator gravity G = 9.7803184558 m/sec Polar gravity G = 9.8321772792 m/sec Taipei ≒ 9.78914 m/sec Shanghai ≒...
  • Page 54 EXCELL PRECISION CO., LTD 3-3-3 CAL 03 Seal Verification Test Press key to enter the Seal V-Test. TARE|PT Display extra digit to perform verification test using X10 method here.  To enter Verification Test Mode, when the software seal is disabled CFn 11 = 0, switch calibration lock to ADJ and restart the scale.
  • Page 55 EXCELL PRECISION CO., LTD 3-5 04 CFn Function Setting CFn 00  Back to the upper level CFn 01  Environment parameters CFn 02  Approval configuration Press TARE|PT CFn 04  Initial Zero Setting CFn 05  Hold Function Setting CFn 06 ...
  • Page 56 EXCELL PRECISION CO., LTD 3-5-1 CFn 01 Environment Parameters  If parameters are changed in , then will be revised automatically Return to zero The display shows the last setting Press Return to zero point TARE|PT Using to enter ZERO UNIT ...
  • Page 57 EXCELL PRECISION CO., LTD 3-5-2 CFn 02 Approval Configuration Press TARE|PT Approval configuration Display shows last setting ZERO UNIT Approval configuration to input a parameter to input the setting ZERO UNIT 0  Non-approval models 1  OIML or NTEP approved model, 2 ...
  • Page 58 EXCELL PRECISION CO., LTD 3-5-3 CFn 04 Initial Zero Setting Zero range setting at switch on LCD displays the last setting Press TARE|PT Initial Zero Setting key to ZERO UNIT key to enter the setting ZERO UNIT enter parameter Default setting = 0 (OIML or NTEP approval model) Default setting = 9 (Non-approval model) 0 ...
  • Page 59 EXCELL PRECISION CO., LTD 3-5-4 CFn 05 Hold Function Setting  When CFn 02 =1 (OIML or NTEP approval), CFn 05 must set to hoLd=0. Hold function setting Display the last used value keys to select 0~5 ZERO UNIT ...
  • Page 60 EXCELL PRECISION CO., LTD Animal scale hold 1 Press TARE|PT Hold function setting Display the last used value key to select 4. ZERO UNIT Press key to enter the hold setting TARE|PT Press TARE|PT Allowed tolerance range keys to enter value (1%~100%)
  • Page 61 EXCELL PRECISION CO., LTD 3-5-5 CFn 06 Zero Tracking Zero tracking setting Display the last used value Press TARE|PT keys to key in the parameters ZERO UNIT  Default setting = 0 0  Enable zero tracking 1  Disable zero tracking...
  • Page 62 EXCELL PRECISION CO., LTD  Here are the default CFn 08 settings for each approval settings of CFn 02. Parameters are fixed and cannot be changed if CFn 02 sets to 2 and 3 (Sri Lanka approval), or sets to 4 (Brazil business).
  • Page 63 EXCELL PRECISION CO., LTD 3-5-11 CFn 11 Software Seal Setting Press TARE|PT Software Seal Function Setting The display shows last saved settings key. ZERO UNIT Selection options can be Software Seal Function Setting repeated. Please Use key to select ZERO...
  • Page 64 EXCELL PRECISION CO., LTD Appendix 1 ASCII Code Table ASCII 30H ASCII 41H ASCII 4CH ASCII 57H ASCII 68H  ASCII 73H Appendix 2 7-Segment Display Characters 02050102 ZSME300000437 02150102...
  • Page 65 EXCELL PRECISION CO., LTD Appendix 3 RS-232 Data Format  Command Mode On RS485 command mode, the format is as following, 1. If RS485’s ID setting is 0(RS1 12), and the command is the same as regular RS232. 2. A. If RS485’s ID setting is not 0(assume 99),”@ID” has to be added in front of every command.
  • Page 66 EXCELL PRECISION CO., LTD RJ,RK,RL Command Description If RL command entered, and if weight is higher than HI (FNC 03 setting), and if the current weight is 10 kg, the following will be displayed: “100+ 10.000” If weight is higher than HI (FNC 03 setting), and if the current weight is 0.5 kg, the following will be displayed: “001+ 0.500”...
  • Page 67 EXCELL PRECISION CO., LTD Command Format D Host Data Slave Value (e.g. Price) Position of decimal point When the Slave receives this data format, it will transfer the data and display it on its LCD. ˙  The function is effective when the weight value is over 0.
  • Page 68 EXCELL PRECISION CO., LTD Comparison status + Simple format Byte0 Byte1 Byte2 +/- Byte0 : HI 30H/31H Byte1 : OK 30H/31H Byte2 : LO 30H/31H 2. 6 places ( first decimal place not included) Weight format Gross 7 SP SP o...
  • Page 69 EXCELL PRECISION CO., LTD  Serial Data Transfer/Receive Format n , 8 , 1 8-bit data STOP e , 7 , 1 7-bit data P STOP o , 7 , 1 7-bit data P STOP Note: : Start bit STOP: Stop bit...
  • Page 70 EXCELL PRECISION CO., LTD RS232 wiring instruction To connect RS232, please open the housing, RS232’s PIN connectors locate on the bottom- right corner of the main board. The most common connection method is using 9PIN and 25PIN, as shown below:...
