GE CG40S AYV Series Owner's Manual & Installation Instructions
GE CG40S AYV Series Owner's Manual & Installation Instructions

GE CG40S AYV Series Owner's Manual & Installation Instructions

Power vent gas residential water heaters

Advertisement

Available languages

Available languages

Quick Links

SAFETY INFORMATION
OPERATING INSTRUCTIONS
Lighting and Shutdown . . . . . . . . . . . . . . . . .7
Temperature Control . . . . . . . . . . . . . . . . . . .8
About the Gas Control/Thermostat. . . . . . . .9
CARE AND CLEANING
Temperature and Pressure Relief Valve . . 10
Water Tank. . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Anode Rod Maintenance and Service . . . . 12
Gas Control/Thermostat Inspection . . . . . . 13
Pilot Light and Burner Inspection . . . . . . . 13
Water, Gas and Venting Systems . . . . . . . . 13
INSTALLATION
INSTRUCTIONS
. . . . . . . . . . . . . . . . . . 14
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Air Supply and Ventilation . . . . . . . . . . . . . 15
Preferred Vent Pipe Assembly
and Fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installing the Water Heater. . . . . . . . . . . . . 21
Horizontal Vent Installation . . . . . . . . . . . .23
Vertical Vent Installation . . . . . . . . . . . . . . .23
Cementing Joints . . . . . . . . . . . . . . . . . . . . 24
Wiring Diagram. . . . . . . . . . . . . . . . . . . . . . .25
Water Supply and Drainage . . . . . . . . . . . . .27
Gas Supply. . . . . . . . . . . . . . . . . . . . . . . . . . 29
Combination Potable Water and
Space Heating . . . . . . . . . . . . . . . . . . . . . 30
TROUBLESHOOTING TIPS
Status Light Codes. . . . . . . . . . . . . . . . . . . .32
REPLACEMENT PARTS
LIMITED WARRANTY
CONSUMER SUPPORT
Product Registration
To register your new GE Appliances water
heater, go to
GEAppliances.com/canada-
water-heater-registration, or
scan the QR code and write
the model/serial number
information on this page.
Model #_________________
Serial # _________________
GE is a trademark of the General Electric Company. Manufactured under trademark license.
. . . . . . . . . .3
. . . .6
. . . . . . . . . . 10
information in these instructions
is not followed exactly, a fire or
explosion may result, causing
property damage, personal
injury, or death.
- Do not store or use gasoline
. . . . . . 31
. . . . . . . . . .33
. . . . . . . . . . .35
- WHAT TO DO IF YOU SMELL
. . . . . . . . . 36
- Installation and service must
OWNER'S MANUAL
& INSTALLATION
INSTRUCTIONS
GE Branded Power Vent Gas Models
CG40S**AYV
CG40T**AYV
CG50S**AYV
CG50T**AYV
CP40S**AYV
CP50S**AYV
ENGLISH/FRANÇAIS
ESPAÑOL
Para consultar una version en
español de este manual de
instrucciones, visite nuestro sitio
de internet GEAppliances.com.
WARNING
If the
or other flammable vapors and
liquids in the vicinity of this or
any other appliance.
GAS
• Do not try to light any
appliance.
• Do not touch any electrical
switch; do not use any phone
in your building.
• Immediately call your gas
supplier from a neighbor's
phone. Follow the gas
supplier's instructions.
• If you cannot reach your
gas supplier, call the fire
department.
be performed by a qualified
installer, service agency or the
gas supplier.
49-6000312 Rev. 0 09-24
